Crown 1-VCAP User manual

Crown International
1718 W. Mishawaka Rd.
Elkhart, IN 46517-9439
TEL: [phone]
FAX: [phone]FAX
www.crownaudio.com
Specifications
1-VCAP
Number of Potentiometers: 1
Potentiometer Resistance: 5 k ohms
Pins: VCA, GND, +10V
Weight: 3.0 oz (85 g)
Dimensions: 2-1/2 in x 4-1/2 in (6.4 cm x
11.4 cm) (Fits into a 1-gang electrical box.)
7/05 135770-1C
Crown’s Three-Year, No-Fault, Fully Transferable Warranty
Crown offers a Three-Year, No-Fault, Fully Transferable Warranty for almost every new Crown
amplifier product —an unsurpassed industry standard. With this unprecedented No-Fault
protection, your new Crown amplifier product is warranted to meet or exceed original specifica-
tions for the first three years of ownership. During this time, if your unit fails, or does not
perform to original specifications, it will be repaired or replaced at our expense. About the only
things not covered by this warranty are those losses normally covered by insurance and those
caused by intentional abuse. And the coverage is transferable, should you sell your unit.
See your authorized Crown dealer for full warranty disclosure and details. For customers
outside of the USA, please contact your authorized Crown distributor for warranty information
or call 574-294-8200.
Specifications subject to change without prior notice. Latest
information available at www.crownaudio.com.
Crown and Crown Audio are registered trademarks of
Crown International. Other trademarks are the property of
their respective owners. Printed in U.S.A.
© 2005 Crown Audio®, Inc.
Crown®VCAP panels are wall-mounted
panels with potentiometers that remote-
control the volume of Crown CTs 4200
and CTs 8200 amplifier channels via a VCA-
MC4 or VCA-MC8 module installed in the
amplifier.
Two models are available: 1-VCAP and 4-VCAP.
1-VCAP: See Figure 1. Used in conjunction
with a VCA-MC module, this is a single-gang
panel with one potentiometer that provides
remote volume control for one or more CTs
amplifier channels. The potentiometer on the
panel is wired directly to the VCA connectors
on the VCA-MC.
4-VCAP: See Figure 2. This is a two-gang panel
with four potentiometers that provide remote
volume control for four or more CTs amplifier
channels. The potentiometers on the panel are
wired directly to the VCA connectors on the
VCA-MC.
See Crown document 135504-1, VCA-MC
Series Operation Manual for installation and
wiring, attenuation per detent, and theory of
operation. This document is packed with the
VCA-MC modules and is available online at
www.crownaudio.com.
For more details about the VCAP panels, con-
tact the Crown Technical Support Group at
800-342-6939 or 574-294-8200.
CTS ACCESSORIES
• 1-VCAP provides remote volume control for
one or more CTs amplifier channels
• 1-VCAP fits into a 1-gang electrical box
• 4-VCAP provides remote volume control for
four or more CTs amplifier channels
• 4-VCAP fits into a 2-gang electrical box
Features
1-VCAP
4-VCAP
Figure 1. 1-VCAP Figure 2. 4-VCAP
4-VCAP
Number of Potentiometers: 4
Potentiometer Resistance: 5 k ohms
Pins: VCA, GND, +10V (x4)
Weight: 6.5 oz (184 g)
Dimensions: 4-1/2 in x 4-1/2 in (11.4 cm x
11.4 cm) (Fits into a 2-gang electrical box.)
