Croydex AP5410 H Series User manual

AP5410##H
INCLUSIVE SHOWER STOOL
ALL PRODUCT DIMENSIONS DETAILED IN
THIS INSTALLATION AND MAINTENANCE
MANUAL ARE APPROXIMATE
ALL ILLUSTRATIONS OF THE PRODUCT ARE
FOR REFERENCE ONLY. COMPONENTS
SUPPLIED WITH INDIVIDUAL PRODUCTS
MAY DIFFER
CONTACT DETAILS
UK: Croydex, Central Way, Andover, Hampshire,
SP10 5AW, UK
EU: MIL, Unit 8 Purcellsinch Ind Est, Dublin Road,
Kilkenny, R95 HP71, Ireland
Tel: [phone]
Email: [e-mail]
www.croydex.com
- Always follow the instructions provided
to ensure that your product is assembled
and fitted safely, and retains it's high
quality finish.
- Before attempting to fit or use this
product, ensure that it can be properly
installed in the desired location.
ALWAYS RETAIN THIS MANUAL
FOR FUTURE REFERENCE
SAFETY & PRODUCT CARE
1. DO NOT use power tools to assemble this
product.
2. DO NOT exceed the maximum user weight
indicated in the fitting instructions.
3. ALWAYS check the legs are level and locked in
place and the arm rests and back rests are secure.
4. ONLY use on surfaces free from obstacles.
5. ALWAYS assemble in accordance with the
instructions provided.
6. ALWAYS make sure all four feet are in contact
with the supporting surface at all times.
7. DO NOT modify the shower stool and its
components in any way.
8. DO NOT use the shower stool if damaged or
altered in any way.
9. REMOVE the shower stool after use.
10. DO NOT stand or kneel on the shower stool.
11. DO NOT use abrasive or chemical cleaners as
these may damage the product.
12. ALWAYS clean the product regularly with a soft
damp cloth to retain the best quality finish.
S&H 087 R01
ALWAYS CHECK THE PACKAGING FOR FIXINGS AND PARTS BEFORE
THROWING AWAY AND RECYCLING.
ENSURE YOU HAVE ALL THE FIXINGS AND PARTS BEFORE ATTEMPTING TO
ASSEMBLE OR FIT THIS PRODUCT.
1
MAX USER
WEIGHT:
175KG
386lbs

1.Check all components are in the packaging. (See fig. 1)
INSTALLATION
S&H 087 R01
Fig. 3
2
Fig. 1
4.Press the seat plugs into the fixing holes to secure the adjustable legs to the seat. (See
fig. 4) Note: Ensure the seat plugs are aligned and
orientated correctly.
Fig. 4
2.Assemble the leg by passing the thinner part of one of the legs through the back of the thicker
part of one of the legs. Repeat this process for all four
legs. (See fig. 2) Note: Only when the stud pops out
into the adjustment holes are the legs assembled
Fig. 2
3.Firmly press all four adjustable legs into the bottom of the seat, ensuring that the
adjustment holes are facing inwards and the fixing
holes on the legs are aligned with the fixing holes in
the seat. (See fig. 3) Note: Ensure the thicker end of
the leg is slotted into the seat to ensure the fixing
holes line up and there is no movement.
Fig. 5
6.The height of the chair can be adjusted by depressing the locking button on each leg then
sliding the thinner leg section up or down. Ensure
that the locking button is relocated into one of the
holes and check that the adjustable leg is locked
in place before use . (See fig. 6) YOU MUST ensure
that all legs are fully secured and are at the same
height before use.
Fig. 6
5.Firmly press the feet onto the bottom of each adjustable leg. Ensure the feet are angled
outwards. (See fig. 5)
7.The chair is fully assembled and
ready to be used.
(See fig. 7)
Note: Ensure you
have read the safety
and product care
section before use.
Fig. 7
x1 SEAT x4 SEAT PLUGS
x4 FEET
x4 ADJUSTABLE LEG
MAX USER
WEIGHT:
175KG
386lbs
