Croydex STICK N LOCK AD1021 Series User manual

Croydex, Central Way, Andover,
Hampshire, SP10 5AW, UK
[phone]
[phone]
[e-mail]
www.croydex.com
R&R 066 R06
AD1021**
AD1095**
x1
SAFETY AND CARE
1. Do not use this product as a grab bar.
2. Clean product regularly with a soft damp cloth but do not use abrasive or chemical cleaners, as these may damage the
product.
3. Do not overload the rail. Suitable for use with a maximum of two standard shower curtains.
4. The adhesive is suitable for surfaces such as gloss paint, tiles, polished stone, laminates and textured surfaces.
5. Do not use tile cleaning chemicals on or around this product as they may aect adhesion.
DO
- Clean the wall surfaces before mounting.
- Extend the rod fully against the walls before locking.
- Tighten the threaded bracket to fully tension the rod.
- Ensure you are happy with the position of the rod before sticking it in place.
- Apply pressure to the Stick N Lock rings for at least 30 seconds.
DON’T
- The adhesive is NOT suitable for unfinished materials such as brick, block-work, wood, emulsion paint, loose, flaky
surfaces or surfaces contaminated with grease, wax or dust. DO NOT USE ON DECORATIVE WALL PAPER FINISHES.
- Over-tighten the locking mechanism as you can damage the rod.
Go to www.croydex.com to
see a helpful installation video.
A
B
C D
E F
Threaded Wall
Bracket
Fixed Wall Bracket Stick N Lock Rings Protective Caps
Telescopic Sections
Extra Section
STICK N LOCK 8’6’’ TELESCOPIC ROD
Note!
If this part is
protruding. It must be
reinserted for the rod to
function properly.

5
1
2
4
6
If required increase the rod length by inserting the extra section.
TWIST TO
UNLOCK
SLIDE & EXTEND
BETWEEN THE
WALLS
TWIST TO LOCK
WHILST UNDER
TENSION
Check the level and height to
ensure that you are happy with
the position of the rod. Then
fully tension by twisting the
collar of the threaded bracket
anti clockwise.
Press the Stick & Lock rings against the wall for
30 seconds ensuring that even pressure is spread
across the bracket and your rod is ready for use.
Complete these steps
for each wall bracket.
Ensure mounting points on the wall
are clean and dry.
Only wash with warm soapy
water.
Check O-Rings
are in place
Ensure the wall brackets are
inserted at the correct end.
Fixed Wall Bracket
Adjustable Wall Bracket
3
Ensure the rods
are extended
to press firmly
against the
walls.
Be careful not to over-tighten
the locking mechanism
Remove protective
film from the Stick
N Lock Rings.
Thin Section
Thick Section
Remove
protective caps
Slide the Stick N Lock
Rings onto the rod.
Max 1750mm
Max 2600mm
Twist bracket
anti clockwise.
