croydon F1B-G User manual

F1B-GP0001 C0
INSTRUCTION MANUAL
GAS FRYER - MODEL: F1B-GP0001 C0
-Please read these instructions carefully before operating this appliance.
SAFETY
-Install your equipment in area well ventilated, to eliminate the gases generated by the combustion.
-It’s recommended to leave at least 6 inches (15 cm) of free space around the equipment.
-DO NOT install the equipment next to combustible materials.
-The installation has to comply to the safety standards.
-As metallic parts are good conductors of heat, let them cool before any maintenance.
-WARNING! Hot oil can cause burns. Spilling oil can cause severe burns. Do not move fryer without
draining all the oil from the tank.
-Do not overfill baskets. Carefully load them into hot oil. A danger of surge boiling can also occur if the
food to be fried is excessively wet or the frying basket is too full.
OPERATION
-The equipment is supplied with a Gas Tap which can adjust the flame (turn 1/4 to maximum flame
and turn 1/2 to minimum flame)
-Incorporated to the Tap there is a safety device that will let open the gas only if it is pressed and
turned counterclockwise.
-To start the equipment do the following:
1. Fill the container with 9.2 lbs (4.5 liters) of quality oil (fat).
2. Light a fire flame.
3. Press and turn 1/4 counterclockwise the Tap Knob.
4. Move the flame through the frontal hole and start the burner flame.
5. Let the Tap Knob in the maximum flame position for at least 20 minutes and the
equipment is ready for use.
6. To turn off the burner turn the Tap Knob completely clockwise.
CLEANING PROCEDURE
- The cleaning procedure should be done daily after the use.
- To clean, use only a soapy damp cloth in all parts, avoiding excess of water.
- It is not recommended the use of any abrasive material.
MAINTENANCE
- Always maintain your equipment clean and in perfect operation conditions, those providences, will
help your equipment to last longer.
- To guarantee a good performance, we recommended an annual revision of the equipment.
F1B-GF1B-G
F1B-GF1B-G
CROYDON
CROYDON CROYDONMAQ INDUSTRIAL LTDA.
Estrada São Lourenço, 891 - Capivari - Duque de Caxias.
RJ - Brasil - CEP 25243-150 Fax: [phone]
Phone: [phone]
e-mail: [email protected]

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
10
7
5.272-3
5.260-3
385
50.004-3
604
345
1.917-3
50.007-3
2.202-3
5.312-3
5.300-3
5.321-3
22.012-3
1.965-3
3.525-3
22.008-3
22.009-3
22.010-3
1.342-3
4
3
11
5
13
6
8
Basket
Container
Screw (3/16”)
Burner
Nut (3/16")
Regulator Screw
Foot
Gas Injection Device
Gas Tap
Collector Pipe
Basket Support
Cabinet
Pilot Burner
Knob
Pilot Gas Pipe
Nut
Metal Ring
Pilot Injection Device
Plate
1
12
9
Technical Data
Power (BTU/h)
Consumption (Gr/h)
Weight (kg/lbs)
Dimensions W x H x D (cm/in)
9000
225
3.8/8.4
32/12.6 x 41/16.2 x 39/15.4
Item Code Description
GAS FRYER (F1B-G) GAS FRYER (F1B-G)
2
CROYDON
CROYDON
F1B-GP0001 C0
18
17
16
15
14
19
