croydon F2B User manual

F2B-100001 C7
F2B
F2B
ELECTRICAL FRYER - MODEL: F2B-100001 C7
-Please read these instructions carefully before operating this appliance.
-The temperature is thermostatically controlled between the range of 80°C to 200°C(176°F to 392°F). A
signal lamp adjacent to the thermostat indicates when the heating element is energized.
SAFETY
-This appliance is designed to operate on alternative current (A.C.) Only
-DO NOT CONNECT TO DIRECT CURRENT (D.C.).
-Care should be taken when operating this appliance, as HOT SURFACES may cause burns.
-WARNING! Hot oil can cause burns. Spilling oil can cause severe burns. Do not move fryer without
draining all the oil from the tank.
-Do not over fill baskets. Carefully load them into hot oil. A danger of surge boiling can also occur if the
food to be fried is excessively wet or the frying basket is too full.
-It is dangerous to use old oil as this can reduce the flash point and cause surge boiling.
-Ensure that power supply cord does not come into contact with hot surfaces.
- When not in use for long period unplug the appliance.
INSTALLATION AND OPERATION
-Before connecting your appliance check if voltage of your power system corresponds to the unit
label.
-Fill each container with 9.2 lbs (4.5 liters) of quality oil (fat).
-Set thermostat to desired operation temperature (table 1) and pilot light will turn on. As soon pilot
light turns off, appliance has reached desired temperature .
-The basket should be filled up to 2/3 of the capacity.
-To turn off your unit turn knob completely towards left.
WARNING!
- UNPLUG THE APPLIANCE AFTER USE.
CLEANING PROCEDURE
-Always ensure that the appliance is disconnected from the main power supply before cleaning.
-Wait until oil cools and proceed as follows:
- Remove installation box.
- Remove oil container and empty the oil.
-Appliance should not be cleaned with a water jet or immersed in water. Use only a damp cloth or sponge
dipped in soapy water.
-Wipe off appliance with a dry cloth and wait at least half an hour before re-connecting to main power
outlet.
The pictures/drawings are illustrations. All data can be changed without notification.
INSTRUCTION MANUAL
0
5
0
5
2
200
5
10
0
10
L
S
DE
C
º
30
2
2
2
1
2
21
32
0
9
32
2
8
4
0
68
ºF
FF
O
50
20
5
00
2
5
10
00
1
EL
DS
ºC
20
3
2
12
12
2
0
32
92
3
482
08
6
F
º
OFF

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
20
5.272-3
5.260-3
552
5.271-3
5.131-3
5.270-3
3.509-3
2.009-B
5.032-3
604
385
2.096-3
9.413-3
601
330
5.218-3
5.019-3
5.207-3
5.226-3
1.917-3
597
1.352-3
329
Basket
Container
Screw (3,5)
Installation Box Cover
Thermostat
Installation Box
Pilot Light
Knob
Rubber Finishing
Nut (3/16")
Screw (3/16”)
Cord Connection
Cord Retainer
Nut (1/4")
Screw
Heating Element 2000W 110V
Bulb Clamp
Position Pin
Body
Foot
Washer (1/4”)
Plate
Screw
2
19
12
13
descriptioncodeitem
ELECTRICAL FRYER (F2B)ELECTRICAL FRYER (F2B)
1
11
16
17
10
15
6
7
9
10
18
14
21
5
3
11
4
Wiring diagram
G
L2
L1
THERMOSTAT
x 2
Technical Data
Voltage (V)
Power (W)
Amperage (A)
Weight (kg/lbs)
Dimensions W x H x D (cm/in)
110
2 x 2000
2 x 18.2
8.0/17.6
55/21.7 x 34/13.4 x 45/17.8
F2B-100001 C7 Fryer Temperature
PRODUCTS TEMPERATURE C / F
Potato 190/374
Fish 180/356
Meat 160/320
Vegetable 150/302
8
22
23
