croydon TFGC-G00001 A5 User manual

GAS FRYER - MODEL: TFGC-G00001 A5
-Please read these instructions carefully before operating this appliance.
SAFETY
-Install your equipment in area well ventilated, to eliminate the gases generated by the combustion.
-It’s recommended to leave at least 6 inches (15 cm) of free space around the equipment.
-DO NOT install the equipment next to combustible materials.
-The installation has to comply to the safety standards.
-As metallic parts are good conductors of heat, let them cool before any maintenance.
-WARNING! Hot oil can cause burns. Spilling oil can cause severe burns. Do not move fryer without
draining all the oil from the tank.
-Do not overfill basket. Carefully load them into hot oil. Adanger of surge boiling can also occur if the food
to be fried is excessively wet or the frying basket is too full.
OPERATION
-The equipment is supplied with a Gas Tap which can adjust the flame (turn 1/4 to maximum flame
and turn 1/2 to minimum flame)
-Incorporated to the Tap there is a safety device that will let open the gas only if it is pressed and
turned counterclockwise.
-To start the equipment do the following:
1. Fill the container with 14.3 lbs (7 liters) of quality oil (fat).
2. Open the burner drawer.
3. Light a fire flame.
4. Press and turn 1/4 counterclockwise the Tap Knob.
5. Bring the flame next to the burner until it lights.
6. Close the burner drawer.
7. Let the Tap Knob in the maximum flame position for at least 20 minutes and the
equipment is ready for use.
-To turn off the burner turn the Tap Knob completely clockwise.
CLEANING PROCEDURE
- The cleaning procedure should be done daily after the use.
- To clean, use only a soapy damp cloth in all parts, avoiding excess of water.
- It is not recommended the use of any abrasive material.
MAINTENANCE
- Always maintain your equipment clean and in perfect operation conditions, those providences, will
help your equipment to last longer.
- To guarantee a good performance, we recommended an annual revision of the equipment.
INSTRUCTION MANUAL
CROYDON
COYDON
R
OW
L
OFF
I
H
CROYDON CROYDONMAQ INDUSTRIAL LTDA.
Estrada São Lourenço, 891 - Capivari
Duque de Caxias - RJ / Brasil - CEP 25243-150
Phone: [phone]
e-mail: [email protected] - www.croydon.com.br
The pictures/drawings are illustrations. All data can be changed without notification.
TFGC-G00001 A5

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
6.109-3
86.024-3
6.208-3
40.113-3
2.208-3
40.112-3
6.212-3
6.210-3
352
566
604
6.203-3
385
6.204-3
2.546-3
2.545-3
2.202-3
6.209-3
1.965-3
1.342-3
Basket
Container
Cabinet
Burner’s Cone
Gas Injection Device
Burner’s Base
Paper Washer
Aluminum Washer
Screw
Screw
Nut
Drawer
Screw
Gas Pipe
Nut
Gas Connection
Gas Tap
Installation Box
Knob
Plate
11
13
12
6
7
8
9
10
1
2
3
19
18
14
15
16
17
13
4
5
Item Code Description
GAS FRYER (TFGC-G) GAS FRYER (TFGC-G)
Technical Data
Power (BTU/h)
Weight (kg/lbs)
Dimension WxHxD (cm/in)
45000
5.0/11.0
48/19 x 29/11.5 x 58/23
CROYDON
CROYDON
TFGC-G00001 A5
20
