CryptoPay Swiper Operating and maintenance manual
CryptoPay Swiper Installation
QUICKSTART
THINGS TO CONSIDER BEFORE YOU BEGIN: Remember to copy the 16 dig-
it Swiper ID labeled on the back of the swiper and the mounting location (58d6561ed06471f7-Bay 1 or
58d6561ed06471f7-Washer 1). You will need this information when you congure your swiper(s) online. Mount
the swiper with sucient clearance above and below the swiper to allow a credit card to enter and exit without
obstruction.
Warning: Turn o equipment power before completing this step.
1
3
2
5
4
Physical Installation – Mount the swiper on the coin box or vacuum. Three holes
are required: two for the mounting screws and one for power and signal wires.
Mount the swiper with a vertical orientation. The swiper button must be at the
bottom of the swiper (See Figure 1: Coin Box).
Signal Wires – The two red/green striped wires are the signal wires – they are
interchangeable. One will be signal input and the other signal common. The wiring
guide on the back of this page will provide detail for connecting to your timer.
Power Wires – Connect 24VAC to the swiper’s black and yellow wires. Black Wire:
24VAC Common, Yellow Wire: 24VAC Hot.
Light Bar – After connecting 24VAC, the light bar on the front of the swiper should
become active. If the LED bar is blinking yellow, the swiper is in “Out of service”
mode and must be congured before use.
Coin Count Wires* – The two gray wires are the coin count wires – they are
interchangeable. One will connect to the coin input of the timer and the other will
connect to the coin common. *Requires CryptoPay Site Analytics. Service
You are now ready to congure your swipers and coordinator in the
next step of the CryptoPay Quickstart Guide: Online Conguration.
CryptoPay
Swiper
Turn over for
more information.
SWIPER WIRING GUIDE
Timer Model Hookup Notes
DC Input Timers
** Red/green striped wires are interchangeable
Dixmor LED5
Dixmor LED6
Dixmor LED9
One Red/green wire to CC input (pin 8)
Other Red/green wire to Common (pin 9)
One Red/green wire to CC input (pin 8)
Other Red/green wire to Common (pin 6)
Firmware on LED5 must support CC input. Set
LED9 Menu setting to CC Yes.
Dixmor LED7
Dixmor DX2002
One Red/green wire to CC input (pin 9)
Other Red/green wire to Common (pin 6)
IDX AT411 One Red/green wire to COIN input (pin 7)
Other Red/green wire to Common (pin 8)
IDX LTT800/
LTT802/
BT912
One Red/green wire to COIN input
(P1- pin 3)
Other Red/green wire to Common
(P1- pin 2 )
Ginsan
24VAC powered
One Red/green wire to COIN input
Other Red/green wire to 24VAC hot
Black wire to 24VAC common
Yellow wire to 24VAC hot
Hot and common are reversed from other
hookups.
Ginsan
110VAC powered
One Red/green wire to COIN input
Other Red/green wire to 24vac low
Black wire to 24VAC hot of transformer
Yellow wire to 24VAC common of transformer
Requires an external transformer for separate
24 VAC power to swiper.
D&S DS200/201/
203/204/224
One Red/green wire to COIN input (pin 2)
Other Red/green wire to Common (pin 6)
Yellow wire to 24VAC hot
Black wire to 24VAC common
AC Input Timers
Coleman 1034S
Timemaster TM5
One Red/green wire to XCOIN input (pin 2)
Other Red/green wire to 24 VAC Hot (pin 10)
Yellow wire to 24VAC hot
Black wire to 24VAC common
Dixmor LED5 One Red/green wire to COIN input (pin 2)
Other Red/green wire to 24 VAC Hot (pin 10)
For older code versions that don’t support a
credit card input, use this connection.
Ginsan GS-400 One Red/green wire to COIN input (red/green)
Other Red/green wire to 24VAC hot (Red wire)
Black wire to 24VAC common (Purple wire )
Yellow wire to 24VAC hot (Red wire)
Additional resources are available at: http://www.getcryptopay.com/knowledgebase.php
