Crystal Image Technologies RM-F117 User manual

UM-CV-751-F17-Q218V1 www.rackmountsales.com
751
RM-F17USD
1920 x 1080 native resolution
User Manual 1U 17″FHD LCD Console Drawer
dedicated KVM switch and rackmount screen technology
1920 x 1080 native resolution
RM-F117
Flexible mounting depth
( 15.7″ - 31.7" Range )

UM-CV-751-F17-Q218V1 www.rackmountsales.com
Legal Information
First English printing, January 2018
Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness
of the contents. The information in this document is subject to change without notice. We are not liable for any injury or
loss that results from the use of this equipment.
Safety Instructions
Please read all of these instructions carefully before you use the device. Save this manual for
future reference.
■Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.
■Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned environment with
temperatures not exceeding 40º Celsius (104º Fahrenheit).
■When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling and causing
damage to other equipment or injury to persons nearby.
■When the equipment is in an open position, do not cover, block or in any way obstruct the gap between it and the
power supply. Proper air convection is necessary to keep it from overheating.
■Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.
■If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the voltage and current
labeled on the equipment’s electrical ratings label. The voltage rating on the cord should be higher than the one listed
on the equipment’s ratings label.
■Observe all precautions and warnings attached to the equipment.
■If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to prevent being
damaged by transient over-voltage.
■Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on to the power
supply or on other hardware may cause damage, fire or electrical shock.
■Only qualified service personnel should open the chassis. Opening it yourself could damage the equipment and
invalidate its warranty.
■If any part of the equipment becomes damaged or stops functioning, have it checked by qualified service personnel.
What the warranty does not cover
■Any product, on which the serial number has been defaced, modified or removed.
■Damage, deterioration or malfunction resulting from:
□Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or
failure to follow instructions supplied with the product.
□Repair or attempted repair by anyone not authorized by us.
□Any damage of the product due to shipment.
□Removal or installation of the product.
□Causes external to the product, such as electric power fluctuation or failure.
□Use of supplies or parts not meeting our specifications.
□Normal wear and tear.
□Any other causes which does not relate to a product defect.
■Removal, installation, and set-up service charges.
Regulatory Notices Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
Any changes or modifications made to this equipment may void the user’s authority to operate this equipment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
■Re-position or relocate the receiving antenna.
■Increase the separation between the equipment and receiver.
■Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

UM-CV-751-F17-Q218V1 www.rackmountsales.com
Options
3.1 3G / HD / SD-SDI Broadcast-grade input
3.2 HDMI 1.3 video input
Audio input & output ( F117 only )
3.3 F17″Touchscreen : Resistive 1-point touch
3.4 DC Power : 12V / 24V / 48V / 125V
3.5 ORB-2.1 : 2-post rack mounting brackets
< Part. 3 >
P.18
P.20 - 21
P.22 - 23
P.24
P.25
< Part. 2 > Specifications / OSD
2.1 Product Specifications
2.2 Keyboard / Mouse Specifications
2.3 On-screen Display Operation ( OSD )
P.10 - 11
P.12 - 14
P.16 - 17
< Part. 1 >
Contents
RM-F117 / RM-F17USD
1.1 Package Content
1.2 Structure Diagram & Dimension
1.3 Installation
1.4 Connection
P.1
P.2 - 3
P.4 - 6
P.8 - 9
KVM integration
4.1 RM-F117
4.2 RM-F17USD
< Part. 4 >
P.26
P.27

UM-CV-751-F17-Q218V1 www.rackmountsales.com
■It is very important to mount the equipment in a suitable cabinet or on a stable surface.
■Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive
dust, dirt, heat, water, moisture and vibration.
The equipment comes with the standard parts shown in package content. Check and make sure they are
included and in good condition. If anything is missing, or damaged, contact the supplier immediately.
Unpacking
Before Installation
How To Clean Your LCD Monitor
Caution :
■To avoid the risk of electric shock, make sure your hands are dry before unplugging your monitor from or
plugging your monitor into an electrical outlet.
■When you clean your monitor, do not press down on the LCD screen. Pressing down on the screen can
scratch or damage your display. Pressure damage is not covered under warranty.
■Use only cleansers made specifically for cleaning monitors and monitor screens. Cleansers not made to
clean monitors and monitor screens can scratch the LCD display or strip off the finish.
■Do not spray any kind of liquid directly onto the screen or case of your monitor. Spraying liquids directly
onto the screen or case can cause damage which is not covered under warranty.
■Do not use paper towels or abrasive pads to clean your monitor. Using an abrasive pad or any wood based
paper product such as paper towels can scratch your LCD screen.
Cleaning Your Monitor
To clean your LCD safely, please follow these steps :
Disconnect the power cord.
Gently wipe the surface using a clean, dry microfiber cloth. Use as little pressure as possible.
1
2
Cleaning Tough Marks and Smudges
To remove tough marks and smudges, please follow these steps :
Disconnect the power cord.
Spray a small amount of non-abrasive cleanser on a microfiber cloth.
Gently wipe the surface. Use as little pressure as possible.
Wait until your monitor is completely dry before plugging it in and powering it up.
1
2
Caution : Do not spray or apply any liquids directly onto the monitor. Always apply the solution to your
microfiber cloth first, not directly on the parts you are cleaning.
3
4

UM-CV-751-F17-Q218V1 www.rackmountsales.com
- DVI-6 6ft DVI-D console cable X 1
( Alternative : KVM-B-6 6ft VGA console cable )
- Power cord X 1
- M6 screw, cage nut & cup washer X 8
- DVI-6 6ft DVI-D console cable X 1
( Alternative : KVM-B-6 6ft VGA console cable )
- 2.5A Power adapter & Power cord X 1
- M6 screw, cage nut & cup washer X 8
< 1.1 > Package Content
P.1
< Part 1 >
The above package content is only for the single console models.
It varies with options such as KVM, SDI, HDMI, Touchscreen & DC power.
< 1.2 > Structure Diagram
4
1
2
5
6
7
311
9
10
8
11
10
9
8
7
6
5
4
3
1LCD interchangeable module kit
Membrane switch (KVM option)
Installation Slides
LCD membrane
Micro switch for screen auto power off
Audio speaker ( for SDI or HDMI option )
Keyboard interchangeable module kit
Mouse interchangeable module kit
Blue Power LED
Front USB port for device access
( USB Hub KVM only )
Molded front handle
2
6
4
5
8
2
1
3
7
8
7
6
5
4
3
1LCD interchangeable module kit
Installation Slides
Low Profile Molded front handle
Audio speaker ( for SDI or HDMI option )
LCD membrane
Micro switch for screen auto power off
Keyboard interchangeable module kit
Mouse interchangeable module kit
2
RM-F17USDRM-F117

UM-CV-751-F17-Q218V1 www.rackmountsales.com
< 1.2 > Dimension - RM-F117
Side View
Top View
Front View
The weight is only for the single console models. It varies with accessories & options
such as KVM, SDI, HDMI, Audio & DC power.
UNIT : mm
1mm = 0.03937 inch
Model Product Dimension
(W x D x H) Packing Dimension (W x D x H) Net Weight Gross Weight
RM-F117 441.6 x 460 x 44 mm
17.4 x 18.1 x 1.73" 590 x 808 x 140 mm 23.2 x 31.8 x 5.5” 10.8 kg 23.8 lb 15.8 kg 34.8 lb
Power VGA DVI-D
Rear View
P.2
RM-F117

UM-CV-751-F17-Q218V1 www.rackmountsales.com
Side View
Top View
Front View
The weight is only for the single console models. It varies with accessories & options
such as KVM, SDI, HDMI & DC power.
UNIT : mm
1mm = 0.03937 inch
Model Product Dimension
(W x D x H) Packing Dimension (W x D x H) Net Weight Gross Weight
RM-F17USD 441.6 x 400 x 44 mm
17.4 x 15.7 x 1.73" 590 x 622 x 140 mm 23.2 x 24.5 x 5.5" 8.6 kg 18.9 lb 13.6 kg 29.9 lb
Rear View
PowerVGADVI-D
< 1.2 > Dimension - RM-F17USD
P.3
RM-F17USD
(15.7" to 23.7" Mounting Range)
(15.74")
(15.74")
(.84")
18.9" (RM-F17USD-16BRK)
RM-F17USD-16BRK
(18.9" to 30" Mounting Range)

UM-CV-751-F17-Q218V1 www.rackmountsales.com
< 1.3 > Installation - Installation Slides
■Fix the LCD console drawer into the rack.
Complete the installation
Step 3
■Insert the left and right rear mounting brackets into
the LCD console drawer.
Step 1
Step 2
■Measure the depth of the front and rear mounting rails.
■Align each rear mounting bracket to a suitable length.
M6 screw, cage nut & cup washer x 8 are provided.
P.4

UM-CV-751-F17-Q218V1 www.rackmountsales.com
P.5
■Hold the handle and slide out the
drawer.
■Operate the LCD console drawer.
■Flip up the LCD to a suitable angle.
< 1.3 > Installation - How to use the RM-F117 drawer

UM-CV-751-F17-Q218V1 www.rackmountsales.com
< 1.3 > Installation - How to use the RM-F17USD drawer
■Press the handle button and gently slide out
the drawer.
■Flip up the LCD to a suitable angle.
■Operate the LCD console drawer.
P.6
