CS Unitec ECO 80 User manual

CS UNITEC, INC.
MODELS ECO 80, ECO 100/3AK & ECO 130
ELECTRIC MAGNETIC DRILLS
OPERATING MANUAL
CS Unitec, Inc., 22 Harbor Avenue, Norwalk, CT 06850 Toll Free: 800-700-5919 Fax: [phone]
ECO 80 AK
ECO 100/3 AK
ECO 130 AK

CS UNITEC, INC.
CS Unitec, Inc., 22 Harbor Avenue, Norwalk, CT 06850 Toll Free: 800-700-5919 Fax: [phone]

CS UNITEC, INC.
CS Unitec, Inc., 22 Harbor Avenue, Norwalk, CT 06850 Toll Free: 800-700-5919 Fax: [phone]

CS UNITEC, INC.
CS Unitec, Inc., 22 Harbor Avenue, Norwalk, CT 06850 Toll Free: 800-700-5919 Fax: [phone]
Picture 2
Picture 2:
1: Center pilot.
2: Center hole in cutter, for mounting the pilot pin.
Put the center pilot (1) in the hole (2), then mount the cutter
into the arbor.
3: Cutter shank, the piece which will slide into the arbor.
4: Oil canal takes the oil down the cutter for optimum
lubrication from the inside.
5: Flat side to tighten the cutter in the arbor.
Each cutter has 2 flat sides.
Make sure the flats (2x) are exactly placed in front of the
cutter retaining screws when mounting the cutter in the arbor.
