FT26andFT20Owner’sManual










FT26andFT20Owner’sManual

1
Contents
AWordFromSteve...............................................................................................................................................2
Safety....................................................................................................................................................................3
CautionandWarningSymbols..............................................................................................................................4
Pre‐RideSafetyChecks..........................................................................................................................................4
GeneralInformation..............................................................................................................................................5
Operation..............................................................................................................................................................5
ElectricBicycleComponents.................................................................................................................................6
LCDDisplaysandSwitchFunctions.......................................................................................................................1
TurningOnYourElectricBicycle............................................................................................................................2
TurningYourHeadlightandTaillightOnandOff...................................................................................................2
ChangingYourLCDDisplayMode.........................................................................................................................2
IlluminatingYourLCD’sBacklight..........................................................................................................................3
TogglingBetweenEnglishandMetricUnits..........................................................................................................4
PedalAssistSystem...............................................................................................................................................4
ThumbThrottle.....................................................................................................................................................5
DisplayingMileageandTime,andResettingtheTripMeter................................................................................5
MaximumElectricMotorBicycleSpeed...............................................................................................................5
ShiftingDriveGears..............................................................................................................................................6
Braking..................................................................................................................................................................6
ChargingtheBattery.............................................................................................................................................7
BatteryRange........................................................................................................................................................8
BatteryStatus........................................................................................................................................................8
BatteryDisposal....................................................................................................................................................8
FrontSuspension..................................................................................................................................................9
AdjustingYourBicycletoFitYou.........................................................................................................................10
TirePressureandTireMaintenance...................................................................................................................11
AssemblingYourElectricBicycle.........................................................................................................................12
RecommendedInspectionIntervals...................................................................................................................29
Troubleshooting..................................................................................................................................................29
TorqueSpecifications..........................................................................................................................................30
BicycleSpecifications..........................................................................................................................................31
Warranty.............................................................................................................................................................33



FT26andFT20Owner’sManual

2
A Word From Steve

ThankyouforpurchasingyournewCSCelectricbicycle.YourCSCFT26orFT20isagreatbicycleand
weareveryproudofit.YourCSCelectricbicycleiseasytomaintain,it’sreliable,andit’sfun.You’ve
madeawisepurchasedecision.

IwantyoutoknowthatwevaluethetrustandconfidenceyouhaveinCSC.Ourguidingprinciplewill
alwaysbethatourcustomerscomefirst.

Wewishyoumanymilesofsafeandenjoyableridingonyournewelectricbicycle.Ifthere’sanything
wecandotoenhanceyourownershipexperience,pleaseletusknow.

Thankyouagain,

SteveSeidner
FounderandCEO
CSCElectricBicycles,LLC
1331W.FoothillBoulevard
Azusa,California91702
9094450900
www.CSCMotorycles.com


FT26andFT20Owner’sManual

3
Safety

ReadthisOwner’sManualinitsentirelybeforeattemptingtorideyournewelectricbike.

Alwayswearahelmet,gloves,andshoeswhileridingthebicycle.Wearbrightly‐coloredclothingso
othervehiclescanseeyou.

Makesurethereisnolessthan1‐inchclearance
betweentherider’sinseamareaandthebicycletop
tubewhentheriderstraddlesthebicyclewithbothfeet
flatontheground.

Ifthebicycleistoolarge,theridermaynotbeableto
reachthepedalsortheground,whichmayresultinloss
ofcontrolandacrash.

Adjusttheseatheightsuchthatyoucancomfortablyreachthepedalswhentheyareatthebottomof
theirstroke.

Donotallowotherswhoareunfamiliarwiththeelectricbike’soperationtoridethebike.

Donotridethebicycleinhighwind,rain,ice,orsnowconditions.Donotridethebicycleifthe
temperatureisbelow15oForabove95oF.Donotridethebicyclewhenitisdarkoutside.

Donotridethebicycleifyouweighmorethanmorethan300pounds.Ifcarryingcargo,donotcarry
orstrapanypackagestotheluggagerackiftheyweighmorethan55pounds.

Beawareofthebattery’schargestate,anddonotridesuchthatthebatterypowerisdepletedandyou
donothavetheabilitytomakeittoyourdestination.

Makesurethebatteryisadequatelychargedbeforeeverytrip.

Chargethebatteryatleastoncemonthlyiftheelectricbicycleisinstorage.

Donotenterpuddlesorotherbodiesofwatersuchthatelectricalcomponentsbecomewet.

Donotattempttomodifytheelectricalcircuits.

FT26andFT20Owner’sManual

4

Disposeofthebatteryinaccordancewithapplicablebatterydisposalregulations.

Alwaysridewithbothhandsonthehandgrips.

Usethechargerprovidedwithyourelectricbicycle.Neverattempttouseanunauthorizedcharger.

Chargethebatteryinawell‐ventilatedarea.

Donotinstallachildseatonyourelectricbicycle.
Caution and Warning Symbols

Cautionandwarningsymbolsinthismanualareasfollows:

TheCaution!symbolindicatesaconditionthatmayleadtoelectricbicycledamage.
TheWarning!symbolindicatesaconditionthatmayleadtoinjuryordeath.
Pre-Ride Safety Checks

Priortoeveryride,pleasecheckthefollowingitemstomakesureyourelectricbicycleisreadyforyouto
ride:

Thebatteryisfullycharged.
Bothtiresareinflatedto20psi.
Boththefrontandrearbrakeareoperational.
Thefrontforkskeweristightened.
Therearwheelnutsaresecure.
Thehandlebarissecure.
Theseatpostclampissecure.


FT26andFT20Owner’sManual

5
General Information

YourCSCelectricbicycleisanelectricmotorassistedbicycleequippedwithpedalsandanelectricmotor.
AtLevel0,nopedalassistisprovided.Levels1through5provideincreasinglevelsofpedalassist.The
electricmotorpedalassistfunctionisactivatedbypedalingthebicyclewhenpedalassistLevels1
through5havebeenselected(dependingonwhichpowerassistlevelyouhaveselected,additional
motivepowerisprovidedwhenyoupedalthebicycle).InLevels1through5,thehandlebar‐mounted
thumbswitchengagestheelectricmotortodrivethebicyclewithoutpedaling.

Caution!Donotactivatethehandlebar‐mountedthumbswitchifyouarenotonthebicycleandthe
pedalassistlevelissettoLevel1,2,3,4,or5,astheelectricmotorwillpropelthebicycleforward.

Yourelectricbicycleincludesaframe‐mountedbatterythatshouldberechargedasrequired.

Thebicycleincludesarearsetofsprocketswithaderailleurthatallowfor7differentgearratios.You
canshiftgearsusingahandlebar‐mountedindexshifterlikeyouwoulddoonaregularbicycle.

Thebicycleincludesfrontandrearhydraulicdiskbrakes,whichareindependentlyoperatedby
handlebar‐mountedlevers.

Thebicycleincludesafrontsuspensionthatisadjustableforcompressionanddamping,andthatcanbe
lockedtorigidfontsuspension.

Thebicycleincludesaheadlightandataillightthatmustbemanuallyswitchedon.Theseshouldbe
turnedonatalltimeswhenthebicycleisriddentoprovideforimprovedridervisibility.
Operation

ReadyingyourbicycleforuseinvolvesturningtheLCDonafterperformingthesafetychecksoutlinedin
thePre‐RideSafetyChecksinthisOwner’sManual.

PleasereadthismanualinitsentiretypriortooperatingyourCSCelectricbicyclepriortoyourfirstride.
Pleaserefertotheelectricbicyclecomponentssection(shownonthenextpage)whenreadingeach
sectionofthisOwner’sManual.


FT26andFT20Owner’sManual

6
Electric Bicycle Components


1. FrameTopTube
2. FrameDownTube
3. FrontFork
4. Headlight
5. BrakeLevers
6. Stem
7. WaterBottleHolder
8. Battery
9. Seat
10. Seatpost
11. Taillight
12. SeatpostClamp
13. FrontTireandWheel
14. RearTireandWheel
15. RearDerailleur
16. Chain
17. Kickstand
18. Chainring
19. Crank
20. Pedals
21. RearDiskBrake
22. Controller
23. ThumbThrottle
24. LCD
25. FrontDiskBrake


FT26andFT20Owner’sManual

1
LCD Displays and Switch Functions

TheLCD(mountedinthecenterhandlebararea)providesa
largearrayofinformationinseveraldisplaymodes.Turning
thebicycle’sLCDon,makingelectricmotorpoweravailableto
drivethebicycle,LCDdisplayinformation,andnumerous
bicyclesettingsareallcontrolledbythreeswitchescontained
inaswitchhousingonthelefthandlebar(showntotheright).
TheswitchesarereferredtoasSwitch1(theUPswitch),
Switch2(thepowerswitch),andSwitch3(theDOWNswitch).

TheswitchandLCDdisplaysareshownintheillustrationbelow.


Warning!TakecarewhenactivatingSwitches1,2,and3whileridingyourelectricbicycle.Lackof
attentiontoridingyourelectricbicyclewhileactuatingtheswitchesmayresultinacrash.

FT26andFT20Owner’sManual

2
Turning On Your Electric Bicycle

TurnonthebicyclebydepressingSwitch2inthephotoshown
totherightuntiltheLCDilluminates.Turningoffthebicycle
requiresdepressingSwitch2andholdingitdownasecond
time.

ThebicycleLCD,theelectricmotorpedalassistfunctions,and
thumbswitchelectricmotoractuationwillturnoff
automaticallyifthebicycleisnotusedfor5minutes.


Turning Your Headlight and Taillight On and Off

Toturnontheheadlightandtaillight,depressSwitch1until
thelightsilluminate.Toturnofftheheadlightandtaillight,
depressSwitch1untilthelightsturnoff.


Changing Your LCD Display Mode
TheLCDmountedinthecenterofthehandlebarshasthree
displaymodes:Display1,Display2,andDisplay3.Youcan
cyclethroughDisplay1,Display2,andDisplay3bypressing
Switch2momentarilyaftertheLCDhasbeenturnedon.By
default,Display1isshownwhenyoufirstturnonyourelectric
bicycle.


FT26andFT20Owner’sManual

3
Display1showsactualspeed,asindicatedbytheredarrowin
thephotototheright.Display1alsoshowsother
informationasshowninthephotototheright.

Display2showsaveragespeedduringtheride,asindicatedby
theredarrowinthephotototheright.Display2alsoshows
otherinformationasshowninthephotototheright.

AftershowingDisplay2,thedisplaychangestoDisplay1after
ridingthebicyclefor5seconds.

Display3showsmaximumspeedattainedduringtheride,as
wellasotherinformationasshowninthephotototheright.

AftershowingDisplay3,thedisplaychangestoDisplay1after
ridingthebicyclefor5seconds.

Illuminating Your LCD’s Backlight
AftertheLCDhasbeenturnedon,youcanilluminatethe
backlightontheLCDbyholdingSwitch1oncontinuouslyfor5
seconds.Youcandothisfromanyofthedisplaymodes.

Toturnthebacklightoff,holdSwitchon1continuouslyfor5
seconds.


FT26andFT20Owner’sManual

4
Toggling Between English and Metric Units
Within15secondsofturningtheLCDon,depressSwitches2and
3for5secondsuntilyouseethescreenstarttoflash.Atthis
point,byrepeatedlydepressingSwitch2youcantogglethrougha
topspeedsetting(donotadjustthis),wheeldiameter(thisisset
atthefactory)andchoicesforfouroptionsyoucancyclethrough
bydepressingSwitches1or2:

1. MPH&Fahrenheitunits
2. KM/H&Fahrenheitunits
3. MPH&Celsiusunits
4. KM/H&Celsiusunits
\
Afterselectingyourdesiredmeasurementunits,depressSwitch2
for5secondstoreturntoDisplay1.


Pedal Assist System
Tochangetheamountofpedalassist(electricmotorpower
providedduringthepedalingeffort),depressSwitches1or3
tochangefromLevel0(nopedalassist)toLevel5(maximum
amountofpedalassist).PressingSwitch1increasesthe
pedalassistlevel(moreassistancefromthemotorisprovided);
pressingSwitch3decreasesthepedalassistlevel(less
assistanceisprovided).
ThePedalAssistLevelselected(0through5)willbedisplayed
ontheLCD’sleftsideasshowninthephotographtotheright.


FT26andFT20Owner’sManual

5
Thumb Throttle

Actuatingthehandlebar‐mountedthumbthrottleaftertheelectricbicyclehasbeenturnedonwillcause
theelectricmotortopropelthebikeforward.

Thethumbthrottleisshowninthephotototheright.

Pushingthethumbthrottledownincreasestheamountof
powerprovidedtothedrivemotor,therebyincreasingthe
bicycle’sspeed.

Caution!Donotactivatethehandlebar‐mountedthumb
switchifyouarenotonthebicycle,astheelectricmotorwill
propelthebicycleforward.

Displaying Mileage and Time, and Resetting the Trip Meter

Todisplaytripmileageandtime,depressSwitch1and3
simultaneouslyfor5seconds.Thetripmileageandriding
timewillbedisplayedontheLCD.

Toresetthedisplaystozero,depressSwitch2untiltheLCD
mileageandtimereverttozero.

Maximum Electric Motor Bicycle Speed

YourCSCelectricbicycle’smaximumspeedthatcanbeattainedthroughelectricmotorpoweris20mph.
Youcanattainhigherspeedsbypedalingthebicyclefasterwithhigherrearderailleurgearsselected,but
noadditionalelectricpowerwillbeprovidedabove20mph.Asexplainedabove,electricmotorpower
willbeprovidedby:

ThumbthrottleactivationifyouhaveselectedpedalassistlevelsofLevel1throughLevel5,or
Thepedalassistfunctiontoassistmanualpedalingifyouhaveselectedpedalassistlevelsof
Level1throughLevel5,or

FT26andFT20Owner’sManual

6
Bothoftheabove.

Beyond20mph,though,noadditionalelectricmotorpowerwillbeprovidedtodriveyourelectric
bicycletohigherspeeds.
Shifting Drive Gears

Rearwheeldrivegearchangesareaccomplishedthroughtheuseofthegearselectorlocatedonthe
handlebarneartherighthandgrip.

Changingtoahighergear(forhigherbicyclespeeds)requires
clickingthegearselectorleverforward(shownbytheupper
arrow)withyourthumb.

Changingtoalowergear(forclimbinghillsorpedalingintothe
wind)requirespressingthegeardownshiftbutton(shownby
thelowerarrow)withyourthumb.

Caution!Youshouldonlychangegearswhilepedalingtoallowtherearderailleurtomovethechain
fromonerearsprockettoanother.Attemptingtochangegearswhilenotpedalingputsunduestress
ontherearderailleur.
Braking

Yourelectricbicyclehasfrontandrearhydraulically‐actuateddiskbrakes.Thebrakesarecontrolledby
handle‐barmountedbrakelevers.Theleftbrakeleveroperatestherearbrakeandtherightbrakelever
operatesthefrontbrake.

Duringnormaloperation,boththefrontandrearbrakesshouldbeusedtodecelerateortostopthe
electricbicycle.

Warning!Donotapplythebrakestoovigorouslyoryoumayinduceaskidandcrash.Donotapplythe
frontbraketoovigorouslyasyoumaylifttherearwheeloffthegroundandcrash.

Warning!Whenridinginwetweather,brakingdistanceswillincreaseduetodecreasedfrictiononthe
brakerotorsanddecreasedtiretraction.Takethisintoconsiderationwhenridinginwetweather.

FT26andFT20Owner’sManual

7

Warning!Checkboththefrontandrearbrakeforproperoperationpriortoeachride.
Charging the Battery

Thebatterymaybechargedeitheronoroffthebicycle.

Tochargethebatteryonthebicycle:

Connectthewallpowersupplyinputplugofthe
chargertothewallACpoweroutletfirst(theplugon
thewall).
Connecttheoutputplugofthechargerwiththe
chargingportofthebattery,asshowninthephototo
theright.

Caution!Donotconnectthechargertothebatterybeforeconnectingthechargertothewalloutlet
first.Doingsomaydamagethecircuit.
Tochargethebatteryoffthebicycle:

Insertthekeyinthebatterylock,turnit,andthenlift
thebatterybyrotatingitawayfromtheframe.
ConnecttheinputplugofthechargerwiththeAC
powersupplyfirst,thenconnecttheoutputplugofthe
chargerwiththechargingportofthebattery.

Caution!Donotconnectthechargertothebatterybeforeconnectingthechargertothewalloutlet
first.Doingsomaydamagethecircuit.

Whenthebatteryischarging,thepowerindicatorofthebatteryandthechargerwillilluminate.
Chargingiscompletewhentheindicatorturnsfromredtogreen.Attainingafullchargetypically
requires6to8hours.

Warning!Chargethebatteryinawellventilated,cool,anddryarea.

Caution!Aftercharging,firstdisconnectthechargerinputplug,andthendisconnectthecharger

FT26andFT20Owner’sManual

8
outputplug.

Caution!Donotallowthechargertoremainconnectedafterthebatteryisfullycharged,asthismay
shortenbatterylife.

Caution!Alwayschargeyourbatteryintemperaturesbetween50°F–77°F(10°C–25°C)andensure
thebatteryandchargerarenotdamagedbeforeinitiatingachargecycle.Ifyounoticeanythingunusual
whilecharging,discontinuecharginganddonotusethebicycle.ContactCSCforhelp.
Battery Range

Yourelectricbicycle’srangeisafunctionofmanyfactors,includingyourweight,yourpedalassistsetting,
howmuchpedaleffortyouprovide,thespeedsatwhichyouride,theterrain(uphillordownhillversus
levelground),theroadsurface,prevailingwinds,andtemperature.

Caution!Donotridesofarthatyouhaveinsufficientchargetocompleteyourtrip.Youshouldalways
leavewithafullychargedbattery,andobservethestateofchargeduringyourridesuchthatadequate
chargeremainstoassistyoutoyourdestination.
Battery Status
BatterychargestatusisshownontheLCDdisplayintheupper
rightcorneroftheLCD,asshowninthephotographtothe
right.

Battery Disposal

Whenyourbatteryisnolongerserviceable,pleasecontactCSCforareplacementat9094450900.Do
nothrowyourbatteryawayasnormaltrash.Disposeofthebatteryinanapprovedbatterydisposal
facility.

FT26andFT20Owner’sManual

9
Front Suspension

Yourelectricbicycle’sfrontsuspensionisadjustableforpreloadanddamping.Preloadreferstothe
howmuchcompressionthefrontspringshaveinitially.Dampingreferstohowquicklythesuspension
cancompress.Preloadanddampingarecontrolledwithtworotaryknobs,eachlocatedoneitherside
ofthefrontforksasshownbelow.Thedampingcontrolcanberotatedallthewaycounterclockwiseto
lockthefrontsuspensionsuchthatnoforkcompressioncanoccur.

Frontsuspensiondampingandadjustmentcontrols.The
dampingadjustorisontherightsideofthefrontfork(as
viewedbytherider.Thepreloadadjustorisontheleftside
ofthefrontfork(asviewedbytherider).

Thedampingadjustorislocatedatthetopoftherightfront
forkasviewedbytherider.Theadjustorcanberotated
counterclockwisethroughninepositionstoadjustthe
damping,fromnodampingallthewaytolockingthe
suspension.

Thepreloadadjustorislocatedatthetopoftheleftfrontfork
asviewedbytherider.Theadjustorcanberotated
counterclockwisetoincreasepreload,andcounterclockwiseto
decreasepreload.


Thepreloadshouldbeadjustedsuchthatwhentheforkcompressionisnotlocked,asmallamountof
forkcompressionoccurswhentheridersitsontheelectricbicycle.Iftheforksbottomout(completely
compress)whenhittingbumpsorirregularitiesintheroadsurface,increasethepreload.


FT26andFT20Owner’sManual

10
Warning!Onlymakepreloadordampingadjustmentswhenyouarestopped.Neverattemptto
maketheseadjustmentswhileriding,asdoingsomaycauseyoutocrash.
Adjusting Your Bicycle to Fit You

Yourelectricbicyclecanbeadjustedforfittoyourbodybymakingadjustmentstoseatheight,seat
position,seatangle,handlebarangle,andbrakeleverpositions.Yourobjectiveshouldbetoadjustthe
bicyclesuchthatitfitsyou.

Seatforeandaftpositioncanbeadjustedbylooseningthe
clampbeneaththeseatandslidingtheseattothefrontorto
therear.Mostpeoplearecomfortablewiththeseat
approximatelycenteredovertheseatpost.

Warning!Makesuretheboltistightaftermakingany
adjustments.Alooseboltcouldcauseyoutocrash.

Seatanglecanbealsoadjustedbylooseningtheboltbeneath
theseatandrotatingtheseatangle.Youshouldadjustthe
seatanglesuchthattheseatisapproximatelyparalleltothe
ground.Youmaywishtomakeminorangularadjustmentsto
movethefrontoftheseatupordowntosuityour
preferences.

Warning!Makesuretheboltistightaftermakingany
adjustments.Alooseboltcouldcauseyoutocrash.


Seatheightcanbeadjustedbylooseningtheseatpostclamp
andmovingtheseatpostupordownintheframe.You
shouldadjusttheseatheightsuchthatwhenthepedalisatits
lowestposition,yourkneeisveryslightlybent.Theseat
shouldbepointedforward,withoutthenoseoftheseat
biasedtotheleftortheright.

Warning!Neveradjusttheseatheightsohighsuchthatthe
seatpostisextendedbeyondthewarninglineinscribedonthe
seatpost.Thiscanresultintheseatpostfailing.


FT26andFT20Owner’sManual

11
Thehandlebarsshouldbeadjustedsuchthattheypoint
straightaheadformostpeople.Ifyourarmsareofslightly
unequallength,youcanadjusttheangleofthehandlebars
withrespecttothefore‐and‐aftaxisofthebicyclesuchthat
youcaneasilyreacheachhandgrip.

Warning!Makesuretheboltsinthephotoshowntothe
rightaresecure.Iftheyareloose,youcanlosecontrolofthe
bicycleandcrash.


Handlebarangularpositioncanbeadjustedbylooseningthe
handlebarclampandrotatingthehandlebarupordown.You
shouldadjustthehandlebarsuchthatitisacomfortabletothe
handlebargrips.

Warning!Makesurethehandlebarmountingboltsare
secure.Iftheyareloose,thehandlebarscanshiftposition
andcauseacrash.


Brakeleveranglecanbeadjustedtolooseningthebrakelever
clampsandrotatingtheleversupordownonthehandlebars.
Youshouldadjusttheleverssuchthatitisacomfortablereach
tothelevers.

Warning!Makesurethebrakeleversaresecure.Iftheyare
loose,theleverscanshiftpositionandcauseacrash.
Tire Pressure and Tire Maintenance

Yourtiresshouldbeinflatedto20psi.Youshouldchecktirepressurepriortoeachride.Tiresare
normalwearitems,anditisroutinefortirestorequirereplacementafteroneortwoseasonsofuse.
Whenthetreadiswornorthetiresidewallsarecracked,orifthetirehasbeentorn,youshouldreplace
yourtiresandyourtubes.It’salsoagoodideatoalwayscarryatirerepairkitandatirepump(orCO2
cartridges)withyouwheneveryourideyourbicycle.Whenyouneedanyoftheseitems,please
contactCSCat9094450900.


FT26andFT20Owner’sManual

12
Caution!Youshouldchecktirepressurepriortoeachride.Donotridethebicycleifthetiresare
underinflated.

Caution!Donotrideyourbicyclewithoutcarryingatuberepairkit,tuberepairtools,andameansof
tireinflation.

Warning!Donotoverinflateyourtires.Thiscouldcausethetiretoburst,resultinginacrash.

Warning!Donotrideyourbicycleifthetreadisseverelyworn,ifthetiresidewallsarecracked,orif
thereisatearinthetire.
Assembling Your Electric Bicycle

Uncrating
YourCSCelectricbicyclewillbedeliveredinacardboardboxas
shownhere.

Opentheboxtop.


FT26andFT20Owner’sManual

13
Usingawirecutter,removetheziptiessecuringtheboxedand
wrappedcomponentscontainer.

Youshouldhaveachargingcord,acharger,threeAllen
wrenches,twowrenches,aplasticnut,thefrontreflector,the
bell,thetaillight,andtwopedals.

Cuttheziptiesandremovethebubblewrapcontainerfrom
thewheel.

Youshouldhavethefrontskewerandtheheadlight.

