QUICK GUIDE &
INSTRUCTION MANUAL
MiniAir

CSL - the trusted choice
Complete Connectivity Solutions
www.csldual.com ©CSL DualCom Limited @CSLDualCom
IFSEC ad 2017 CSL full page v20.indd 1 30/05/2017 11:00

Figure 1 - MiniAir
3
12v DC Power Supply
Ground
A
B
To Armed Status Output
} To panel’s Digi-Modem
To Keyswitch Zone
Twist to fit
LED STATUS
Flashing every second On Flashing every 5
seconds 3 Fast flashes
Establishing connection Good signal Low signal Transferring data
Figure 2 - LED Indications

This section provides basic information to enable you to install and commission the MiniAir quickly.
Before installation or testing, the ARC should be contacted and system placed on test.
STEP 1. WIRING
1. Power panel down
2. Wire as per diagram on Page 3
3. Connect aerial
4. LED will show connection status
STEP 2. DIAL CAPTURE
For panels with PSTN Modems:
a. Configure PSTN dialler of alarm panel – refer to manufacturer’s guide
b. Select DTMF (tone dialling)
c. Select signalling format: Fast Format / Contact ID / SIA
d. Enter any PSTN receiver telephone number (ie 01)
e. Enter any 4 digit chip/account number (ie 1234)
Please note:
When using Fast Format, the MiniAir Installer App and My Home Alarm App are predefined with a standard Fast
Format channel configuration. Please programme the below within your control panel:
4
QUICK GUIDE
PIN CHANNEL
1Fire
2Panic
3Intruder
4Open/Close
5Fault
6Bypass
7Confirmed Alarm
STEP 3. BELL OUTPUT
For older panels with a bell output, please only use the below method to trigger an alarm:
a. Configure bell/siren output of alarm panel – refer to manufacturer’s guide
b. Wire the bell trigger to the MiniAir input (IN – white cable)
c. Download the MiniAir Installer App for Android/iOS
d. Please contact CSL to obtain log in credentials to the MiniAir Installer App & select device by serial
number/ICCID
e. Enter Settings the select Advanced Settings
f. Depending on your panel configuration set Input pins as: General Alarm N.O./N.C.

STEP 5. REMOTE ARM AND DISARM
Firstly, configure the panel as below:
a. Configure a momentary/latching keyswitch – refer to manufacturer’s guide
b. Wire OUT (orange wire) to the momentary/latching keyswitch of the panel
c. Configure a programmable output from the panel to Activate (switch to ground) when the panel is
armed and to deactivate when disarmed – refer to manufacturer’s guide
d. Wire the programmable output to IN (white wire) on the MiniAir
Please note: A relay may be required when configuring a panel with a latching keyswitch
Secondly, configure the App:
a. Enable Open/Close reporting on the panel
b. Enable arming/disarming from the settings menu on the My Home Alarm App
c. Ask the customer to enter a remote pin of their choice
d. Arm/Disarm from the panel’s keypad within 2 minutes to complete synchronisation
STEP 4. END USER APP
a. Download the My Home Alarm App for Android/iOS
b. Login with credentials provided on the back of this quick guide
c. When logging in for first time change username and password. Then enter recovery email address
d. Within the App, select menu button and then settings option
e. Select notifications and adapt as per the on screen instructions
f. If you require remote arming/disarming follow step 5 of this guide
g. Provide a demo for your customer
TROUBLESHOOTING
If you have issues receiving events try the following settings of the panel:
Disable “Telephone line monitoring”
Disable “Wait for dial tone” option
Use “A” instead of “0” in the account number
If there is more than one partition, enter an account number for each partition. For certain panels you may
need to also specify an account number for the main partition (sometimes referred to as system number)
5
WARNINGS
Wiring should only be done when the unit is powered down
Ensure, once connected, the aerial is positioned outside the panel

© Copyright CSL GroupCSL794V3 17012018 PD000794-003
Dimensions 30mm (h) x 45mm (w) x 15mm (d)
Weight 25g excluding aerial
Temperature -20C to +60C transit, -10C to +50C operating
Humidity 0 - 80% non-condensing
Mounting Any orientation
Warranty 2 years
Power Requirement 9.0v - 30.0v DC
Current Consumption Quiescent = 15 mA. Signalling = 200 mA
LED Indications
LED Function
Flashing every second Establishing connection
On Good signal
Flashing every 5 seconds Low signal
3 fast flashes Transferring data
Radio Path GPRS service
Aerial 50 ohm (nominal) on MMCX socket
CIE Interconnections 1 Digital Input, 1 Digital Output and Analogue (Dial Capture)
RCT Protocols Fast Format, SIA & Contact ID
User Serviceable Parts There are no user serviceable parts within MiniAir
Standards
Suitable for use in alarm systems complying to:
EN50136-1:2012 SP1
ATS Classification: EN50136-1-1:1998 ATS 1/Grade 1
SPECIFICATIONS
username/password
SUPPORT
For more information on MiniAir or other DualCom products please contact
CSL Technical Support:
UK Tel: [phone]
Ireland Tel: [phone]
Email: [email protected]
Hours: 08.30 to 18.00 weekdays, 10.00 to 16.00 Saturday
Visit www.csl-group.com for the latest copies of all manuals.
