CST DLE User manual

INSTRUCTION MANUAL
Effective date:
30.09.2013
Digital Light Engraver DLE
ORIGINAL INSTRUCTION MANUAL
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Telephone:[phone]
Fax: [phone]
Email: [e-mail]
[e-mail]
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 1 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
0
Contents
Effective date
30.09.2013
0.
0. Contents ....................................................................................................... 2
1. General Information..................................................................................... 4
1.1 Notes about the Technical Annex.................................................................. 4
1.2 Explanation of symbols.................................................................................. 5
2. Safety............................................................................................................ 7
2.1 Appropriate use and improper modes of operation........................................ 7
2.2 General information for operators and personnel........................................... 9
2.2.1 Requirements placed on personnel ............................................................... 9
2.2.2 Operator’s duties............................................................................................ 9
2.2.3 Important rules of conduct ........................................................................... 10
2.3 Protective equipment................................................................................... 12
2.3.1 Existing protective equipment...................................................................... 13
2.3.2 Inspection of the protective equipment ........................................................ 14
2.4 Emissions (noise levels/sounds).................................................................. 15
2.5 Fire protection.............................................................................................. 15
2.6 Pneumatics.................................................................................................. 16
2.7 Hydraulics.................................................................................................... 16
2.8 Electrical...................................................................................................... 17
2.9 Spare parts.................................................................................................. 17
2.10 Personal protective equipment .................................................................... 18
2.11 EC DECLARATION OF CONFORMITY ...................................................... 19
3. Transportation, storage, installation, electrical connection .................. 20
3.1 Special safety instructions ........................................................................... 20
3.2 Transport ..................................................................................................... 21
3.3 Storage........................................................................................................ 22
3.4 Installation.................................................................................................... 23
3.5 Electrical connection.................................................................................... 23
4. Machine description .................................................................................. 24
4.1 Machine housing.......................................................................................... 25
4.2 Screen frame clamping system.................................................................... 26
4.3 Bridge .......................................................................................................... 27
4.4 Operating control units................................................................................. 28
5. Initial commissioning, decommissioning................................................ 30
5.1 Special safety instructions ........................................................................... 30
5.2 Preparatory work for commissioning............................................................ 32
5.3 Decommissioning......................................................................................... 33
5.4 Instructions about disposal .......................................................................... 34
6. Operation and cleaning............................................................................. 35
6.1Special safety instructions ........................................................................... 35
6.2 Operation..................................................................................................... 37
6.2.1 Starting the machine.................................................................................... 37
6.2.2 Start an imaging process............................................................................. 38
6.2.3 Four colour printing...................................................................................... 41
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 2 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
0
Contents
Effective date
30.09.2013
6.2.4 Checking the LEDs...................................................................................... 42
6.2.5 Finishing work on the machine .................................................................... 43
6.2.6 EMERGENCY STOP................................................................................... 44
6.2.7 Action to be taken after an EMERGENCY STOP ........................................ 44
6.2.8 DLE settings ................................................................................................ 45
6.3 Focus test for the DLE Engraver.................................................................. 49
6.4 Cleaning....................................................................................................... 53
7. Dealing with faults ..................................................................................... 56
8. Service and Maintenance.......................................................................... 61
8.1 Special safety instructions ........................................................................... 61
8.2 General........................................................................................................ 64
8.3 Weekly/monthly intervals............................................................................. 65
8.4 Biannual/ annual interval.............................................................................. 65
8.5 Maintenance plan......................................................................................... 67
8.6 Maintenance Logbook.................................................................................. 68
9. Technical Annex ........................................................................................ 69
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 3 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
1
General Information
Effective date
30.09.2013
1. General Information
This instruction manual provides a wealth of safety and operating instructions
for the following product:
Vertical Digital Light Engraver (DLE)
1.1 Notes about the Technical Annex
The Technical Annex is an integral part of this instruction manual and in-
cludes all important technical details agreed upon
between the purchaser
and the manufacturer, including, for example:
•Project technical drawings/data sheets
•Spare parts list for parts subject to wear
•Relevant operating instructions
•Information pertaining to the necessary certification
•Miscellaneous
Apart from the basic model, we also offer optional extras and a variety of
configurations.
Options include:
•A semi-automatic unloading system for the machine in cooperation with
other vendors
•A fully automatic loading and unloading system in cooperation with other
vendors
•Customer-specific adaptation.
This instruction manual contains important information that needs to be taken
into account in all stages of the life cycle of the machine, including the trans-
portation, installation, operation, maintenance and disposal.
Therefore, it is imperative that this instruction manual is read by the installa-
tion engineer and the responsible technical personnel/operator prior to instal-
lation and commissioning and must always be stored at the operating loca-
tion of the machine.
Information pertaining to specific hazards to persons, property or the envi-
ronment is highlighted in the relevant chapters of this instruction manual.
Apart from this instruction manual, it is important to take into account the rel-
evant technical documentation provided by the vendors. This contains the
operational safety instructions which have to be observed.
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 4 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
1
General Information
Effective date
30.09.2013
1.2 Explanation of symbols
Danger
Nature and source of hazard!
This symbol warns of an immediate danger to the life and health of people.
•Failure to observe such instructions could lead to severe adverse health
effects or even life-threatening injuries as well as substantial damage to
property.
•Action that has to be avoided to prevent hazards from arising.
Warning
Nature and source of hazard!
This symbol warns of a possible dangerous situation to the life and health of
people as well as damage to the environment and property.
•Failure to observe such instructions could lead to severe adverse health
effects to life-threatening injuries as well as substantial damage the envi-
ronment and property.
•Action that has to be avoided to prevent hazards from arising.
Caution
Nature and source of hazard!
This symbol warns of a possible dangerous situation to the life and health of
people as well as damage to the environment and property.
•Failure to observe such instructions could result in moderate
to slight
health effects or even injuries as well as damage to the environment and
property.
•Action that has to be avoided to prevent hazards from arising
Information
Nature and source of hazard to the machine and equipment!
This symbol warns of a hazardous situation and indicates important instruc-
tions on how to handle the machine and the equipment.
•Failure to observe such instructions can lead to extensive damage to
property.
•Action that has to be avoided to prevent
damage to the machine and
equipment.
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 5 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
1
General Information
Effective date
30.09.2013
Warning symbol denoting
remotely started equipment
Warning symbol denoting
drawing-in hazard
Caution, warning symbol de-
noting a danger zone
Warning symbol denoting
bottleneck
Warning symbol denoting a
slip hazard
Warning symbol denoting
fork lift trucks in operation
Warning symbol denoting
hazardous voltage
Warning symbol denoting UV
radiation
Warning symbol denoting hot
surface
Warning symbol denoting
suspended load
Warning symbol denoting
hand injury
Always wear protective safe-
ty glasses against UV radia-
tion
Please follow these instructions and act accordingly in all cases.
Instruct all other users in regard to these safety guidelines.
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 6 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
2
Safety
Effective date
30.09.2013
2. Safety
2.1 Appropriate use and improper modes of operation
Information
Improper operation could lead to damage to the machine and equip-
ment!
Improper operation can lead to damage to the machine and equipment.
•Make sure that all operations are carried out by qualified, authorized and
trained personnel.
•Follow the instructions given in the manufacturer’s instruction manual
carefully and comply with them accordingly.
•Make sure that the workplaces are clean when the machine and equip-
ment are in operation.
•Do not place any tools, appliances or the like on the machine and equip-
ment.
•Do not operate the machine and equipment without having prior adequate
training or without having first read the manufacturer’s instruction manual.
•Do not operate the machine and equipment with products that are not in-
tended to be used with the machine and equipment.
•Ensure that there is sufficient lightning when the machine and equipment
are in operation.
•Do not climb on or through the machine and equipment.
The CST Digital Light Engraver is intended to be used in the print industry for
imaging screen stencils.
The machine is designed to be used only in the field of application listed in
the Technical Information section of the order confirmation or in this manual.
Any changes to the operating conditions shall necessitate a new contractual
agreement.
The machine shall be exclusively used in such a way as is described in the
order confirmation. Any other or additional operation, including, for example,
processing other products or operating with a mesh on the screen stencil that
is not intended for the process, shall be deemed improper usage.
The manufacturer/vendor shall not be held liable for any damage that results
from this. The risk is borne solely by the user.
The warranty and liability shall be in accordance with the contractual terms
and conditions.
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 7 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
2
Safety
Effective date
30.09.2013
The machine and equipment shall only be operated with correctly installed
safety devices.
We would like to explicitly point out that no safety devices should be re-
moved or disabled while the machine and equipment are in operation.
When maintenance work and cleaning as well as maintenance and repair
services are being performed, the machine and equipment shall be se-
cured in such a way as to preclude unauthorized or inadvertent switching
on of the machine and equipment.
When the maintenance and repair work as well as service work for over-
hauling and carrying out repairs are complete, all safety systems shall be
fully reinstalled and made operative again. An expert should check the
systems to make sure they function correctly.
When a member of staff recognises that there exists the immediate risk of
danger to people at the machine and equipment
, the EMERGENCY
STOP device on the machine and equipment must be activated immedi-
ately.
In such cases of damage that would cause an immediate shutdown of the
machine and equipment, an EMERGENCY STOP device on the machine
and equipment can also be activated or automatically triggered.
The EMERGENCY STOP device should never be used to shut down the
machine and equipment under normal working conditions.
Special attention must be given to mounting and removing screen frames
and screens on the machine and equipment as it has to be carried out
carefully.
If work is carried out in an inattentive or careless manner, there exists the
hazard of limbs, items of clothing and objects being crushed, impacted
and sheared, which is due to moving parts. Therefore, particular attention
needs to be paid to the following points:
•Do not reach into the open gaps between the screen frame and bridge
•Extreme caution is needed when the bridge is in motion
•Apart from exceptional cases, screen frames are only to be inserted when
the machine and equipment are not in operation
•Tight fitting safety clothing and gloves should be worn
•Please exercise caution with lighting units and motors as they can be-
come very hot! Do not touch the lighting units and motors with exposed
limbs. Depending on the temperature of the lighting units, being in close
proximity to the lighting units can lead to burns
•Do not change the specific purpose of the machine
•During the manufacture of this product, the safety devices were specially
designed to work with this machine
•Please consult CST GmbH if you intend to change the intended use of the
machine
•Please make sure that the operators are familiar with the operation of the
machine and equipment
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 8 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
2
Safety
Effective date
30.09.2013
2.2 General information for operators and personnel
Prior to commencing work, the personnel designated to use
the machine
must be instructed on the hazards relating to their work and the measures
used to prevent such hazards. Such instructions shall be derived from this
instruction manual.
The instruction manual and the applicable regulations should be stored in
such a way that they are accessible to operators and maintenance staff.
Disregarding the safety instructions can adversely affect the safety of both
the personnel and the environment as well as the machines. Disregarding
the safety instructions can also lead to the forfeiture of all claims against war-
ranty.
In detail, disregarding the safety instructions could result in the following
hazards:
• Failure of important functions of the machine
• Failure of specified procedures of maintenance and repair
• Exposure of people to electrical, mechanical, physical and chemical
hazards
2.2.1 Obligation of the personnel
All work on/with the machine shall be carried out only by personnel who, by
virtue of their training and qualifications, are authorised to do so.
Responsibilities, competence and supervision of the personnel
must be
clearly defined by the operator.
Task
Qualification
Connection and installation operations Trained personnel
Qualified personnel from the
manufacturer
Repair, maintenance, inspection
Loading, supervision Trained personnel
Electrical work Qualified electrician
2.2.2 Operator’s duties
The operator is obliged to operate the machine only in perfect working condi-
tion.
The operating personnel must be assigned by the operator to operate the ma-
chine.
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 9 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
2
Safety
Effective date
30.09.2013
In particular, the operator’s area of responsibility includes:
• Assigning trained and instructed personnel,
• Defining the responsibilities for operation, set up, maintenance, and re-
pairs,
• Making regular checks on
the operating personnel in regard to potential
hazards and making sure they work in a risk-aware manner in accordance
with this instructions manual
The operator is to safeguard against any possible danger zones which may
arise between this machine and any upstream or downstream devices that
have been provided by the customer.
If the Digital Light Engraver is to be integrated into an
interlinked machine
line/machine, the provisions of the European Directives with regard to the
major modifications made to the machine have to be observed, if applicable.
The operator is legally obliged (irrespective of the operational state or as-
delivered state of the machine) to assess the hazards that may arise out of
the employees work and to determine any occupational safety measures that
may be required.
The operator is responsible for the observance of the relevant regulations.
2.2.3 Important rules of conduct
Danger
Increased risk of accidents as a result of moving masses!
The movement of masses can lead to serious/fatal injuries.
•People who operate power-driven machinery must make sure that they do
not endanger themselves or others through hazardous motions
•Access to the interior of the machine housing is only permitted when the
machine has been switched off and measures have been taken to prevent
it from being inadvertently switched back on
•Long hair, loose clothing, jewellery or the like can be drawn into moving
parts. This can lead to serious injury.
•Wear tight-fitting clothing. Long hair can be protected by wearing a hair
net. Remove jewellery.
•It is not permitted to climb on the machine while it is in operation.
Danger
Increased risk of accidents as a result of partly intense/high levels of
ultraviolet radiation!
When monitoring/checking the ultraviolet light, there is always the risk of se-
rious eye injuries and even permanent eye damage.
Wear appropriate protective equipment in the form of safety glasses that are
suitable for the particular light source.
•Never look directly at the ultraviolet beam or the image of the pattern on
the screen to be imaged without personal protective equipment (safety
glasses).
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 10 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
2
Safety
Effective date
30.09.2013
For the protection of the operators, warning and danger signs are placed on
the machine. Please observe these signs and act with extreme caution.
Additionally placed instructions must be strictly observed.
If warning and danger signs are damaged or illegible, they shall be replaced
immediately!
In addition to the instructions given in this manual, existing national accident
prevention rules as well as generally applicable legal and other mandatory
regulations relevant to accident prevention and environmental protection
must be observed!
Danger
Injuries and fatal accidents can occur as a result of hazardous voltage!
If there is a fault with electrical components or cables, the direct or indirect
contact with live parts could result in serious or fatal injury by electric shock.
•Replace faulty electrical cables and components immediately.
•Do not touch any components or cables that may be electrically live.
Warning
Adverse health effects due to the coolant used in machine!
The coolant contains 1.2-Ethanediol. The following precautions are recom-
mended by the manufacturer/supplier of the heat transfer concentrate:
•R22: Harmful if swallowed.
•S2: Keep out of the reach of children.
•S24/25: Avoid contact with skin! In case of contact with skin, rinse imme-
diately with plenty of water.
•S46: If swallowed, seek medical advice immediately and show the con-
tainer or label.
•Not a hazardous material in compliance with GGVS
(ordinance on the
transport of dangerous goods by road) and GGVE
(ordinance on the
transport of dangerous goods by rail)
•Processing instructions of the manufacturer/vendor must be observed
Before working on electrical equipment, the entire machine must be discon-
nected from the mains. This is achieved by switching off the main switch and,
if necessary, isolating it from the power supply (disconnect the power supply
plug).
Work on electrical installations shall only be undertaken by qualified electri-
cians and in accordance with the applicable rules of electrical engineering.
Fuses may not be repaired or bypassed. Only u
se fuses specified by the
manufacturer.
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 11 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
2
Safety
Effective date
30.09.2013
2.3 Protective equipment
Danger
Injuries and fatal accidents can occur as a result of missing protective
equipment!
If protective equipment is missing, damaged and/or modified there exists the
risk of injuries and fatal accidents.
•The machine and equipment may only be operated when all protective
equipment is in place and full working order.
•Do not remove or modify any protective equipment.
Operators and users are responsible for operating the machine in the correct
manner!
Danger zones that cannot be eliminated by constructional measures are fit-
ted with protective equipment and, where appropriate, the machine is marked
with warning signs; moreover, relevant information relating to safe working
practice is specified in the instruction manual.
No alterations, additions or modifications that could affect safety are to be
made to the machine.
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 12 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
2
Safety
Effective date
30.09.2013
2.3.1 Existing protective equipment
The machine is equipped with the following safety devices:
•The lockable main switch is located on the main control panel (01).
•An EMERGENCY STOP button (02) is located on the vertical protective
cover (03) of the traversing head unit.
•A protective cover (03) covers the traversing head unit.
•Warning and information signs (04) indicate possible danger zones.
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 13 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
2
Safety
Effective date
30.09.2013
2.3.2 Inspection of the protective devices
Planning, execution and documentation pertaining to the inspection shall be
carried out by the operator and shall take into consideration the applicable
laws and regulations. The following information specifies some of the criteria
and proposals.
Main Power Switch and EMERGENCY STOP button
Intervals
When the machine is switched on as well as every 4 years
in the scope of the electrical test in accordance with the reg-
ulations of the Employer's
Liability Insurance Association
[BGV A3]
Scope
Functionality
Inspector
Operating personnel
Action to be
taken when
faults occur
• Do not switch on the machine
• Disconnect from the mains supply
• Arrange for qualified electrician to carry out maintenance
Protective cover
Intervals
When the machine is switched and before it is opened
Scope
Functionality (the machine must switch off when the protec-
tive cover is opened.)
Inspector
Operating personnel
Action to be
taken when
faults occur
• Do not switch on the machine
• Disconnect from the mains
• Arrange for qualified electrician to carry out maintenance
Protective guard (cover)
Intervals
During the commissioning and when the machine is
switched on
Scope
Visual inspection of the physical integrity
Inspector
Operating personnel
Action to be
taken when
faults occur
• Close off the danger zone
• Carry out repairs
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 14 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
2
Safety
Effective date
30.09.2013
2.4 Emissions (noise levels/sounds)
Sound emissions are inevitable with machines and equipment in operation.
These emissions are within the stipulated limits.
However, the on-site sound pressure level can vary. This depends upon the
operating conditions, such as the number of machines and equipment in the
room, external noise, and the design of the production area.
If this is the case, the operator of the machine or system must provide ap-
propriate protection for the operating personnel. The noise protection devices
must not be removed from the machine or equipment.
All personnel who work on the machine or equipment must wear the speci-
fied personal hearing protection.
Advice for when to wear personal hearing protection:
•Up to 70 dB (A):
In this case, no special measures are required
. People’s sensitivity to
noise varies. Therefore, people who feel that they are bothered or even
harmed by such noise should wear hearing protection
•From 80 dB (A):
People constantly working in this particular area should wear hearing pro-
tection
•From 85 dB (A): Hazardous noise area
Such areas must be marked with warning signs. People working in these
areas must wear hearing protection
2.5 Fire protection
The local fire protection regulations are to be observed.
Avoid naked flames, extreme heat and sparks when using cleaning agents,
flammable or deformable parts in the vicinity of the machine. Failure to com-
ply could result in a fire; this may result in harmful gases or damage to the
insulation.
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 15 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
2
Safety
Effective date
30.09.2013
2.6 Pneumatics
Any work to be carried out on the pneumatic systems of the machine or
equipment shall only be undertaken by a pneumatic system specialist.
Prior to working on pneumatic equipment, the moving parts of the pneumatic
system are to be placed in their home or park position.
Depressurise the
pneumatic system before performing any work on it.
Caution is needed when looking for leaks in pneumatic lines that are under
pressure. Pressurized air can penetrate clothing and skin, which can result in
injury or severe infections.
Caution is needed when loosening or replacing pneumatic lines; incorrectly
connected pneumatic lines can result in operations not functioning correctly.
The movement area of the actuator should not be blocked and access to the
area of movement of the actuator must be sufficiently secured.
2.7 Hydraulics
Any work
to be carried out on the hydraulic systems of the machine or
equipment shall only be undertaken by a hydraulic system specialist.
Prior to working on hydraulic equipment, the moving parts of the pneumatic
system are to be placed in their home or park position. Depressurise the hy-
draulic system before performing any work upon it.
Caution is needed when looking for leaks in hydraulic lines that are under
pressure. Pressurized hydraulic fluid can penetrate clothing and skin, which
can result in injury or severe infections.
Caution is needed when loosening or replacing hydraulic lines; incorrectly
connected hydraulic lines can result in operations not functioning correctly.
The movement area of the actuator should not be blocked and access to the
area of movement of the actuator must be sufficiently secured.
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 16 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
2
Safety
Effective date
30.09.2013
2.8 Electrical
Before the machine and equipment is commissioned, all connections and
connected loads must be checked. The values that are measured must cor-
respond to those specified on the electrical circuit diagram.
When the main switch is turned off the machine and equipment are isolated.
Nevertheless, inside the cabinets there could still be voltage-carrying parts,
such as power supplies for the interior lighting and service electrical sockets,
and these need to be switched off separately.
Before any work can be started on the electrical equipment, the machine or
equipment have to be checked if the power is switched off, and, if necessary,
earthed and short circuited. Suitable insulated tools, safety equipment and
personal protective equipment must be used and tested every time before
being used.
Before disconnecting and connecting any electrical plug connections, make
sure they are isolated (this is with the exception of network connections, as
long as they have non-hazardous voltages which satisfy the safety regula-
tions).
Electrical parts (such as motors), which have been stored for a long time,
should not be used until they have undergone prior isolation tests.
When electrical equipment parts or components have become wet, some
parts, which would normally be voltage free in a dry condition, could be live.
Before touching a component that has become damp or wet, please check,
by means of a measurement, if exposed components have a voltage.
Faulty fuses must not be repaired or bypassed and are to be replaced by a
fuse of the same type.
2.9 Spare parts
You should only use genuine parts that are specified by us.
When you don’t use original components, or spare
parts that were neither
supplied by us nor were tested and approved by us, they could impair the
safety.
We will not be held liable for damage that is caused by such items.
For the erection, installation, integration as well as services for maintenance
and repair work, or alterations to machinery and equipment, our experienced
service technicians are available.
All details about contacting CST GmbH can be found on the cover of the op-
erator handbook.
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 17 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
2
Safety
Effective date
30.09.2013
2.10 Personal protective equipment
The type and extent of personal protective equipment required shall be de-
fined by the operator in the scope of the risk assessment (see 2.2). The fol-
lowing information specifies some of the criteria and proposals.
Head
Not required in normal operation. Adjust appropriately to surroundings.
The minimum protection required are industrial hard hats conforming to DIN
en 812 which is recommended for maintenance work (refer to Occupational
Health and Safety Regulations of the Trade A
ssociations regulation 193
[BGR 193])
Eyes
For exposure to hazardous
ultraviolet (UV) radiation: tight fitting protective
safety glasses with side protection (refer to Occupational Health and Safety
Regulations of the Trade Associations regulation 192 [BGR 192])
Body
Not required in normal operation. Adjust appropriately to surroundings.
Ears
Not required. Adjust appropriately to surroundings.
Hands
When there is the danger of a hot surface:
suitable protective gloves (e.g.
protective gloves in respect of mechanical hazards, in accordance with EN
388, category 1, also refer to Occupational Health and Safety Regulations of
the Trade Associations regulation 195 [BGR 195]).
Feet
Protective shoes classified S1 or P1 or professional shoes classified P1 are
required.
For maintenance work: safety boots
Please observe the hygiene rules when using personal protective equipment
and work clothes!
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 18 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
2
Safety
Effective date
30.09.2013
2.11 EC DECLARATION OF CONFORMITY
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 19 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx

INSTRUCTION MANUAL Digital Light Engraver
3
Transportation, storage, installation, electrical
connection
Effective date
30.09.2013
3. Transportation, storage, installation, electrical connec-
tion
3.1 Special safety instructions
Danger
Serious or even fatal injury can occur during transportation, storage,
installation and electrical connection!
Disregarding the safety instructions can lead to injuries and fatal accidents.
•Please observe the safety information given in the chapter entitled
"Safety" as well as the appropriate on-site applicable safety and accident
prevention regulations.
•All lifting and transportation work should be undertaken by qualified and
trained personnel and those who have been assigned to do such work.
•When permitted only use appropriate safety equipment, such as secure
ladders, lifting truck or the like to secure the means of transport (such as
transport crates).
•Do not climb on the means of
transport, unless it has been expressly
permitted.
Danger
Injuries and fatal accidents can occur as a result of the improper han-
dling of loads!
The improper handling of loads can lead to injuries or fatal accidents as well
as the hazard of damage to the machine and equipment.
•Secure the load before any lifting and transport work is to be undertaken.
•Use cranes, hoists, lifting devices, slings and lifting tackle,
which are in
accordance with the applicable on-
site safety and accident prevention
regulations, and are designed for the weight of the machine and equip-
ment.
•Use cranes, hoists, lifting devices, slings and lifting tackle which are speci-
fied by the manufacturer. Relevant approvals must be submitted (e.g.,
driving permits for cranes).
•All cranes, hoists, lifting devices, slings and lifting tackle must be regularly
checked and keep a record of this in the inspection logbooks.
•Only use the designated lifting points for lifting the load.
•
Wear the appropriate protective equipment (e.g. gloves, safety boots,
hard hat, etc.).
•When undertaking any lifting or transportation work please exercise due
care and attention.
•Check that there are no personnel in the immediate lifting or transporta-
tion area and make sure that the lifting or transportation area is cordoned
off
•Do not reach underneath or between suspended loads.
•Do not walk under suspended loads.
CST GmbH
Königsberger Straße 117
47809 Krefeld - Germany
Page 20 of 69
Betriebsanleitung DLE-AF 01.0 engl.docx
