Installation and operating manual
CTC EcoWater
Model 300, 301, 302
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE

Table of Content
English ................................................3
Français ............................................ 19
Nederlands .......................................35
Svenska ............................................ 51
Deutsch ............................................67
Declaration of conformity ..................83

Installation and operating manual
CTC EcoWater
English
162 500 01-3 2015-11-04

4CTC EcoWater
Table of Content
1. Technical data _______________________________________________________ 6
1.1 Technical data____________________________________________________6
1.2 Construction______________________________________________________7
1.3 Control panel_____________________________________________________8
1.4 Heat pump principle___________________________________________8
2. Installation______________________________________________________________ 9
2.1 Air ducts ___________________________________________________________9
2.2 Domestic hot water__________________________________________10
2.3 Circulation connection ______________________________________10
2.4 Insulating the connections_________________________________10
2.5 Connection example for boiler/solar ___________________10
2.6 System installation ___________________________________________ 11
2.7 Supplementary heating_____________________________________ 12
2.8 Hot water production________________________________________12
2.9 Heating coil _____________________________________________________12
2.10 Fan control______________________________________________________12
2.11 Electrical installation _________________________________________13
2.12 Wiring diagram ________________________________________________ 13
3. Control System____________________________________________________ 14
3.1 Main menu ______________________________________________________14
3.4 Service menu - Only for the installer ___________________ 15
3.2 Anode_____________________________________________________________ 15
3.3 Legionella________________________________________________________15
4. Alarm handling ____________________________________________________ 16
5. Maintenance ________________________________________________________ 17
5.1 Replacing the anode ________________________________________17
5.2 Maintenance of the evaporator __________________________17
6. Troubleshooting___________________________________________________ 18
7. Declaration of Conformity __________________________________ 83

5CTC EcoWater
English
Congratulations
Congratulations on the purchase of your new CTC
domestic hot water heat pump. You will with no doubt
be pleased with this quality product.To ensure the
best performance and safety from this product, we
recommend you to read the instructions carefully. These
instructions contain the information you need to install
and use your new heat pump.
The heat pump normally covers a family’s need for hot
water throughout the year. CTC EcoWater is equipped
with a built in coil for additional heat from an external
boiler, solar panels, etc.
Information for the installer
This manual should be read carefully before installation.
It contains all information needed for the installation.
Consider standards and local regulations regarding
water installation before taking the product into use.
Special consideration must be taken to water qualities
with larger amounts of for example; limestone, ochre
and dirt particles.
Before the first start check that the system is filled
with water and has been vented. Confirm that all
connections are screwed tight.
At the first start, or when the tank has been emptied,
there must be an operating time of 8 to 10 hours at an
air temperature of 15 °C to reach a water temperature
of 45-55 °C.
Basic heating principle
The heat pump operates on the air to water principal;
i.e. the air is drawn through an evaporator and cooled.
In the compressor the thermal energy of the air is
transformed to a higher temperature and through a heat
exchanger transferred to the water in the boiler.
For your own reference
Fill in the information below. It may be useful if anything should happen
Product Manufacturing No.
Date of installation Telephone No.
Installer
With reservation for typing errors. Subject to alterations in design.

6CTC EcoWater
English
1. Technical data
CTC EcoWater 300 301 302
Dimensions H x D 1921 x Ø707 mm
Weight with/without packaging 130/114 kg 153/137 kg 175/159 kg
Voltage/frequency 230 V, 1N~ / 50 Hz
Operational current, heat pump*2.6 A
Power, input heat pump*600 Watt
Immersion heater 2000 Watt/230 V
Power input total*2600 Watt/230 V
Minimum group fuse 13 A
Thermostat for supplementary heating Set at 65 °C, controlled via the display
Refrigerant 840 g R134a
Nominal air flow Min/Max. 200/300 m3/h
Air temperature Min. -10 °C to max. +35 °C
Heating power*1850 W
COP 2,5*/4**
Storage volume (Enameled) 270 l 258 l 242 l
Maximum operating pressure Max.10 bar
Anode Magnesium - 1¼" RT
Water temperature Adjustable - max. 55 °C
Water capacity** 800 l / 24h
Thermal losses*** 0.7 kWh/24h
Heat exchanger, heat surface (upper/lower) -1 m20,6+1,5 m2
Water connections:
Cold water 1" RT
Hot water 1" RT
Condensation water 1/2" RT
Heat exchangers - 1" RT 1" RT
DHW circulation 3/4" RT
* Air temperature of +7 °C Water heating 52,5 °C according to EN 16147:2011.
** Air temperature of +15 °C Water heating 45 °C
*** 15 °C air temperature and 55 °C water temperature - measured according to DIN 8947
1.1 Technical data
This appliance is not intended for use by persons ( including children ) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
Safety instructions

7CTC EcoWater
English
1.2 Construction
1. Air outlet Ø160mm
2. Evaporator
3. Compressor
4. Air inlet Ø 160mm 1)
5. Enameled storage
6. Pocket for sensor - thermometer
7. Automatic sacrificial anode
8. Supplementary heating
9. Pocket for sensor
10. Anode
11. Adjustable feet
12. Cold water inlet
13. Safety condenser
14. Insulation
15. Heating coil lower (301/302)
16. Heating coil – inlet lower
(301/302)
17. Heating coil – outlet lower
(301/302)
18. Circulation connection
19. Hot water outlet
20. Defrost water outlet
21. Fan
22. Heating coil upper (302)
23. Heating coil outlet upper (302)
24. Heating coil inlet upper (302)
1 4

8CTC EcoWater
English
25
26
24
23
Water
45 ˚C
1
M
3
2
4
8
6
5
7
9
HP
1. Fan
2. Evaporator
3. Expansion valve
4. Heat exchanger
5. Compressor
6. High pressure switch
7. Condenser
8. Dry filter
9. Solenoid valve
1.3 Control panel
23. Control button (push/rotation)
24. Control panel (display)
25. Operating-/alarm lamp heat pump
26. Operating-/alarm lamp additional heating
Upper line displays the actual function (menu). The lower line displays the
status or a value. There are 12 menus in the main menu. They are activated
by turning the control button (23). To change in the status or change a value,
push the control button and the value starts flashing. Turn the button until
the desired value appears and then press the button to accept.
If the control button is pressed for more than 3 seconds a service menu will
appear. This is where all settings are displayed. Any changes in the service
menu shall be made by or in consultation with the installer.
1.4 Heat pump principle
The picture below describes the heat pump principle.

9CTC EcoWater
English
2. Installation
The heat pump is delivered complete and preset from factory (electrical
connection may be adjusted to fit local standards). The heat pump should
be installed as close as possible to the existing hot water conduit to minimize
the energy losses.
The place of installation must be in level. Small irregularities can be adjusted
by the feet. When filled the heat pump weighs approx. 465 kg. The place for
the installation must stand a corresponding load.
NOTE: Complementary rules in the building regulations must be observed.
2.1 Air ducts
The air can be taken from the room where the heat pump is placed, or
from another room, or from outside. In these cases the heat pump can be
equipped with duct connections, both at the air inlet and the air outlet. The
air pipe must be insulated to avoid condensation. The air inlet (2) and the air
outlet (1) are located at the top of the heat pump. No connections for the air
are needed if air from the room where the heat pump is placed will be used.
The duct connections are intended for ø160 mm ducts.
If ducts are used pressure losses has to be considered. Fan speed has
to be set on high speed (for fan settings see chapter 4 - control system).
If ø160 mm ducts are used the maximum length is approximately 3 meter
(2 x 90°-bends included). If longer ducts are needed a ø200 mm duct
can be used to reach distances up to 7 meters (2 x 90°-bends included).
If more bends are needed the maximum distance has to be reduced by
approximately 500 mm per 90°-bend.
1. Air outlet
2. Air inlet
3. Outside air - air inlet
4. Indoor air - air inlet

10 CTC EcoWater
English
2.2 Domestic hot water
When connecting the hot water please consider the piping material and
water quality to avoid problems with corrosion.
Pipes of Galvanized Steel
One of the major causes of damage to the water system is internal corrosion
of hot water pipes in galvanized steel systems. Normally fittings are most
vulnerable to internal corrosion. Dissolved copper in the water from copper
pipes in the system, increases the risk of corrosion. Considering the rule that
copper should follow galvanized steel in the water flow direction will reduce
the risk. In some installations reflux can occur and thus increasing the risk of
corrosion due to higher copper content in the water.
Pipes of Copper
Copper is usually fully resistant to corrosion in water, but as all other
materials, it has its limitations. Internal corrosion of copper due to turbulence
corrosion is a frequent cause of damages. This applies particularly in bends.
Turbulence corrosion occurs when the speed of the water is between 1,2 to
1,5 m/s and the quality of the water is adverse.
2.3 Circulation connection
Circulation of hot water will increase energy losses and installed piping and
connections must be well insulated. Circulating pump must not be too large,
use any variable pump type or a flow control valve.
2.4 Insulating the connections
All pipes must be insulated to prevent heat loss. If the heating coil is not
used it must be blinded and insulated.
2.5 Connection example for boiler/
solar
Heat pump status: “HP+Boil”.
When the temperature is below Tmin -1 °C the supplementary heating starts.
The supplementary heating stops when the temperature is above Tmin +1°C
Tmin 35 °C ensures 35 °C domestic water, even if the heat pump cannot
provide enough energy.
Connecting to relay exits:
CN2-5 Phase and CN2-6 Null.
Supplementary heating Boiler (230 V AC, 10 amps).
Cold water
pipe:
Hot water
pipe:
Copper pipe Copper pipe
Steel pipe Steel or copper
Plastic pipe Steel or copper
Recommended pipe configurations

11CTC EcoWater
English
Thermostatic mixing valve
Cold water
inlet
Hot water
outlet
Hot water tank
2.6 System installation
Installations of water should be carried out in accordance with the present
standards concerning installation of water. In accordance with the present !Never start the
heat pump unless it
is filled with water.
rules the coldwater connection should be provided with a drain valve, a
safety valve and an adjustable retaining valve. The valves are not standard
equipment.
Safety valve, check valve, drain
The heat pump installation must be equipped with a double check valve
and safety valve on the cold water supply line. This is to ensure that hot
water from the tank is not leaking into the cold water system and to release
pressure when the tank is heated. From the evaporator in the heat pump
there will be condensation water. The amount is depending on air humidity.
The safety valve and the condensation connection should be connected to a
drain to avoid leakage. For the specification of pipe connections - please see
the dimensional sketch ”Technical data”.
To maintain your cylinder for safety there is a requirement to check the
pressure relief valve 2-3 times yearly. To do this, the valve needs to be
turned clock wise half a turn until the valve clicks and closes. It is normal for
water to be released when this action is carried out” If water continues to
release after this test has been carried out the valve is faulty and requires
replacement.
To avoid injuries (scalding) from high water temperatures it is recommended
to install a thermostatic mixing valve on the hot water outlet. At normal
operation the temperature will not reach levels where scalding is a risk. If a
failure occurs during normal heating temperatures up to 70 °C is possible
before the safety thermostat will stop the immersion heater, otherwise the
immersion heater cuts out at 80 °C. If the safety thermostat cuts, it has to be
reset manually.
In order to avoid noise in the piping system it is recommended to use
approved couplings when connecting the heat pump. The heat pump can be
installed both stand alone and as a part of an existing system. When the tank
is filled during the startup it is necessary to bleed in order to get it filled.
The time needed to raise the water temperature from 10 °C to 45-55 °C is
between 8 and 10 hours at an ambient temperature of 15 °C.
Note:
model 300: without coil(s)
model 301: upper coil (heating circuit)
model 302: upper coil (heating
circuit)+lower coil (solar)
1. Boiler
2. Heating circuit
3. CTC EcoWater
4. Thermal solar panel
5. Water inlet
6. Water outlet






12 CTC EcoWater
English
2.7 Supplementary heating
If the performance of the heat pump is not sufficient due to high hot water
use or low ambient temperatures supplementary heating can be used. An
immersion heater is integrated in the product and can be activated in the
control system by choosing HP+EL in the menu "Heat pump". Also external
boilers or solar can be connected to the product (model 301 and 302) via
the internal coil. For this alternative HP+Boil is set in the menu. For electrical
connections and relay outputs see the wiring diagram. The immersion heater
has a built is operational and safety thermostat set at 75/85 °C. With an
external boiler or solar consider the maximum allowed temperature of 75 °C.
When activated, the control system will start the supplementary heating when
the water temperature is 1 degree below Tmin or lower and close it when the
temperature is 1 degree above Tmin.
2.8 Hot water production
Heating of domestic water can be made using the heat pump, immersion
heater and/or boiler/solar. Immersion heater, boiler and solar are described as
supplementary heating. Energy sources are selected in the control system.
They can be selected individually or together (boiler and immersion heater
cannot be chosen at the same time).
Temperature setting range: from 5 °C to Tmax °C. Tmin and Setpoint can be set
independently. A normal setting would be Tmin = 35 °C and setpoint 45 °C to 55
°C. Setpoint is achieved with the heat pump if allowed. If no heat pump is
selected it is achieved with the supplementary heating. Tmin is achieved with
heat pump and supplementary heating, if selected.
The heat pump runs with a hysteresis of (+)1 – (-)3 K for the setpoint. The
supplementary heating runs with a hysteresis of (±) 1 K. The heat pump stops
when the evaporator temperature gets too low. The temperature limit for defrost
is -18 °C.
Chosen operating settings are indicated by lamps in the front panel (25, 26).
The upper (25) is for the heat pump and the lower (26) is for supplementary
heating.
2.9 Heating coil
CTC EcoWater (model 301) is equipped with a heating coil with 1 m2heat
surface. When using the coil, thermostats must always be mounted on the
primary flow and the storage to ensure the correct temperature. To ensure
the water capacity the storage temperature must always have the 1st priority.
Additional heat may not exceed 65 °C, higher temperatures can damage the
heat pump circuit.
2.10 Fan control
The fan has 2 speeds which can be adjusted in the menu “FanOper”. Normally,
the highest speed should be used (Option 2 in the menu “FanOper” is the high
speed). The noise level can be reduced by decreasing the fan speed. Lower
speed setting can be selected with minor influence of the heat pump efficiency.
With air duct connections the highest speed always must be used. The fan
can, in the ”FanCon” always be connected so that a constant ventilation can
be made. The fan will in the setup 0 be disconnected with heat pump. In
setup 1 it runs on low speed and in setup 2 it runs high-speed with heat pump
disconnected.
Off: Inactive.
Orange: Activated but in standby
mode.
Green: Activated.

13CTC EcoWater
English
S1 Control panel
N3 Thermostat Heating element
C1A Operation capacitor fan
C1B Operation capacitor
Compressor
C2 Capacitor fan speed
C4 Motor protector
E1 Heating element
F1 High pressure switch
F2 Thermostatic max switch
M1 Compressor
M2 Fan
MV1 Solenoid valve
K1 Start relay compressor
X X1 / X2 = Earth
SA Automatic sacrificial anode
"FanPause" is a function for preventing the overflow of condensation water
if the heat pump is placed in a room with high air humidity. When activated,
the fan will stop either for 15 or 30 seconds per hour unless the heat pump
has reached its set point and the compressor and fan stops automatically.
If "FanCon" is activated, then the "FanPause" function still works. When the
set point has decreased enough, the compressor and fan start again and
the "FanPause" function is automatically activated from the moment the
compressor and fan start. If "FanPause" is set to "Off", then the function is
deactivated.
2.11 Electrical installation
The heat pump is to be used on 230V, 1N~ (single phase). The product is
equipped with a 2 m power supply cord, 3 x 1.5 mm2and a European socket.
The power supply shall be connected to a socket with a security breaker. For
details regarding electrical specification see chapter “Technical data”.
2.12 Wiring diagram
1. Orange
2. Red
3. Yellow/
Green
4. Blue
5. Brown
6. Black
7. Grey
8. White

14 CTC EcoWater
English
3. Control System
3.1 Main menu
Language
English
At the first start language has to be selected. Factory setting is ENGLISH. Available languages
are: Danish, Swedish, German, English, Spanish, Portug., Dutch, French, Polish. Language can
be reset/changed later by entering the installers menu (service menu).
Water
45 °C
Water temperature.
Presents current water temperature.
Evapor
5 °C
Evaporator temperature.
Shows the current evaporator temperature
Alarm
0 0 0
Alarm display. Up to 3 alarms are shown. ”0” = no alarm. For details regarding different alarms
see chapter "Alarm handling". Alarms can be reset by pressing the control button.
Status
Off
The current operating condition of the heat pump.
”off” = switched off
”Standby” = Standby
”H.Water ” = Operating
”Legionel” = 65 °C heating is ongoing
”Def.Gas”/”Def.Air”/”Def.Stop” = Defrosting
Setpoint
45 °C
Desired water temperature.
The temperature can be changed by pressing the control button (the temperature starts flashing).
Desired water temperature can then be adjusted by turning the button. Another press on the
button will confirm the new setpoint.
A normal operating temperature is between 45 °C and 55 °C.
T min
35 °C
Minimum temperature.
Lowest allowed temperature (normally about 35°C). If the water temperature is lower than ”T min”
supplementary heating will be activated until Tmin is reached. The temperature can be changed
by pressing the control button (the temperature starts flashing). Desired settings can then be
adjusted by turning the button. Another press on the button will confirm the new setpoint.
T 2 min
10 °C
Similar function to Tmin, used as “holiday function” or when the DHW HP is in “standby” mode.
T2 min protects the DHW HP and your installation against freezing. The default setting is “10°C”.
Heat
pump
HP+EL
Energy sources. The following options are available:
”OUT” = standby
”HP” = Only heat pump is allowed
”EL” = Only immersion heater is allowed
”HP+EL” = Heat pump and immersion heater in combination
”BOILER” = Only boiler is available
”HP+BOIL” = Heat pump and boiler is allowed
If no boiler is installed, the last 2 combinations can not be used.
Legionel
Off
Legionella setting. If switched (”ON”) the heat pump will once weekly increase the temperature to
65 °C, in order to prevent legionella.
FanCon
Off
Displays the fan operating mode. When set to "Off", the fan will stop together with the heat
pump. The "Low" setting is for low speed and the "High" setting is for high speed. This also
means that there is constant ventilation.
FanOper
High
Fan speed, when the heat pump is operating. ”Low” = low speed ”High” = high speed
Solarcell
Off
This function allows you to operate the DHW HP using cheap and environmentally -friendly
energy from your own solar cell panels.
"Off" = Solar cells are not connected to the system or have not been chosen to be used by the
user.
"HP only" , “EL only” and “HP + EL”: These values indicate the chosen operation mode, when
the solar cell function is activated by the external inverter signal. See the wiring diagram for the
connection to the controller.
SC-HP
52 °C
Set point temperature of “HP only” operating mode, when the solar cell function is activated
(inverter signal).
SC-EL
53 °C
Set point temperature of “EL only” and “HP + EL” operating mode, when the solar cell function is
activated (inverter signal).
Holiday
Off
This parameter activates/deactivates the holiday mode. The holiday mode can be selected with
the rotary/push button. The possible selections are:
“Off”, “1 week”, “ 2 weeks”, “3 weeks”, “3 days”, “Manual”
When the holiday mode is activated, “T2 min” is the safety level for frost protection.

15CTC EcoWater
English
Man.days
1
This parameter displays the number of holiday days. The holiday days can be selected with the
rotary/push button. The possible selections are between: 1-99.
ReDays
0
This parameter displays the status of the remaining number of holiday days.
The possible values are 0-99
Boost
Off
This parameter activates/deactivates the BOOST operating mode in the case of additional need
for DHW. If the BOOST operating mode is activated, “ON”, the DHW production will be made by
the HP and the supplementary electrical heating will either be for a maximum cycle of 1 hour or
up until T max is reached. Possible values are “Off”, “On”. The default setting is “OFF”.
Fan Pause
Off
When activated, the fan will stop for either 15 or 30 seconds every full operating hour, according
to the selected value.
Language
English
Danish, Swedish, German, English, Spanish, Portug., Dutch, French, Polish.
Software
1.31
The menu presents actual software version.
Defrost
Def.Gas
Shows defrosting method: ”GAS” (standard).
Anode
Off
"Off", "On"
Activated if signal anode is installed.
T max
55 °C
”T max” is the highest temperature allowed, set in menu ”SETPOINT”.
Temperature range from 5 °C to 62 °C.
(Please note that the efficiency of the heat pump is reduced at higher temperatures)
3.4 Service menu - Only for the installer
3.2 Anode
The storage tank is corrosion protected internally with enamel. To prevent corrosion in the small defect that can
appear with enameled corrosion protection an automatic sacrificial anode is placed in the storage. The anode menu
will show "Auto", and alarm no. 9 will light up if the anode is worn and has to be replaced.
Defrosting
If the temperature at the evaporator is -2 °C or less, defrosting is activated. The time interval between the defrosting
periods is 2 hours. This means that a defrost sequence is started every 2 hours as long as the evaporator
temperature is below -2 °C. During the defrost sequence the bypass valve opens, the compressor will run and the
fan is switched off. When the evaporator temperature reaches +5 °C, the defrost cycle is stopped and the bypass
valve closes, and the fan starts. If the temperature for the evaporator does not reach +5 °C within 20 minutes, the
defrosting will stop and the normal operation is continued anyway. If the evaporator temperature reaches -18 °C or
less the heat pump will stop. The supplementary heating source (if activated) will be used.
3.3 Legionella
The legionella function can be activated in the control system. If the function is activated the sequence will start
immediately. After 7 days (168 hours) a new legionella sequence will start. During the legionella sequence the water
temperature is raised to 65 °C using the heat pump and the additional heating source. This temperature is held for
1hour before switching back to normal mode. If the temperature is not reached in 12 hours the function will timeout.
An alarm will be presented in the display. The alarm will be reset as soon as a successful sequence is made (or if the
alarm is confirmed by user). Reasons for a timeout; too low air temperature and/or water use is higher than the power
input and/or supplementary heating is blocked.
!For best performance, the Legionella function shall be activated when the
domestic hot water demand is low. for example at 22.00.

16 CTC EcoWater
English
Alarm
Number
Alarm lamps:
No. 25 No.26
Alarm name Comment
1 X X
(red) (red)
Short circuit in the temperature
sensor in the top of the tank.
Complete product is blocked
2 X X
(red) (red)
Temperature sensor in the top of
the tank is switched off.
Complete product is blocked
3 X
(red)
Short circuit in the temperature
sensor for the evaporator.
Compressor stops
4 X
(red)
Temperature sensor for the
evaporator is switched off.
Compressor stops
5 X
(red)
First pressure switch alarm Compressor stops and starts again
automatically.
6 X
(red)
Second pressure switch alarm Compressor stops and actions are needed
before alarm confirmation and restart.
7 X
(red)
N/A N/A
8 X
(red)
Short circuit in temperature sensor
”Temp 1”.
Sensor for external boiler or outdoor
temperature. Information alarm.
9 X
(red)
Automatic sacrificial anode Change anode. Information alarm.
10 X
(red)
Legionella temperature not reached Information alarm.
4. Alarm handling
There are three different alarm levels; information
alarms, heat pump circuit alarm and system alarm.
Three different alarms can be stored at the same time.
Each alarm must be reset by pressing the control button
at the control panel.
The information alarms do not stop the heat pump, but
informs the user that there is a disturbance that has to
be solved as soon as possible (Alarm no: 8, 9 and 10).
The heat pump circuit alarms stop the hot water
production with the compressor and switches to
100 % supplementary heating sources (immersion
heater or external boiler). (Alarm No: 3, 4, 5 and 6).
System alarms blocks the whole product. (Alarm no: 1
and 2).
The alarms are presented in the alarm menu, where
also the alarms are confirmed. Each alarm must be
confirmed before normal operation is possible. If no
action is taken before an alarm is confirmed the alarm
will still be on. In the case several simultaneous alarms,
they are placed in a row. The alarms will be presented in
order of importance.
Pressure switch alarms
Pressure switch alarm (5, 6) will be handled in the
following way;
At the first break, alarm no. 5 will show in the display
and lamp (25) flashes. The heat pump will stop and
automatically restart. If the error is eliminated, the lamp
(25) will switch to flash orange, and after the alarm is
confirmed constant orange or green.
If a second alarm occurs less than 6 hours after the
first alarm, alarm no. 6 will show in the display and the
heat pump will stop. The heat pump can now only be
restarted by confirming the alarm. With alarm no. 6 the
lamp (25) will flash red. When the pressure switch is
controlled and repaired the alarm can be confirmed and
the product restarted.

17CTC EcoWater
English
5. Maintenance
5.1 Replacing the anode
The anode has to be replaced when the alarm no. 9 is presented in the
display. The anode (7) is situated behind the front cover. Before the anode is
replaced the storage has to be emptied. This is made by turning off the cold
water supply and then open the drain valve (on the cold water inlet). At the
same time the hotwater tap has to be turned on to avoid negative pressure
inside the tank.
5.2 Maintenance of the evaporator
Once or twice a year the evaporator should be examined and cleaned
if necessary. To reach the evaporator the air inlet/outlet ducts has to
be removed. If not cleaned the heat pump capacity will decrease. The
evaporator is preferably cleaned with water and a brush. Avoid any water
on electrical parts! The evaporator fins must not be damaged. The intervals
needed for cleaning is depending on the air quality. If the air used for the
heat pump contains a lot of particles, a more frequent cleaning may be
necessary.
Maintenance of the drain
The condensation water outlet must be connected to a drain in accordance
with the present regulations. The defrost/condensed water outlet of the
heat pump must always be kept free from dirt. How frequent this has to
be done depends on the local conditions concerning dirt, humidity and air
temperature. A blocked outlet causes the defrost/condensed water tray to
flood and the fault circuit breaker may cut if electrical parts are exposed to
water.
The warranty does not cover damages caused by lack of maintenance.

18 CTC EcoWater
English
6. Troubleshooting
Information / Failure Action / Cause
There is water on the floor around
the product
Check that the heat pump is standing horizontally
Check the connection of the drain tube
Check if there is any dirt in the drain tube
The compressor does not start even
though the water temperature is
below setpoint
If the compressor recently has been running there is a start delay for 5
minutes
The water is not hot enough Increase the set point to a higher value
Adjust the mixing valve for hot water
The compressor runs constantly but
still there is no hot water
If a lot of hot water has been consumed it can take a long time for the
heat pump to reach the set point
Is the evaporator is blocked by ice or dust? Clean and restart.
If there is a small radiator system connected this might take too much
energy. If so install a thermostat to let hot water production be first
priority.
If there is hot water circulation installed this must be controlled by timer to
make it possible for the heat pump to produce enough hot water.
There might be a leakage in the refrigerant circuit. Contact service.
High pressure alarm (Alarm 5) The air through the evaporator is too low. Clean and reset the alarm.
The temperature in the tank is too high. Change the tank sensor and reset
the alarm
The temperature in to the heat pump is higher than +35 °C
The temperature on the evaporator is
below -19 °C. (Alarm 4)
Wait until the temperature rises to more than -10 °C.
If the alarm repeats contact service.
Manuel d’installation et d’utilisation
CTC EcoWater
Français

Manuel d’installation et d’utilisation
CTC EcoWater
Français

20 CTC EcoWater
Français
Sommaire
Consignes de sécurité_______________________________________________ 22
1. Caractéristiques techniques______________________________ 22
1.1 Caractéristiques techniques ______________________________22
1.2 Fabrication _____________________________________________________23
1.3 Panneau de configuration _________________________________24
1.4 Principe de la pompe à chaleur _________________________24
2. Installation____________________________________________________________ 25
2.1 Gaines d’aération_____________________________________________25
2.2 Eau chaude sanitaire ________________________________________ 26
2.3 Raccordement de bouclage ______________________________26
2.4 Isolation des raccordements _____________________________26
2.5 Exemple de raccordement chaudière / solaire ____26
2.6 Installation du système ____________________________________27
2.7 Chauffage d’appoint_________________________________________28
2.8 Production d’eau chaude sanitaire ____________________28
2.9 Serpentin de chauffage_____________________________________28
2.10 Commande du ventilateur ________________________________28
2.11 Raccordement électrique __________________________________ 29
2.12 Schéma de câblage _________________________________________29
3. Système de régulation________________________________________ 30
3.1 Menu principal _________________________________________________30
3.2 Menu Expert____________________________________________________31
3.3 Anode_____________________________________________________________ 31
3.4 Dégivrage________________________________________________________ 31
3.5 Légionelles ______________________________________________________31
4. Traitement de l’alarme _______________________________________ 32
5. Entretien_______________________________________________________________ 33
5.1 Remplacement de l’anode _______________________________33
5.2 Maintenance de l’évaporateur ___________________________33
6. Dépannage/Diagnostic ______________________________________ 34
Félicitations
Nous vous félicitons pour l’acquisition de votre nouvelle
pompe à chaleur pour eau chaude sanitaire. Nous sommes
certains que vous serez pleinement satisfait de la qualité
de ce produit. Nous vous recommandons de lire
attentivement ces instructions avant de la mettre en service.
Cesinstructions renferment les informations nécessaires
pour installer et utiliser votre nouvelle pompe à chaleur.
La pompe à chaleur couvre normalement les besoins
d’une famille en eau chaude sanitaire tout au long de
l’année. Selon les modèles CTC EcoWater est équipé
d’un serpentin incorporé comme chauffage d’appoint à
partir
d’une chaudière externe, de panneaux solaires, etc.
Information destinée à l’installateur
Il est nécessaire de lire soigneusement ce manuel
avant de procéder à l’installation; il comprend toutes
les informations nécessaires pour l’installation.
Tenez compte des normes et réglementations locales
relatives à l’eau avant de mettre le produit en service.
Il faut particulièrement prendre en compte les qualités
de l’eau dans le cas de teneurs importantes en,
par exemple, calcaire et impuretés.
Avant la première mise en marche, vérifiez que le
système est rempli d’eau et qu'il a été purgé. Assurez-
vous que tous les raccordements sont serrés.
A la première mise en marche, ou lorsque le ballon a été
vidé, il faut de 8 à 10 heures de marche à une température
d'air de 15 °C pour atteindre une température d’eau de
45-55 °C.
Principes de base du chauffage
La pompe à chaleur fonctionne sur le principe air/eau;
c’est-à-dire que l’air est aspiré à travers un évaporateur
et refroidi. L’énergie thermique de l’air est transformée
dans le compresseur à une température supérieure,
puis transférée à l’eau dans la chaudière au moyen
d’un échangeur de chaleur.
Pour votre information
Remplissez la demande d’informations ci-dessous. Ceci peut vous être utile en cas de problème
Produit N° de fabrication
Date d’installation N° de téléphone
Service
Sous réserve de fautes de frappe. Susceptible de modifications dans le concept.
