CTEK BATTERY ANALYZER User manual

CTEK BATTERY
ANALYZER
INNOVATION IN BATTERY TESTING
The CTEK BATTERY ANALYZER tests with high accuracy the condition
of all types of 12V lead-acid batteries including Wet, Maintenance
Free, Ca/Ca, Gel and AGM. Easy to use it provides fast, and easy to
understand results. Operating voltage range is 8–15V with a test range of
200–1 200EN. Simply connect the clamps to the battery and follow the
step by step instructions on the display. The easy to read display gives clear
information on the condition of any 12V lead-acid battery and advises what
action is required. With no need to disconnect the battery from the vehicle,
the patented technology used by the CTEK BATTERY ANALYZER is safe for
the user and vehicle electronics. It is reverse polarity protected, creates no
battery loads, heat or sparks. The CTEK BATTERY ANALYZER features a
2-year warranty.
TECHNICAL DATA
TYPE OF ANALYZER Conductance
TYPE OF BATTERY ANALYZED 12V Lead-Acid
MIN.TESTING VOLTAGE 8V
MAX.TESTING VOLTAGE 15V
RESOLUTION 0.1V
ACCURACY ± 0.1V
RANGE 200–1 200EN
RESOLUTION 25EN
ACCURACY ± 25EN

www.ctek.com
+
+
–
–
TEST
DOWN
UP
BATTERYANALYZER
+
+
–
–
TEST
DOWN
UP
BATTERY ANALYZER
1
2
3
4
CTEK BATTERY
ANALYZER
CTEK BATTERY
ANALYZER
BATTERY TEST RESULTS
Battery good — the battery is in good condition and there is no need
to charge the battery.
Good recharge — the battery is in good condition but charging is
required to restore capacity.
Charge and retest — charge the battery and test again.
The analyzer wants to ensure the battery can retain the charge.
Replace battery — the battery can no longer be relied upon to
provide adequate service and should be replaced immediately.
20018385C 56-600 EN
Easy to use — simply attach to battery (no need to disconnect) and follow
the on screen instructions.
Fast, accurate results — the CTEK BATTERY ANALYZER tests the
battery in seconds providing an instant on screen result which advises what
action should be taken.
Safe – no heat or sparks — the patented technology used by the
CTEK BATTERY ANALYZER not only provides fast, accurate results but
undertakes the test without placing load on the battery and generates no
potentially dangerous heat or sparks.
For all 12V lead-acid batteries — the CTEK BATTERY ANALYZER
works equally well with all lead-acid battery types and requires no
adjustment to perform an accurate test.
GUARANTEED QUALITY WITH CTEK
CTEK customer support is available to answer any questions related to
charging and CTEK chargers. Safety, simplicity and flexibility characte-
rizes all products and solutions developed and sold by CTEK. CTEK
supply chargers to more than 60 countries throughout the world. CTEK is
also a reliable OEM supplier to many of the world’s most prestigious car
and motorcycle manufacturers.
Contact customer support: [email protected]
1. Connect the red clamp to the positive battery terminal.
2. Connect the black clamp to the negative battery terminal.
3. Enter the EN value of the battery to be tested by using the UP or
DOWN button. (Default setting is 500EN).
4. Press the TEST button and the test result is displayed on the easy to
read screen.
EASY TO PERFORM BATTERY
TESTING FROM CTEK
