Ctouch Laser User manual

CAUTION
• Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
• This User Manual includes detailed usage instructions for your product.
Please read this manual thoroughly.
• Figures and illustrations in this User Manual are provided for reference only and
may differ from actual equipment appearance.
Equipment design and specifications may be changed without notice.
User Manual
Laser
ver 3.1
Function
is key

2
Important Safety Instructions
Always comply with the following precautions and usage tips to avoid dangerous situations and
ensure peak performance of your product.
CAUTION CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
RISK OF EXPLOSION IF BATTERY BY
AN INCORRECT TYPE. DISPOSE OF
USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
THERE ARE NO USER SERVICEABLE PARTS
INSIDE. REFER ALL SERVICING TO QUALIFIED
PERSONNEL.
WARNING
This symbol indicates that high voltage is present inside. It is dangerous to
make any kind of contact with any internal part of this product.
CAUTION
This symbol alerts you that important literature concerning operation and
maintenance has been included with this product.
The slots and openings in the cabinet and in the back or bottom are provided for
necessary ventilation. To ensure reliable operation of this apparatus, and to protect it
from overheating, these slots and openings must never be blocked or covered.
Do not cover the slots and openings with a cloth or other materials.
Do not block the slots and openings by placing this apparatus on a bed, sofa, rug or other similar
surface.
Do not place this apparatus in a confined space, such as a bookcase, or built-in cabinet, unless
proper ventilation is provided.
Do not place this apparatus near or over a radiator or heat resistor, or where it is exposed
to direct sunlight.
Do not place heat generating items such as candles, ashtrays, incense, flammable gas or
explosive materials near the product.
Do not place a water containing vessel on this apparatus, as this can result in a risk of fire
or electric shock.
Do not expose this apparatus to rain or place it near water (near a bathtub, washbowl,
kitchen sink, or laundry tub, in a wet basement, or near a swimming pool etc.). If this
apparatus accidentally gets wet, unplug it and contact an authorized dealer immediately.
This apparatus use batteries. In your community there might be regulations that require
you to dispose of these batteries properly under environmental considerations. Please
contact your local authorities for disposal or recycling information.

Important Safety Instructions
3
Do not exceed the standard capacity of a multi-plug or power outlet extension when
using it for the product.
There is a danger of electric shock of fire hazard.
To protect this apparatus from a lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and disconnect the antenna or
cable system. This will prevent damage to the set due to lightning and power line surges.
Never insert anything metallic into the open parts of this apparatus.
Doing so many create a danger of electric shock.
To avoid electric shock, never touch the inside of this apparatus.
Only a qualified technician should open this apparatus.
Do not touch the power cord with wet hands.
There is a danger of electric shock.
Plug the power cord firmly into the power outlet.
Failure to do so may cause fire hazard.
Do not unplug the power cord by pulling the cable only.
If the cord is damaged, it may cause electric shock.
If this apparatus does not operate normally - in particular, if there are any unusual sounds
or smells coming from it - unplug it immediately and contact an authorized dealer or
service center.
Be sure to pull the power plug out of the outlet if the product is to remain unused or if you
are to leave the house for an extended period of time.
Accumulated dust can cause an electric shock, an electric leakage or a fire by causing the power
cord to generate sparks and heat or the insulation to deteriorate.
Be sure to contact an authorized service center, when installing your product in a
location with heavy dust, high or low temperatures, high humidity, chemical substances
and where it operates for 24 hours such as the airport, the train station etc.
Failure to do so may cause serious damage to your product.
Do not allow children to hang onto the product.
Store the accessories (battery, etc.) in a location safely out of the reach of children.
Do not install the product in an unstable location such as a shaky self, a slanted floor or a
location exposed to vibration.
Do not drop or impart any shock to the product. If the product is damaged, disconnect
the power cord and contact a service center.
Make sure to pull out the power cord from the outlet before cleaning the product.

4
Contents
Getting Started ………… 6
Unpacking …………………… 6
Viewing the control panel …… 7
Viewing the connection panel… 8
Viewing the remote control …… 9
Basic Functions ………… 10
Turning on/off your CTOUCH
interactive display ……………10
Using the touch sensor ………10
Adjusting a volume level ………11
Mute function …………………11
Selecting a input mode ………11
Picture Control …………… 12
Adjusting picture mode ……… 12
Setting advanced video ……… 13
Sound Control …………… 14
Adjusting sound mode ………14
Setup Control……………… 15
Using the Setup menu ………15
PC Settings………………… 16
Adjusting the PC screen ………16

Contents
5
Introduction ……………… 19
Gesture …………………… 21
Touch Gesture ………………21
Calibration ………………… 32
Calibration ……………………32
Screen Margin………………… 33
Area Settings ………………… 33
Touch Settings ………………35
Sensor Settings…………… 36
Enable/Disable Touch Screen …36
Buzzer …………………………37
Shortcut Keys ………………… 37
Sensor Diagnostics……………38
General Settings ………… 39
Language………………………39
Tray Icon ………………………39
Touch Input Mode ……………41
Positioning of the Monitor ……42
Troubleshooting ………… 43
Device Not Connected ………43
Firmware Download …………43
This program does not support
vx.xx firmware …………………44
When More than Two CTOUCH
sensors are Connected ………44
Some menus are disabled cannot
be used ……………………… 45
Touch Sensor

6
Getting Started
Unpacking
The following items are included in your product box.
The illustrations may differ slightly from the items shipped with your product.
A
B
C
F
E
D
C
E
A
CTOUCH interactive display Remote Control with Battery
AC Power Code UK AC Power Code
User Manual Activation Card
Touch Pen
USB Cable
HDMI Cable

Getting Started
7
Viewing the control panel
①INPUT Display all the inputs.
②MENU Displays a menu.
③VOL ▲/▼Adjust the volume.
In the menu screen, adjust menu settings.
④CH ▲/▼Select a menu item.
⑤Standby Toggles between normal and standby modes.
⑥Power LED Blue : In power on mode.
Red : In standby mode.
⑦Remote control sensor Aims the remote control towards this spot on the CTOUCH
interactive display.
⑧Sound bar holder Combine Sound Bar (Option)
⑧

Getting Started
8
Viewing the connection panel
For Full HD Display
For UHD Display
①USB Connect USB memory for MP3 or JPEG.
②HDMI Connect an HDMI device to this jack.
③PC Audio Audio input for PC.
④PC Connect a video from a computer to this jack.
⑤Component Connect a component video device to this jack.
⑥Audio Audio input for component, video and S-Video.
⑦Video Connect a video device to this jack.
⑧S-Video Connect a S-Video device this jack. (Option)
⑨Digital Audio output Optical digital audio output.
⑩Sensor USB Connect PC USB for touch screen.
⑪RS232C Connect the controller.
⑫Audio output Connect to external audio amplifier.
⑬HDMI 4 (UHD) Connect an HDMI device for UHD to this jack. (Option)
⑭Display Port Connect a Display Port device to this jack. (Option)
①
① ⑭
②
② ⑬②
③
③
④
④
⑤
⑤
⑥
⑥
⑧⑦
⑦
⑨
⑨
⑩
⑩
⑪
⑪
⑫
⑫

Getting Started
9
Viewing the remote control
①
POWER
Press to turn the CTOUCH interactive
display on and off.
②
OK
Press to accept your selection or
display the current mode.
▲/▼/◄/►
Press to select on-screen menu items
or change menu values.
③MENU
Press to display the on-screen menu.
④
INPUT
Press to display a menu of all available
input sources.
⑤
VOL
Press to increase or decrease the
volume.
⑥EXIT
Press to exit the current menu.
⑦ARC
Press to adjust the screen size.
⑧FREEZE
Press to freeze the picture.
⑨
MUTE
Press to temporarily switch the sound
off.
①
②
④
③
⑦
⑥
⑧
⑨
⑤

10
Basic Functions
Turning on/off your CTOUCH interactive
display
Standby Setup: The AC power cord must be set up and connected to get the CTOUCH
interactive display in standby mode ready to be turned on.
Press the Power button on the front panel to make the CTOUCH interactive display go into
standby mode.
1
If the CTOUCH Interactive display is in standby mode, press the Power button on the remote
control or CTOUCH interactive display itself to turn the CTOUCH interactive display on.
Power button
2
Press the Power button again on the remote control or the CTOUCH interactive display itself to
turn the CTOUCH interactive display off.
Using the touch sensor
To operate the touch sensor, connect the USB cable from a computer to the Sensor USB, and
then turn on the computer.

Basic Functions
11
Adjusting a volume level
Press the VOL +/- button to adjust a sound level.
Volume level: 0 ~ 100
Volume 20
VOL +/- button
Mute function
You can mute the audio sound.
MUTE button
1
Press the MUTE button on the remote control to temporarily cut off the sound.
2
When mute is on, press the MUTE button again on the remote control to play the audio.
Selecting a input mode
You can change the input mode.
1
Press the INPUT button to display inputs.
AV
Component
PC
HDMI1
HDMI2
USB
INPUT SOURCE
2
Press the ▲/▼button on the remote control to select a input mode.
3
Press the OK button to accept your selection.

12
Picture Control
Adjusting picture mode
Picture menus adjust the CTOUCH interactive display for the best picture appearance.
1
Press the MENU button to display the main menu.
2
Press the ◄/►button to select the Picture menu, and then press the OK button.
3
Press the ▲/▼button to select the desired picture option.
(Picture Mode, Contrast, Brightness, Color or Sharpness)
Select Move Exit
Picture Mode 〈Standard 〉
Contrast 50
Brightness 50
Color 50
Sharpness 0
Advanced Video 〉
4
Press the ◄/►button to make appropriate adjustments.
5
Press the EXIT button to return to CTOUCH interactive display viewing or press the MENU
button to return to the previous menu.
Picture Mode items
Picture Mode
Select a preset Picture Mode (Standard, Theater, Custom, Vivid).
Contrast
Adjusts the difference between the light and dark levels in the picture.
Brightness
Increases or decreases amount of white in the your picture.
Color
Adjust intensity of all colors.
Tint
Adjust the balance between red and green levels.
Sharpness
Adjust the level of sharpness in the edges between the bright and dark areas of the picture.

Picture Control
13
Setting advanced video
1
Press the MENU button to display the main menu.
2
Press the ◄/►button to select the Picture menu, and then press the OK button.
3
Press the ▲/▼button to select Advanced Video, and then press the OK button.
Select Move Exit
Color Temperature 〈 Normal 〉
Zoom Mode 〈Original 〉
Noise Reduction 〈Auto 〉
Adaptive Contrast 〈On 〉
4
Press the ▲/▼button to select menu items.
5
Press the EXIT button to return to CTOUCH interactive display viewing or press the MENU
button to return to the previous menu.
Advanced Video items
Color Temperature
Select one of three color preset (Warm, Normal, Cool).
Zoom Mode
Select a zoom mode according to input source (Wide, Zoom, Cinema, Original, Normal).
Noise Reduction
To reduce any static and ghosting that may appear on the screen.
Adaptive Contrast
Adjust the screen contrast automatically.

14
Sound Control
Adjusting sound mode
Sound menus adjust the CTOUCH interactive display for the best sound appearance.
1
Press the MENU button to display the main menu.
2
Press ◄/►button to select the Sound menu, and then press OK button.
3
Press the ▲/▼button to select menu items.
4
Press the EXIT button to return to CTOUCH interactive display viewing or press the MENU
button to return to the previous menu.
Sound Mode items
Sound Mode
Select a preset sound mode (Standard, News, Music, Movie, Custom).
Treble
Adjust tones of high frequency.
Bass
Adjust tones of low frequency.
Balance
Adjust the balance between the right and left speakers.
AVC
Equalize the volume level on each program.
Digital Output
Select the Digital Audio output format from the options PCM or RAW.
Select Move Exit
Sound Mode 〈Standard 〉
Bass 50
Treble 50
Balance 50
AVC 〈Off 〉
Digital Output 〈PCM 〉

15
Setup Control
Using the Setup menu
1
Press the MENU button to display the main menu.
2
Press ◄/►button to select the Setup menu, and then press OK button.
3
Press the ▲/▼button to select menu items.
Select Move Exit
Time 〉
Menu Settings 〉
PC Settings 〉
Key Lock 〈Off 〉
Variable Audio 〈Off 〉
Internal Speaker 〈On 〉
Restore Default 〉
4
Press the EXIT button to return to CTOUCH interactive display viewing or press the MENU
button to return to the previous menu.
Setup items
Time
Press the OK button, and then select Off Timer, Auto ON and No Signal Auto Off.
Menu Settings
Press the OK button, and then adjust the transparency of main menu (0, 25, 50, 75, 100%), and select
menu language.
Key Lock
Disable front key buttons.
Variable Audio
Line out audio volume can be controlled.
Internal Speaker
Enable internal speakers.
Restore Default
Restore the OSD values from user’s to defaults.

16
PC Settings
Adjusting the PC screen
1
Select the input for PC.
2
Press the MENU button to display the main menu.
3
Press the ◄/►button to select the Setup menu, and then press the OK button.
4
Press the ▲/▼button to select PC Settings, and then press the OK button.
5
Press the ▲/▼button to select the items.
Select Move Exit
H-Position 50
V-Position 34
Clock 50
Phase 5
Auto 〉
6
Press the EXIT button to return to CTOUCH interactive display viewing or press the MENU
button to return to the previous menu.
PC Settings items
H-Position and V-Position
If the screen is skewed towards a specific direction, try to adjust the position.
Clock
This function will remove or reduce flickering on the screen, unstable boundaries, unnecessary noise or
blurring of the screen.
Phase
If adjusting the frequency does not remove unnecessary noise, adjust the phase.
Auto
The Position, Clock and Phase values are adjusted automatically.

17
Notes

18
Touch Sensor

19
Introduction
This document1is the User Manual of the settings software for CTOUCH sensors.
Program CTOUCH_tools.exe
Operating System Microsoft Windows XP (32 & 64 bit), Vista (32 & 64 bit), and 7 (32 & 64 bit), Mac OSX,
Linux
Minimum Requirements Intel Celeron 333 MHz Processor
Resolution of 1024 x 768 or higher
[ Prerequisites for Running CTOUCH_tools ]
The following is the window that comes up when one launches the CTOUCH_tools.exe
program. The left side is where buttons for setting the mouse, calibration and settings are
located. Select each to go to the appropriate menus. One can see from the lower right hand
side of this window that the software has gotten information from the Touch sensor hardware.
1This document is subject to change without prior notice.

Introduction
20
Tabbed Menu
When one goes into one of the Mouse, Calibration, Sensor Settings, or General Settings menus,
one is provided with five different buttons (six if one has Softkey installed) on the top right
whereby the selection of which will give the user access to its specific settings.
①
Home
Access to the menus in a wider named format. One can also see the firmware version of the device.
②
Gesture
Setting the Touch Gesture Profiles.
③
Touch Coordinate Calibration
To calibrate the touch coordinates and settings of the area to touch.
④
Sensor Settings
Enabling and disabling touch functionality; turning the sound on and off; shortcut keys for calibrating and
enabling / disabling touch; and a diagnostic tool for the sensors.
⑤
General Settings
Language settings and the input mode for touch functionality.
Control Buttons
On the bottom of each menu window are keys to go to the default, to refresh the settings from
the sensors, and terminate the program.
Default Change values to the manufacturing defaults.
Exit Terminate the program.
The following is the detailed explanation of each function of the CTOUCH tools software.
