CTX PR500 User manual

English8188
♦♦♦
1
English
Table of Contents
Safety Instructions ...................................................................................2
Section 1 Introduction........................................................................... 4
1.1 Contents of the Package ................................................................... 4
1.2 Removing or Installing the Tilt/Swivel Base ..................................... 5
1.3 Feature Highlights ............................................................................ 5
1.4 Specifications .................................................................................... 6
1.5 Recommended Use of the Monitor.................................................. 7
Section 2 Installation............................................................................. 8
2.1 Pin Assignment Table....................................................................... 8
2.2 Preset Timing Chart.......................................................................... 9
Section 3 Controls and Adjustments ................................................ 10
3.1 Front User Controls........................................................................ 10
3.2 How to Use ON-Screen Adjustment.............................................. 11
3.3 Energy Declaration ......................................................................... 13
Section 4 Trouble-Shooting ................................................................ 13
Appendix/Anhang/Appendice
A. Dimension/Abmessungen/Dimension............................................ 43
B. Plug & Play: Display Data Channel (DDC).................................. 44
Manufacturer's Limited Warranty. ................................................. 45
.

♦♦♦
2
English
1. Please read carefully all of these instructions below and keep the manual
for later use.
2. Please install the swivel base below this product before it comes into use.
3. The voltage ratings and the rated frequency are on the overlay centered at
rear side of this product. Do not connect with any source of other voltage
or frequency and please follow all warnings and instructions marked on
the product.
4. Unplug this product from the wall outlet before cleaning and use a damp
cloth to clean it. Do not use liquid cleaners or aerosol cleaners.
5. Do not expose this product to rain or moisture.
6. Do not place this product on an unstable cart, stand, or table. The product
may fall, causing serious damage to the product.
7. Do not block or cover ventilating openings with cloth or other material.
Neither should this product be placed near or over a radiator or a heat
register, nor should the product be placed in a built-in installation unless
proper ventilation is provided.
8. This product is equipped with a 3-wire grounding type plug. This plug
will only fit into a grounding-type power outlet. This is a safety feature.
If you are unable to insert the plug into the outlet, contact your electrician
to replace your obsolete outlet. Do not defeat the safety purpose of the
grounding-type plug. Choose a Tandem Blade attachment plug
configuration power cord for 230V AC input.
Due to the safety requirements of different areas, please select a suitable
power cord according to the following rules, in addition to the electric
rating:
A. Northern America area: Please select a UL listed and CSA certified
power cord.
B. Germany: Please select a VDE certified power cord.
C. Nordic countries: Please select a power cord certified by SEMKO,
NEMKO, DEMKO or FIMKO.
D. The other areas: Please select a power cord suitable to the local power
system and power outlet.
SAFETY INSTRUCTIONS

English8388
♦♦♦
3
English
Usually a suitable power cord is provided by the manufacturer, while this
product is sold. However, this product is sometimes, resold or transported
to another area of different power system and safety requirements, please
pay attention to the selection of a suitable power cord.
The plug on the power cord is intended to serve as the disconnect device,
the scoket-outlet shall be installed near the equipment and shall be easily
accessible.
9. Do not allow anything to rest on the power cord. Do not locate this
product where persons will walk on the cord.
10. Never push objects of any kind into this product through cabinet slots as
they may touch dangerous voltage points or short out parts that could
result in a risk of fire or electric shock. Never spill liquid of any kind on
the product.
11. Do not attempt to service this product yourself, as opening or removing
covers may expose you to dangerous voltage points or other risk. Refer
all servicing to service personnel.
12. Unplug this product from the wall outlet and refer servicing to qualified
service personnel under the following conditions.
A. When the power cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally, when the operating
instructions are followed, adjust only those controls that are covered
by the operating instructions since improper adjustment of other
controls may result in damage and will often require extensive work
by a qualified technician to restore the product to normal operation.
E. If the product has been dropped or the cabinet has been damaged.
F. If the product exhibits a distinct change in performance, indicating a
need for service.

♦♦♦
4
English
USER'SMANUAL
BENUTZERHANDBUCH
Manueldel'utlisateur
1569UA/1569UE
1.1 Contents of the Package
The following lists all of the items included in your color monitor package,
please save the original box and packing materials for future transportation
or shipment of this monitor.
1. The color monitor with tilt/swivel base
2. Power cord
3. User's manual Rear View Front View
Power Cord
User's Manual
Section 1 Introduction
The monitor is a multiple frequency high resolution color monitor for IBM
compatible, Macintosh family and workstation systems. The monitor is
equipped with microprocessor based intelligence and multiple frequency scan-
ning capability, allowing it to provide maximum compatibility for various
kinds of graphic system hardwares.
The monitor is designed with the latest screen technology including a 0.25mm
Aperture Grille CRT to display crisp text and vivid color graphics with max.
resolution up to 1280 x 1024, and supports VESA 85Hz modes to provide flicker-
free picture. The full function digital control and On-Screen Display system
provides easy adjustment of image geometry and color for different display modes
with the precision of a fixed frequency monitor.
The design of the monitor is also ergonomics concerned, in addition to the friendly
controls and user comfort features, the emission level of electric and magnetic
field is kept low to meet the Swedish MPR II(PR500) standard or TCO(PR500T)
standard.
The monitor is also equipped with energy saving function, it is compatible with
VESA power saving proposal, the lowest power consumption is less than 8 W.

English8588
♦♦♦
5
English
1.2 Removing or Installing the Tilt/Swivel Base
1. Turn off the system and all attached options.
2. Carefully set the display upside down.
Remove the Tilt/Swivel Base
1. Squeeze and hold the latches.
2. Pull the Tilt/Swivel Base to the rear of the display and
lift to remove the base. Install
Remove
Install the Tilt/Swivel Base
1. Align the base with the slots in the bottom of the
display and insert the Tilt/Swivel Base into the
slots.
2. Push the Tilt/Swivel Base firmly toward the front
of the display until the latches click into the locked
position.
* with optional adapter
1.3 Feature Highlights
Maximum Compatibility
• Automatically scans all horizontal frequencies between 30 KHz and 70
KHz, and all vertical frequencies between 50 Hz and 160 Hz.
• Supports multiple operating platforms such as IBM compatible,
Macintosh* family.
• Maximum compatibility 640 x 480/130Hz, 800 x 600/110Hz, 1024 x 768/85Hz,
1280 x 1024/66Hz.
• Supports wide range of graphics standards including VGA, super VGA,
XGA, Mac II 13" (640 x 480), Mac 16" (832 x 624), Mac 21" (1152 x
870), all VESA standards.
Latest Screen Technology
• 0.25 mm Aperture Grille 38.1cm/15 inches CRT increases the clarity and
displays greater detail.
• Special anti-reflection, anti-glare and anti-static coating of the screen
face provides better focus, contrast and color performance.
• Dark tint tube to provide the high contrast performance.
• Built-in dynamic focus to provide better legibility and clear image.
• Flat and square screen reduces image distortion and glare.
• Full feature digital control and multi-lingual OSD system allows easy
adjustment of geometry and color. Besides the monitor provides even
trapezoid, parallelogram, pin-corner, pin-balance and rotation adjustments
for user to finely tune the picture image.

♦♦♦
6
English
1.4 Specifications
Note: Specifications are subject to change without notice.
Ergonomics Concerned
• Electric and magnetic field emission are kept low to meet the Swed-
ish MPR II or TCO standard.
• Front user controls allow easy access and comfort for user to adjust the
screen image to individual preference.
• Horizontal and vertical fullscan capability allows user to use the entire
screen area in most resolutions.
• A tilt/swivel base for horizontal and vertical adjustments provides the
optimum viewing angle.
Instant Power Saving Solutions
• The monitor is compatible with VESA DPMS (Display Power Manage-
ment Signalings), providing four power saving modes by detecting hori-
zontal and vertical sync signals.
• The monitor consumes 65 W to 100 W depending on the display content
in normal operation, when the power saving mode is activated, it con-
sumes less than 15 W in "stand-by" mode, less than 15 W in "suspend"
mode and less than 8 W in "off" mode.
Specification
Color Picture Tube
Dot Pitch
Input Signal
Scan Frequency
Display Area
Max. Resolution
Display Colors
Video Bandwidth
Misconvergence
Power Supply
Power Consumption
Dimensions
Weight
Environmental
Consideration
38.1cm/15 inches (viewable 35.1cm/13.8") diagonal measurement. 90 degree deflection,
anti-glare, anti-reflection, anti-static, medium short persistance phosphor, dark tint
0.25mm, Aperture Grille
Video: 0.7 Vp-p/75 ohm Analog Positive
Sync. : Separate Sync. TTL Level
Horizontal Sync. Positive/Negative, Vertical Sync. Positive/Negative
: Composite Sync. TTL Level Positive/Negative
Horizontal 30 to 70 KHz (Automatically) Vertical 50 to 160 Hz (Automatically)
Horizontal 282 mm (Adjustable), Vertical 212 mm (Adjustable)
1280 x 1024 non-interlaced
Analog input unlimited colors
110 MHz
Center 0.3 mm, Corner 0.45mm maximum
AC 100-120/200-240VAC, 50/60 Hz (Automatically)
100W max.
370(W) x 337(H) x 400(D) mm
15 Kgs (G.W.) 13.6 Kgs (N.W.)
Operating Temperature 0°C to 40°C Humidity 20% to 80%
Storage Temperature -20°C to 60°C Humidity 10% to 90%

English8788
♦♦♦
7
English
1.5 Recommended Use of the Monitor
When setting up and using the monitor, pay special attention to the following
for optimum performance.
• Do not use your monitor against a bright background or where sunlight or
other light sources will shine directly on the screen.
• The monitor should be placed just below eye level (10°~15°) for opti-
mum viewing.
• Set the monitor's brightness to match the ambient room light.
• For optimum focus, the contrast control should not be set to the maxi-
mum unless the input signal level is extremely low. Also, the brightness
control should be set to a point where the overall background area just
begins to disappear.
• Allow adequate ventilation around the monitor so that the heat from the
monitor can properly dissipate.
• Neither the monitor itself, nor any other heavy object, should rest on the
power cord. Damage to a power cord can cause fire or electrical shock.
• Keep the monitor away from high capacity transformers, electrical motors,
and other strong magnetic field.
• Your monitor should not be used in damp, dusty, or dirty areas.
• Handle your monitor with care when transporting it.
• Clean the CRT surface with a lint-free, non-abrasive cloth and a non-
alcohol, neutral, non-abrasive cleaning solution or glass cleaner.

♦♦♦
8
English
Section 2 Installation
This color monitor supports multiple operating platforms such as IBM
compatible, Macintosh family. This section gives the details on pin assignment
of the input connectors and the Preset Timing Chart of prevailing video
standards are included in this section for your reference.
2.1 Pin Assignment Table
1. Pin Assignments of the Mini- D-SUB 15 Pin Connector
MALE MINI D-SUB 15 PIN
5
10
15
11
6
1
Signal Mini D-SUB15 Pin
Red Video 1
Green Video 2
Blue video 3
Horizontal sync 13
Vertical Sync 14
Ground 4,5,6,7,8,10,11
No Connection 9
SDA (DDC) 12
SCL (DDC) 15

English8988
♦♦♦
9
English
HORIZONTAL VERTICAL
2.2 Preset Timing Chart Note:This monitor is equipped with a micro-processor which allows user to
set his own preferred mode(s) beyond those listed below.
* Bµs (Pulse Width) should be more than 0.5 µs.
To reduce visual tiredness and eye strain, choice of the higher refreshed mode is prefered.
Display Format VGA MAC II VESA 640x480
at 85 Hz 640x480
at 120 Hz VESA
800x600
at 85 Hz 800x600
at 100 Hz VESA
1024x768
at 85 Hz
VESA
1280x1024
at 60 Hz
Hotizontal Dots 640 720 640 640 640 800 800 1024 1280
Vertical Lines 480 400 480 480 480 600 600 768 1024
H. Frequency(kHz) 31.500 35.000 43.269 63.500 53.674 63.800 68.677 63.679
H.Sync.Polarity–––––++++
Aµs (Period) 31.780 28.571 23.111 15.74 18.631 15.660 14.561 15.700
*Bµs (Pulse Width) 3.810 2.116 1.333 1.742 1.138 1.118 1.016 1.333
Cµs (Back Porch) 1.910 3.175 3.111 1.738 2.702 2.006 2.201 2.222
Dµs (Active Area) 25.420 21.164 17.778 11.660 14.222 11.870 10.836 11.852
Eµs (Front Porch) 0.640 0.000 0.889 0.600 0.569 0.596 0.508 0.293
V. Frequency(Hz) 60.000 70.000 66.667 85.000 119.830 85.062 99.973 84.997 60.018
V. Sync. Polarity – + + – – + + + +
Oms (Period) 16.680 14.270 15.000 11.763 8.342 11.756 10.006 11.765 16.700
Pms (Pulse Width) 0.060 0.086 0.069 0.094 0.056 0.063 0.044 0.047
Qms (Back Porch) 1.050 1.110 1.114 0.578 0.057 0.503 0.501 0.524 0.534
Rms (Active Area) 15.250 12.710 13.714 11.093 7.555 11.179 9.396 11.183 16.081
Sms (Front Porch) 0.320 0.380 0.000 0.023 0.538 0.041 0.046 0.015 0.038

♦♦♦
10
English
Section 3 Controls and Adjustments
Once you have installed the monitor with your system, this section gives you
some guidelines on how to use it more efficiently. It leads you through the
various function of the user controls as well as explains how to adjust the
monitor to your individual preference.
3.1 Front User Controls
–+
1
2
3
4
5
6
7
1. POWER SWITCH
To turn the monitor On and Off.
2. POWER INDICATOR
When the power to the monitor is ON, the indicator is lit.
In normal operation, the indicator is green.
While in power saving mode, the indicator will turn to amber.
3. DEGAUSS/EXIT SWITCH
To manually degauss the monitor or to exit from the OSD window.
4. CONTROL KEYS
•To adjust the parameter of the selected function.
•To adjust the contrast level or brightness of the screen.
5. STATUS
To display and select functions of "Mode", "Off time", "Power save", "Recall",
"Language" and "Location".
•"Mode" is to show Horizontal/Vertical frequency & polarity
•"Off time" is to set OSD window display time.
•"Power save" is to enable or disable function of power save.
•"Recall" is to recall the factory settings of "Picture" and "Color".
•"Language" is to select the OSD languages
•"Location" is to move the OSD window.
6. COLOR
To display and select color mode.(three color modes are available for
choice)
7. PICTURE
To display and select functions of "Position", "Size", "Pincushion",
"Geometry" and "Rotation".
Power save note
This monitor is equipped with autmatic power-saving circuitry design which will
work with any computer unit following the VESA DPMS detection format, and it
meets ENERGY STARand Nutek low power state definition. When first power
on and input signal into the monitor, the power save function remains in active,
the function will then be triggered when the input signal is cut off by the computer
itself, or loss of signal input afterwards.
▼▼
▼▼
▼
▲▲
▲▲
▲
