Cub Cadet SS270 User manual

769-09453 / 00 11/13
2-Cycle Trimmer
SS270
TABLE OF CONTENTS
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Know Your Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Oil and Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Starting and Stopping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Cleaning and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
All information, illustrations, and specifications in this manual are based
on the latest product information available at the time of printing. We
reserve the right to make changes at any time without notice.
Copyright© 2013 MTD SOUTHWEST INC, All Rights Reserved.
SAVE THESE INSTRUCTIONS
SERVICE
DO NOT RETURN THIS UNIT TO THE RETAILER. PROOF OF
PURCHASE WILL BE REQUIRED FOR WARRANTY SERVICE.
For assistance regarding the assembly, controls, operation or
maintenance of the unit, please call the Customer Support Department
at 1-877-282-8684 in the United States or 1-800-668-1238 in Canada.
Additional information about the unit can be found on our website:
www.cubcadet.com (U.S.) or www.cubcadet.ca (Canada).
For service, please call the Customer Support Department to obtain
a list of authorized service dealers near you. Service on this unit,
both within and after the warranty period, should only be performed
by an authorized and approved service dealer. When servicing, use
only identical replacement parts.
IMPORTANT: Read this manual thoroughly before using this product. Follow all instructions.
Operator’s Manual

• IMPORTANT SAFETY INSTRUCTIONS •
SAFETY
SPARK ARRESTOR NOTE
NOTE: For users on U.S. Forest Land and in the states of
California, Maine, Oregon and Washington. All U.S. Forest Land
and the state of California (Public Resources Codes 4442 and
4443), Oregon and Washington require, by law that certain internal
combustion engines operated on forest brush and/or grass-covered
areas be equipped with a spark arrestor, maintained in effective
working order, or the engine be constructed, equipped and
maintained for the prevention of fire. Check with your state or local
authorities for regulations pertaining to these requirements. Failure
to follow these requirements could subject you to liability or a fine.
This unit is factory equipped with a spark arrestor. If it requires
replacement, contact your local service dealer to install the
appropriate muffler assembly.
Read the operator’s manual and follow all warnings and safety
instructions. Failure to do so can result in serious injury to the
operator and/or bystanders.
SYMBOL MEANING
WARNING:Signals a SERIOUS hazard.
Failure to obey a safety WARNING signal CAN result in
serious injury to yourself or to others.
CAUTION:Signals a MODERATE hazard.
Failure to obey a safety CAUTION signal MAY result in
property damage or injury to yourself or to others.
The purpose of safety symbols is to attract your attention to
possible dangers. The safety symbols, and their explanations,
deserve your careful attention and understanding. The safety
warnings do not by themselves eliminate any danger. The
instructions or warnings they give are not substitutes for proper
accident prevention measures.
NOTE: Advises you of information or instructions vital to the
operation or maintenance of the equipment.
DANGER:Signals an EXTREME hazard.
Failure to obey a safety DANGER signal WILL result in
serious injury or death to yourself or to others.
CALIFORNIA PROPOSITION 65
WARNING:Engine exhaust, some of its
constituents and certain finished components contain or
emit chemicals known to the State of California to cause
cancer and birth defects or other reproductive harm. Wash
hands after handling.
2
READ ALL INSTRUCTIONS BEFORE OPERATING
• Read the instructions carefully. Be familiar with the controls and
proper use of the unit.
• Do not operate this unit when tired, ill or under the influence of
alcohol, drugs or medication.
• Children must not operate the unit. Teens must be accompanied
and guided by an adult.
• All guards and safety attachments must be installed properly
before operating the unit.
• Inspect the unit before use. Replace damaged parts. Check for
fuel leaks. Make sure all fasteners are in place and secure.
Replace parts that are cracked, chipped, or damaged in any
way. Do not operate the unit with loose or damaged parts.
• Only use the trimming line described in the Specifications section
of this manual. Never use metal-reinforced line, wire, chain or
rope. These can break off and become dangerous projectiles.
• Do not replace the cutting head with rigid or metal blades. Doing
so could result in serious injury.
WARNING:When using the unit, all safety
rules must be followed. Please read these instructions
before operating the unit in order to ensure the safety of
the operator and any bystanders. Please keep these
instructions for later use.
• Be aware of risk of injury to the head, hands and feet.
• Carefully inspect the area before starting the unit. Remove
rocks, broken glass, nails, wire, string and other objects that
may be thrown or become entangled with the unit.
• Clear the area of children, bystanders and pets; keep them
outside a 50-foot (15 m) radius, at a minimum. Even then, they are
still at risk from thrown objects. Encourage bystanders to wear
eye protection. If you are approached, stop the unit immediately.
• Squeeze the throttle control and check that it returns
automatically to the idle position. Make all adjustments or
repairs before using the unit.
• This unit is intended for occasional, household use only.

SAFETY WARNINGS FOR GAS UNITS
• Store fuel only in containers specifically designed and approved
for the storage of such materials.
• Always stop the engine and allow it to cool before filling the
tank. Never remove the fuel tank cap or add fuel when the
engine is hot. Always loosen the fuel tank cap slowly to relieve
any pressure in the tank before fueling.
• Always mix and add fuel in a clean, well-ventilated outdoor area
where there are no sparks or flames. DO NOT smoke.
• Never operate the unit without the fuel cap securely in place.
• Avoid creating a source of ignition for spilled fuel. Wipe up any
spilled fuel from the unit immediately, before starting the unit.
Move the unit at least 30 ft. (9.1 m) from the fueling source and
site before starting the engine. DO NOT smoke.
• Never start or run the unit inside a closed room or building.
Breathing exhaust fumes can kill. Operate this unit only in a well
ventilated outdoor area.
WARNING:Gasoline is highly flammable and
its vapors can explode if ignited. Take the following
precautions:
3
WHILE OPERATING
• Wear safety glasses or goggles that meet current ANSI / ISEA
Z87.1 standards and are marked as such. Wear ear/hearing
protection when operating this unit. Wear a face mask or dust
mask if the operation is dusty.
• Wear heavy long pants, boots, gloves and a long sleeve shirt. Do
not wear loose clothing, jewelry, short pants, sandals or go
barefoot. Secure hair above shoulder level.
• The cutting head shield must always be in place while operating
the unit. Do not operate the unit without both trimming lines
extended and the proper line installed. Do not extend the
trimming line beyond the length of the shield.
• This unit has a clutch. The cutting head remains stationary when
the engine is idling. If it does not, take the unit to an authorized
service dealer for an adjustment.
• Adjust the handle to provide the best grip, if applicable.
• Make sure the attachment is not in contact with anything before
starting the unit.
• Use the unit only in daylight or good artificial light.
• Avoid accidental starting. Be in the starting position whenever
pulling the starter rope. The operator and unit must be in a stable
position while starting. Refer to Starting and Stopping.
• Use the right tool. Only use this tool for its intended purpose.
• Always hold the unit with both hands when operating. Keep a
firm grip on both handles or grips.
• Do not overreach. Always keep proper footing and balance. Take
extra care when working on stairs, steep slopes or inclines. To
avoid serious injury, do not operate the unit while on a ladder or
a roof.
• Keep hands, face, and feet away from all moving parts. Do not
touch or try to stop moving parts.
• Do not touch the engine, gear housing or muffler. These parts get
extremely hot from operation, even after the unit is turned off.
• Do not operate the unit faster than the speed needed to do the job.
Do not run the unit at high speed when not in use.
• Do not force the unit. It will do a better, safer job when used at
the intended rate.
• Always stop the unit when operation is delayed or when walking
from one location to another.
OTHER SAFETY WARNINGS
• All service, other than the maintenance procedures described in
this manual, should be performed by an authorized service dealer.
• Before inspecting, servicing, cleaning, storing, transporting or
replacing any parts on the unit:
1. Stop the unit.
2. Make sure all moving parts have stopped.
3. Allow the unit to cool.
4. Disconnect the spark plug wire.
• Secure the unit while transporting.
• Never store the unit with fuel in the tank, inside a building where
fumes may reach an open flame (pilot lights, etc.) or sparks
(switches, electrical motors, etc.).
• Store the unit in a dry place, secured or at a height to prevent
unauthorized use or damage. Keep the unit out of the reach of
children.
• Never douse or squirt the unit with water or any other liquid.
Keep handles dry and clean (free from debris, oil and grease).
Clean the unit after each use. Refer to Cleaning and Storage. Do
not use solvents or strong detergents.
• Keep these instructions. Refer to them often and use them to
instruct other users. If you loan this unit to others, also loan
them these instructions.
SAVE THESE INSTRUCTIONS
• If you strike or become entangled with a foreign object, stop the
unit immediately and check for damage. Do not operate the unit
before repairing damage. Do not operate the unit with loose or
damaged parts.
• Turn the engine to off and disconnect the spark plug for
maintenance or repair.
• Use only original equipment manufacturer (OEM) replacement
parts and accessories for this unit. These are available from your
authorized service dealer. Use of any other parts or accessories
could lead to serious injury to the user, or damage to the unit,
and void the warranty.
• Keep the unit clean. Carefully remove vegetation and other
debris that could block moving parts.
• To reduce fire hazard, replace a faulty muffler and spark arrestor.
Keep the engine and muffler free from grass, leaves, excessive
grease or carbon build up.
• If the unit starts to vibrate abnormally, stop the unit immediately.
Inspect the unit for the cause of the vibration. Vibration is
generally an indicator of trouble.

• SAFETY & INTERNATIONAL SYMBOLS •
This operator's manual describes safety and international symbols and pictographs that may appear on this product. Read the operator's
manual for complete safety, assembly, operating and maintenance and repair information.
SYMBOL MEANING SYMBOL MEANING
• SAFETY ALERT SYMBOL
Indicates danger, warning or caution. May be used in
conjunction with other symbols or pictographs.
• READ OPERATOR'S MANUAL
WARNING: Read the operator’s
manual(s) and follow all warnings and safety
instructions. Failure to do so can result in serious
injury to the operator and/or bystanders.
• WEAR EYE AND HEARING PROTECTION
WARNING:Thrown objects and loud
noise can cause severe eye injury and hearing loss.
Wear eye protection meeting current ANSI / ISEA
Z87.1 standards and ear protection when operating
this unit. Use a full face shield when needed.
• UNLEADED FUEL
Always use clean, fresh unleaded fuel.
• OIL
Refer to operator’s manual for the proper type of oil.
• DO NOT USE E85 FUEL IN THIS UNIT
WARNING:It has been proven that fuel
containing greater than 10% ethanol will likely
damage this engine and void the warranty.
• ON/OFF STOP CONTROL
ON / START / RUN
• ON/OFF STOP CONTROL
OFF or STOP
• PRIMER BULB
Push primer bulb, fully and slowly, 10 times.
• CHOKE CONTROL
1. • FULL choke position
2. • PARTIAL choke position
3. • RUN choke position
• THROWN OBJECTS AND ROTATING CUTTER CAN
CAUSE SEVERE INJURY
WARNING:Small objects can be
propelled at high speed, causing injury. Keep away
from the rotating rotor.
• KEEP BYSTANDERS AWAY
WARNING:Keep all bystanders,
especially children and pets, at least 50 feet (15 m)
from the operating area.
• HOT SURFACE
WARNING:Do not touch a hot muffler
or cylinder. You may get burned. These parts get
extremely hot from operation. When turned off, they
remain hot for a short time.
• SHARP BLADE
WARNING:Sharp blade on trimmer
attachment shield. To prevent serious injury, do not
touch the line cutting blade.
4

Cutting Head
Shield
Fuel Cap
Handle
Cutting Head
Shaft Grip
Shaft Housing
Starter Rope
Grip
Throttle
Control
Spark Plug
Muffler
On/Off Switch
Primer Bulb
Line Cutting Blade
Choke Lever
Air Filter
Cover
Coupler
5
KNOW YOUR UNIT
APPLICATIONS
As a trimmer:
• Cutting grass and light weeds.
• Edging
• Decorative trimming around trees, fences, etc.
Other optional accessories may be used with this unit.
SPECIFICATIONS*
* All specifications are based on the latest product information available at the time of printing. We reserve the right to make changes at any
time without notice.
Engine Type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Air-Cooled, 2-Cycle
Displacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 cc (1.64 cu. in.)
Spark Plug Gap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.025 in. (0.635 mm)
Spark Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Champion® RDJ7J or equivalent plug
Lubrication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fuel/Oil Mixture
Fuel/Oil Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40:1
Fuel Tank Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 oz. (414 ml)
Approximate Unit Weight (No fuel) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 - 13 lbs. (5.4 - 5.9 kg)
Trimmer Mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fixed-line cutting head
Trimming Line. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.105 inches (2.67 mm) pre-cut line
Cutting Path Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 in. (43.2 cm)
ASSEMBLY TOOLS REQUIRED:
• #2 Phillips screwdriver
• 3/8” Socket

ASSEMBLY
6
Fig. 2
Bolt
Shaft Grip
Minimum 6 in.
(15.24 cm)
Handle
Shaft
Housing
INSTALLING AND ADJUSTING THE HANDLE
Installing the Handle
1. Push the handle down onto the shaft housing (Fig. 2). The bolt
hole in the handle should be to the right.
2. Insert the bolt into the bolt hole and push it through (Fig. 2).
Tighten the bolt with a 3/8” socket, but do not tighten the bolt
completely.
3. While holding the unit in the operating position (Fig. 9), move the
handle to the location that provides the best grip. Place it a
minimum of 6 inches (15.24 cm) from the end of the shaft grip
(Fig. 2).
4. Tighten the bolt with a 3/8” socket until the handle is secure.
Adjusting the Handle
If the handle requires adjustment:
1. Loosen the bolt with a 3/8” socket (Fig. 2).
2. While holding the unit in the operating position (Fig. 9), move the
handle to the location that provides the best grip. Place it a
minimum of 6 inches (15.24 cm) from the end of the shaft grip
(Fig. 2).
3. Tighten the bolt with a 3/8” socket until the handle is secure.
INSTALLING THE CUTTING HEAD SHIELD
1. Place the cutting head shield onto the mount bracket. Align the
holes in the cutting head shield with the holes in the mount
bracket. (Fig. 1)
2. Screw the 2 screws through the mount bracket and into the
cutting head shield until finger tight.
3. Using a #2 Phillips screwdriver, tighten the screws until the
cutting head shield is firmly in place. Tighten the screws equally.
The gap between the mount bracket and the cutting head shield
should be the same on each side.
WARNING: To prevent serious personal injury, never
operate the unit without the cutting head shield in place.
Fig. 1
Mount Bracket Cutting Head Shield
Screws (2)

7
Fig. 4
90˚ Hole
(Trimmer Only)
Knob
OPERATING THE COUPLER
The coupler enables the use of various optional attachments.
Installing the Attachment
1. Remove the hanger cap from the attachment. Keep the hanger
cap for use when storing the attachment. If present, remove the
gray spacer from the coupler.
2. Set the unit on a flat, level surface.
3. Turn the knob counterclockwise to loosen the coupler (Fig. 4).
4. Align the release button with the guide recess (Fig. 5).
5. Push the attachment straight into the coupler (Fig. 3) until the
release button snaps firmly into the primary hole (Fig. 5).
6. Turn the knob clockwise to tighten the coupler (Fig. 4).
NOTE: For decorative trimming with a string trimmer attachment,
lock the release button into the 90° hole (Fig. 4).
Removing the Attachment
1. Set the unit on a flat, level surface.
2. Turn the knob counterclockwise to loosen the coupler (Fig. 4).
3. Press and hold the release button (Fig. 5).
4. Pull the attachment straight out of the coupler (Fig. 3).
CAUTION: Before operating the unit, make sure the
release button is fully snapped into the primary hole and the
knob is securely tightened.
CAUTION: Unless specified otherwise, the release
button should be snapped into the primary hole only. Using
the wrong hole could lead to personal injury or damage to
the unit.
Tighten
Loosen
WARNING: Before using any attachment, read and
understand the manual that came with the attachment.
Follow all safety information contained within.
WARNING: To avoid serious personal injury and
damage to the unit, shut the unit off before removing or
installing an attachment.
Fig. 5
Fig. 3
Coupler Attachment
Release Button
Guide Recess
Primary Hole

8
OIL AND FUEL
FUELING THE UNIT
1. Position the unit with the fuel cap facing up.
2. Remove the fuel cap.
3. Place the fuel container spout into the fill hole on the fuel tank
and fill the tank.
NOTE: Do not overfill the tank.
4. Wipe up any fuel that may have spilled.
5. Reinstall the fuel cap.
6. Move the unit at least 30 ft. (9.1 m) from the fuel container and
the fueling site before starting the engine.
OIL AND FUEL MIXING INSTRUCTIONS
The use of old and/or improperly mixed fuel is the most common cause
of performance problems. Use only fresh, clean unleaded gasoline.
Follow the instructions carefully for the proper gasoline/oil mixture.
Definition of Blended Fuels
Today's fuels are often a blend of gasoline and oxygenates such as
ethanol, methanol or MTBE (ether). Alcohol-blended fuel absorbs
water. As little as 1% water in the fuel can make fuel and oil
separate, forming acids when stored. ALWAYS use fresh fuel (less
than 30 days old).
NOTE: Dispose of old fuel according to federal, state and local
regulations.
Using Blended Fuels
If using a blended fuel:
• Always use the fresh fuel mix explained in your operator's manual
• Use the fuel additive STA-BIL® or an equivalent
• Always agitate the fuel mix before fueling the unit
• Drain the tank and run the engine dry before storing the unit
Using Fuel Additives
The bottle of 2-cycle oil provided with this unit contains a fuel
additive to help inhibit corrosion and minimize gum deposits.
Always use the brand of 2-cycle oil that came with this unit. If this is
unavailable, use a 2-cycle oil designed for air-cooled engines and
mix it with a fuel additive, such as STA-BIL Fuel Stabilizer or an
equivalent. Add 0.8 oz. (23 ml) of fuel additive per gallon of fuel,
according to the instructions on the container. NEVER add fuel
additives directly to the unit's fuel tank.
Mixing the Fuel
NOTE: This unit comes with a 3.2 oz. bottle of 2-cycle oil. To obtain
the correct fuel mixture described below, pour the entire bottle
into one gallon of unleaded gasoline.
Thoroughly mix the proper ratio of unleaded gasoline with 2-cycle
engine oil. Do not mix them directly in the unit’s fuel tank. Use a
separate fuel can. Use a 40:1 gasoline/oil ratio. See the table below
for specific gasoline and oil mixing ratios.
Unleaded gasoline 2-cycle oil
1 gallon U.S.
(3.8 liters)
3.2 fl. oz.
(95 ml)
1 liter 25 ml
MIXING RATIO - 40:1
CAUTION: For proper engine operation and maximum
reliability, pay strict attention to the gasoline and oil mixing
instructions on the 2-cycle oil bottle. Using improperly
mixed fuel can severely damage the engine.
WARNING: Gasoline is extremely flammable. Ignited
vapors may explode. Always stop the engine and allow it
to cool before filling the fuel tank. Do not smoke while
filling the tank. Keep sparks and open flames at a distance
from the area.
WARNING: Remove the fuel cap slowly to avoid injury
from fuel spray. Never operate the unit without the fuel cap
securely in place.
WARNING: Add fuel in a clean, well ventilated outdoor
area. Wipe up any spilled fuel immediately. Avoid creating
a source of ignition for spilled fuel. Do not start the engine
until fuel vapors dissipate.
WARNING: DO NOT USE E85 FUEL IN THIS UNIT. It
has been proven that fuel containing greater than 10%
ethanol will likely damage this engine and void the warranty.

9
STARTING AND STOPPING
WARNING: Operate this unit only in a well-ventilated
outdoor area. Carbon monoxide exhaust fumes can be
lethal in a confined area.
WARNING: Avoid accidentally starting the unit. To avoid
serious injury, the operator and the unit must be in a stable
position when pulling the starter rope (Fig. 8).
STARTING INSTRUCTIONS
1. Mix gasoline with oil. Refer to Oil and Fuel Mixing Instructions.
2. Fill the fuel tank. Refer to Fueling the Unit.
NOTE: There is no need to turn the unit on. The On/Off switch is in
the ON ( I ) position at all times (Fig. 6).
3. Slowly press and release the primer bulb 10 times (Fig. 7). If fuel
cannot be seen in the primer bulb, press and release the primer
bulb until fuel is visible.
4. Move the choke lever to Position 1 (Fig. 7).
5. Crouch in the starting position (Fig. 8).
NOTE: SQUEEZE and HOLD the throttle control for ALL further steps.
6. Squeeze the throttle control (Fig. 6) and pull the starter rope with
a controlled and steady motion 5 times (Fig. 8).
7. Continue to squeeze the throttle control. Move the choke lever
to Position 2 (Fig. 7).
8. Continue to squeeze the throttle control. Pull the starter rope with
a controlled and steady motion 3 to 5 times to start the engine.
9. Continue to squeeze the throttle control. Allow the engine to
warm up for 30 to 60 seconds.
10. Continue to squeeze the throttle control. Move the choke lever
to Position 3 (Fig. 7) and continue warming the engine for an
additional 60 seconds. The unit may be used during this time.
NOTE: The engine is properly warmed up when it accelerates
without hesitation.
IF... the engine hesitates, return the choke lever to Position 2 (Fig. 7)
and continue the warm-up.
IF... the engine does not start, begin the starting procedure with
step 3.
IF... the engine fails to start after a few attempts, move the choke
lever to Position 3 and squeeze the throttle control. Pull the
starter rope with a controlled and steady motion 3 to 8 times.
The engine should start. If it does not, repeat this instruction.
IF... the engine is already warm, begin the starting procedure with
step 7.
STOPPING INSTRUCTIONS
1. Release the throttle control and allow the engine to idle.
2. Press and hold the On/Off switch in the OFF (O) position until
the engine comes to a complete stop (Fig. 6).
Fig. 6
Fig. 8
On ( I ) / Start
Off (O) / Stop
Throttle Control
Starting
Position
Throttle Control
Starter Rope Grip
Fig. 7
Position 2
Position 1
Position 3
Choke Lever
Primer Bulb

10
OPERATION
HOLDING THE UNIT
• Stand in the operating position (Fig. 9). Stand up straight. Do not
bend over.
• Keep feet apart and firmly planted.
• Hold the shaft grip with the right hand. Keep the right arm
slightly bent.
• Hold the handle with the left hand. Keep the left arm straight.
• Hold the unit at waist level.
• Position the cutting head a few inches above the ground.
WARNING: Always wear eye, hearing, hand, foot and
body protection to reduce the risk of injury when operating
this unit.
TIPS FOR BEST RESULTS
• To direct clippings away from the operator, tilt the cutting head
slightly down to the right; cut from left to right whenever possible.
• Do not trim wet grass or weeds.
NOTE: Some line breakage will occur from:
• Entanglement with foreign matter
• Normal line fatigue
• Attempting to cut thick vegetation
• Forcing the line into objects such as walls or fence posts
DECORATIVE TRIMMING
When trimming around trees, posts, fences, etc., rotate the whole
unit so that the cutting head is at a 30° angle to the ground (Fig. 10).
Fig. 9
Fig. 10

11
MAINTENANCE
MAINTENANCE SCHEDULE
Perform these required maintenance procedures at the frequency
stated in the table. These procedures should also be a part of any
seasonal tune-up.
NOTE: Some maintenance procedures may require special tools or
skills. If you are unsure about these procedures, take the unit to
an MTD authorized service dealer.
NOTE: Maintenance, replacement, or repair of the emission control
devices and system may be performed by an MTD authorized
service dealer.
NOTE: Please read the California/EPA statement that came with the
unit for a complete listing of terms and coverage for the emissions
control devices, such as the spark arrestor, muffler, carburetor, etc.
WARNING: To prevent serious injury, never perform
maintenance or repairs while the unit is running. Always
allow the unit to cool before servicing or repairing the unit.
Disconnect the spark plug wire to prevent the unit from
starting accidentally.
FREQUENCY MAINTENANCE REQUIRED
Every 10 hours • Clean and re-oil the air filter. Refer to
Maintaining the Air Filter.
Every 25 hours • Check the spark plug condition and gap.
Refer to Maintaining the Spark Plug.
REPLACING THE TRIMMING LINE
Only use the trimming line described in the Specifications section.
Other types of trimming line may cause the unit to overheat or fail.
1. Remove the old line from the cutting head.
2. Use a clean cloth to clean the surface of the cutting head.
3. Insert the ends of the line through the circular holes in the side
of the cutting head (Fig. 11). Push the line through the holes until
both ends protrude from the positioning tunnels (Fig. 12).
4. Pull the ends of the line until the line is tight against the cutting
head. Make sure the ends of the line are of equal length (Fig. 13).
If one end is longer than the other, push the longer end back
through the cutting head partway and pull the shorter end out. If
necessary, repeat this process until both ends are of equal length.
5. Press the exposed trimming line between the circular holes until
it lies flat against the cutting head (Fig. 13).
WARNING: Never use metal-reinforced line, wire, chain or
rope. These can break off and become dangerous projectiles.
Fig. 11
Fig. 12
Fig. 13
Line
Holes
Cutting Head
Positioning
Tunnel Positioning
Tunnel
Line
Line
Line
Cutting Head
Line

12
ADJUSTING THE IDLE SPEED
NOTE: Careless adjustments can seriously damage the unit. An
authorized service dealer should make carburetor adjustments.
If, after checking the fuel and cleaning the air filter, the engine still
will not idle, adjust the idle speed screw as follows:
1. Start the engine. Refer to Starting and Stopping.
2. Release the throttle control and let the engine idle.
• If the engine stops, use a small Phillips screwdriver to turn the
idle speed screw clockwise, 1/8 of a turn at a time (as needed)
until the engine idles smoothly (Fig. 16).
• If the engine idles too quickly, turn the idle speed screw
counterclockwise, 1/8 of a turn at a time (as needed) to reduce
the idle speed (Fig. 16).
NOTE: The cutting head should not spin when the engine idles. If it
does, reduce the idle speed until the cutting head stops moving.
Checking the fuel, cleaning the air filter, and adjusting the idle speed
should solve most engine problems. If not, and any of the following
conditions are true, take the unit to an authorized service dealer:
• the engine will not idle
• the engine hesitates or stalls on acceleration
• there is a loss of engine power
WARNING: The cutting head may spin during idle speed
adjustments. Wear protective clothing and observe all
safety instructions to prevent serious personal injury.
MAINTAINING THE AIR FILTER
Failure to maintain the air filter can result in poor performance or can
cause permanent damage to the engine. Engine failure due to
improper air filter maintenance is not covered by the product warranty.
Cleaning the Air Filter
1. Open the air filter cover by unscrewing the cover screw (Fig. 14).
2. Remove the air filter from the air filter housing (Fig. 14).
3. Wash the air filter in detergent and water. Rinse the air filter
thoroughly and allow it to dry.
4. Lightly coat the air filter with clean SAE 30 oil.
5. Squeeze the air filter to spread and remove excess oil.
6. Reinstall the air filter in the air filter housing (Fig. 14).
NOTE: Operating the unit without the air filter and air filter cover will
VOID the warranty.
7. Insert the hooks on the air filter housing into the slots on the air
filter cover (Fig. 15).
8. Swing the air filter cover to the right and align the cover screw
with the cover screw hole (Fig. 15). Tighten the cover screw to
secure the air filter cover.
NOTE: Do not over tighten, as this may strip the screw.
WARNING: To avoid serious personal injury, always stop
the engine and allow it to cool before cleaning or maintaining
the unit.
Fig. 14
Fig. 15
Hooks
Air Filter
Cover
Air Filter
Air Filter
Housing
Air Filter Cover
Cover Screw
Cover
Screw Hole
Air Filter
Housing
Slots
Fig. 16
Idle Speed Screw

13
Fig. 17
0.025 in.
(0.635 mm)
MAINTAINING THE SPARK PLUG
1. Stop the engine and allow it to cool. Grasp the spark plug boot
firmly and pull it from the spark plug.
2. Clean around the spark plug. Remove the spark plug from the
cylinder head with a 5/8-inch socket, turning counterclockwise.
3. Inspect the spark plug. If the spark plug is cracked, fouled or
dirty, replace it with replacement part #753-06193, a Champion
RDJ7J or an equivalent spark plug.
4. Use a feeler gauge to set the air gap at 0.025 in. (0.635 mm)
(Fig. 17).
5. Install the spark plug in the cylinder head. Tighten the spark plug
with a 5/8-inch socket, turning it clockwise until snug.
NOTE: If using a torque wrench, torque to:
110-120 in.•lb. (12.3-13.5 N•m). Do not over tighten.
6. Reattach the spark plug boot.
WARNING: Do not sand blast, scrape or clean spark plug
electrodes. Grit in the engine could damage the cylinder.

14
CLEANING AND STORAGE
CLEANING
Use a small brush to clean the outside of the unit. Do not use strong
detergents. Household cleaners that contain aromatic oils such as
pine and lemon, and solvents such as kerosene, can damage plastic.
Wipe off any moisture with a soft cloth.
STORAGE
• Never store a fueled unit where fumes may reach an open flame
or spark.
• Allow the engine to cool before storing.
• Lock up the unit to prevent unauthorized use or damage.
• Store the unit in a dry, well-ventilated area.
• Store the unit out of the reach of children.
• To suspend the attachment from a hook, install the hanger cap
onto the attachment. Make sure the release button is securely
locked into one of the holes on the hanger cap.
Short-term Storage (1-2 weeks)
1. Store the unit in a horizontal position. If this is not possible, store
the unit vertically with the engine at the top.
Long-term Storage
1. Remove the fuel cap, tip the unit and drain the fuel into an
approved container. Reinstall the fuel cap.
2. Start the engine and allow it to run until it stalls. This ensures
that all fuel has been drained from the carburetor.
3. Allow the engine to cool. Remove the spark plug and put 5
drops of any high quality motor oil or 2-cycle oil into the cylinder.
Pull the starter rope slowly to distribute the oil. Reinstall the
spark plug.
4. Thoroughly clean the unit and inspect it for any loose or
damaged parts. Repair or replace damaged parts and tighten
loose screws, nuts or bolts.
Preparing the Unit for Use after Long-term Storage
1. Remove the spark plug and drain all of the oil from the cylinder.
NOTE: Do not use fuel that has been stored for more than 30 days.
Dispose of old fuel according to federal, state and local regulations.
WARNING: To avoid serious personal injury, always stop
the engine and allow it to cool before cleaning or maintaining
the unit.

15
TROUBLESHOOTING
The engine overspeed protection is engaged Allow the engine to cool down for 10 minutes before restarting the unit
The fuel tank is empty Fill the fuel tank with properly mixed fuel
The primer bulb was not pressed enough Press the primer bulb 10 times or until fuel is visible
The engine is flooded Move the choke lever to Position 3, squeeze the throttle control and
pull the starter rope
The fuel is old (over 30 days) and/or improperly mixed Drain the fuel tank and add fresh, properly mixed fuel
The spark plug is fouled Replace the spark plug
The fuel is old (over 30 days) and/or improperly mixed Drain the fuel tank and add fresh, properly mixed fuel
The cutting head is bound with grass Stop the engine and clean the cutting head
The air filter is dirty Clean or replace the air filter
PROBLEM SOLUTION
The air filter is dirty Clean or replace the air filter
The fuel is old (over 30 days) and/or improperly mixed Drain the fuel tank and add fresh, properly mixed fuel
The idle speed is incorrect Adjust the idle speed
The fuel is old (over 30 days) and/or improperly mixed Drain the fuel tank and add fresh, properly mixed fuel
The air filter is dirty Clean or replace the air filter
The spark plug is fouled Replace the spark plug
THE ENGINE WILL NOT START
THE ENGINE WILL NOT IDLE
THE ENGINE WILL NOT ACCELERATE
THE ENGINE LACKS POWER OR STALLS
THE ENGINE STOPS WHILE IN USE
If further assistance is required, contact an authorized service dealer.

16
The limited warranty set forth below is given by Cub Cadet LLC (Cub Cadet) with respect to new merchandise purchased and used in the
United States, its possessions and territories.
Cub Cadet warrants this product against defects in material and workmanship for a period of three (3) years commencing on the date of
original purchase and will, at its option, repair or replace, free of charge, any part found to be defective in material or workmanship. This
limited warranty shall only apply if this product has been operated and maintained in accordance with the Operator’s Manual furnished with
the product, and has not been subject to misuse, abuse, commercial use, neglect, accident, improper maintenance, alteration, vandalism,
theft, fire, water or damage because of other peril or natural disaster. Damage resulting from the installation or use of any accessory or
attachment not approved by Cub Cadet for use with the product(s) covered by this manual will void your warranty as to any resulting
damage. This warranty is limited to ninety (90) days from the date of original retail purchase for any Cub Cadet product that is used for rental
or commercial purposes, or any other income-producing purpose.
HOW TO OBTAIN SERVICE: Warranty service is available, WITH PROOF OF PURCHASE THROUGH YOUR LOCAL AUTHORIZED SERVICE
DEALER. To locate the dealer in your area, visit our website at www.cubcadet.com or www.cubcadet.ca, check for a listing in the Yellow
Pages, call 1-877-282-8684 or 1-800-668-1238 in Canada, or write to P.O. Box 361131, Cleveland, OH 44136-0019. No product returned
directly to the factory will be accepted unless prior written permission has been extended by the Customer Service Department of Cub Cadet.
This limited warranty does not provide coverage in the following cases:
A. Tune-ups - Spark Plugs, Carburetor Adjustments, Filters
B. Wear items - Bump Knobs, Outer Spools, Cutting Line, Inner Reels, Starter Pulley, Starter Ropes, Drive Belts, Saw Chains, Guide Bars,
Cultivator Tines, Blades.
C. Cub Cadet does not extend any warranty for products sold or exported outside of the United States of America, its possessions and
territories, except those sold through Cub Cadet’s authorized channels of export distribution.
Cub Cadet reserves the right to change or improve the design of any Cub Cadet Product without assuming any obligation to modify any
product previously manufactured.
No implied warranty, including any implied warranty of merchantability or fitness for a particular purpose, applies after the
applicable period of express written warranty above as to the parts as identified. No other express warranty or guaranty, whether
written or oral, except as mentioned above, given by any person or entity, including a dealer or retailer, with respect to any product
shall bind Cub Cadet. During the period of the Warranty, the exclusive remedy is repair or replacement of the product as set forth
above. (Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.)
The provisions as set forth in this Warranty provide the sole and exclusive remedy arising from the sales. Cub Cadet shall not be
liable for incidental or consequential loss or damages including, without limitation, expenses incurred for substitute or replacement
lawn care services, for transportation or for related expenses, or for rental expenses to temporarily replace a warranted product.
(Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.)
In no event shall recovery of any kind be greater than the amount of the purchase price of the product sold. Alteration of the safety features
of the product shall void this Warranty. You assume the risk and liability for loss, damage, or injury to you and your property and/or to others
and their property arising out of the use or misuse or inability to use the product.
This limited warranty shall not extend to anyone other than the original purchaser, original lessee or the person for whom it was purchased
as a gift.
How State Law Relates to this Warranty: This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.
To locate your nearest service dealer, dial 1-877-282-8684 in the United States or 1-800-668-1238 in Canada.
CUB CADET LLC
P.O. Box 361131
Cleveland, OH 44136-0019
MANUFACTURER’S LIMITED WARRANTY FOR:

TABLE DES MATIÈRES
Service technique . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Sécurité . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Apprenez à connaître votre appareil . . . . . . . . . . . . . . . . . . . . . . .21
Caractéristiques . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Assemblage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Huile et carburant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Mise en marche et arrêt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Utilisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Entretien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Nettoyage et entreposage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Dépannage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Garantie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Toutes les informations, illustrations et caractéristiques contenues
dans ce manuel reposent sur les dernières informations disponibles
sur ce produit à la date d’impression. Nous nous réservons le droit
d’apporter à tout instant des modifications, sans préavis.
Copyright© 2013 MTD SOUTHWEST INC, Tous droits réservés.
CONSERVEZ CES
INSTRUCTIONS
Taille-bordure à 2 temps
SS270
SERVICE TECHNIQUE
NE RAMENEZ PAS CET APPAREIL CHEZ LE
REVENDEUR. UNE PREUVE D’ACHAT SERA EXIGÉE
POUR AVOIR RECOURS À LA GARANTIE.
Pour obtenir de l’aide concernant l’assemblage, les commandes,
l’utilisation ou l’entretien de cet appareil, veuillez contacter le service
à la clientèle au 1-877-282-8684 (États-Unis) ou au 1-800-668-1238
(Canada). Pour obtenir des informations supplémentaires sur cet
appareil, visitez le site Internet : www.cubcadet.com (É.-U.) ou
www.cubcadet.ca (Canada).
Pour profiter du service technique, veuillez appeler le service à la
clientèle pour obtenir une liste des centres de réparation agréés les
plus proches. Les réparations de cet appareil doivent être confiées
uniquement à un centre de réparation agréé, à la fois pendant et
après la période de garantie. Lors d’une réparation, utilisez
uniquement des pièces de rechange identiques.
IMPORTANT : Lisez attentivement ce manuel avant d'utiliser ce produit. Respectez toutes les instructions.
769-09453 / 00 11/13
Manuel de l’opérateur

18
• CONSIGNES DE SÉCURITÉ IMPORTANTES •
SÉCURITÉ
NOTE SUR LE PARE-ÉTINCELLES
REMARQUE : à l’intention des utilisateurs sur les terrains
forestiers américains et dans les États de Californie, du Maine,
de l’Oregon et de Washington. Tous les services des forêts
américains et les États de Californie (codes des ressources
publiques 4442 et 4443), de l’Oregon et de Washington exigent, au
titre de la loi, que certains moteurs à combustion interne utilisés
dans les broussailles de forêt et/ou les zones recouvertes d’herbe
soient équipés d’un pare-étincelles, soient maintenus en bon état
de marche, ou soient construits, équipés et entretenus en vue
d’éviter tout risque d’incendie. Veuillez contacter les autorités
nationales ou locales pour connaître les réglementations à cet
égard. Le non-respect de ces exigences pourrait impliquer votre
responsabilité ou entraîner une amende. Cet appareil est équipé
en usine d’un pare-étincelles. Si un remplacement est nécessaire,
communiquez avec votre distributeur local pour l’installation du
silencieux approprié.
Veuillez lire le manuel de l’opérateur et respecter tous
les avertissements et consignes de sécurité. Dans le cas
contraire, l’opérateur et/ou les passants peuvent subir des
blessures graves.
SYMBOLE SIGNIFICATION
AVERTISSEMENT :indique un
danger GRAVE.
Le non-respect d’un symbole d’AVERTISSEMENT PEUT
provoquer des blessures graves de l’opérateur ou d’autres
personnes.
ATTENTION :indique un danger MODÉRÉ.
Le non-respect d’un symbole ATTENTION POURRAIT
provoquer des blessures ou des dommages des biens
de l’opérateur ou d’autres personnes.
Les symboles de sécurité visent à attirer votre attention sur les
dangers éventuels. Vous devez accorder une attention particulière
aux symboles de sécurité afin de bien les comprendre. Les
avertissements de sécurité n’éliminent pas les dangers en eux-
mêmes. Les instructions ou mises en garde ne remplacent en rien
les mesures de prévention appropriées contre les accidents.
REMARQUE : vous donne des informations ou des consignes
essentielles pour l’utilisation ou l’entretien de l’équipement.
DANGER :indique un danger EXTRÊME.
Le non-respect d’un symbole de DANGER ENTRAÎNERA
des blessures graves, voire un décès, de l’opérateur ou
d’autres personnes.
PROPOSITION 65 DE L’ÉTAT DE CALIFORNIE
AVERTISSEMENT :les gaz
d’échappement, certains de leurs constituants et certains
composants finis contiennent ou émettent des produits
chimiques reconnus par l’État de Californie comme étant à
l’origine de cancers ou de malformations congénitales ou
autres dangers pour la reproduction. Lavez-vous les mains
après avoir manipulé l’appareil.
VEUILLEZ LIRE TOUTES LES INSTRUCTIONS AVANT
• Veuillez lire soigneusement ces instructions. Familiarisez-vous
avec les commandes et l’utilisation correcte de l’appareil.
• N’utilisez pas cet appareil quand vous êtes fatigué, malade ou sous
l’influence de boissons alcoolisées, de drogues ou de médicaments.
• Les enfants ne doivent pas utiliser cet appareil. Les adolescents
doivent être supervisés par des adultes.
• Tous les carters et dispositifs de sécurité doivent être
correctement installés avant l’utilisation de cet appareil.
• Inspectez l’appareil avant l’utilisation. Remplacez les pièces
endommagées. Détectez les fuites de carburant éventuelles.
Assurez-vous que toutes les fixations sont en place et bien
serrées. Remplacez les pièces fissurées, ébréchées ou
endommagées d’une manière ou d’une autre. N’utilisez pas
l’appareil quand des pièces sont desserrées ou endommagées.
AVERTISSEMENT :quand vous
utilisez l’appareil, vous devez respecter toutes les règles
de sécurité. Veuillez lire ces consignes avant d’utiliser
l’appareil pour assurer la sécurité de l’opérateur et de tous
les passants. Veuillez conserver ces instructions pour
référence ultérieure.
• Utilisez uniquement le fil de coupe décrit dans la section
Caractéristiques de ce manuel. N’utilisez jamais de fils, de
câbles, de chaînes ou de cordons à renfort métallique. Ils
peuvent se casser et se transformer en projectiles dangereux.
• Ne pas remplacer la tête de coupe par des lames rigides ou en
métal. Cela pourrait entraîner de graves blessures.
• Vous devez être conscient des risques de blessures à la tête,
aux mains et aux pieds.
• Inspectez attentivement la zone de travail avant de démarrer
l’appareil. Retirez les pierres, le verre cassé, les clous, les fils, les
ficelles et autres objets qui peuvent être projetés ou s’enrouler
dans l’appareil.
• Éloignez les enfants, les passants et les animaux domestiques ;
ils doivent rester dans un rayon d’au moins 15 mètres (50 pieds).
Même à cette distance, il existe néanmoins un risque de
projectiles pour les personnes à proximité. Encouragez-les à
porter des lunettes de sécurité. Si quelqu’un s’approche de
vous, arrêtez immédiatement l’appareil.
• Appuyez sur la manette des gaz et vérifiez qu’elle revient
automatiquement à la position de ralenti. Effectuez tous les
réglages ou réparations avant d’utiliser l’appareil.
• Cet appareil est uniquement destiné à un usage domestique
occasionnel.

19
AVERTISSEMENTS DE SÉCURITÉ POUR LES APPAREILS
À GAZ
• Stockez le carburant uniquement dans des récipients
spécifiquement conçus à cet usage et approuvés pour le
stockage de telles substances.
• Arrêtez toujours le moteur et laissez-le refroidir avant de remplir
le réservoir d’essence. N’enlevez jamais le bouchon du réservoir
de carburant ou ne remplissez jamais ce dernier quand le
moteur est chaud. Dévissez toujours lentement le bouchon du
réservoir de carburant afin de relâcher toute pression présente
avant de le remplir.
• Mélangez et ajoutez toujours le carburant dans une zone
extérieure propre et bien aérée, en l’absence totale d’étincelles
ou de flammes. NE fumez PAS.
• N’utilisez jamais l’appareil quand le bouchon du réservoir de
carburant n’est pas correctement vissé.
• Évitez de créer une source d’inflammation en présence d’un
déversement de carburant. Essuyez immédiatement tout carburant
échappé du réservoir avant de démarrer l’appareil. Éloignez
l’appareil à 9,1 mètres (30 pieds) au moins de la source de
ravitaillement et du site avant de démarrer le moteur. NE fumez PAS.
• Ne démarrez jamais ou n’utilisez jamais l’appareil à l’intérieur
d’un espace ou d’un bâtiment clos. L’inhalation des fumées
d’échappement peut tuer. Utilisez cet appareil uniquement dans
une zone extérieure bien aérée.
AVERTISSEMENT :l’essence est
extrêmement inflammable et ses vapeurs peuvent exploser
en présence d’une source d’inflammation. Prenez les
précautions suivantes :
PENDANT L’UTILISATION
• Portez des lunettes de sécurité conformes aux normes ANSI / ISEA
Z87.1 en vigueur et marquées comme telles. Portez une protection
auditive pendant l’utilisation de cet appareil. Portez un écran facial
ou un masque antipoussières si la tâche est poussiéreuse.
• Portez un pantalon long et épais, des bottes, des gants et une
chemise à manches longues. Ne portez pas des vêtements
amples, des bijoux, un pantalon court, des sandales et ne travaillez
pas pieds nus. Attachez vos cheveux au-dessus des épaules.
• Le carter de la tête de coupe doit toujours être en place pendant
l’utilisation de l’appareil. N’utilisez pas l’appareil sans que les
deux fils de coupe soient tendus et que le fil correct soit installé.
Ne tirez pas le fil de coupe au-delà du carter de protection.
• Cet appareil est doté d'un embrayage. La tête de coupe reste
immobile quand le moteur tourne au ralenti. Si ce n'est pas le
cas, apporter l'appareil à un centre de réparation agréé pour
obtenir un ajustement.
• Ajustez la poignée pour procurer une meilleure prise, le cas échéant.
• Assurez-vous que l'accessoire n'est pas en contact avec quoi
que ce soit avant de démarrer l'appareil.
• Utilisez l’appareil uniquement en plein jour ou avec un bon
éclairage artificiel.
• Évitez tout démarrage accidentel. Placez-vous dans la position de
démarrage dès que vous tirez sur le câble de démarreur. L’opérateur
et l’appareil doivent être dans une position stable pendant le
démarrage. Consultez les sections Mise en marche et Arrêt.
• Utilisez le bon outil. Utilisez uniquement cet outil pour l’usage prévu.
• Tenez toujours l’appareil à deux mains lorsqu’il est en marche.
Tenez fermement les deux anses ou poignées.
• Ne vous penchez pas trop en avant. Conservez toujours une
position stable et un bon équilibre. Redoublez de prudence
lorsque vous travaillez dans des escaliers, des pentes ou des
rampes abruptes. Pour éviter les blessures graves, n'utilisez pas
l'appareil lorsque vous vous trouvez sur une échelle ou un toit.
• Éloignez vos mains, votre visage et vos pieds des pièces
mobiles. Ne touchez pas ou n’essayez pas d’arrêter des pièces
en mouvement.
• Ne touchez pas le moteur, le carter d’engrenage ou le pot
d’échappement. Ces composants deviennent extrêmement
chauds pendant l’utilisation, même après l’arrêt de l’appareil.
• N’utilisez pas l’appareil à une vitesse supérieure à celle
nécessaire pour réaliser le travail. Ne faites pas fonctionner
l’appareil à haute vitesse quand vous ne l’utilisez pas.
• Ne forcez pas l’appareil. Il sera plus efficace et plus sûr si vous
l’utilisez à la vitesse pour laquelle il a été conçu.
• Arrêtez toujours l’appareil quand le travail est interrompu ou
quand vous vous déplacez d'un endroit à un autre.
• Si vous heurtez ou enroulez un objet étranger dans l’appareil,
arrêtez immédiatement l’appareil et vérifiez les dommages
éventuels. Ne redémarrez pas l’appareil avant de l’avoir réparé.
N’utilisez pas l’appareil quand des pièces sont desserrées ou
endommagées.
• Arrêtez le moteur et débranchez la bougie pour les tâches
d’entretien ou les réparations.
• Utilisez uniquement des pièces et des accessoires de rechange
du fabricant d’origine pour cet appareil. Ils sont disponibles
auprès de votre centre de réparation agréé. L’utilisation d’autres
pièces ou accessoires pourrait entraîner de graves blessures de
l’utilisateur ou endommager l’appareil, et annuler la garantie.
• L’appareil doit rester propre. Retirez avec précaution la végétation
et autres débris qui pourraient bloquer les pièces mobiles.
• Pour réduire les risques d’incendie, remplacez un pot
d’échappement et un pare-étincelles défectueux. Nettoyez l’herbe,
les feuilles, les couches de graisse excessives ou les dépôts de
carbone présents sur le moteur et le pot d’échappement.
• Si l’appareil commence à vibrer de façon anormale, arrêtez-le
immédiatement. Inspectez l’appareil pour découvrir l’origine des
vibrations. Les vibrations indiquent en général un problème.
AUTRES AVERTISSEMENTS DE SÉCURITÉ
• Toutes les réparations, autres que les procédures de
maintenance décrites dans ce manuel, doivent être effectuées
par un centre de réparations agréé.
• Avant une inspection, un entretien, un nettoyage, un entreposage,
un transport ou le remplacement d’une pièce de l’appareil :
1. Arrêtez l’appareil.
2. Assurez-vous que toutes les pièces mobiles se sont arrêtées.
3. Laissez l’appareil refroidir.
4. Débranchez le fil de la bougie.
• Assurez-vous que l’appareil est sécurisé pour les transports.
• Quand le réservoir contient du carburant, ne rangez jamais
l’appareil à l’intérieur d’un bâtiment où des vapeurs d’essence
pourraient atteindre une flamme nue (veilleuses, etc.) ou des
étincelles (interrupteurs, moteurs électriques, etc.).
• Rangez l’appareil dans un endroit sec et sûr ou en hauteur pour
éviter une utilisation non autorisée ou des dommages. Gardez
toujours l’appareil hors de portée des enfants.
• Ne mouillez pas ou n’éclaboussez pas l’appareil avec de l’eau ou
tout autre liquide. Gardez les poignées sèches et propres (sans
débris, huile et graisse). Nettoyez l’appareil après chaque
utilisation. Consultez la section Nettoyage et entreposage.
N'utilisez pas de solvants ou de puissants détergents.

20
• SYMBOLES DE SÉCURITÉ ET INTERNATIONAUX •
Le présent manuel de l’opérateur décrit les symboles et pictogrammes de sécurité et internationaux, susceptibles d’apparaître sur ce
produit. Veuillez lire le manuel de l’opérateur pour connaître les informations complètes sur la sécurité, l’assemblage, l’utilisation, l’entretien
et la réparation.
SYMBOLE SIGNIFICATION SYMBOLE SIGNIFICATION
• SYMBOLE D’ALERTE DE SÉCURITÉ
Indique un danger, un avertissement ou une mise en
garde. Peut être utilisé conjointement avec d’autres
symboles ou pictogrammes.
• LISEZ LE MANUEL DE L’OPÉRATEUR
AVERTISSEMENT :veuillez
lire le(s) manuel(s) de l’opérateur et respecter tous les
avertissements et consignes de sécurité. Dans le cas
contraire, l’opérateur et/ou les passants peuvent subir
des blessures graves.
• PORTEZ DES PROTECTIONS AUDITIVES ET
OCULAIRES
AVERTISSEMENT :la
projection d’objets et les bruits forts peuvent provoquer
des blessures oculaires graves et une perte auditive.
Portez une protection oculaire conforme aux normes
ANSI / ISEA Z87.1 en vigueur, ainsi qu’une protection
auditive pendant l’utilisation de cet appareil. Utilisez un
écran facial complet dès que nécessaire.
• ESSENCE SANS PLOMB
Utilisez toujours de l’essence sans plomb, propre et
neuve.
• HUILE
Consultez le manuel de l’opérateur pour connaître le
type d’huile à utiliser.
• N’UTILISEZ PAS UN CARBURANT E85 DANS CET
APPAREIL
AVERTISSEMENT :il a été
prouvé qu’un carburant contenant plus de 10 %
d’éthanol est susceptible d’endommager ce moteur et
d’annuler la garantie.
• COMMANDE DE MARCHE/ARRÊT
ALLUMAGE / DÉMARRAGE / MARCHE
• COMMANDE DE MARCHE/ARRÊT
ARRÊT
• POIRE D’AMORÇAGE
Poussez complètement et lentement la poire
d’amorçage à 10 reprises.
• COMMANDE DE L’ÉTRANGLEUR
1. • Position d’étranglement MAXIMUM
2. • Position d’étranglement PARTIELLE
3. • Position d’étranglement MARCHE
• LES OBJETS PROJETÉS ET LA TÊTE ROTATIVE
PEUVENT PROVOQUER DES BLESSURES GRAVES
AVERTISSEMENT :les petits
objets peuvent être propulsés à des vitesses élevées,
provoquant des blessures. Tenez-les à l’écart du rotor
en mouvement.
• ÉLOIGNEZ LES PASSANTS
AVERTISSEMENT :éloignez
tous les passants, en particulier les enfants et les
animaux domestiques, à 15 m (50 pieds) au moins de
la zone de coupe.
• SURFACE CHAUDE
AVERTISSEMENT :ne
touchez pas un pot d’échappement ou un cylindre
chaud. Vous pourriez vous brûler. Ces éléments
chauffent énormément lorsque l’appareil est en
marche. Ils restent chauds pendant un court instant
après l’arrêt.
• LAME TRANCHANTE
AVERTISSEMENT :lame
tranchante sur le
carter de protection de l’accessoire de coupe.
Pour éviter toute blessure grave, ne touchez pas
la lame du coupe-fil.
• Conservez ces instructions. Consultez-les souvent et utilisez-les
pour former d’autres utilisateurs. Si vous prêtez cet appareil à
d’autres personnes, remettez-leur également ces instructions.
CONSERVEZ CES
INSTRUCTIONS
