Cub Cadet 19B70064100 Assembly instructions

Form No. 769-23150A
September 17, 2020
Contents of Carton
Ref Part # Description Qty
1710-3168 Carriage Bolt 3/8-16 X 1.00 Gr5 4
2710-3178 Carriage Bolt 3/8-16 X 0.75 Gr5 9
3712-05007 Hex Flange Nuts 13
4742-04278A-X XTREME™ Mulch Blade (48” Deck) 3
501005380-X XTREME™ Mulch Blade (54” Deck) 3
601005381-X XTREME™ Mulch Blade (60” Deck) 3
7689-02359 Discharge Baffle (48” Deck) 1
8689-02360 Discharge Baffle (54” Deck) 1
9689-02362 Discharge Baffle (60” Deck) 1
10 703-07182A Center Baffle (48” Deck) 1
11 703-07194 Center Baffle (54” Deck) 1
12 703-07178A Center Baffle (60” Deck) 1
13 703-07210A Left Baffle (48” Deck) 1
14 703-07193A Left Baffle (54” Deck) 1
15 703-07177A Left Baffle (60” Deck) 1
Installation Sheet
19B70064100 (48”); 19B70065100 (54”); 19B70066100 (60”) -- Mulch Kit
13
4
5
6
7
8
9
10
11
12
14
15
1
2
3
48” Deck
54” Deck
60” Deck
Figure 1
CUB CADET LLC, P.O. BOX 361131, CLEVELAND, OHIO 44136-0019
Blade Installation
WARNING
Before beginning installation, place the tractor on a firm and level surface, set the
parking brake, place the PTO in the disengaged (OFF) position, stop the tractor’s engine
and remove the ignition key to prevent unintended starting.
WARNING
Cutting blades are sharp. Always protect hands by wearing heavy leather work gloves
to grasp blades.
1. Remove cutting deck from beneath tractor as instructed in your Operator’s Manual.
2. Gently flip deck over to expose
its underside.
IMPORTANT! Flipping the deck will require
two people.
3. Place a block of wood between deck
housing baffle and cutting blade to
act as a stabilizer, then use a wrench
to remove hex flange nut securing
each blade to its spindle assembly. See
Figure 2.
IMPORTANT! Hex flange nuts have a
right-handed (normal) thread pattern. Do NOT
attempt to force nuts in opposite direction.
Doing so may damage nut.
4. Remove chute deflector baffle from
underside of deck by removing two
carriage bolts and flange lock nuts
that secure it to deck. See Figure 3.
5. When baffle is removed, re-install one
carriage bolt and flange lock nut into
deck in most central opening. See
Figure 3.
NOTE: Replacing hardware keeps material
from escaping the deck.
6. Replace blades with blades included in
kit. Be sure to install each blade with
side marked ‘‘Bottom’’ (or with a part
number stamped on it) facing the ground when mower is in operating position.
IMPORTANT! Use a torque wrench to tighten each blade spindle’s hex flange nut to between 90 ft-lb
and 110 ft-lb.
Baffle Installation
CAUTION
Do not remove cutting deck’s discharge chute when operating mower with mulch
kit installed.
1. Install center baffle using four 3/4”
carriage bolts (710-3178) and four hex
flange nuts (712-05007). See Figure 4.
2. Install discharge baffle in the
following order:
a. Install discharge baffle to
underside of top of deck with
two 1” carriage bolts (710-
3168) and two hex flange nuts
(712-05007). See Figure 5.
b. Working from inside out,
secure discharge baffle to
outside wall of deck with two
1” carriage bolts (710-3168)
and two hex flange nuts (712-
05007). See (1) in Figure 6.
c. Stabilize discharge baffle by
connecting it to previously
installed center baffle with two
3/4” carriage bolts (710-3178)
and two hex flange nuts (712-
05007). See (2) in Figure 6.
3. Install left baffle using three 3/4”
carriage bolts (710-3178) and three hex flange nuts (712-05007). See Figure 7.
Figure 2
Figure 3
Figure 4
Figure 5
1
2
Figure 6
Figure 7

LIMITED WARRANTY
The limited warranty set forth herein is given by Cub Cadet LLC with respect to
a new Spreader (hereinafter “Attachment”) purchased and used in the United
States and/or Canada to the Initial Purchaser (as defined herein). For Canadian
sales, the warranty is provided by MTD Products Limited.
Scope of the Limited Warranty
Cub Cadet LLC offers the following limited warranty to the Initial
Purchaser for residential or otherwise non-commercial use: except
for the Exclusions (defined herein), during the Warranty Period (as
defined herein), this Attachment will be free from manufacturing
defects (including workmanship and materials). The “Initial
Purchaser” is the first person to purchase this new Attachment from
an authorized Cub Cadet dealer, distributor and/or retailer of such
products. This limited warranty is non-transferrable. Except as
otherwise set forth herein, the limited warranty period for this new
Attachment purchased by the Initial Purchaser is one (1) year from
the date of purchase as shown on the original sales receipt for the
product (“Warranty Period”).
Defects in Workmanship or Materials
Except for the Exclusions, this Attachment is warranted to be free from
manufacturing defects in either workmanship or materials for the Warranty
Period. During the Warranty Period, Cub Cadet LLC will, at its option, either
repair or replace any original part that is covered by this limited warranty and
is determined to be defective in workmanship or material.
To qualify for this limited warranty this Attachment:
1. Must have been purchased from an authorized retailer.
2. Must have been purchased within the United States or Canada by the
Initial Purchaser.
3. Must have been used for residential purposes only.
4. Must have been used in a manner consistent with the normal and
proper intended use for this Attachment. This Attachment is not
intended for rental or commercial use.
Who can perform repairs under this warranty?
In order to qualify for the limited warranty as set forth herein, the repairs
made under this warranty must be performed by an authorized Cub Cadet
service provider.
How to get service under this limited warranty:
To locate a Cub Cadet warranty service provider, contact your authorized Cub
Cadet dealer, distributor, or retailer or contact Cub Cadet LLC at P.O. Box 361131,
Cleveland, Ohio 44136-0019 or call 1-877-282-8684 or log on to our Website at
www.cubcadet.com. In Canada, contact MTD Products Limited, Kitchener, ON
N2G 4J1, or call 1-800-668-1238 or log on to our Web site at www.mtdcanada.
com. This limited product warranty is provided by Cub Cadet LLC and is the only
product warranty provided by Cub Cadet LLC for this Attachment. A COPY OF
YOUR SALES RECEIPT IS REQUIRED FOR WARRANTY SERVICE.
What this limited warranty does not cover.
This limited warranty does not cover the following (the “Exclusions”):
1. Product purchased outside of the United States or Canada.
2. Damage due to lack of maintenance and/or improper maintenance as
described in the operator’s manual
3. Normal wear and tear resulting from use of the product.
4. Any expendable, consumable, or routine maintenance item which
needs replacement or service as part of normal maintenance, unless
such items have defects that cause failure or premature wear within the
first thirty (30) days of purchase. Normal wear items include but are not
limited to, tires, fuses, blades, batteries, belts, hoses, string trimmer line,
engine oil, hydraulic oil, grass bags, and other consumable items where
applicable, or adjustments, such as clutch, brake or deck adjustments
or tune-ups.
5. Use of the product that is not consistent with the intended use
thereof as described in the operating instructions, including, but not
limited to, abuse, misuse and/or neglect of the Attachment or any use
inconsistent with and/or non-compliant with instructions contained in
the Operator’s Manual.
6. Any Attachment that has been altered or modified in a manner not
consistent with the original design of the Attachment or in a manner
not approved by Cub Cadet LLC.
7. Paint repairs or replacements for defective paint (including materials
and application) are covered for a period of three (3) months; provided
however, that this limited warranty for defective paint does not apply
to and shall not cover damage(s) to the paint application resulting from
exposure to weather conditions and/or resulting from normal use of the
Attachment, including misuse.
This warranty does not cover and Cub Cadet LLC disclaims any responsibility
for:
1. Loss of time or loss of use of the Attachment.
2. Transportation costs and other expenses incurred in connection with
the transport of the Attachment to and from the authorized Cub Cadet
service provider.
3. Any loss or damage to other equipment or personal items.
4. Damages caused by improper maintenance or the use of other than the
specified fuel, oil or lubricants as approved in the operator’s manual.
5. Damage resulting from the installation or use of any accessory or part
not approved by Cub Cadet for use with the Attachment.
Limitations:
1. THERE ARE NO IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED
TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE. NO WARRANTY SHALL APPLY AFTER THE
APPLICABLE WARRANTY PERIOD AS SET FORTH ABOVE AS TO THE
PARTS AS IDENTIFIED. NO OTHER EXPRESS WARRANTY OR GUARANTY,
WHETHER WRITTEN OR ORAL, EXCEPT AS MENTIONED ABOVE, GIVEN
BY ANY PERSON OR ENTITY, INCLUDING A DEALER OR RETAILER, WITH
RESPECT TO ANY PRODUCT SHALL BIND CUB CADET LLC. DURING THE
WARRANTY PERIOD, THE EXCLUSIVE REMEDY IS REPAIR OR REPLACEMENT
OF THE DEFECTIVE PART, AS SET FORTH ABOVE. (SOME STATES DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO
THE ABOVE LIMITATION MAY NOT APPLY TO YOU.)
2. THE PROVISIONS AS SET FORTH HEREIN PROVIDE THE SOLE AND
EXCLUSIVE REMEDY ARISING FROM THE SALE. CUB CADET SHALL NOT
BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL LOSS OR DAMAGES
INCLUDING, WITHOUT LIMITATION, FOR TRANSPORTATION OR FOR
RELATED EXPENSES, OR FOR RENTAL EXPENSES TO TEMPORARILY REPLACE
A WARRANTED PRODUCT. (SOME STATES DO NOT ALLOW THE EXCLUSION
OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE EXCLUSION OR LIMITATION MAY NOT APPLY TO YOU.)
3. In no event shall recovery of any kind be greater than the amount of the
purchase price of the product sold. Alteration of the safety features of
the product shall void this limited warranty. You assume the risk and
liability for loss, damage, or injury to you and your property and/or to
others and their property arising out of the use or misuse or inability to
How State Law Relates to this Warranty:
This limited warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
CUB CADET LLC
LIMITED WARRANTY  ATTACHMENTS AND ACCESSORIES
Cub Cadet LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019, Phone: [phone]
MTD Products Limited, Kitchener, ON N2G 4J1, Phone: [phone]
108402
