Cuisinart C790SR User manual

CUISINART™ C790SR
Assembly Manual
85-3032-4 (G51217) Propane
85-3033-2 (G51218) Natural Gas
LIMITED 5YEAR WARRANTY
Manual Revision #: 17052011 PD
Read and save manual for future reference.
Assemble your grill immediately.
Missing or damaged parts should be
claimed within 30 days of purchase.
For product inquiries, parts, warranty and troubleshooting support,
please call 1-800-309-3452.
www.cuisinartbbqs.com
TM

1
WARNING
Failure to follow all of the Manufacturer’s
instructions could result in hazardous res,
explosions, property damage, or serious
personal injury or even death.
Follow all leak check procedures carefully
prior to operation of barbecue, even if grill
was dealer assembled. Do not try to light
this barbecue without reading the Lighting
Instructions section of this manual.
THIS MANUAL MUST REMAIN WITH THE PRODUCT AT ALL TIMES
CAUTION
Read and follow all safety statements,
assembly instructions, and use and
care directions before attempting to
assemble and cook.
CAUTION
Sharp edges. Wear gloves when assembling
your grill.
THIS BARBECUE IS FOR OUTDOOR USE ONLY
CONTACT CALL CENTRE IF ANY PARTS ARE MISSING
INSTALLER OR ASSEMBLER/CONSUMER
This manual should be kept with the BBQ at
all times.
HEAVY ARTICLE NEEDS 2 TO LIFT
Caution:
Sheet metal can cause injury. Wear gloves when installing the grill.
HARDWARE PACK
¼” - 20UNCX13 Screw
X 8
ø7 Lock Washer
X 20
ST4.2x10 Tapping Screw
X 4
¼” - 20UNCX38 Screw
X 4
ø7 Washer
X 20
ø5 Lock Washer
X 24
¼” - 20UNCX16 Screw
X 8
NO. 10-24UNC10 Screw
X 24
ø5 Washer
X 24
U Pin
X 1
NO. 8-32UNCx10 Screw
X 4
1 2 3
4 5 6
7 8 9
10 11 12
13
Wing Nut
X 1
Control Knob
X 1
TOOLS NEEDED FOR ASSEMBLY
• #2 Phillips screwdriver (Long and short)
• ¼” Slotted screwdriver (Long and short)
• Adjustable wrench
• Pliers
• Rubber Mallot
Before assembling the barbecue, read these
instructions carefully.
Assemble the barbecue on a at, clean surface.
Grill is heavy.
Notes: Do not fully tighten all the nuts during
this initial stage.
No. Description Part Number Quantity
1 ¼"-20UNCX13 Screw 20120-13013-250 8
2 ¼"-20UNCX38 Screw 20120-13038-250 4
3 ¼"-20UNCX16 Screw 20120-13016-250 8
4 ø7 Lock Washer 41400-07000-250 20
5 ø7 Washer 40300-07000-250 20
6 NO.10-24UNCx10 Screw 20124-10010-250 24
7 ø 5 Lock Washer 41400-05000-250 24
8 ø 5 Washer 40300-05000-250 24
9 ST4.2x10 Tapping Screw 22500-42010-137 4
10 U Pin G350-0026-9000 1
11 NO.8-32UNCx10 Screw 20332-08010-250 4
12 Control Knob G412-4500-9000 1
13 Wing Nut 33301-04000-032 1
14 Venturi Clip, Side Burner G405-0019-9200 1
1-800-309-3452
To ORDER non-warranty replacement parts or accessories, or to register your warranty,
please visit us on the web at
www.cuisinartbbqs.com
DANGER
1. If you smell Gas:
a. Shut o gas to the appliance
b. Extinguish any open ame
c. Open lid
d. If odor continues, keep away from
the appliance and immediately
call your gas supplier or your
re department
2. Requires two people to complete the
assembly process.
3. Beware of sharp edges.
WARNING
1. Do not store or use gasoline or other
ammable liquids or vapours in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
14
Venturi Clip, Side Burner
X 1

2 3
PARTS LIST (PROPANE) FOR 85-3032-4 (G51217) EXPLODED DIAGRAM (PROPANE) FOR 85-3032-4 (G51217)
Item Qty. Description Part No.
CN 1 Upper Back Panel G512-0036-01
CO 1 Heat Shield G512-0026-01
DA 1 Side Shelf Table- Left G512-0600-02
DB 1 Side Shelf Fascia- Left G512-0065-01
DC 1 Side Burner Drip Pan G617-0035-01
DD 1 Side Burner G433-1400-01
DE 1 Electrode Set, Sideburner G433-0047-01
DF 1 Lid-Sideburner G501-0070-01
DG 1 Cooking Grate, Sideburner G501-0077-01
DH 1 Side Shelf Table- Right G512-0500-02
DI 1 Side Shelf Fascia-Right G512-0064-01
EA 1 Cart Side Panel-Left G512-0700-01
EB 1 Cart Side Panel, Right G512-0800-01
EC 1 Pillar, Left G512-B400-01
ED 1 Pillar, Right G512-8700-01
EE 2 Magnet Assembly G501-00F2-02
EF 1 Door Assembly G512-B300-01
EG 1 Bottom Shelf G512-9800-01
EH 2 Wheel with Lock G515-0082-01
EI 2 Wheel G350-0024-01
F1 1 Hardware Pack G512-B017-01
F2 1 Instruction Manual G512-M017-01
F3 1 Safety & Care Manual G412-M008-02
F4 1 Tank Screw G505-0047-01
Item Qty. Description Part No.
AA 1 Top Lid G512-B800-01
AB 1 Lid Handle G512-0053-01
AC 1 Thermometer G512-0085-01
AD 2 Screw for Top Lid G501-0005-02
AE 2 Lid Bumper G508-0063-01
BA 1 Burner Box Assembly G512-B500-01
BB 1 Upper Side Panel- Left G512-C200-01
BC 1 Upper Side Panel- Right G512-B200-01
BD 2 Main Burner-A G607-0700-A1
BE 1 Main Burner-B G502-1800-A1
BF 1 Carryover Assembly G502-0012-01
BG 3 Flame Tamer G512-0079-01
BH 3 Cooking Grate, Burner Box G512-0062-01
BI 1 Warming Rack G512-0080-01
BJ 1 Stainless Steel Rotisserie Burner G501-B100-01
BK 1 Electrode Set, Rotisserie Burner G508-0009-01
BL 1 Wind Shield, Rotisserie G501-00B1-01
BM 1 Match Holder G608-0019-01
BN 1 Towel Bar G512-0063-01
CA 1 Manifold Assembly G512-7800-01
CB 1 Regulator G433-0034-01
CC 1 Valve, Sideburner G512-0055-01
CD 1 Metal Hose, Sideburner G608-0039-01
CE1 1 Rotisseries Flexible Hose G601-0055-A1
CE2 1 Rotisseries LP Orice G601-0055-03
CE3 1 Rotisseries Burner Collector Box G501-00C1-01
CF1 1 Electronic Igniter Assembly G512-0070-02
CF2 1 Electronic Ignition Button G512-0070-01
CG 3 Electrode Set, Main Burner G512-0059-01
CH 3 Control Knob Assy G512-7900-01
CI 1 Rotisserie Knob Assy G512-9400-01
CJ 1 Control Panel G512-0056-01
CK 1 Front Brace G512-0043-01
CL 1 Grease Tray G512-A000-01
CM 1 Grease Cup G416-0015-01
CE1
CE3
CE2 BL
BI
CD
CA
CC
CB
DG DF
BB
DA
DD
DE
DB
EC
EE
EA
BM
F1
F2
F3
CN
CK
CO
DC
CJ
CI
AE
AD
BH
BG
BJ
BC
EF
BK
BA
DH
DI
CL
CM
EB
EG
EI EH
ED BN
CH
CG
CF2
CF1
BE
BF
BD
AA
AB
AC
Assembly
Manual
Safety & Care
Manual
Hardware
Pack
Extras
No.12

4 5
PARTS LIST (NATURAL GAS) FOR 85-3033-2 (G51218) EXPLODED DIAGRAM (NATURAL GAS) FOR 85-3033-2 (G51218)
Item Qty. Description Part No.
CN 1 Upper Back Panel G512-0036-01
CO 1 Heat Shield G512-0026-01
DA 1 Side Shelf Table- Left G512-0600-02
DB 1 Side Shelf Fascia- Left G512-0065-01
DC 1 Side Burner Drip Pan G617-0035-01
DD 1 Side Burner G433-1400-01
DE 1 Electrode Set, Sideburner G433-0047-01
DF 1 Lid- Sideburner G501-0070-01
DG 1 Cooking Grate, Sideburner G501-0077-01
DH 1 Side Shelf Table- Right G512-0500-02
DI 1 Side Shelf Fascia-Right G512-0064-01
EA 1 Cart Side Panel-Left G512-0700-01
EB 1 Cart Side Panel, Right G512-0800-01
EC 1 Pillar, Left G512-B400-01
ED 1 Pillar, Right G512-8700-01
EE 2 Magnet Assembly G501-00F2-02
EF 1 Door Assembly G512-B300-01
EG 1 Bottom Shelf G512-A700-01
EH 2 Wheel with Lock G515-0082-01
EI 2 Wheel G350-0024-01
F1 1 Hardware Pack G512-B017-01
F2 1 Instruction Manual G512-M017-01
F3 1 Safety & Care Manual G412-M008-02
Item Qty. Description Part No.
AA 1 Top Lid G512-B800-01
AB 1 Lid Handle G512-0053-01
AC 1 Thermometer G512-0085-01
AD 2 Screw for Top Lid G501-0005-02
AE 2 Lid Bumper G508-0063-01
BA 1 Burner Box Assembly G512-B500-01
BB 1 Upper Side Panel- Left G512-C200-01
BC 1 Upper Side Panel- Right G512-B200-01
BD 2 Main Burner-A G607-0700-A1
BE 1 Main Burner-B G502-1800-A1
BF 1 Carryover Assembly G502-0012-01
BG 3 Flame Tamer G512-0079-01
BH 3 Cooking Grate, Burner Box G512-0062-01
BI 1 Warming Rack G512-0080-01
BJ 1 Stainless Steel Rotisserie Burner G501-B100-01
BK 1 Electrode Set, Rotisserie Burner G508-0009-01
BL 1 Wind Shield, Rotisserie G501-00B1-01
BM 1 Match Holder G608-0019-01
BN 1 Towel Bar G512-0063-01
CA 1 Manifold Assembly G512-A200-01
CB 1 Natural Gas Hose G501-0099-01
CC 1 Valve, Sideburner G512-0067-01
CD 1 Metal Hose, Sideburner G608-0039-01
CE1 1 Rotisseries Flexible Hose G601-0055-A1
CE2 1 Rotisseries NG Orice G601-0055-04
CE3 1 Rotisseries Burner Collector Box G501-00C1-01
CF1 1 Electronic Igniter Assembly G512-0070-02
CF2 1 Electronic Ignition Button G512-0070-01
CG 3 Electrode Set, Main Burner G512-0059-01
CH 3 Control Knob Assy G512-7900-01
CI 1 Rotisserie Knob Assy G512-9400-01
CJ 1 Control Panel G512-0056-01
CK 1 Front Brace G512-0043-01
CL 1 Grease Tray G512-A000-01
CM 1 Grease Cup G416-0015-01
CE1
CE3
CE2 BL
BI
CD
CA
CC
DG DF
BB
DA
DD
DE
DB
EC
No.12
EE
EA
BM
F1
F2
F3
CN
CK
CO
DC
CJ
CI
AE
AD
BH
BG
BJ
BC
EF
BK
BA
DH
DI
CL
CM
EB
EG
EI EH
ED
CB
BN
CH
CG
CF2
CF1
BE
BF
BD
AA
AB
AC
Assembly
Manual
Safety & Care
Manual
Hardware
Pack
Extras

6 7
1 3
24
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS
8
8
7
7
6
6
YOU WILL NEED:
YOU WILL NEED:
6
1
7
4
8
5
EA
EB
EG
Front view
Ensure that the wheels are rmly locked in the
“ON”position before continuing.
Assemble the left side panel (EA) and the right
side panel (EB) to the bottom shelf (EG).
Close up
Attach the front brace (CK) to the left and right
cart side panels (EA and EB)
TIP: One person should align the left side, while
the second person assembles the right side.
EB
CK
EA
Back view
X 6 X 6 X 6
X 4 X 4 X 4
876
YOU WILL NEED:
6 7 8
X 8 X 8 X 8
Left pillar to cart side panel
Left pillar to bottom panel
Left pillar to front brace
Close up
A
EC
EA
B
CK
CEG
EA
a. Assemble the left and right pillars (EC and ED)
to the cart side panels (EA and EB), as shown in
gure A.
b. Assemble the left and right pillars (EC and ED)
to the front brace (CK), as shown in gure B.
c. Assemble the left and right pillars (EC and ED)
to the bottom panel (EG), as shown in gure C.
TIP: One person should align the left side, while
the second person assembles the right side.
Separate the 2 dierent types of wheels,
2 locking wheels (EH) and 2 regular wheels (EI).
Insert the U Pin (#10) into one of the regular
wheels (EI), as shown in image B. Attach the
regular wheel (EI) to the front of the bottom
shelf (EG), and use the U Pin (#10) to secure and
tighten.
Repeat for remaining 3 wheels (EI & EH).
NOTE: Regular wheels (EI) need to be
assembled to the front of the bottom
shelf (EG), and wheels with lock (EH)
need to be assembled to the back of the
bottom shelf (EG), as shown in image A.
Close up
6
10
X 1
YOU WILL NEED:
A
B
EI
EG
Back view
EH

8 9
5
6
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS
YOU WILL NEED:
7
8
2 4 5
a. Position the top lid and burner box assembly
(A and B) onto cart assembly (C) as shown.
b. Use the hardware to connect both parts, on
the left and right sides, at the three points
indicated in Figure B and C.
THIS STEP REQUIRES 3 OR MORE PEOPLE.
DO NOT ATTEMPT ALONE. EXTREMELY
HEAVY.
BC
A
Attach the upper back panel (CN) to both the left
and right side panels (EA and EB).
Only install hardware in the bottom portion of the
back panel, as shown in gure B.
DO NOT TIGHTEN SCREW UNTIL SIDE SHELF HAS
BEEN INSTALLED
CN
Back view
EB
EA
A+B
C
B
Attach the right side shelf fascia (DI) to the right
side shelf table (DH), as shown.
DI
DH
TIP: To position the right side shelf, insert the two
hooks on the side shelf assembly into the two
support brackets located on the right upper side
panel (BC).
Assemble the right side shelf assembly to the cart
assembly, as shown in gure B.
DH
DI
B
BC
876
YOU WILL NEED:
6 7 8
X 6
X 2
X 6
X 2
X 6
X 2
876
YOU WILL NEED:
6 7 8
X 3 X 3 X 3
YOU WILL NEED:
A
B
B
B
B
2
3
4
4
5
5
X 1X 1X 1
X 4 X 4 X 4
BA
Side view Back view

10 11
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS
11
10
9
YOU WILL NEED:
12
Attach the left side shelf fascia (DB) to the left side
shelf table (DA).
DA
DB
Front
DA
DB
*
A
B
TIP: To position the left side shelf, insert the two
hooks on the side shelf assembly into the two
support brackets located on the upper left side
panel (BB).
Assemble the left side shelf assembly to the cart
assembly, as shown in gure B.
BB
Remove the hardware that is pre-assembled to the
side burner valve bracket (CC), as shown in gure
A. Insert the side burner valve stem through the
rear of the left side shelf fascia (DB). Assemble the
side burner valve (CC) to the side shelf fascia (DB),
using the hardware removed.
Assemble the side burner control knob (#12) to
the side burner valve (CC).
Hardware may be included with the hardware
pack.
DA
DB
CC
A
876
YOU WILL NEED:
6 7 8
X 3 X 3 X 3
X 1
YOU WILL NEED:
A
A
B
B
B
B
B
2
3
4
4
5
5
X 1X 1X 1
X 4 X 4 X 4
B
12

12 13
ASSEMBLY INSTRUCTIONS
12
d. Using the wing nut provided, assemble the
side burner to the side burner drip pan (DC), as
shown in gure D.
e. Attach the end of the side burner electrode wire
(DE) to the underside of the side burner elec-
trode, as shown in gure E.
Ensure that the wire is pushed in rmly.
DE
f. Place the side burner cooking grate (DG) into
postion on the side burner shelf, as shown in
gure F.
YOU WILL NEED:
13
X 1
DC
DG
D
E
F
12 a. Position the side burner (DD) through the
opening in the left side burner drip pan (DC).
Underside view
DD
b. Make sure that the side burner (DD) engages
the side burner valve (CC) as shown in gure B.
A
B
DC
ASSEMBLY INSTRUCTIONS
YOU WILL NEED:
9
Position the heat shield (CO) into the lower cart
and assemble to the bottom of the front brace
(CK), and the bottom of the Upper back panel
(CN), as shown in gure A, B and C.
X 4
A
CO
CK
B
CO
CN
Front view
Back view
c. Use the side burner Venturi clip (#14) to
connect the side burner (DD) to the side
burner valve (CC).
YOU WILL NEED:
14
X 1
13
14
C
CC
DD

14 15
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
15
16
Place the ame tamers (BG) into the burner box.
BG
Model may not be exactly as shown.
a. Place the cooking grates (BH) into the burner
box, as shown.
b. Insert the three small positioning rods of the
warming rack (BI) into the rear panel of the
burner box.
BH
BI
14
TIP: Before attempting to assemble the door (EF)
to the right pillar (ED), locate the two clasps
on the door Hinge. Next, locate the two
small openings on the right side pillar (ED).
b. Hold the door perpendicular to the BBQ Cart.
Align the two clasps on the door hinge (EF),
with the two holes on the right side pillar (ED).
Once aligned push the two clasps into the
openings, and immediately push down to lock
clasps in place.
c. Assemble the door (EF) to the right pillar (ED),
as shown in gure B, using the screws pro-
vided.
EF
YOU WILL NEED:
11
B
X 4
a. Assemble the towel bar (BN) onto door (EF).
876
YOU WILL NEED:
1 4 5
X 2 X 2 X 2
ED
EF
BN

16 17
ASSEMBLY INSTRUCTIONS
19
20
FOR PROPANE MODEL ONLY.
For natural gas model, follow step 20.
a. Position the 20 lb propane tank onto the bot-
tom shelf (EG), and secure using the bolt (F4)
(already attached) located on the underside of
the bottom shelf, as shown in gure B.
b. Attach the regulator coupling nut to the LP
cylinder valve.
ATTENTION: For your families safety, do
not attempt to light this BBQ until you have
reviewed pages 4-7 of the CuisinartTM Safety
& Care Manual. All Safety and Leak test MUST
BE PERFORMED BY THE END USER, prior to
lighting this BBQ.
B
WARNING
Do not store extra propane tanks within
BBQ cart.
FOR NATURAL GAS MODEL ONLY.
Attach the natural gas hose (CB) to the side burner
valve (CC) as shown.
ATTENTION: In order to complete installa-
tion of your Natural Gas BBQ a 1/2”or 3/8”
adapter may be required to connect your
BBQ’s Natural Gas hose to your home gas
supply.Contact your Natural Gas supplier to
purchase the necessary part.
CB
CC
F4
www.cuisinartbbqs.com
AEG
ASSEMBLY INSTRUCTIONS
17
18
a. Insert the grease tray (CL) into the opening
in the upper back panel (CN), making sure to
engage tracks located under burner box.
b. Place the grease cup (CM) onto the tracks,
located on the underside of the grease tray
(CL).
Unscrew the electronic ignitor button (CF2) and
insert one AA battery into the electronic igniter
battery compartment, with the positive end facing
outward.
* Battery not included.
CF2
CN
CL
CM
+
-
