Cuisinart GRSM2U User manual

2 IN 1 GRILL &SANDWICH MAKER
GRSM2U
CPT445U

Important Safeguards
When using electrical appliances, basic safety precautions should
always be followed, including the following:
1. The appliance is not intended to be operated by means of external
timer or separate remote-control system.
2. This appliance is not intended for use by persons with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
3. Children should always be supervised to ensure that they do not play
with this product.
4. Not for use by children. Keep out of reach of children during and
after use.
5. Once you have finished cooking, turn the selector control to the ‘OFF’
position, unplug the power cord from the mains and allow the appliance
to cool for at least 30 minutes before handling. The sandwich plates can
be washed by hand or in the dishwasher. Do not use metallic objects
such as knives when cleaning. This will damage the non stick coating.
Use wooden or heatproof plastic utensils only. The housing base, cover
and control knob can be wiped clean with a soft, dry cloth. For tough
stains dampen cloth. Never use an abrasive cleaner or harsh pad.
6. The temperature of all surfaces marked with this symbol will
be very hot when the appliance is in use. DO NOT TOUCH these
surfaces as possible injury could occur. Allow to cool completely
before handling this appliance.
7. The outer surface may get hot when the appliance is in use.
8. Always inspect the appliance before use for noticeable signs of
damage. Do not use if damaged, or if the appliance has been dropped.
Do not use this appliance if the lead is damaged. In the event of damage,
or if the appliance develops a fault, contact the Cuisinart Customer Care
Line (refer to “UK After Sales Service section“ for further information).

3
Congratulations on your purchase of the Cuisinart 2 In 1
Grill and Sandwich Maker.
For over 30 years Cuisinart’s aim has been to produce the
very finest kitchen equipment. All Cuisinart products are
engineered for exceptionally long life, and designed to be
easy to use as well as to give excellent performance day
after day.
To learn more about our products and for recipe ideas visit
our website www.cuisinart.co.uk

4
Contents
Product Description.............................................................................5
Safety Cautions &Wiring Instructions .............................................6
Selecting The Plates ............................................................................9
Fitting and Removing the Plates..................................................... 10
Fitting and Removing the Integrated Drip Tray .............................11
Using the 2 in 1 Grill &Sandwich Maker...................................... 12
Cooking with the Grill Plates .......................................................... 13
Cooking with the Sandwich Plates ................................................. 14
Cleaning &Maintenance ................................................................. 15
UK Guarantee.................................................................................... 16
UK After Sales Service ..................................................................... 17

5
Product Description
Handle
Upper Plate Release Button
Grill Plates
Temperature Control Dial
Indicator Lights
Housing Base
Lower Plate Release Button
Sandwich Plates
Handle Release Button
Includes scraping tool (image not shown)

6
Safety Cautions
Carefully read all the instructions before using the appliance and keep
in a safe place for future reference
Always follow these safety cautions when using this appliance to avoid
personal injury or damage to the appliance. This appliance should be used
only as described within this instruction book.
nEnsure all packaging materials and any promotional labels or stickers
are removed from the sandwich maker before first use.
nAlways inspect the appliance before use for noticeable signs
of damage. Do not use if damaged, or if the appliance has been dropped.
In the event of damage, or if the appliance develops a fault, contact the
Cuisinart Customer Care Line (refer to ‘UK After Sales Service’ section
for further information).
nDo not use this appliance if the lead is damaged. In the event of lead
damage discontinue use immediately. If the lead is damaged it must
be replaced with a special lead available from the manufacturer or its
service agent. (See ‘UK After Sales Service’).
nWhilst in use the surfaces will become extremely hot. Do not touch hot
surfaces. Always use handles.
nUnplug from the mains when not in use and before cleaning. Allow to
cool before cleaning the appliance. To disconnect, turn the control to
‘OFF’ setting, and then remove the plug from the mains.
nThis appliance is not intended for use by persons with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
nChildren should always be supervised to ensure that they do not play
with this product.
nNot for use by children. Keep out of reach of children during and after
use.
nDo not use any accessories or attachments with this appliance other than
those recommended by Cuisinart.
nTo protect against fire, electric shock or personal injury, do not immerse
cord, plug or unit in water or other liquids.
nDo not leave the lead hanging over the edge of a kitchen table or
worktop. Avoid contact between the lead and hot surfaces.

7
nFor indoor, domestic use only.
nThis appliance should be used only for preparation of food as described
within the instructions for use that accompany it. Please retain these
instructions for further use.
nAlways ensure that your hands are dry before removing the plug from
the mains socket. Never pull the plug out of the mains socket by its
lead.
nTo avoid injury or possible fire, do not cover the appliance when in use.
nIf this appliance is used for re-heating foods, also ensure the food is
piping hot before eating.
nAllow to cool before putting on or taking off parts, and before cleaning
appliance.
nDo not connect this appliance to an external timer or remote control
system.
nThis appliance complies with the basic requirements of Directives
04/108/EC (Electromagnetic Compatibility) and 06/95/EC (Safety of
domestic electrical appliances).
WARNING: Polythene bags over the product or packaging may
be dangerous. To avoid danger of suffocation, keep away from
babies and children. These bags are not toys.
The temperature of all surfaces marked with this symbol will be very
hot when the appliance is in use.
DO NOT TOUCH these surfaces as possible injury could occur.
Allow to cool completely before handling this appliance.
The symbol on the product or on its packaging indicates that this
product may not be treated as household waste. Instead it should be
handed over to the applicable collection point for the recycling of electrical
and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of this
product. For more detailed information about the recycling of this product,
please contact your local council office or your household waste disposal
service.

8
UK Wiring Instructions
The wires in the mains lead are coloured in accordance with the following
code:
nBLUE = NEUTRAL
nBROWN = LIVE
nYELLOW &GREEN = EARTH
As the colours of the wire in the mains lead of this appliance may not
correspond with the colour marking identifying the terminals on your plug,
proceed as follows:
The wire which is coloured BLUE must be connected to the terminal which
is marked with the letter N
The wire which is coloured BROWN must be connected to the terminal
which is marked with the letter L
The wire which is coloured YELLOW &GREEN must be connected to the
terminal which is marked with the letter E or the symbol
This appliance is supplied fitted with a BS1363 mains plug and a BS1362
13A fuse. If this plug is removed from the appliance please ensure it is
disposed of safely as a disconnected plug is dangerous if reconnected to
the mains. If any other type of plug is used, a 13A fuse must be fitted.

9
Whether you are cooking a complete meal or a light snack, the Cuisinart
2 in 1 Grill &Sandwich Maker is the perfect machine. With two sets of
interchangeable plates, a floating hinge that adjusts to any thickness of
food and a choice of variable temperature settings, you can achieve perfect
cooking results every time.
Before First Use
Before using your 2 in 1 Grill &Sandwich Maker for the first time, ensure all
packaging is removed and clean the grill and sandwich plates (see Cleaning
&Maintenance section).
Selecting the Plates
Before you begin, select which plates are best suited for the food you wish
to cook.
Grill Plates
The ribbed grill plates can be used open, as a contact grill or as a panini
press. They are perfect for succulent burgers, seared steaks, café style
paninis and delicious vegetables.
Sandwich Plates
The extra large, deep pocketed plates enable you to create delicious deep
filled sandwiches with perfectly sealed edges and no spills. When in
sandwich mode, the locking handle ensures even browning every time.
In addition to sandwiches, the sandwich plates are also perfect for omelettes,
calzones, quesadillas, fruit pastries, French toast and much more.

10
Fitting &Removing The Plates
Fitting the Plates
nEnsure the product is switched off and is fully cooled down.
nSelect either the grill or sandwich plates.
nPosition the unit so that the controls are facing towards you.
nPress the handle release button and lift the handle to fully open the
product.
nAlign the two cut outs at the back of the plate (see Fig. 1) with the
brackets on the bottom of the housing base. Tilt the plate and slide it
underneath the bracket.
nPush down the front end of the plate until it locks into place.
nRepeat with the second plate.
Removing the Plates
nEnsure the product is switched off and is fully cooled down. Always
allow the appliance to cool for at least 30 minutes before removing the
plates.
nLocate the plate release buttons which can be found on the right side of
the units upper and lower housing (see Fig. 2). Press the upper release
button firmly, and the upper plate will pop up slightly from the base.
Lift the plate up and slide out from under the
brackets in the centre.
nRepeat by pressing the lower release button
and releasing the lower plate.
nThe plates can be hand washed or cleaned in
the dishwasher after use.
Upper
Plate
Release
Button
Lower
Plate
Release
Button
Positioning guides Positioning guides
Fig. 1
Sandwich Plates Grill Plates
Fig. 2

11
Fitting and Removing the Integrated Drip Tray
The 2 In 1 Grill &Sandwich Maker has a clever fat drainage system. Fat is
drained via a small recess at the rear of the plates, allowing fat and grease
to drip down into the integrated tray.
To insert the drip tray, insert it into the slot on the right side of the lower
housing. (see Fig. 3). To remove the drip tray, simply slide the tray out of
the slot. Grease should be disposed of safely after cooking. The drip tray
can be washed in the dishwasher.
H
I
G
H
O
F
F
•
•
•
L
O
W
•
•
•
M
E
D
•
•
•
Fig. 3

12
Using the 2 in 1 Grill &Sandwich Maker
Once you have fitted the plates and integrated drip tray you are ready to
start using the 2 in 1 Grill &Sandwich Maker.
Preheating the Appliance
For optimum results, always preheat the unit completely before using.
nPlug the unit into a suitable mains socket.
nAlthough the plates have a non-stick coating, we recommend that you
prepare the plates with cooking spray or oil. If using oil, apply with a
paper towel or pastry brush.
nClose the lid and turn the temperature control dial to
the desired setting for cooking; Low, Medium or High.
N.B. Adjust the temperature according to the food. For
example, when in grill mode use high heat for searing
meats, but low heat on more delicate foods such as
prawns, vegetables or fruits.
nWhen the dial is in place a red light will illuminate on
the front of the appliance to indicate that the power
is on, and the appliance is heating up.
nOnce the appliance has reached the optimal temperature, the green
light will illuminate to indicate the appliance is ready to cook.
Using the handle
The handle is designed to lock when used in sandwich mode.
To open the grill/sandwich maker, grasp the handle, pressing in the handle
release button as you lift the lid upwards.
To close the grill/sandwich maker, push the handle downwards.
ACTUAL SIZE SAMPLE:
150%
CONTINENTAL CONAIR LIMITED
Customer:
Model No.
Description:
Prepared by:
Version:
Checked by:
Approved by:
Released on:
Vendor:
Printer:
Artwork No.:
CUISINART
GR-3
Knob Bezel sa
PETER 03/14/07
CH HO 03/19/07
Beth Lowe 03/19/07
03/19/07
TSANN KUEN
Scale 1 : 1
12345cm
H
I
G
H
O
F
F
•
•
•
L
O
W
•
•
•
M
E
D
•
•
•

13
Cooking with the Grill Plates
nPreheat the appliance, until the green indicator illuminates.
nPlace the food on the bottom plate and lower the lid.
nThe floating hinge design means that the space between the upper and
lower plate adjusts to the thickness of your food (see fig. 4).
N.B. You can apply light pressure using the handle to press whilst cooking
to lock in flavour. When cooking more than one item at a time, try to
ensure the thickness of the food is consistent to ensure even cooking for
each piece of food.
nAfter placing your food on the grill, it may take a few seconds for the
green light to switch off. This is normal.
nThe green light runs on a thermostat and indicates when the product is
up to temperature. As part of the cooking cycle the light will go on and
off during this process. You will need to assess if the food is cooked by
lifting the lid. The green light does not indicate when food is cooked.
nWhen you are happy the food is cooked, remove it with the scraping tool
or a heat-proof plastic spatula.
IMPORTANT: Never use metal utensils, as they may damage the non-stick
coating.
nOnce you have finished cooking, turn the dial to the ‘OFF’ position and
unplug the power cord from the mains. Allow the appliance to cool for
at least 30 minutes before handling.
N.B. When using the appliance for the first time, there may be a slight
odour and the unit may smoke a little. This is normal and common for
appliances with a non-stick surface.
H
I
G
H
O
F
F
•
•
•
L
O
W
•
•
•
M
E
D
•
•
•
Floating Hinge Position
Fig. 4

14
Cooking with the Sandwich Plates
nPreheat the appliance, until the green indicator illuminates.
nPlace the food on the lower sandwich plate and close the handle. You
will hear a click when it locks securely.
N.B. It is important to lock the plates in sandwich mode to ensure your
sandwich seals properly.
nIt may take a few seconds for the green light to switch off. This is
normal.
nThe green light runs on a thermostat and indicates when the product is
up to temperature. As part of the cooking cycle the light will go on and
off during this process. You will need to assess if the food is cooked by
firmly pressing the release button and lifting the lid.
nWhen you are happy the food is cooked, remove it by gently loosening
the edges with the scraping tool or a heat-proof plastic spatula.
IMPORTANT: Never use metal utensils, as they may damage the non-stick
coating.
nOnce you have finished cooking, turn the selector to the ‘OFF’ position
and unplug the power cord from the mains. Allow the appliance to cool
for at least 30 minutes before handling.
N.B. When using the appliance for the first time, there may be a slight
odour and the unit may smoke a little. This is normal and common for
appliances with a non-stick surface.

15
Cleaning &Maintenance
nBefore first use and after every use, clean each part thoroughly.
nOnce you have finished cooking, turn the dial control to the ‘OFF’ position
and unplug the power cord from the mains and allow the appliance to
cool for at least 30 minutes before handling.
nWhen cold use the scraping tool to remove any leftover food from
the cooking plates. The scraping tool can be washed by hand or in the
dishwasher.
nDispose of grease from the drip tray. The drip tray can be cleaned by
hand or in the dishwasher.
nThe cooking plates can be washed by hand or in the dishwasher. Do not
use metallic objects such as knives when cleaning. This will damage the
non-stick coating. Use wooden or heatproof plastic utensils only.
nIf you have been cooking seafood, wipe the cooking plate with lemon
juice to prevent seafood flavour transferring to the next recipe.
nThe housing base, cover and control knobs can be wiped clean with a
soft, dry cloth. For tough stains dampen cloth. Never use an abrasive
cleaner or harsh pad.
nIn between recipes, scrape excess food build up, then wipe off any
residue with a paper towel before proceeding with the next recipe.
nNever leave plastic utensils in contact with the hot grill plate.
nMake sure all the parts are clean and dry before storing.
nNever wrap the cord around the outside of the unit.
nNever immerse the plug, lead or housing in water or any other liquid.

16
UK Guarantee
This Cuisinart 2 in 1 Grill and Sandwich Maker has a 5 year guarantee for
domestic use.
The guarantee covers defects under normal use from date of purchase
and ceases to be valid in the event of alteration or repair by unauthorised
persons. If the appliance does not perform satisfactorily due to defects of
material or manufacture, it will be repaired or replaced by the manufacturer
(see ‘UK After Sales Service’ for details). This guarantee is only valid in the
United Kingdom and Eire (includes Channel Islands and Isle of Man). No
responsibility will be accepted for any damage caused in transit. A charge
may be made if goods are returned outside the relevant guarantee period
or if the product is returned unnecessarily. The manufacturer reserves the
right to amend terms and specifications without prior notice.
This guarantee in no way affects your statutory rights.

17
UK After Sales Service
For further advice on using the appliance or should you need to re-
turn your product, please contact the Conair Customer Care Line on
03702 406 902 (09:00 to 17:00 Monday to Friday) or email your enquiry to
[email protected]
The return address is:
Customer Care Centre
Conair Logistics
Unit 4 Revolution Park
Buckshaw Avenue
Buckshaw Village
Chorley
PR7 7DW
Please enclose your returns number, name and address details, together
with a copy of proof of purchase and details of the fault.

18

19

www.cuisinart.co.uk
IB-15/388A
