Culina IND60KC User manual

Operation / Installation Manual
Induction Hob
MODEL: IND60KC / INDTC60
Ceramic Hob
MODEL: CER60TC / CER60DTC / CER60MZ
Congratulations on the purchase of your new hob.
We recommend that you spend some time to read this Instruction / Installation
Manual in order to fully understand how to install correctly and operate it.
For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruction /
Installation Manual for future reference.

2
SAFETY WARNINGS
Please read this user manual thoroughly before attempt-
ing to use this appliance for the first time. This manual
contains important information on safe installation, use
and care of the appliance. Keep these instructions for
reference and pass them on to future user.
Installation
Electrical Shock Hazard
• Disconnect the appliance from the mains electricity
supply before carrying out any work or maintenance
on it.
• Connection to a good earth wiring system is essential
and mandatory.
• Alterations to the domestic wiring system must only be
made by a qualified electrician.
• Failure to follow this advice may result in electrical
shock or death.
Cut Hazard
• Take care - panel edges are sharp.
• Failure to use caution could result in injury or cuts.
Important safety instructions
• Read these instructions carefully before installing or
using this appliance.
• No combustible material or products should be placed
on this appliance at any time.
• Please make this information available to the person
responsible for installing the appliance as it could re-
duce your installation costs.

3
• In order to avoid a hazard, this appliance must be in-
stalled according to these instructions for installation.
• This appliance is to be properly installed and earthed
only by a suitably qualified person.
• This appliance should be connected to a circuit which
incorporates an isolating switch providing full discon-
nection from the power supply.
• Failure to install the appliance correctly could invalidate
any warranty or liability claims.
Operation and maintenance
Electrical Shock Hazard
• Do not cook on a broken or cracked hob. If the hob
surface is break or crack, switch the appliance off im-
mediately at the mains power supply (wall switch) and
contact a qualified technician.
• Switch the hob off at the wall before cleaning or mainte-
nance.
• Failure to follow this advice may result in electrical
shock or death.
Health Hazard
• This appliance complies with electromagnetic safety
standards.
Hot Surface Hazard
• During use, accessible parts of this appliance will be-
come hot enough to cause burns.
• Do not let your body, clothing or any item other than
suitable cookware contact the ceramic glass until the
surface is cool.

4
• Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they
can get hot
• Keep children away.
• Handles of saucepans may be hot to touch. Check
saucepan handles do not overhang other cooking
zones that are on. Keep handles out of reach of chil-
dren.
• Failure to follow this advice could result in burns and
scalds.
Cut Hazard
• The razor-sharp blade of a hob scraper is exposed
when the safety cover is retracted. Use with extreme
care and always store safely and out of reach of chil-
dren.
• Failure to use caution could result in injury or cuts.
Important safety instructions
• Never leave the appliance unattended when in use.
Boilover causes smoking and greasy spillovers that
may ignite.
• Never use your appliance as a work or storage surface.
• Never leave any objects or utensils on the appliance.
• Never use your appliance for warming or heating the
room.
• After use, always turn off the cooking zones and the
hob as described in this manual (i.e. by using the
touch controls).
• Do not allow children to play with the appliance or sit,
stand, or climb on it.

5
• Do not store items of interest to children in cabinets
above the appliance. Children climbing on the hob
could be seriously injured.
• Do not leave children alone or unattended in the area
where the appliance is in use.
• Children or persons with a disability which limits their
ability to use the appliance should have a responsible
and competent person to instruct them in its use. The
instructor should be satisfied that they can use the ap-
pliance without danger to themselves or their sur-
roundings.
• Do not repair or replace any part of the appliance un-
less specifically recommended in the manual. All other
servicing should be done by a qualified technician.
• Do not use a steam cleaner to clean your hob.
• Do not place or drop heavy objects on your hob.
• Do not stand on your hob.
• Do not use pans with jagged edges or drag pans
across the glass surface as this can scratch the
glass.
• Do not use scourers or any other harsh abrasive clean-
ing agents to clean your hob, as these can scratch the
ceramic glass.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly quali-
fied persons in order to avoid a hazard.
• This appliance is intended to be used in a domestic
household environment only! Commercial use of any
kind is not covered under the manufacturer's warranty!
• WARNING: The appliance and its accessible parts be-
come hot during use.

6
• Care should be taken to avoid touching heating ele-
ments. Children less than 8 years of age shall be kept
away unless continuously supervised.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
• Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.
• WARNING: Unattended cooking on a hob with fat or
oil can be dangerous and may result in fire. NEVER
try to extinguish a fire with water, but switch off the
appliance and then cover flame e.g. with a lid or a fire
blanket.
• WARNING: Danger of fire: do not store items on the
cooking surfaces.
• WARNING: If the surface is cracked, switch off the ap-
pliance to avoid the possibility of electric shock, for
hob surfaces of glass-ceramic or similar material
which protect live parts
• A steam cleaner is not to be used.
• The appliance is not intended to be operated by means
of an external timer or separate remote-control system.

7
GUIDE TO THE APPLIANCE
CER60TC / CER60DTC
CER60MZ
CONTROL PANEL
1. max. 1000/2200 W zone
2. max. 1200 W zone
3. max. 1100/2000 W zone
4. max. 1200 W zone
5. Glass plate
6. Control panel
1. Main switch
2. Zone selection
3. Power level setting
4. Child lock
5. Timer
6. Dual zone
1. max. 1800 W zone
2. max. 1200 W zone
3. max.1800 W zone
4. max.1200 W zone
5. Control panel
1. max. 1800/2200 W zone
2. max. 1200 W zone
3. max.1100/2000 W zone
4. max.1200 W zone
5. Control panel
1
2
3
4
5
6

8
INDTC60
CONTROL PANEL
IND60KC
CONTROL PANEL
1. max. 1800/2200 W zone
2. max. 1200 W zone
3. max.1800 W zone
4. max.1200 W zone
5. Control panel
1. max. 1800 W zone
2. max. 1200 W zone
3. max.1800 W zone
4. max.1200 W zone
5. Control panel
1
3
5
4
2
1. Main switch
2. Zone selection
3. Power level setting
4. Child lock
5. Timer
6. Boost
7. Pause
1. Main switch
2. Knob control
1
2
6
7

9
A Word on Induction Cooking (for Induction hob only)
Induction cooking is a safe, advanced and efficient cooking technology. It works
by electromagnetic vibrations generating heat directly in the pan, rather than in-
directly through heating the glass surface. The glass becomes hot only because
the pan eventually warms it up.
Before using your New Hob
• Read this guide, taking special note of the ‘Safety Warnings’ section.
• Remove any protective film that may still be on your hob.
• Remove any protective film that may still be on your hob.
Using the Touch Controls
• The controls respond to touch, so you don’t need to apply any pressure.
• Use the ball of your finger, not its tip.
• You will hear a beep each time a touch is registered.
• Make sure the control panel is always clean, dry, and that there is no object (e.g., a
utensil or a cloth) covering them. Even a thin film of water may make the controls difficult
to operate.
Choosing the right Cookware (for Induction hob)
• Only ferromagnetic cookwares are suitable for induction cooking.
Look for the induction symbol on the packaging or on the bottom of
the pan.
• You can check whether your cookware is suitable by carrying out a
magnet test. Move a magnet towards the base of the pan. If it is
attracted, the pan is suitable for induction.
iron pot
magnetic circuit
ceramic glass plate
induction coil
induced currents

10
• If you do not have a magnet:
1. Put some water in the pan you want to check.
2. Follow the steps under ‘To start cooking’.
3. If does not flash in the display and the water is heating, the pan is suitable.
• Cookware made by the following materials is not suitable: pure stainless steel,
aluminum or copper without a magnetic base, glass, wood, porcelain, ceramic,
and earthenware.
Size of hob(mm)
The minimum hob(diameter /mm)
160
120
180
140
210
160
280
220
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass, and is
the same size as the cooking zone. Always centre your pan on the cooking zone.
Always lift pans off the hob – do not slide, or they may scratch the glass.
To Start Cooking
Switching the hob on and off
Switch the hob on and off by using the main swtich.
1. Touch the main switch key . All the indicators show “- “.
2. Place a suitable pan on the cooking zone that you wish to use.
• Make sure the bottom of the pan and the surface of the glass are clean
and dry.
3. Touching the zone selecting key, an indicator next to the key will flash.
4. Select power level by touching the or control. / Turn the knobs for
IND60KC.

11
• If you don’t choose a heat setting within 1 minute, the hob will automati-
cally switch off. You will need to start again from step 1.
When you have finished cooking
1. Selecting the burner that you wish to switch off.
2. Turn the cooking zone off by touching until power level reduce to ”0”.
3. To turn the whole hob off, touching the main switch .
Beware of hot surfaces
“H” (Red light for IND60KC) will show which cooking zone is too hot. It
will disappear when the surface has cooled down to a safe temperature.
It can also be used as an energy saving function if you want to heat further
pans, use the cooking zone that is still hot.
Using Boost function (If available)
To activate the boost function
1. Select the zone with boost function (with word “Booster”).
2. Touch BOOST function key and power level indication shows “P”.
Cancel Boost function
1. Select the zone under BOOST mode.
2. Touching the power changing key to cancel the Boost function, and select
the level you want to set.
NOTE: boost function can only last for 5 minutes, after that the zone will go to
level 9 automatically.
Child Lock Function
You can use Childlock function to prevent unintended use (for example children
accidentally turning the cooking zones on).
To lock the controls
Touch the Childlock control until the timer indicator show “Lo”.
To unlock the controls
1. Make sure the hob is turned on.

12
2. Touch and hold the keylock control for 3 seconds.
3. “Lo” will disappear and the hob is unlocked.
When the hob is in Childlock mode, all the controls are disable except
the main switch key, you can always turn the hob off with the main switch
in an emergency, but you shall unlock the hob first in the next operation.
Residual Heat Warning
When the hob has been operating for some time, there will be some residual heat.
The power indicator will appear “H” to warn you to keep away from it.
Auto Shutdown
Safety feature of the hob is auto shut down. This occurs whenever you forget to
switch off a cooking zone. The default shutdown times are shown in the table
below:
Power level
1
2
3
4
5
6
7
8
9
Default working timer (hour)
8
8
8
4
4
4
2
2
2
Using the Timer
You can use the timer in two different ways:
• You can use it as a minute minder. In this case, the timer will not turn any
cooking zone off when the set time is up.
• You can use it as a cut off timer to turn one or more cooking zones off when the
set time is up.
• You can set the timer up to 99 minutes.
Using the Timer as a Minute Minder
1. Make sure the hob is turned on, and none cooking zone is in selecting mode.
Note: you can use the minute minder before or after cooking zone setting finished.
2. Touch timer key, “ ” will show in the display. and single digit “0” fiashes.
3. Set the desired minutes by touching the - or +.
4. Touch timer key again, then number to represent tens digit will flash.

13
5. set the desired number of minutes by touching the or key.
6. When the time is set, it will begin to count down immediately. The display will
show the remaining time.
7. A signal sound will beep for 30 seconds and the timer indicator shows “ ”
when the setting time finished.
Setting the timer to turn one or more cooking zones off
If the timer is set on one zone:
1. Selecting the heating zone that you want to set timer.
2. Touch timer key, the digits will show in the timer display. and the “0” fi-
ashes.
3. Set the desired time in the control panel.
6. When the time is set, it will begin to count down immediately. The display will
show the remaining time.
NOTE: The red dot next to power level indicator (eg. ) will illuminate indicat-
ing that the zone is in timer mode.
7. When cooking timer expires, the corresponding cooking zone will be switch off
automatically.
NOTE: Other cooking zones will keep operating if they are turned on previously.
If the timer is set on more than one zone:
1. When you set the time for several cooking zones simultaneously, decimal
dots of the relevant cooking zones are on. The minute display shows the re-
maining time. The dot of the corresponding zone flashes (eg. ).
2. Once the countdown timer expires, the corresponding zone will switch off. Then
it will show the remaining activated timer and the dot of corresponding zone will
flash.
3. To check the remaining time set on a particular zone, touch the zone and the
corresponding timer will be shown in the timer indicator.
Cancel the timer
1. Select the zone that you want to cancel the timer.
2. Touch the timer key, the indicator will flash.
3. Set the timer to ”00”, the timer is cancelled.

14
Pause function
To use Pause function
Touch the pause function , all the heating zones stop working, All the zone
indicators show“||”.
Cancel Pause function
Touching the Pause function again, all the heating zones will revert to its
original setting.
NOTE: The function is available when one or multi heating zones are working.
NOTE: If you don`t cancel the stop Pause mode within 30 minutes, the induction
hob will automatically switch off.
Cooking Guidelines
Take care when frying as the oil and fat heat up very quickly, particularly
if you’re using Power Boost. At extremely high temperatures oil and fat
will ignite spontaneously and this presents a serious fire risk.
Cooking Tips
• When food comes to the boil, reduce the power setting.
• Using a lid will reduce cooking times and save energy by retaining the heat.
• Minimise the amount of liquid or fat to reduce cooking times.
• Start cooking on a high power and reduce it when the food has been well heated.
Heat Settings
Heat setting
Suitability
1 - 2
• delicate warming for small amounts of food
• melting chocolate, butter, and foods that burn quickly
• gentle simmering
• slow warming
3 - 4
• reheating
• rapid simmering
• cooking rice
5 - 6
• pancakes

15
7 - 8
• sauteing
• cooking pasta
9
• stir-frying
• searing
• bringing soup to the boil
• boiling water
Care and Cleaning
What?
How?
Dirty stuff on glass (fin-
gerprints, marks, resid-
ual stains or non-sug-
ary spillovers on the
glass).
1. Switch off the power of the hob.
2. Apply a hob cleaner while the glass is still warm (but not
hot!)
3. Rinse and wipe dry with a clean cloth or paper towel.
4. Switch the power to the hob back on.
Boilovers, melts, and
hot sugary spills on the
glass
Remove these immediately with a fish slice, palette knife or
razor blade scraper suitable for ceramic glass hobs, but be-
ware of hot cooking zone surfaces.
1. Switch the power to the hob off at the wall.
2. Hold the blade or utensil at a 30° angle and scrape the soil-
ing or spill to a cool area of the hob.
3. Clean the soiling or spill up with a dish cloth or paper towel.
Spillovers on the
touch controls
1. Switch off the power of the hob.
2. Remove the spillovers
3. Wipe the touch control area with a clean damp sponge or
cloth, then wipe the area completely dry with a paper towel.
4. Switch the power to the hob back on.
Important!
• When the hob is switched off, there will be no ‘hot surface’ indication but the
cooking zone may still be hot! Take extreme care!
• Heavy-duty scourers, some nylon scourers and harsh/abrasive cleaning
agents may scratch the glass. Always read the label to check if your cleaner or
scourer is suitable.
• Never leave cleaning residue on the hob: the glass may become stained.

16
• Remove stains left by melts and sugary food or spillovers as soon as possible.
If left to cool on the glass, they may be difficult to remove or even permanently
damage the glass surface.
• Cut hazard: when the safety cover is retracted, the blade in a scraper is razor-
sharp. Use with extreme care and always store safely and out of reach of children.
• The hob may beep and turn itself off, and the touch controls may not function
while there is liquid on them. Make sure you wipe the touch control area dry be-
fore turning the hob back on.
Questions and quick check
Problem
Possible causes and What to do
The hob cannot be
turned on.
No power. Check the connection to the power supply and make sure it is
switched on.
Check whether there is a power outage in your home or area. If you’ve
checked everything and the problem persists, call a qualified technician.
The touch controls are
unresponsive.
The control panel is locked by Child lock function.
Unlock the controls. See section ‘Using your hob’ for instructions.
The touch controls are
difficult to operate.
There may be a slight film of water over the controls or you may be using
the tip of your finger when touching the controls.
Make sure the touch control area is dry and use the ball of your finger
when touching the controls.
The glass is being
scratched.
Rough-edged cookware. Unsuitable, abrasive scourer or cleaning prod-
ucts being used.
Use cookware with flat and smooth bases. See ‘Choosing the right
cookware’.
See ‘Care and cleaning’.
Some pans make crack-
ling or clicking noises.
This may be caused by the material of your cookware (layers of different
metals vibrating differently).
This is normal for cookware and does not indicate a fault.

17
The induction hob
makes a low humming
noise at some certain
power setting.
This is caused by the technology of induction cooking.
This is normal, but the noise may quiet down or disappear completely
when you change the power level setting.
Fan noise coming from
the induction hob.
A cooling fan is built in your induction hob which prevent the electronics
from overheating. It may continue to run even after you’ve turned the in-
duction hob off. This is normal and needs no action. Do not switch the
power to the induction hob off at the wall while the fan is running.
Pans do not become hot
and appears in the
display.
The induction hob cannot detect the pan. Check the pan base size, if it is
too small for the cooking zone or not properly centered. Use cookware
suitable for induction cooking. See section ‘Choosing the right
cookware’. Centre the pan and make sure that its base matches the size
of the cooking zone.
The induction hob or a
zone turn itself off unex-
pectedly. A tone sounds
and error code is dis-
played.
Technical fault.
Please note down the error code (typically alternating with one or two
digits in the cooking timer display)., switch the power to the induction hob
off at the wall, and contact a qualified technician.
Error Code
If an abnormality comes up, the hob will enter the protective state automatically
and display corresponding protective codes:
Error Code for Ceramic hob
Problem
Possible causes
What to do
E0 & repeated
beep sound
warning.
Overheating protection:
the hob is over heated.
Stop cooking till the internal temperature
back to normal. Please contact after sales
service to check the hob if there is PCB
failure.
E1
Open circuit failure of
thermocouple
Please contact after sales service.

18
Error Code for Induction hob
Problem
Possible causes
What to do
E1
Signal lost (PCB failure)
Please contact after sales service.
E2/E3
Abnormal high/Low in-
put voltage
Stop cooking and wait until input voltage back
to normal. If not please contact service center.
E4/E5/E6
Thermistor failure.
Please contact service center to repair.
E7
Abnormal high temper-
ature (dry burning)
Cut off power, wait for 30min and switch on. If
still not working, please contact service.
E8/E9
Failure of IGBT sensor
Please contact service center to repair.
E0
IGBT Overheat
Check if the fan is still working. If not please
contact service center to repair.
EE
Display PCB failaure.
Please contact service center.
The above are the judgment and inspection of common failures.
ATTENTION! To avoid danger, please do not disassemble the unit by your-
self!
Installation
Selection of installation equipment
Cut out the work surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 50mm space shall be pre-
served around the hole.
Be sure the thickness of the work surface is at least 30mm. Please select heat-
resistant work surface material to avoid larger deformation caused by the heat
radiation from the hotplate. As shown below:

19
L(mm)
W(mm)
H(mm)
D(mm)
A(mm)
B(mm)
X(mm)
590
520
55
51
560
490
50 mini
ATTENTION: Under any circumstances, make sure the hob is well ventilated and
the air inlet and outlet are not blocked. Ensure the hob is in good work state. As
shown below
Note: The safety distance between the
hotplate and the cupboard above the hot-
plate should be at least 760mm.
A(mm)
760
B(mm)
50 minimum
C(mm)
20 minimum
D
Air intake
E
Air exit 5mm
X(mm)
50 minimum
Y(mm)
50 minimum
Before you install the hob, make sure that
• the work surface is square and level, and no structural members interfere with
space requirements
• the work surface is made of a heat-resistant material
• if the hob is installed above an oven, the oven has a built-in cooling fan
• the installation will comply with all clearance requirements and applicable stand-
ards and regulations
• a suitable isolating switch providing full disconnection from the mains power
supply is incorporated in the permanent wiring, mounted and positioned to com-
ply with the local wiring rules and regulations.
The isolating switch must be of an approved type and provide a 3 mm air gap
contact separation in all poles (or in all active [phase] conductors if the local
wiring rules allow for this variation of the requirements).

20
• the isolating switch will be easily accessible to the customer with the hob in-
stalled
• you consult local building authorities and by-laws if in doubt regarding installa-
tion
• you use heat-resistant and easy-to-clean finishes (such as ceramic tiles) for the
wall surfaces surrounding the hob.
When you have installed the hob, make sure that
• the power supply cable is not accessible through cupboard doors or drawers
• there is adequate flow of air from outside the cabinetry to the base of the hob
• if the hob is installed above a drawer or cupboard space, a thermal protection
barrier is installed below the base of the hob
• the isolating switch is easily accessible by the customer
Before locating the fixing brackets
The unit should be placed on a stable, smooth surface (use the packaging). Do
not apply force onto the controls protruding from the hob.
locating the fixing brackets
Fix the hob on the work surface by screw two brackets on the bottom of hob (see picture)
after installation.
Adjust the bracket position to suit for different work surface’s thickness.
Cautions
1. The hob must be installed by qualified personnel or technicians. We have pro-
fessionals at your service. Please never conduct the operation by yourself.
