Culina UBKCIND60BV Specification sheet

Induction hob
Instruction Manual / Installation Manual
MODEL:
UBKCIND60BV
UBKCIND60PF

2
SAFETY WARNINGS
PLEASE READ THE FOLLOWING INSTRUCTIONS
CAREFULLY BEFORE USING THE APPLIANCE.
Installation
Electrical Shock Hazard
•Disconnect the appliance from the mains electricity supply
before carrying out any work or maintenance on it.
•Connection to a good earth wiring system is essential and
mandatory.
•Means for disconnection must be incorporated in the fixed
wiring in accordance with the wiring rules.
•Alterations to the domestic wiring system must only be
made by a qualified electrician.
•Failure to follow this advice may result in electrical shock
or death.
Cut Hazard
•Take care - panel edges are sharp.
•Failure to use caution could result in injury or cuts.
Important safety instructions
•Read these instructions carefully before installing or using
this appliance.
•No combustible material or products should be placed on
this appliance at any time.
•Please make this information available to the person
responsible for installing the appliance as it could reduce
your installation costs.
•In order to avoid a hazard, this appliance must be installed
according to these instructions for installation.

3
•This appliance is to be properly installed and earthed only
by a suitably qualified person.
•This appliance should be connected to a circuit which
incorporates an isolating switch providing full
disconnection from the power supply.
•WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by the
manufacturer of the appliance in the instructions for use as
suitable or hob guards incorporated in the appliance. The
use of inappropriate guards can cause accidents.
•Failure to install the appliance correctly could invalidate
any warranty or liability claims.
•Regarding the details of installation, thanks to refer to the
section <Installation>.
Operation and maintenance
Electrical Shock Hazard
•Do not cook on a broken or cracked cooktop. If the cooktop
surface is break or crack, switch the appliance off
immediately at the mains power supply (wall switch) and
contact a qualified technician.
•Switch the cooktop off at the wall before cleaning or
maintenance.
•Failure to follow this advice may result in electrical shock
or death.
Health Hazard
•This appliance complies with electromagnetic safety
standards.
Hot Surface Hazard

4
•During use, accessible parts of this appliance will become
hot enough to cause burns.
•Do not let your body, clothing or any item other than
suitable cookware contact the ceramic glass until the
surface is cool.
•Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they can get
hot.4
•Children less than 8 years of age shall be kept away unless
continuously supervised.
•Handles of saucepans may be hot to touch. Check saucepan
handles do not overhang other cooking zones that are on.
Keep handles out of reach of children.
•Failure to follow this advice could result in burns and
scalds.
Cut Hazard
•The razor-sharp blade of a cooktop scraper is exposed when
the safety cover is retracted. Use with extreme care and
always store safely and out of reach of children.
•Failure to use caution could result in injury or cuts.
Important safety instructions
•Never leave the appliance unattended when in use. Boilover
causes smoking and greasy spillovers that may ignite.
•Never use your appliance as a work or storage surface.
•Never leave any objects or utensils on the appliance.
•Never use your appliance for warming or heating the room.
•After use, always turn off the cooking zones and the
cooktop as described in this manual (i.e. by using the touch
controls).
•Do not allow children to play with the appliance or sit,
stand, or climb on it.

5
•Do not store items of interest to children in cabinets above
the appliance. Children climbing on the cooktop could be
seriously injured.
•Do not leave children alone or unattended in the area where
the appliance is in use.
•Children or persons with a disability which limits their
ability to use the appliance should have a responsible and
competent person to instruct them in its use. The instructor
should be satisfied that they can use the appliance without
danger to themselves or their surroundings.
•Do not repair or replace any part of the appliance unless
specifically recommended in the manual. All other
servicing should be done by a qualified technician.
•Do not use a steam cleaner to clean your cooktop.
•Do not place or drop heavy objects on your cooktop.
•Do not stand on your cooktop.
•Do not use pans with jagged edges or drag pans across the
glass surface as this can scratch the glass.
•Do not use scourers or any other harsh abrasive cleaning
agents to clean your cooktop, as these can scratch the
ceramic glass.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
•This appliance is intended to be used in a domestic
household environment only! Commercial use of any kind
is not covered under the manufacturer's warranty!
•WARNING: The appliance and its accessible parts become
hot during use.

6
•Care should be taken to avoid touching heating elements.
•Children less than 8 years of age shall be kept away unless
continuously supervised.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
•Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without
supervision.
•WARNING: Unattended cooking on a hob with fat or oil
can be dangerous and may result in fire. NEVER try to
extinguish a fire with water, but switch off the appliance
and then cover flame e.g. with a lid or a fire blanket.
•WARNING: Danger of fire: do not store items on the
cooking surfaces.
•WARNING: If the surface is cracked, switch off the
appliance to avoid the possibility of electric shock, for hob
surfaces of glass-ceramic or similar material which protect
live parts.
•A steam cleaner is not to be used.
•The appliance is not intended to be operated by means of an
external timer or separate remote-control system.
•CAUTION: The cooking process has to be supervised. A
short term cooking process has to be supervised
continuously.
•Power cord can’t accessible after installation.

7
Congratulations on the purchase of your new hob. We recommend that you
spend some time to read this Instruction / Installation Manual in order to fully
understand how to install correctly and operate it.
Read all the safety instructions carefully before use and keep this Instruction /
Installation Manual for future reference.
Product Overview
Top View
UBKCIND60BV / UBKCIND60PF
The Control Panel
UBKCIND60BV / UBKCIND60PF
1. ON/OFF switch
2.
Knob power control
3. Residual heat indicator
4. Heating zone
1. max. 1800 W zone
2. max. 1200 W zone
3. max. 1800 W zone
4. max. 1200 W zone
5. Control panel

8
Product Information
The ceramic/induction hob can meet different kinds of cuisine demands because of
resistance wire heating, micro-computerized control and multi-power selection, really
the optimal choice for modern families.
The hob centers on customers and adopts personalized design. The hob has safe and
reliable performances, making your life comfortable and enabling to fully enjoy the
pleasure from life.
Before using your New Hob
•Read this guide, taking special note of the ‘Safety Warnings’ section.
•Remove any protective film that may still be on your Induction hob.
Using the Touch Controls
•The controls respond to touch, so you don’t need to apply any pressure.
•Use the ball of your finger, not its tip.
•You will hear a beep each time a touch is registered.
•Make sure the controls are always clean, dry, and that there is no object (e.g. a
utensil or a cloth) covering them. Even a thin film of water may make the
controls difficult to operate.
Choosing the right Cookware
•Only use cookware with a base suitable for induction cooking. Look for the
induction symbol on the packaging or on the bottom of the pan.
•You can check whether your cookware is suitable by carrying out a magnet
test. Move a magnet towards the base of the pan. If it is attracted, the pan is
suitable for induction.
•If you do not have a magnet:
1. Put some water in the pan you want to check.
2. Follow the steps under ‘To start cooking’.
3. If there is no any beep sounds and the water is heating,
the pan is suitable.

9
4. If there is 2 beep sounds each cycle, which means the
pan is not suitable, and you need to change another pan.
•Cookware made by the following materials is not
suitable: pure stainless steel, aluminum or copper
without a magnetic base, glass, wood, porcelain, ceramic,
and earthenware.
Size of burner (mm)
The minimum cookware (diameter /mm)
160
120
180
140
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same
size as the cooking zone. Always centre your pan on the cooking zone.
Always lift pans off the ceramic hob –do not slide, or they may scratch the glass.
Using your Hob
To start cooking
•After power on, the buzzer beeps once, the indicators light up for 1 second then go
out, indicating that the hob has entered the state of standby mode.
1. Touch the ON/OFF switch, and the switch
indicator will display.
Note: Each cooking zone is independent of others.

10
2. Place a suitable pan on the cooking zone that you
wish to use.
Make sure the bottom of the pan and the surface of
the cooking zone are clean and dry.
3. Select power level by turning the “knob” control to
right.
•If you don’t choose a heat setting within 1
minute, the induction hob will automatically
switch off. You will need to start again at
step 1.
•You can modify the heat setting between 1
and 9 level at any time during cooking.
Note: Do not leave the cooking unattended.
When you have finished cooking
1. Select the cooking zone that you wish to swich off.
2. Turn the cooking zone off by scrolling “knob”control
to left to“OFF”. The Residual heat indicator will flash.
3. Turn the whole cooktop off by touching the ON/OFF
control.
4. Beware of hot surfaces
Residual heat indicator will flash which means cooking zone is too hot to touch. It
will disappear when the surface has cooled down to a safe temperature. It can also
be used as an energy saving function if you want to heat further pans, use the
hotplate that is still hot.

11
Residual Heat Warning
When the hob has been operating for some time, there will be some residual heat. The
indicator “” appears to warn you to keep away from it.
Auto Shutdown
Safety feature of the hob is auto shut down. This occurs whenever you forget to switch
off a cooking zone. The default shutdown times are shown in the table below:
Power level
1
2
3
4
5
6
7
8
9
Default working timer (hour)
8
8
8
4
4
4
2
2
2
Cooking Guidelines
Take care when frying as the oil and fat heat up very quickly, particularly if you’re
using Boost. At extremely high temperatures oil and fat will ignite spontaneously
and this presents a serious fire risk.
Cooking Tips
•When food comes to the boil, reduce the power setting.
•Using a lid will reduce cooking times and save energy by retaining the heat.
•Minimise the amount of liquid or fat to reduce cooking times.
•Start cooking on a high setting and reduce the setting when the food has heated
through.
Simmering, cooking rice
•Simmering occurs below boiling point, at around 85˚C, when bubbles are just rising
occasionally to the surface of the cooking liquid. It is the key to delicious soups and
tender stews because the flavours develop without overcooking the food. You
should also cook egg-based and flourthickened sauces below boiling point.
•Some tasks, including cooking rice by the absorption method, may require a setting
higher than the lowest setting to ensure the food is cooked properly in the time
recommended.

12
Searing steak
To cook juicy flavoursome steaks:
1. Stand the meat at room temperature for about 20 minutes before cooking.
2. Heat up a heavy-based frying pan.
3. Brush both sides of the steak with oil. Drizzle a small amount of oil into the hot pan
and then lower the meat onto the hot pan.
4. Turn the steak only once during cooking. The exact cooking time will depend on the
thickness of the steak and how cooked you want it. Times may vary from about 2 –8
minutes per side. Press the steak to gauge how cooked it is –the firmer it feels the
more ‘well done’ it will be.
5. Leave the steak to rest on a warm plate for a few minutes to allow it to relax and
become tender before serving.
For stir-frying
1. Choose a ceramic compatible flat-based wok or a large frying pan.
2. Have all the ingredients and equipment ready. Stir-frying should be quick. If cooking
large quantities, cook the food in several smaller batches.
3. Preheat the pan briefly and add two tablespoons of oil.
4. Cook any meat first, put it aside and keep warm.
5. Stir-fry the vegetables. When they are hot but still crisp, turn the cooking zone to a
lower setting, return the meat to the pan and add your sauce.
6. Stir the ingredients gently to make sure they are heated through.
7. Serve immediately.

13
Heat Settings
Heat setting
Suitability
1 - 2
•delicate warming for small amounts of food
•melting chocolate, butter, and foods that burn quickly
•gentle simmering
•slow warming
3 - 4
•reheating
•rapid simmering
•cooking rice
5 - 6
•pancakes
7 - 8
•sauteing
•cooking pasta
9
•stir-frying
•searing
•bringing soup to the boil
•boiling water

14
Care and Cleaning
What?
How?
Important!
Everyday soiling on
glass (fingerprints,
marks, stains left by
food or non-sugary
spillovers on the glass)
1. Switch the power to the cooktop off.
2. Apply a cooktop cleaner while the
glass is still warm (but not hot!)
3. Rinse and wipe dry with a clean
cloth or paper towel.
4. Switch the power to the cooktop
back on.
•When the power to the cooktop is
switched off, there will be no ‘hot
surface’ indication but the cooking
zone may still be hot! Take extreme
care.
•Heavy-duty scourers, some nylon
scourers and harsh/abrasive cleaning
agents may scratch the glass. Always
read the label to check if your cleaner
or scourer is suitable.
•Never leave cleaning residue on the
cooktop: the glass may become
stained.
Boilovers, melts, and
hot sugary spills on
the glass
Remove these immediately with a fish
slice, palette knife or razor blade
scraper suitable for ceramic glass
cooktops, but beware of hot cooking
zone surfaces:
1. Switch the power to the cooktop off
at the wall.
2. Hold the blade or utensil at a 30°
angle and scrape the soiling or spill
to a cool area of the cooktop.
3. Clean the soiling or spill up with a
dish cloth or paper towel.
4. Follow steps 2 to 4 for ‘Everyday
soiling on glass’ above.
•Remove stains left by melts and
sugary food or spillovers as soon
as possible. If left to cool on the
glass, they may be difficult to
remove or even permanently
damage the glass surface.
•Cut hazard: when the safety cover
is retracted, the blade in a scraper
is razor-sharp. Use with extreme
care and always store safely and
out of reach of children.
Spillovers on the
touch controls
1. Switch the power to the cooktop off.
2. Soak up the spill
3. Wipe the touch control area with a
clean damp sponge or cloth.
4. Wipe the area completely dry
with a paper towel.
5. Switch the power to the cooktop
back on.
•The cooktop may beep and turn
itself off, and the touch controls
may not function while there is
liquid on them. Make sure you wipe
the touch control area dry before
turning the cooktop back on.

15
Hints and Tips
Problem
Possible causes
What to do
The cooktop cannot
Be turned on.
No power.
Make sure the cooktop is connected to
the power supply and that it is
switched on.
Check whether there is a power
outage in your home or area. If you’ve
checked everything and the problem
persists, call a qualified technician.
The touch controls are
unresponsive.
The controls are locked.
Unlock the controls. See section
‘Using your ceramic cooktop’ for
instructions.
The touch controls are
difficult to operate.
There may be a slight film of
water over the controls or you
may be using the tip of your
finger when touching the
controls.
Make sure the touch control area is
dry and use the ball of your finger
when touching the controls.
The glass is being
scratched.
Rough-edged cookware.
Unsuitable, abrasive scourer or
cleaning products being used.
Use cookware with flat and smooth
bases. See ‘Choosing the right
cookware’.
See ‘Care and cleaning’.
Some pans make crackling
or clicking noises.
This may be caused by the
construction of your cookware
(layers of different metals
vibrating differently).
This is normal for cookware and
does not indicate a fault.
The induction hob makes a
low humming noise when
used on a high heat setting.
This is caused by the technology
of induction cooking.
This is normal, but the noise should
quieten down or disappear completely
when you decrease the heat setting.
Fan noise coming from the
induction hob.
A cooling fan built into your
induction hob has come on to
prevent the electronics from
overheating. It may continue to
run even after you’ve turned the
induction hob off.
This is normal and needs no action.
Do not switch the power to the
induction hob off at the wall while the
fan is running.
Pans do not become hot
and appears in the display.
The induction hob cannot
detect the pan because it is not
suitable for induction cooking.
The induction hob cannot detect the pan
because it is too small for the cooking
zone or not properly centered on it.
Use cookware suitable for induction
cooking. See section ‘Choosing the
right cookware’.
Centre the pan and make sure that its
base matches the size of the cooking
zone.
The induction hob or a
cooking zone has turned
itself off unexpectedly, a
tone sounds and an error
code is displayed (typically
alternating with one or two
digits in the cooking timer
display).
Technical fault.
Please note down the error
letters and numbers, switch
the power to the induction hob
off at the wall, and contact a
qualified technician.

16
Failure Indicator
If an abnormality comes up, the induction hob will enter the protective state
automatically and there is 3 beep sounds each cycle.
Please do not disassemble the unit by yourself to avoid any dangers and damages to the
induction hob.
Technical Specification
Induction Hob
UBKCIND60BV
Cooking Zones
4 Zones
Supply Voltage
220-240V~ 50/60Hz
Installed Electric Power
6000W
Product Size D×W×H(mm)
590×520×58
Building-in Dimensions A×B (mm)
560×490
Induction Hob
UBKCIND60PF
Cooking Zones
4 Zones
Supply Voltage
220-240V~ 50/60Hz
Installed Electric Power
6000W
Product Size D×W×H(mm)
590×520×58
Building-in Dimensions A×B (mm)
560×490
Weight and Dimensions are approximate. Because we continually strive to improve our products
we may change specifications and designs without prior notice.

17
Installation
Selection of installation equipment
•Cut out the work surface according to the sizes shown in the drawing.
•For the purpose of installation and use, a minimum of 50mm space shall be
preserved around the hole.
•Be sure the thickness of the work surface is at least 30mm. Please select
heat-resistant work surface material to avoid larger deformation caused by the heat
radiation from the hotplate. As shown below:
Warning: The work surface material must use the impregnated wood or other insulation
material.
L(mm)
W(mm)
H(mm)
D(mm)
A(mm)
B(mm)
X(mm)
UBKCIND60BV
590
520
58
54
560
490
50 mini
UBKCIND60PF
590
520
58
54
560
490
50 mini
Under any circumstances, make sure the hob is well ventilated and the air inlet
and outlet are not blocked. Ensure the hob is in good work state. As shown below
Note: The safety distance between the hotplate and the cupboard above the hotplate
should be at least 760mm.

18
A(mm)
B(mm)
C(mm)
D
E
760
50 mini
20 mini
Air intake
Air exit 5mm
Before you install the hob, make sure that
•Tthe work surface is square and level, and no structural members interfere with
space requirements.
•The work surface is made of a heat-resistant material.
•If the hob is installed above an oven, the oven has a built-in cooling fan.
•The installation will comply with all clearance requirements and applicable
standards and regulations.
•A suitable isolating switch providing full disconnection from the mains power
supply is incorporated in the permanent wiring, mounted and positioned to comply
with the local wiring rules and regulations.
•The isolating switch must be of an approved type and provide a 3mm air gap contact
separation in all poles (or in all active [phase] conductors if the local wiring rules
allow for this variation of the requirements).
•The isolating switch will be easily accessible to the customer with the hob installed
•You consult local building authorities and by-laws if in doubt regarding installation
•You use heat-resistant and easy-to-clean finishes (such as ceramic tiles) for the wall
surfaces surrounding the hob.

19
When you have installed the hob, make sure that
•The power supply cable is not accessible through cupboard doors or drawers.
•There is adequate flow of air from outside the cabinetry to the base of the hob.
•If the hob is installed above a drawer or cupboard space, a thermal protection barrier
is installed below the base of the hob.
•The isolating switch is easily accessible by the customer.
Before locating the fixing brackets
The unit should be placed on a stable, smooth surface (use the packaging). Do not apply
force onto the controls protruding from the hob.
Locating the fixing brackets
•The unit should be placed on a stable, smooth surface (use the packaging). Do not
apply force onto the controls protruding from the hob.
•Fix the hob on the work surface by screw four brackets on the bottom of hob (see
picture) after installation.
•Adjust the bracket position to suit for different work surface’s thickness.
UBKCIND60BV/UBKCIND60PF

20
Cautions
The hob must be installed by qualified personnel or technicians. We have
professionals at your service. Please never conduct the operation by yourself.
The hob shall not be mounted to cooling equipment, dishwashers and rotary dryers.
The hob shall be installed such that better heat radiation can be ensured to enhance
its reliability.
The wall and induced heating zone above the work surface shall withstand heat.
To avoid any damage, the sandwich layer and adhesive must be resistant to heat.
A steam cleaner is not to be used.
This ceramic can be connected only to a supply with system impedance no more
than 0.427 ohm. In case necessary, please consult your supply authority for system
impedance information.
Connecting the hob to the mains power supply
The power supply should be connected in compliance with the relevant standard, or a
single-pole circuit breaker. The method of connection is shown below.
UBKCIND60BV / UBKCIND60PF
If the cable is damaged or needs replacing, this should be done by an after-sales
technician using the proper tools, so as to avoid any accidents.
If the appliance is being connected directly to the mains supply, an omnipolar circuit
breaker must be installed with a minimum gap of 3mm between the contacts.
The installer must ensure that the correct electrical connection has been made and
that it complies with safety regulations.
The cable must not be bent or compressed.
The cable must be checked regularly and only replaced by a proper qualified person.
