Cuppone Donatello KDN 435 User manual

Donatello
HOOD
Pre-installation and installation manual
KDN 435
KDN 635
KDN 635L
KDN 935

2
Contents
This hood has been designed and constructed with the utmost
care and undergone rigorous tests in our laboratories and for
this reason we guarantee its absolute safety and functionality.
The installation must be carried out by professionally
qualied sta, that can take responsibility for the installation
and guarantee the best safe operating conditions.
Before the installation, read the content of this manual
carefully: it contains important information regarding product
assembly and safety regulations.
Technical service
The Dealer can solve any technical problem regarding
installation.
Do not hesitate to contact him in case of doubt.
Introduction
1CHECKS BEFORE PURCHASING...................................................................................3
2HOOD TECHNICAL DATA .................................................................................................5
Donatello hood technical data.......................................................................................................6
Donatello KDN 435 hood technical data | hood + single oven.................................8
Donatello KDN 435 hood technical data | hood + double oven..............................9
Donatello KDN 435 hood technical data | hood + triple oven................................ 10
Donatello KDN 635 hood technical data | hood + single oven..............................11
Donatello KDN 635 hood technical data | hood + double oven...........................12
Donatello KDN 635 hood technical data | hood + triple oven................................ 13
Donatello KDN 635L hood technical data | hood + single oven ...........................14
Donatello KDN 635L hood technical data | hood + double oven.........................15
Donatello KDN 635L hood technical data | hood + triple oven............................. 16
Donatello KDN 935 hood technical data | hood + single oven..............................17
Donatello KDN 935 hood technical data | hood + double oven...........................18
Donatello KDN 935 hood technical data | hood + triple oven................................ 19
3INSTALLATION........................................................................................................................ 20
Symbols used in the manual and on the labels applied to the machine......... 20
Transport...................................................................................................................................................21
Preliminary operations...................................................................................................................... 21
Serial number plate reading ......................................................................................................... 21
Positioning and connection to the oven below...............................................................22
Wiring diagrams: Suction hood .................................................................................................. 24
Smoke extraction.................................................................................................................................25
Pre-testing and nal inspection..................................................................................................26
Checking the operation...................................................................................................................26
Notes............................................................................................................................................................ 27
The company cannot be held liable for any print or transcription errors, reserving the right to make changes where deemed suitable without prior notice.
Partial reproduction without the Manufacturer's consent is prohibited. Measurements are purely indicative and not binding.
The original language used to prepare this manual is English: the Manufacturer is not responsible for any translation/interpretation or print errors.
CUPPONE 1963
Cuppone F.lli S.r.l.
Via Sile, 36
31057 Silea (TV) - ITALY
T [phone]
F [phone]
[e-mail] - www.cuppone.com

3
Ed. 0221 - 70702730 REV03 Donatello hood - Pre-installation - Installation
Kg
Max 35°C
Max 70% Min 5°C
Max 95°F
Min 41°F
min. 600 mm.
 24 in.
Ø150 mm  Ø5,91 in.
Fig.2.
Fig.1.
1CHECKS BEFORE PURCHASING
Before purchasing the hood and before installing it, check the
following conditions, necessary for the correct installation,
operation and maintenance of the hood.
A Transport (Owner’s inspection)
√Make sure that, on the day when you receive the hood
or it is installed:
• lifting equipment is available that can handle the
appliance safely (check weight and dimensions in the
following pages), together with sta qualied to carry
out this operation;
• personal protection equipment is available (e.g. safety
shoes, gloves, etc.)
B Installation room (Owner’s inspection)
√Make sure that:
• the oor of the installation room is reproof, perfectly
at and capable of withstanding the weight of the
hood and underlying oven.
• the installation room:
• is dedicated and suitable to cooking food;
• has adequate air ventilation;
• complies with the current regulations on health
and safety and systems in the workplace;
• is protected from the weather;
• has a maximum temperature of between +5° (41°F)
and +35°C (95°F);
• has a maximum humidity of 70%.
• between the hood and the ceiling there is a distance
of about 600 mm [24 in.] (shorter distances could
damage ceilings made of particularly delicate and
heat sensitive materials - e.g. wood)
• there is adequate ventilation according to the regula-
tions in force in the Country of installation. If this is not
the case, a ø14 cm [Ø5.51 in.] air intake is mandatory,
communicating with the outside or a ventilated room
(i.e. storeroom, attic, garage, basement).
When choosing the positioning room, take into account
that the appliance must be easy to move for any extraor-
dinary maintenance: be careful that any brickwork after
installation (e.g.: wall construction, replacement of a door with a
narrower one, renovations, etc.) do not hamper movements.
CElectrical connection (qualied electrician’s
inspection)
The equipment is supplied with the power cord already
installed that must be connected to the electrical panel of
the Donatello oven.
Evacuation tube, 150 mm [Ø5,91 in.] in diameter (NOT supplied)

4
min. 600 mm.
 24 in.
C
D
Ø150mm
 Ø5,91 in.
A
B
Ø150 mm  Ø5,91 in.
Fig.3.
Checks before purchasing
D Smoke evacuation (Owner’s inspection)
The oven is tted with an adjustable exhaust in the top
to get rid of the steam from the cooking chamber.
This steam, together with the one from the door during
the work phases, must be conveyed outside through
the hood.
There are two hood variants: the ventilation versions
have a built-in 5-speed suction motor while the user's
exhaust system can be installed in neutral versions.
Fig.3.
The following must be installed during installation:
• the pipe A(supplied by the Manufacturer)
• the connection B(supplied by the Manufacturer)
• a ue Dblocking it with a metallic clamp C
(NEITHER supplied by the Manufacturer).
The ue must:
• be exclusively used by the equipment,
• have a 150 mm diameter [Ø5,91 in.] (to guarantee
correct draught up to a maximum of 20 linear metres
[787.4 in.] , three curves and a terminal on the roof),
• meet current regulations.
The recommended material is stainless steel resistant to
high temperatures.
Provide a condensate drain (not supplied) to permit
normal control and draining operations.

5
Ed. 0221 - 70702730 REV03 Donatello hood - Pre-installation - Installation
2HOOD TECHNICAL DATA
DN 435
Units of
measurement
DN435NT
(neutral)
KDN435AS
(with extraction fan)
Electrical supply
(50/60 Hz) Volt - AC 230
Maximum
absorption
kW
max - 0.13
Connection cable
(n x mm2)
Installed cable type:
H07RN-F three-pole cable for single-phase cabling
Installed cable section:
3x1 mm2silicone cable
Maximum
capacity m3/h - 700
DN 635
Units of
measurement
DN635NT
(neutral)
KDN635AS
(with extraction fan)
Electrical supply
(50/60 Hz) Volt - AC 230
Maximum
absorption
kW
max - 0.13
Connection cable
(n x mm2)
Installed cable type:
H07RN-F three-pole cable for single-phase cabling
Installed cable section:
3x1 mm2silicone cable
Maximum
capacity m3/h - 700
DN 635L
Units of
measurement
DN635LNT
(neutral)
KDN635LAS
(with extraction fan)
Electrical supply
(50/60 Hz) Volt - AC 230
Maximum
absorption
kW
max - 0.13
Connection cable
(n x mm2)
Installed cable type:
H07RN-F three-pole cable for single-phase cabling
Installed cable section:
3x1 mm2silicone cable
Maximum
capacity m3/h - 700
DN 935
Units of
measurement
DN935NT
(neutral)
KDN935AS
(with extraction fan)
Electrical supply
(50/60 Hz) Volt - AC 230
Maximum
absorption
kW
max - 0.13
Connection cable
(n x mm2)
Installed cable type:
H07RN-F three-pole cable for single-phase cabling
Installed cable section:
3x1 mm2silicone cable
Maximum
capacity m3/h - 700
model neutral with extraction fan
DN 435 35 kg [ 77,1 lb ] 40 kg [ 88,1 lb ]
DN 435
1200x1400x580 / 47.24x 55.12x 22.83 in .
57 kg [ 125,6 lb ]
1200x1400x580 / 47.24x 55.12x 22.83 in .
62 kg [ 136,6 lb ]
model neutral with extraction fan
DN 635 35 kg [ 77,1 lb ] 40 kg [ 88,1 lb ]
DN 635
1200x1400x580 / 47.24x 55.12x 22.83 in .
57 kg [ 125,6 lb ]
1200x1400x580 / 47.24x 55.12x 22.83 in .
62 kg [ 136,6 lb ]
model neutral with extraction fan
DN 635L 43 kg [ 94,7 lb ] 48 kg [ 105,8 lb ]
DN 635L
1560x1400x580 / 61.42x 55.12x 22.83 in.
75 kg [ 165,3 lb ]
1560x1400x580 / 61.42x 55.12x 22.83 in.
80 kg [ 176,3 lb ]
model neutral with extraction fan
DN 935 43 kg [ 94,7 lb ] 48 kg [ 105,8 lb ]
DN 935
1560x1400x580 / 61.42x 55.12x 22.83 in.
75 kg [ 165,3 lb ]
1560x1400x580 / 61.42x 55.12x 22.83 in.
80 kg [ 176,3 lb ]
