Cuppone Tiziano KTZ 420 User manual

KTZ 420
KTZ 425
KTZ 230
KTZ 430
KTZ 435
Tiziano
HOOD
Pre-installation and installation,
use and maintenance manual

2
Contents
This hood has been designed and constructed with the utmost
care and undergone rigorous tests in our laboratories and for
this reason we guarantee its absolute safety and functionality.
Before delivery to the customer, the hood is checked and
tested in the Manufacturer's factories.
The “production process check sheet” enclosed with it
guarantees that each step in the production process, from
assembly to packaging, was carefully checked from both the
operating and safety standpoints.
This booklet is dedicated to the pre-installation, installation and
use of the Tiziano hood.
The installation must be carried out by professionally
qualied staff, that can take responsibility for the installation
and guarantee the best safe operating conditions.
Before installation, use and maintenance, carefully read the
contents of this manual: it contains important information
regarding the assembly, use and cleaning of the product and
the safety rules.
Technical service
The Dealer can solve any technical problem regarding
installation.
Do not hesitate to contact him in case of doubt.
Introduction
1CHECKS BEFORE PURCHASING..........................................3
2HOOD TECHNICAL DATA........................................................5
Tiziano KTZ 420 hood technical data............................................6
Tiziano KTZ 425 hood technical data.........................................11
KTZ 230 Tiziano hood technical data .........................................16
Tiziano KTZ 430 hood technical data.........................................21
Tiziano KTZ 435 hood technical data.........................................26
3INSTALLATION (part reserved for the installer)........31
Safety instructions .....................................................31
Symbols used in the manual .................................................................. 31
Installation..................................................................32
Transport ......................................................................................................32
Preliminary operations.........................................................................32
Serial number plate reading ............................................................32
Positioning and connection to the oven below..................33
Smoke extraction....................................................................................33
Inserting the hood filters....................................................................34
Pre-testing and final inspection.....................................................35
4USE (part reserved for the user)........................................36
Safety instructions .................................................... 36
Basic notions.............................................................. 37
Knowing the hood................................................................................. 37
Preparing to use the hood................................................................ 37
Using the hood .......................................................... 38
Cleaning the hood ..................................................... 38
Warnings....................................................................................................... 38
Cleaning the external steel parts .................................................. 38
Hood downtime for prolonged periods................................... 38
Replacements ............................................................ 39
Replacing the filters............................................................................... 39
Disposal at end of life........................................................................... 40
Warranty..................................................................... 41
Something is not working......................................... 42
What to do in case of any malfunction..................................... 42
The company cannot be held liable for any print or transcription errors, reserving the right to make changes where deemed
suitable without prior notice. Partial reproduction without the Manufacturer's consent is prohibited. Measurements are purely
indicative and not binding. The original language used to prepare this manual is English: the Manufacturer is not responsible for
any translation/interpretation or print errors.
CUPPONE 1963
Cuppone F.lli S.r.l.
Via Sile, 36
31057 Silea (TV) - ITALY
T [phone]
F [phone]
[e-mail] - www.cuppone.com

3
Ed. 0121 - 70702700 REV03 Tiziano hood - Pre-installation - Installation
0
200
100
300
°C 400
600
500
0
200
100
300
°C 400
600
500
Kg
Max 35°C
Max 70% Min 5°C
Max 95°F
Min 41°F
Fig. 2
Fig. 1
1CHECKS BEFORE PURCHASING
After purchasing the hood and installing it, check the following
conditions, necessary for the correct installation, operation and
maintenance of the hood.
A Transport (Owner’s inspection)
√Make sure that, on the day when you receive the hood
or it is installed:
• lifting equipment is available that can handle the
appliance safely (check weight and dimensions in the
following pages), together with staff qualified to carry
out this operation;
• personal protection equipment is available (e.g. safety
shoes, gloves, etc.)
B Installation room (Owner’s inspection)
√Make sure that:
• the floor of the installation room is fireproof, perfectly
flat and capable of withstanding the weight of the
hood and underlying oven.
• the installation room:
• is dedicated and suitable to cooking food;
• has adequate air ventilation;
• complies with the current regulations on health
and safety and systems in the workplace;
• is protected from the weather;
• there is a distance of about 850 mm [33.46 in.] from
the ceiling (shorter distances could damage ceilings
made of particularly delicate and heat sensitive
materials - e.g. wood);
• there is adequate ventilation according to the regula-
tions in force in the Country of installation. If this is not
the case, a Ø14 cm air intake is mandatory [Ø5.41 in.]
communicating with the outside or a ventilated room
(i.e. storeroom, attic, garage, basement).
When choosing the positioning room, take into account
that the appliance must be easy to move for any
extraordinary maintenance: be careful that any brickwork
after installation (e.g.: wall construction, replacement of a door
with a narrower one, renovations, etc.) do not hamper
movements.
Evacuation tube, 150 mm [5.91 in.] in
diameter (NOT supplied)
abo ut
850 mm
[33.46 in.]

4
0
200
100
300
°C 400
600
500
0
200
100
300
°C 400
600
500
Ø150mm
[
Ø5,91
in.]
B
AA
Ø150mm
[
Ø5,91
in.]
E
F
D
D
Fig. 3
Fig. 4
Checks before purchasing
D Smoke evacuation (Owner’s inspection)
The oven is fitted with a flue in the top to get rid of the
steam from the cooking chamber.
This steam, together with the one from the door during
the work phases, can be conveyed outside through the
hood.
Fig. 3
The hood must be connected to a flue for the exclusive use
of the appliance that complies with current regulations and
that has a diameter that allows the passage of an exhaust
pipe “ A ” measuring Ø150mm [Ø5,91in] which corresponds
to the diameter of the pipe to be mounted on the hood
by means of a clamp “ B ” (the pipe and the clamp are not
supplied by the Manufacturer) . We recommend that the
evacuation pipe “ A ” is in stainless steel resistant to high
temperatures and complies with the regulations in
force.
Fig. 4
The hood is not equipped with a suction motor, however
it is possible to connect it to a suitable suction system
of the user: connect a Ø150mm [Ø5,91in] exhaust pipe “ D ”
to the hood with a clamp “ E ” and interpose mandatorily a
fume damper “ F ” between the extractor and the hood (the
extractor, the connection pipe and the damper are not
supplied by the Manufacturer).
We recommend that the evacuation pipe “ D ” is in
stainless steel resistant to high temperatures and
complies with the regulations in force.
Provide a condensate drain (not supplied) to permit
normal control and draining operations.
extraction system
suction system not
supplied
clamp not supplied
evacuation pipe not
supplied
evacuation pipe not
supplied
damper not
supplied
clamp not
supplied
damper

5
Ed. 0121 - 70702700 REV03 Tiziano hood - Pre-installation - Installation
0
200
100
300
°C 400
600
500
0
200
100
300
°C 400
600
500
A
B
0
200
100
300
°C 400
600
500
AHood fume exhaust
BOven smoke exhaust
Key
2Tiziano hood technical data
Model
KTZ 420 NT hood weight
11 kg [24,2 lb]
hood packaging measurements
860x1150x190 [33,86x45,28x7,48 in.] 13 kg [28,6 lb]
KTZ 425 NT hood weight
13 kg [28,6 lb]
hood packaging measurements
860x1150x190 [33,86x45,28x7,48in.] 15 kg [33 lb]
KTZ 230 NT hood weight
14 kg [30,8 lb]
hood packaging measurements
860x1150x190 [33,86x45,28x7,48in.] 17 kg [37,4 lb]
KTZ 430 NT hood weight
15 kg [33 lb]
hood packaging measurements
1150x1220x190 [45,28x48,03x7,48 in.] 18 kg [39,6 lb]
KTZ 435 NT hood weight
17 kg [37,4 lb]
hood packaging measurements
1150x1220x190 [45,28x48,03x7,48 in.] 21 kg [46,2 lb]

6
Tiziano KTZ 420 hood technical data | hood

7
Ed. 0121 - 70702700 REV03 Tiziano hood - Pre-installation - Installation
Tiziano KTZ 420 hood technical data | hood + single oven

8
Tiziano KTZ 420 hood technical data | hood + double oven

9
Ed. 0121 - 70702700 REV03 Tiziano hood - Pre-installation - Installation
Tiziano KTZ 420 hood technical data | hood + triple oven

10
Tiziano KTZ 420 hood technical data | hood + quadruple oven

11
Ed. 0121 - 70702700 REV03 Tiziano hood - Pre-installation - Installation
Tiziano KTZ 425 hood technical data | hood

12
Tiziano KTZ 425 hood technical data | hood + single oven

13
Ed. 0121 - 70702700 REV03 Tiziano hood - Pre-installation - Installation
Tiziano KTZ 425 hood technical data | hood + double oven

14
Tiziano KTZ 425 hood technical data | hood + triple oven

15
Ed. 0121 - 70702700 REV03 Tiziano hood - Pre-installation - Installation
Tiziano KTZ 425 hood technical data | hood + quadruple oven

16
Tiziano KTZ 230 hood technical data | hood

17
Ed. 0121 - 70702700 REV03 Tiziano hood - Pre-installation - Installation
Tiziano KTZ 230 hood technical data | hood + single oven

18
Tiziano KTZ 230 hood technical data | hood + double oven

19
Ed. 0121 - 70702700 REV03 Tiziano hood - Pre-installation - Installation
Tiziano KTZ 230 hood technical data | hood + triple oven

20
Tiziano KTZ 230 hood technical data | hood + quadruple oven
