Currys Essentials CFSESV18 Service manual

Freestanding Electric
Cooker
Installation / Instruction Manual
CFSESV18 / CFSEWH18
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 1Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 1 14/01/2021 16:3814/01/2021 16:38

Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 2Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 2 14/01/2021 16:3814/01/2021 16:38

Contents
Safety Warnings............................................................................................................................ 4
Unpacking..................................................................................................................................... 7
Product Overview......................................................................................................................... 8
Front View ...................................................................................................................................................................8
Top View.......................................................................................................................................................................8
Control Panel..............................................................................................................................................................9
Before Using Your Cooker ............................................................................................................ 9
Using Your Hotplates.................................................................................................................... 9
First Time Use of the Hotplates............................................................................................................................9
Choosing the Right Cookware.............................................................................................................................9
Controlling Your Hotplates.................................................................................................................................10
Using the Oven ........................................................................................................................... 10
First Time Use of the Oven .................................................................................................................................10
Shelf Positions.........................................................................................................................................................11
Temperature (Thermostat) Control.................................................................................................................11
Using the Grill ............................................................................................................................. 12
Oven Function Selector Control....................................................................................................................... 12
Cleaning Instructions ................................................................................................................. 13
Cleaning the Outside of the Cooker...............................................................................................................13
Cleaning the Oven Door Glass..........................................................................................................................13
Cleaning the Inside of Your Oven .................................................................................................................... 13
Removing the Oven Door .......................................................................................................... 14
Replacing the Oven Lamp.......................................................................................................... 15
Hints and Tips ............................................................................................................................. 15
Product Fiche and Specications .............................................................................................. 16
Energy Saving Tips and Energy Label....................................................................................... 17
- Main Oven.....................................................................................................................................................17
- Hob ..................................................................................................................................................................17
Installation .................................................................................................................................. 18
Adjusting the Feet ...................................................................................................................... 19
Moving the Cooker ..................................................................................................................... 19
Stability Bracket ......................................................................................................................... 19
Electrical Connection ................................................................................................................. 20
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 3Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 3 14/01/2021 16:3814/01/2021 16:38

4
Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
• It is recommended that this appliance is installed by a qualied electrical
engineer. The manufacturer is not responsible for any damage caused
by incorrect installation.
• Check whether there is any damage to the appliance after you have
unpacked it. If any damage is found, do not use the appliance and
contact the store where you purchased it.
• This appliance is for indoor domestic use only.
• This appliance is for cooking purposes only. It must not be used for other
purposes, for example room heating.
• For disconnection from the mains supply you must have a switch with
a contact separation of at least 3.0 mm in all poles and rated 32 Amp that
provides full disconnection, this must be incorporated in the xed wiring
in accordance with the local wiring rules.
• If the mains cable gets damaged, it should be replaced by an authorized
service agent or qualied electrician in order to avoid a hazard.
• The oven must be used in a well ventilated location and installed on
at/level ground.
• Only operate your appliance in a dry atmosphere.
• Do not use steam cleaners for cleaning the appliance.
• Do not rest any items on or stand on the open door.
• Keep the electrical cables of your other appliances away from hot areas;
do not let them touch the appliance.
• Ensure that the appliance is switched o at the mains supply switch
and allowed to completely cool down before cleaning, replacing the
oven lamp or performing any maintenance to avoid the possibility of an
electric shock or burns.
• Use of your appliance creates moisture in the room in which it is placed,
make sure that your kitchen is well ventilated. Maintain the natural
ventilation ducts properly.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 4Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 4 14/01/2021 16:3814/01/2021 16:38

5
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory and mental capabilities, or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children
without supervision.
• During use the appliance becomes hot. Care should be taken to avoid
touching the heating elements inside the oven or the hotplates.
• The appliance and its accessible parts become hot during use. Care
should be taken to avoid touching heating elements. Children less than 8
years of age shall be kept away unless continuosly supervised.
• Unattended cooking on a hob with fat or oil can be dangerous and may
result in re. NEVER try to extinguish a re with water, but switch o the
appliance and then cover the ame e.g. with a lid or a re blanket.
• The cooking process has to be supervised. A short term cooking process
has to be supervised continuously.
• Danger of re: Do not store items on the cooking surfaces.
• When the oven is hot never touch the oven glass or any other parts that
get hot. Allow the oven to cool before touching these parts.
• Do not use harsh abrasives cleaners or sharp metal scrapers to clean the
oven door glass since they can scratch the surface, which may result in
the glass shattering.
• Before starting to use your appliance, keep curtains, tulle, paper or
ammable materials away from your appliance. Do not keep combustible
or ammable things in or on the appliance.
• If the hob surface is cracked, switch o the appliance to avoid possibility
of electric shock.
• Take care when handling parts with glass, knocks, chips, heavy handling
and dropping could cause the glass to shatter.
• The glass oven door uses toughened glass and is designed to break into
many‘nugget’ size pieces if it breaks. These pieces will still have sharp
edges, please handle broken glass with care.
• The appliance is not intended to be operated by means of an external
timer or separate remote-control system.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 5Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 5 14/01/2021 16:3814/01/2021 16:38

6
• The supplied stability bracket or a recognized cooker stability device
must be tted.
• This appliance is not designed to be used with hob guards. Use of
inappropriate hob guards can cause accidents.
• Do not install your appliance behind a decorative door it may over heat.
• The cooker must not to be used with an extension lead.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 6Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 6 14/01/2021 16:3814/01/2021 16:38

7
Thank you for purchasing your new Currys Essentials Freestanding Electric Cooker.
You must read this manual in order to fully understand how to operate your appliance correctly.
This cooker must be installed by a competent engineer. Please allow the installer to view the
installation section of this manual.
Read all the safety instructions carefully before use and keep this manual for future reference.
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to local
regulations.
The following items are included:
0
50°
100°
150°
0
1
6
5
4
0
1
6
5
4
0
1
6
5
4
0
1
6
5
4
Grill Pan x 1
Grill Pan Rack x 1
Grill Pan Handle x 1
Oven Tray x 1Oven Shelf x 1
The Main Unit
Stability Bracket x 1
If items are missing or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
* All images are for indication only; please refer to your individual unit for actual item.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 7Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 7 14/01/2021 16:3814/01/2021 16:38

8
Product Overview
Front View
1. Cooktop
2. Control Panel
3. Oven Shelf
4. Oven Tray
5. Oven Door
6. Oven Handle
7. Levelling Feet
Top View
1. Large Hotplate
2. Small Hotplate
1
2
2
1
0
50°
100°
150°
0
1
6
5
4
0
1
6
5
4
0
1
6
5
4
0
1
6
5
4
1
3
4
5
6
7
2
* All images are for indication only; please refer to your individual unit for actual item.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 8Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 8 14/01/2021 16:3814/01/2021 16:38

9
Choosing the Right Cookware
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits at, and is the same size as the cooking zone. Always centre
your pan on the cooking zone.
Using Your Hotplates
First Time Use of the Hotplates
Operate your electric hotplates at level 3 for 5 minutes. This will remove any manufacturing residues.
The chrome rings may discolour, this is normal and not a fault with the cooker.
Before Using Your Cooker
Before using your new cooker, please:
• Make sure all the controls are turned o.
• Read this Instruction/Installation Manual, taking special note of the “Safety Warnings” section.
• Turn the mains power on.
This appliance is for cooking purposes only. It must not be used for other purposes, for example room
heating.
Control Panel
1. Oven Function Selector Control
2. Thermostat lamp
3. Temperature (Thermostat) Control
1 3 4 4 4 42 5
4. Hotplate Controls
5. Hotplate Warning Lamp
* All images are for indication only; please refer to your individual unit for actual item.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 9Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 9 14/01/2021 16:3814/01/2021 16:38

10
Low cooking
temperatures
Normal cooking
temperatures
Frying
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 LEVEL 5 LEVEL 6
145 mm 90 W 140 W 175 W 550 W 720 W 1000 W
180 mm 145 W 200 W 275 W 725 W 1000 W 1500 W
2. When the hotplate warning lamp illuminates, this means that one or more of the hotplates are switched on.
3. When you are nished cooking rotate the control back to the“0” position, the hotplate warning lamp will
turn o.
The hotplates will remain hot for some time; do not touch until they have completely cooled down.
Controlling Your Hotplates
1. Rotate the control to the heat level you wish to use for the selected hotplate.
Using the Oven
First Time Use of the Oven
Ensure that nothing has been left in the oven. Remove any insert cards, packaging, labels or plastic bags and
the grill pan handle.. Before connecting the power, use a damp cloth to carefully wipe the inner cavity wall and
housing. Clean all the detachable parts in hot, soapy water before using.
Heat the oven on maximum for 45 minutes. There may be a little smoke and odour upon initial start up (for about
15 mins). This is normal. It is due to the protective substance on the heating elements which protects the cooker
from the eects of corrosion during shipping from the factory.
* All images are for indication only; please refer to your individual unit for actual item.
• Under no circumstances should the oven be lined with aluminium foil as overheating may occur.
• Do not place dishes or baking trays directly onto the base of the oven as it becomes very hot and
damage may occur.
• During use, this appliance becomes hot. Care should be taken to avoid touching hot surfaces,
e.g., oven door, heating elements.
• Accessible parts may become hot when in use. Children should be kept away.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 10Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 10 14/01/2021 16:3814/01/2021 16:38

11
Shelf Positions
1. To get the best results, the smallest distance allowed
between the food and the upper heating element is
30 mm.
2. On the wall of the inner cavity there are 5 dierent
shelf guide slots. You can place the shelf at dierent
heights to achieve the best cooking performance
depending on the temperature set, size of food and
the function of the oven selected. If only the upper
heating element is on, we suggest that you place the
shelf on guide 1 (make sure that there is a minimum
distance of 30 mm between the food and the upper
heating element).
3. Always monitor the food during cooking to ensure
that you are not overcooking it.
4. For heavy food, use the oven tray rather than the wire shelf.
5. During cooking, do not open the door unnecessarily as you will lose heat and your cooking results
may change.
6. Using cake tins when cooking cakes will give better results.
If accurate temperatures are required then this should be checked using an oven thermometer available at most
cookware shops.
Temperature (Thermostat) Control
The temperature can be set from 50°C - 240°C. Select the desired temperature, as follows:
To keep food warm 50 - 100°C position
For traditional oven cooking 50 - 250°C position
For all types of grilling 190°C position
Bread may catch fire if the toasting time is too long. Close supervision
is necessary during toasting.
Guide 1
Guide 2
Guide 3
Guide 4
Guide 5
During use the appliance becomes hot. Care should be taken to avoid touching any elements, hotplates
or the oven glass door. Children should be kept away.
* All images are for indication only; please refer to your individual unit for actual item.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 11Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 11 14/01/2021 16:3814/01/2021 16:38

12
Oven Function Selector Control
This control is used to select the cooking functions available, which are:
The oven’s lamp will be switched on.
The oven’s thermostat, indicator lamp and the lower and upper heating
elements will be switched on.
The oven’s thermostat, indicator lamp and the lower heating element
will be switched on.
The oven’s thermostat, indicator lamp and the upper heating element
will be switched on.
The oven’s indicator lamp and grill heating element will be switched on.
Set the thermostat to a maximum of 190°C.
The oven’s thermostat, indicator lamp, grill and upper heating elements
will be switched on.
Set the thermostat to a maximum of 190°C.
Using the Grill
1. Turn the Oven Function Selector control to the Grill position and ensure the thermostat is set to 190°.
2. Preheat the grill element for approximately 5-10 minutes before placing the food on the grill pan grid in the
grill pan.
3. The grill pan has a detachable handle. When using the grill pan handle, ensure that it is centralised and
secure as shown below.
4. Using the handle, insert the grill pan into the oven onto the oven shelf placed in shelf guide position 1.
The food to be cooked must be placed on the grill pan rack within the grill pan. Ensure there is at least
30 mm between the food and the elements, if necessary use a lower shelf guide slot.
5. Remove the grill pan handle and close the door.
6. Check the food regularly to ensure you do not overcook the food. If slower cooking is required use a lower
shelf guide slot or a lower temperature.
7. The grill pan has a detachable handle. Ensure when using the grill pan handle that it is centralised and secure
as shown below.
• Bread may catch re if the toasting time is too long. Close supervision is necessary during toasting.
• Do not leave the handle in position when grilling. If the handle is left in position when grilling,
it will get very hot.
* All images are for indication only; please refer to your individual unit for actual item.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 12Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 12 14/01/2021 16:3814/01/2021 16:38

13
Cleaning the Inside of Your Oven
• Do not use abrasive cleaners, cloths or pads to clean the enamel.
• Clean the enamel on the inside of the oven when it has cooled down, using household detergents
or an ammonia-based cleaner. You may use‘o the shelf’ oven cleaners, if you carefully follow the
manufacturers’ instructions.
• The oven door can be removed to allow easier access to the inside of your oven. (Please refer to the
"Removing the Oven Door" section)
Cleaning Instructions
• Wipe the oven clean after every use.
• Wipe up spills. Avoid leaving alkaline or acidic substances (such as lemon juice or vinegar) on the oven surfaces.
• Do not use cleaning products with a chlorine or acidic base.
• Never clean the interior, panel, lid, trays and all other parts of the oven by using tools like hard brush, cleaning
mesh or knives. Do not use abrasive, scratching agents or detergents.
• After cleaning the interior parts of the oven with a soapy cloth, rinse it and then dry thoroughly with a soft
cloth.
• Never use ammable agents like acid, thinner or petrol when cleaning your oven.
• Do not wash any part of your oven in a dishwasher.
Cleaning the Outside of the Cooker
Wipe the outside surfaces often, using warm water and a mild household detergent. Any stainless steel parts may
also be cleaned with a suitable cleaner.
Cleaning the Oven Door Glass
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven
door glass since they may scratch the surface, which could result in the
glass shattering.
0
50°
100°
150°
0
1
6
5
4
0
1
6
5
4
0
1
6
5
4
0
1
6
5
4
Before you start cleaning your cooker, please:
• Read the cleaning instructions and the ‘Safety Warnings’sections.
• Turn the cooker o at the wall.
• Allow the cooker to cool fully before cleaning.
• Do not use a steam cleaner.
• If you choose to use a commercial stainless steel cleaner, please read the label to make sure it does not
contain chlorine compounds as these are corrosive and may damage the appearance of your cooker
• Do not use abrasive cleaners, cloths or pads on the outside surfaces.
• Immediately wipe o any caustic cleaners if they are spilled onto the oven door handles.
Take care when handling parts with glass, knocks, chips,
heavy handling and dropping could cause the glass to shatter.
* All images are for indication only; please refer to your individual unit for actual item.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 13Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 13 14/01/2021 16:3814/01/2021 16:38

14
6. To replace the door, repeat the above steps in reverse order ensuring the
hinge slot engages over the edge of the door frame.
Removing the Oven Door
2. The swivel retainers of the right hand and left hand hinges are hooked
onto the metal bar above them. Lift the retainers as shown.
3. Close the oven door gently until it meets the open retainer.
4. Support the door by holding both sides at the same time. Continue to
close the door further then lift to disengage the hinge from the bottom.
5. Pull the oven door towards you to remove the hinges from their slots.
• Ensure the door has cooled down.
• Take care when handling glass.
The oven door can easily be removed as follows:
1. Open the door completely.
* All images are for indication only; please refer to your individual unit for actual item.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 14Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 14 14/01/2021 16:3814/01/2021 16:38

15
Hints and Tips
Problem Possible Causes What To Do
The cooker cannot be
turned on.
No power. Make sure the cooker is
connected to the power and that
the mains supply is switched on.
Check whether there is a power
outage in your home or area.
If you’ve checked everything and
the problem persists, call your
service agent.
The glass has been scratched. Unsuitable, abrasive scourer or
cleaning products being used.
Do not use harsh abrasive
cleaners or sharp metal scrapers
to clean the glass.
Some pans make crackling or
clicking noises.
This may be caused by the
construction of your cookware
(layers of dierent metals
expanding/shrinking dierently).
This is normal for cookware and
does not indicate a fault.
The oven temperature is too high
or too low.
Wrong temperature selected /
or the wrong shelf position
was used.
Check that the recommended
temperatures and shelf position
are being used. Be prepared
to adjust the temperature up
and down. If the temperature
needed is critical use an oven
thermometer.
Replacing the Oven Lamp
Let the oven cavity and the heating elements cool down.
• Remove the glass lens by turning anti-clockwise.
• Unscrew and replace the bulb with a new one suitable for high
temperatures (300°C).
• Ret the glass lens by turning clockwise.
Ensure that the cooker is switched o before replacing the lamp to avoid the possibility of electric shock.
Bulb Specications:
230-240V~ 50 Hz, 25W, E14
* All images are for indication only; please refer to your individual unit for actual item.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 15Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 15 14/01/2021 16:3814/01/2021 16:38

16
Product Fiche and Specications
Brand Essentials
Model CFSEWH18 / CFSESV18
Product Type Electric Cooker
Mass of the appliance 41 Kg
Main Oven cavity
Energy Eciency Index - Convection 93.5
Enegy Class A
Energy Consumption (electricity) - Convection 0.73 kWh/cycle
Heat Source Electric
Volume 55 litres
Number of Cavities 1
This product complies with EN 60350-1
Overall Dimension (W x D X H) 500(W) x 600(D) x 900-930(H) mm
(Not including Controls or Handles)
Oven Lamp 25W
Thermostat 50 - 285°C
Oven Heating Element 1000 + 1000 W
Grill Heating Element 1600 W
Supply Voltage 230 - 240V
Rated Frequency 50 Hz
Vitroceramic Heater 145 mm 1000 W at 230V
1100 W at 240V
Vitroceramic Heater 180 mm 1500 W at 230V
1650 W at 240V
Type of Hob Electric
Number of Cooking Zones 4
Heating Zone(s) Small
Heating Technology Hotplate
Size 14.5 cm diameter
Energy Consumption 193 Wh/Kg
Heating Zone(s) Large
Heating Technology Hotplate
Size 18 cm diameter
Energy Consumption 193 Wh/Kg
Energy Consumption of Hob 193 Wh/Kg
The Hob complies with EN 60350-2
Features and specications are subject to change without prior notice.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 16Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 16 14/01/2021 16:3814/01/2021 16:38

17
Energy Saving Tips and Energy Label
Main Oven
• Cook the meals togeter, if possible.
• Keep the pre-heating time short.
• Do not elongate cooking time.
• Do not forget to turn o the oven at
the end of cooking.
• Do not open the oven door during
cooking.
Hob
• Use cookware that has a at base.
• Use the correct sized cookware for
the cooking zone being used.
• Use a lid on your cookware.
• Minimize the amount of liquid or
fat used.
• When liquids start boiling reduce
the heat.
55 L-
0.73
52344671
CFSESV18 CFSEWH18
55 L-
0.73
52344673
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 17Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 17 14/01/2021 16:3814/01/2021 16:38

18
Installation
• The cooker must be installed by a competent person, if in doubt consult a qualied technician, and in
compliance with local electrical, safety and building regulation standards.
• If the cooker is installed adjacent to furniture which is higher than the hob, a gap of at least 100 mm must be
left between the side of the cooker and the furniture unless non-combustible materials (ceramic tiles, metal
splashback, etc.) are used which then allows this distance to be reduced to 20 mm.
• The furniture walls adjacent to the cooker must be made of heat resistant material (check with your furniture
supplier). The veneered synthetic material and the glue used must be resistant to a temperature of 100°C in
order to avoid ungluing or deformations.
• The cooker may be located in a kitchen, a kitchen/diner or bed-sitting room but not in a room containing a bath
or shower.
• Flammable materials such as curtains, wood, wallpaper, etc. must not be tted immediately behind the
appliance or within 500 mm of the sides.
• Do not place next to a refrigerator.
• This cooker must NOT be placed on a pedestal or base.
• It is essential that the cooker is positioned as stated or freestanding taking into account the distances of any
combustible materials detailed above.
• Any cooker hoods must be installed according to the requirements of the cooker hood instruction/installation
manual but no less than 650 mm.
• Any cupboards placed directly above the cooker must be no less than 700 mm.
For all dimensions marked “X”, please
refer to the information below:
X : 100mm for combustible materials
20mm for non-combustible materials.
500 mm
420 mm
700 mm
X
Cupboard
500 mm
420 mm
650 mm
X
Cupboard
Cooker Hood
* All images are for indication only; please refer to your individual unit for actual item.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 18Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 18 14/01/2021 16:3814/01/2021 16:38

19
Adjusting the Feet
Your oven stands on 4 adjustable feet. When the oven is placed where it will be used, check if the oven is level. If it
is not level, you can adjust by turning the feet clockwise if required. It is possible to raise the appliance a maximum
of 30mm using the feet. DO NOT move the appliance by dragging; it should only be moved by lifting it up.
Level the cooker by screwing the bottom of the feet
in or out, as shown.
Moving the Cooker
Using the tted adjustable feet is
MANDATORY. For safety reasons and to
ensure adequate ventilation,
the cooker chassis MUST NOT sit directly on
the oor, a plinth, or other support surface.
• Two people must always raise the cooker, as shown,
to prevent damaging the adjustable feet.
• Do not lift the cooker by the door handles.
• DO NOT DRAG the cooker. Lift the feet clear of the oor.
* All images are for indication only; please refer to your individual unit for actual item.
Stability Bracket
The supplied stability bracket or a recognized cooker stability device must be tted to either of the back feet
as shown.
50x60 : 420mm
Plastic Foot
Stability Bracket
Wall Plug
Washer
Screw
You can connect a stability
chain (not supplied) to the
screws shown here...
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 19Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 19 14/01/2021 16:3814/01/2021 16:38

20
Electrical Connection
Electric cookers come without a power supply cable. The cooker is designed to operate on an electricity supply
which conforms to the electrical data shown on the Rating Plate. The cooker can be connected to the mains only
after you complete the connections in the terminal box..
For the installation of the supply cable carry out the following operations:
• Release both clips then open the terminal box lid.
Colours of the wires in the mains lead should correspond with the markings (as detailed below and on the label
next to the terminal box) identifying the terminals, proceed as follows:
Ensure all screws are adequately tightened. Do not over tighten as you may risk damaging the screw threads.
The Green & Yellow wire is connected to the terminal marked .
The Brown wire is connected to the terminal marked “L” .
The Blue wire is connected to the terminal marked“N” . Live Neutral
Jumpers
Earth
• The power supply cable must have these minimum requirements:
- Type: H05VV-F (PVC insulated and sheathed exible cable)
- 3 cores x 4 mm2minimum.
• This appliance must be earthed.
• The cooker must be connected to the mains supply with a
switched (double pole) cooker outlet providing full disconnection
correctly fused with a capacity appropriate to that shown on
the cooker Rating Plate and incorporated in the xed wiring in
accordance with the latest wiring regulations. All electrical wiring
from the consumer unit to the cooker, via the switched double
pole cooker outlet, must be of the correct rating.
• The supply cable must be positioned away from any hot parts
of the rear of the cooker. If this cannot be done then another
method of protecting the supply cable from the hot parts must
be used i.e. Heat resistant sleeving or high temperature cables.
The following installation procedure must be carried out by a competent person. If in doubt consult
a qualied electrician. The electrical installation must comply with the IEE Regulations, Building & local
By Laws.
The wires in the mains lead are coloured
in accordance with the following code:
• Green & Yellow — Earth
• Blue — Neutral
• Brown — Live
• Fix the supply cable in the cable clamp, tighten the cable clamp screw and
close the cover.
* All images are for indication only; please refer to your individual unit for actual item.
Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 20Currys Essentials Freestanding Electric Cooker CFSESV18 Manual.indd 20 14/01/2021 16:3814/01/2021 16:38
