INSTRUCTION MANUAL

FREE STANDING GAS COOKER

CFSG60W17

Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 1Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 1 20/01/2021 17:4220/01/2021 17:42

Contents

Safety Warnings............................................................................................................................ 4

Unpacking..................................................................................................................................... 7

Installation .................................................................................................................................... 8

Ventilation Requirements............................................................................................................ 9

Gas Installation............................................................................................................................. 9

Gas Installation Checks ................................................................................................................ 9

Installation and Service Regulations .......................................................................................... 9

Adjusting the Feet ...................................................................................................................... 10

Moving the Cooker ..................................................................................................................... 10

Stability Bracket ......................................................................................................................... 11

Gas Connection........................................................................................................................... 12

Installation Relevant to Natural Gas ............................................................................................................... 12

Installation Relevant to Liquid Petroleum Gas (LPG)................................................................................12

To Connect the Gas Supply:...............................................................................................................................12

Replacement of Burner Injectors .............................................................................................. 13

To Replace the Hob Injectors ............................................................................................................................13

Adjusting the Reduced Flame Position .........................................................................................................13

- Removal of the Oven Burner Injector.................................................................................................. 14

To Replace the Oven/Grill Injectors ................................................................................................................14

- Removal of the Grill Burner Injector .................................................................................................... 14

Adjusting the Reduced Flame Position .........................................................................................................14

Injector Size Table....................................................................................................................... 15

Lubrication of the Gas Taps ....................................................................................................... 15

Electrical Connection ................................................................................................................. 15

Product Overview....................................................................................................................... 16

Front View ................................................................................................................................................................ 16

Top View....................................................................................................................................................................16

Control Panel........................................................................................................................................................... 17

Gas Burners..............................................................................................................................................................17

Before Using Your Cooker .......................................................................................................... 17

Using the Hob Burners ............................................................................................................... 18

Flame Failure Safety Feature..............................................................................................................................18

If the Burner Does Not Light..............................................................................................................................19

If the Flame is Irregular........................................................................................................................................19

General Guidelines................................................................................................................................................ 19

Using the Oven ........................................................................................................................... 21

Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 2Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 2 20/01/2021 17:4220/01/2021 17:42

First Time Use of the Oven ................................................................................................................................. 21

Oven/Grill Control .................................................................................................................................................21

Lighting the Oven ................................................................................................................................................. 21

Flame Failure Safety Feature..............................................................................................................................22

Shelf Positions.........................................................................................................................................................22

Replacing the Anti-tilting Oven Shelf ............................................................................................................22

Adjusting the Temperature................................................................................................................................22

Preheating................................................................................................................................................................23

Cooking.....................................................................................................................................................................23

Using the Grill ............................................................................................................................. 24

Lighting the Grill.................................................................................................................................................... 24

Cooking with the Grill..........................................................................................................................................25

Cleaning Instructions ................................................................................................................. 26

Cleaning the Outside of the Cooker...............................................................................................................26

Cleaning the Oven Door Glass..........................................................................................................................26

Cleaning the Inside of Your Oven ....................................................................................................................26

Cleaning the Gas Hob ..........................................................................................................................................27

Hob Burner Parts and Pan Supports............................................................................................................... 27

Replacing the Hob Burner Parts....................................................................................................................... 27

Hob Controls (Gas Taps) ............................................................................................................. 28

Removing the Oven Door .......................................................................................................... 28

Replacing the Oven Lamp.......................................................................................................... 29

Hints and Tips ............................................................................................................................. 29

Product Fiche and Specications .............................................................................................. 30

Energy Saving Tips and Energy Label ....................................................................................... 31

Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 3Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 3 20/01/2021 17:4220/01/2021 17:42

Safety Warnings

IMPORTANT SAFETY INSTRUCTIONS

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

• This appliance must be installed by a qualied Gas Safe registered

engineer (in the UK). The manufacturer is not responsible for any

damage caused by incorrect installation.

• Check whether there is any damage to the appliance after you have

unpacked it. If any damage is found, do not use the appliance and

contact the store where you purchased it.

• This appliance is for indoor domestic use only.

• The cooker is tted with a moulded mains plug. The mains plug must

remain accessible or a switch providing full disconnection incorporated

in the xed wiring.

• If the mains cable gets damaged, it should be replaced by an authorized

service agent or qualied electrician in order to avoid a hazard.

• The oven must be installed on at/level ground.

• Only operate your appliance in a dry atmosphere.

• Keep the electrical cables of your other appliances away from hot areas;

do not let them touch the appliance.

• Ensure that the appliance is switched o at the mains supply switch and

allowed to completely cool down before cleaning, replacing the oven

lamp or performing any maintenance to avoid the possibility of an

electric shock or burns.

• The use of a gas cooking appliance results in the production of heat,

moisture and products of combustion in the room in which it is installed.

Ensure that the kitchen is well ventilated especially when the appliance

is in use. Keep natural ventilation holes open or install a mechanical

ventilation device (mechanical extractor hood).

• Prolonged intensive use of the appliance may call for additional ventilation,

for example opening of a window, or more eective ventilation, for

example increasing the level of mechanical ventilation where present.

Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 4Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 4 20/01/2021 17:4220/01/2021 17:42

• This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory and mental capabilities, or lack of

experience and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way and understand

the hazards involved. Children shall not play with the appliance. Cleaning

and user maintenance shall not be made by children without

supervision. Cleaning and user maintenance shall not be made by

children without supervision.

• During use the appliance becomes hot. Care should be taken to avoid

touching the parts inside the oven or the hob burners/pan stands.

• The appliance and its accessible parts become hot during use. Care

should be taken to avoid touching heating elements. Children less than 8

years of age shall be kept away unless continuously supervised.

• Unattended cooking on a hob with fat or oil can be dangerous and may

result in re. NEVER try to extinguish a re with water, but switch o the

appliance and then cover the ame e.g. with a lid or a re blanket.

• The cooking process has to be supervised. A short term cooking process

has to be supervised continuously.

• Danger of re: Do not store items on the cooking surfaces.

• When the oven is hot never touch the oven glass or any other parts that

get hot. Allow the oven to cool before touching these parts.

• Do not use harsh abrasives cleaners or sharp metal scrapers to clean the

oven door glass since they can scratch the surface, which may result in

the glass shattering.

• Before starting to use your appliance, keep curtains, tulle, paper or

ammable materials away from your appliance.

• Do not keep combustible or ammable things in, on or near the appliance.

• This appliance is for cooking purposes only. It must not be used for other

purposes, for example room heating.

• Do not use steam cleaners for cleaning the appliance.

• Do not rest any items on the open door and do not let children climb on

or stand on it.

• Take care when handling parts with glass, knocks, chips, heavy handling

and dropping could cause the glass to shatter.

Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 5Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 5 20/01/2021 17:4220/01/2021 17:42

• The glass oven door uses toughened glass and is designed to break into

many‘nugget’ size pieces if it breaks. These pieces will still have sharp

edges, please handle broken glass with care.

• The appliance is not intended to be operated by means of an external

timer or separate remote-control system.

• This appliance is not designed to be used with hob guards. Use of

inappropriate hob guards can cause accidents.

• Do not install your appliance behind a decorative door it may over heat.

• The cooker must not to be used with an extension lead.

• To prevent the appliance tipping, the stabilizing

bracket must be installed.

Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 6Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 6 20/01/2021 17:4220/01/2021 17:42

Thank you for purchasing your new Currys Essentials Free Standing Gas Cooker.

You must read this manual in order to fully understand how to operate it correctly.

This unit MUST be installed by a competent and Registered Engineer (Gas Safe in the UK).

Please allow the installer to view the installation section of this manual.

Read all the safety instructions carefully before use and keep this manual for future reference.

Unpacking

Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to local regulations.

The following items are included:

The Main Unit

Stability Bracket x 1

Baking Tray Shelf x 1Oven Shelf x 1

Pan Supports (Left/Right) × 2

Large Burner Ring × 1

Large Burner Cap × 1

Standard Burner Ring × 2

Standard Burner Cap × 2

Small Burner Ring × 1

Small Burner Cap × 1

If items are missing or damaged please contact Partmaster (UK only).

Tel: 0344 800 3456 for assistance.

LPG Conversion Kit:

LPG nozzles x 6

LPG Replacement Rating

Plate Sticker x 1

LPG Nozzle Installation

Guide x 1

Large Burner

Standard Burner x 2

Small Burner

Oven Burner

Grill Burner

Grill deector x 1

* All images are for indication only; please refer to your individual unit for actual item.

Grill Rack x 1

Grill Pan x 1

Grill Pan Handle x 1

Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 7Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 7 20/01/2021 17:4220/01/2021 17:42

Installation

• The cooker must be installed by a competent and Gas Safe Registered Engineer (in the UK) and in compliance

with local safety and building regulation safety standards.

• Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the

adjustment of the appliance are compatible. The adjustment conditions for this appliance are stated on the

label (or data plate).

• The cooker may be located in a kitchen, a kitchen/diner or bed-sitting room in accordance with the latest

editions of BS6172, BS5440-2 and BS6891, but not in a room containing a bath or shower. Please refer to the

local legislation/regulations to ensure location is permitted.

• If the cooker is installed adjacent to furniture which is higher than the gas hob, a gap of at least 100 mm must

be left between the side of the cooker and the furniture unless non-combustible materials (ceramic tiles, metal

backsplash etc.) are used which then allows this distance to be reduced to 20 mm.

• The furniture walls adjacent to the cooker must be made of heat resistant material (check with your furniture

supplier). The veneered synthetic material and the glue used must be resistant to a temperature of 100°C in

order to avoid ungluing or deformations.

• Flammable materials such as curtains, wood, wallpaper etc. must not be tted immediately behind the

appliance or within 500 mm of the sides.

• Do not place next to a refrigerator.

• This cooker must NOT be placed on a pedestal or base.

• It is essential that the cooker is positioned as stated or freestanding ensuring the distances to ammable

materials etc. are still observed.

• Any cooker hoods must be installed according to the requirements of the cooker hood instruction/installation

manual but no less than 650 mm.

• Any cupboards placed directly above the cooker must be no less than 700 mm away.

For all dimensions marked “X”, please refer to the information below:

X : 100 mm for combustible materials

20 mm for non-combustible materials.

600 mm

420 mm

700 mm

Cupboard

600 mm

420 mm

650 mm

Cupboard

Cooker Hood

* All images are for indication only; please refer to your individual unit for actual item.

Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 8Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 8 20/01/2021 17:4220/01/2021 17:42

Ventilation Requirements

• This appliance is not connected to a combustion products evacuation device. It should be installed and

connected in accordance with current installation regulations. Particular attention should be given to the

relevant requirements regarding ventilation.

• The appliance should be installed in a room or space with an air supply in accordance with the latest edition

of BS5440-2.

• For rooms with a volume of less than 5m3— permanent ventilation of 100cm2free area will be required.

• For rooms with a volume of between 5m3and 10m3a permanent ventilation of 50cm2free area will be required

unless the room has a door which opens directly to the outside air in which case no permanent ventilation

is required.

• For rooms with a volume greater than 10m3— no permanent ventilation is required.

Installation and Service Regulations

• Regardless of room size, all rooms containing the appliance must have direct access to the outside air

via a window that opens or equivalent.

• Where there are other fuel burning appliances in the same room, the latest edition of BS 5440-2 should

be consulted to determine the correct amount of free area ventilation requirements.

Gas Installation

Gas Installation Checks

This cooker uses and is ready to use NATURAL GAS only and cannot be used with any other gas without

modication. This appliance is manufactured for conversion to LPG after tting new injectors, new supply

hose and making adjustments. Refer to“replacement of burner injectors”section for details.

After installation, check for gas soundness. The supply pressure can be checked at the front left hotplate

burner injector.

This appliance must be installed and serviced only by a suitably qualied and Gas Safe Registered

engineer, and in accordance with the current editions of the following standards and regulations or other

locally applicable regulations:

• Gas Safety (Installation and Use) Regulations

• Building Regulations

• British Standards (BS 5440, BS 6172 and BS 6891)

• Regulations for Electrical Installation (BS 7671, (Latest Edition))

Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 9Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 9 20/01/2021 17:4220/01/2021 17:42

Adjusting the Feet

Moving the Cooker

Using the tted adjustable feet is MANDATORY. For safety reasons and to ensure adequate ventilation,

the cooker chassis MUST NOT sit directly on the oor, a plinth, or other support surface.

• Two people must always raise the cooker, as shown, to

prevent damaging the adjustable feet.

• Do not lift the cooker by the door handles.

• DO NOT DRAG the cooker. Lift the feet clear of the oor.

* All images are for indication only; please refer to your individual unit for actual item.

The cooker stands on 4 levelling legs. Your cooker is set at its

lowest level when shipped, it is required that the product is

levelled before operating it. This adjustment can be made

by turning the levelling leg clockwise to raise the cooker, if

required. It is possible to raise the product a maximum of

30mm via the levelling leg. The product must NOT be moved

by dragging. The cooker must always be moved by lifting it

up. The levelling leg can be adjusted by hand or by using the

Stability bracket as a tool.

Level the cooker by screwing the bottom of the feet in or out,

as shown.

The Stability bracket can be used as a tool to

adjust the levelling legs.

Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 10Currys Essentials Free Standing GAS Cooker CFSG60W17 Manual.indd 10 20/01/2021 17:4220/01/2021 17:42
