Curtis RCD313 User manual

Model : RCD313
PROGRAMMABLE COMPACT DISC PLAYER
ALARM CLOCK
AM/FM STEREO RADIO
Operating instructions
20-TRACK PROGRAMMABLE CD PLAYER
LCD CLOCK
AM/FM STEREO RADIO
SNOOZE & SLEEP FUNCTIONS
ALARM FUNCTION-WAKE TO RADIO,CD PLAYER OR BUZZER
AC POWER SUPPLY WITH CLOCK BATTERY BACKUP
STEREO HEADPHONE JACK
BEFORE OPERATING THIS PRODUCT, READ, UNDERSTAND, AND
FOLLOW THESE INSTRUCTIONS.
Be sure to save this booklet for future reference.

SAFETY INSTRUCTIONS
The Lightning flash with
arrowhead symbol, with an
equilateral triangle is intended
to alert the user of the
presence of uninsulated
dangerous voltage within the
product’s enclosure that may
be of sufficient magnitude to
constitute a risk of electric
shock to persons.
CAUTION: TO REDUCE THE RISK
OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
The exclamation point within
an equilateral triangle is
intended to alert the
user of the presence of
important operating and
maintenance (servicing)
instructions in the
literature accompanying
the appliance.
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCHWIDEBLADEOFPLUG
TOWIDESLOT,FULLYINSERT.
WARNING: TO REDUCE THE RISK OF FIRE
ORELECTRICSHOCK,DONOT
EXPOSETHEAPPLIANCETORAIN
ORMOISTURE.

SAFETY INSTRUCTIONS
THESE IMPORTANT SAFETY INSTRUCTIONS ARE
INCLUDED, AS APPLICABLE TO THE APPLIANCE,
CONVEYING TO THE USER THE INFORMATION
ITEMIZED BELOW
1. Read instructions-All the safety and operating instructions should be read before the
appliance is operated.
2. Retain instructions-The safety and operating instructions should be retained for
future reference.
3. Head Warnings-All warnings and cautions on the appliance and in the operating
instructions should be adhered to.
4. Follow instructions-All operating and use instructions should be followed.
5. Water and Moisture-The appliance should not be used near water, e.g. near a
bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a
swimming pool or lake.
6. Wall or Ceiling Mounting-The appliance should not be mounted to a wall or ceiling.
7. Ventilation-The appliance should be situated so that its location or position does not
interfere with its proper ventilation. For example, the appliance should not be
situated on a bed, sofa, rug or similar surface that may block the ventilation
openings, or placed in a built-in installation, such as a bookcase or cabinet, that may
impede the flow of air through the ventilation openings.
8. heat-The appliance should be situated away from neat sources such as radiators,
heat registers, stoves, or other appliances (including amplifiers) that produce heat..
9. Power Sources-The product should be operated only with the type of power supply
indicated on the marking label. If you are not sure of the type of power supply to your
home, consult your product dealer or local power company. For products intended to
operate from battery power, or other sources, refer to the operation instructions.
10. Grounding Polarization-This product may be equipped with a polarized alternating
current line plug (a plug having one blade wider than the other). This plug will fit into
the power outlet only one way this is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the plug should still fail to fit,
contact your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
11. Power-Cord Protection-Power supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them, paying
particular attention to cords at plugs, convenience receptacles, and the point where
they exit from the appliance.

12. Cleaning-The appliance should be cleaned only as recommended by the
manufacturer.
13. Nonuse periods-The power cord of the appliance should be unplugged from the
outlet when left when left unused for a long period of time.
14. Object and Liquid Entry-Care should be taken so that objects do not fall and liquids
are not spilled into the product case through product openings.
15. Damage Requiring Service-Unplug this product from the wall outlet and take it to
qualified service personnel under the following conditions.
a) When the power-supply cord or plug is damaged.
b) If liquid has been spilled into, or objects have fallen into the product.
c) If the product has been exposed to rain or water.
d) If the product does not operate when used according to the operating
instructions.
Adjust only those controls that are covered by the operating instructions as an
improper adjustment of other controls may interfere with the product’s normal
operation.
e) If the product has been dropped or damaged in any way.
f) When the product exhibits a distinct change in performance-this indicates a need
for service.
16. Servicing-The user should not attempt to service the product beyond that described
in the operating instruction. All servicing should be referred to qualified service
personnel.
17. Power Lines-An outside antenna system should not be located in the vicinity of
overhead power lines, or other electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching power lines or circuits as contract with
them might be fatal.
18. If an outside antenna is connected to the receiver, be sure the antenna system is
grounded so as to provide some protection against voltage surges and built up static.
Section 810 of the National Electrical Code ANSI/NEFA 70 provides information with
respect to proper to grounding of the mast and supporting structure, grounding
conductress, location of antenna-discharge unit, size of grounding electrodes, and
requirements for the grounding electrode (see figure).
19. Cleaning-Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
20. Lightning-For added protection for this product during a lightning storm, or when it is
left unattended and unused for long periods of time, unplug it from the wall outlet
and disconnect the antenna or cable system. This will prevent damage to the
product due to lightning and power-line surges.
21. Safety Check-Upon completion of any service or repairs to this product, ask the
service technician to perform safety checks to determine that the product is in
proper operation condition.
22. Overloading-Do not overload wall outlets, extension cords, or integral convenience
receptacles as this can result in a risk of fir or electric shock.

NEC NATIONAL ELECTRICAL CODE
Do not apply oil or petroleum products to this product.
CAUTION
Invisible laser radiation will be emitted when the product is
open and interlocks are defeated. Do not defeat the safety
interlocks.
GRAPHIC SYMBOLS WITH SUPPLEMENTARY MAKING
ARE LOCATED ON THE BOTTOM OF THE UNIT.
USE OF CONTROLS, ADJUSTMENTS, OR PERFORMANCE
PROCED URE HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
Non-wall mounting Instructions:
“Not Suitable For In-Wall Mounting.”

LOCATION OF CONTROLS
1. POWER (ON/OFF) BUTTON
2. CD PROGRAM BUTTON
3. CD REPEAT BUTTON
4. CD REVERSE SKIP/SEARCH BUTTON
5. CD FORWARD SKIP/SEARCH BUTTON
6. CD STOP BUTTON
7. LCD DISPLAY (for CD, clock, Frequency display)
8. CD PLAY/PAUSE BUTTON
9. CD RANDOM BUTTON
10. HOUR SET BUTTON
11. ALARM ON/OFF BUTTON
12. MINUTE SET BUTTON
13. SLEEP BUTTON
14. TIME SETBUTTON
15. LED ON/OFF BUTTON
16. ALARM SET BUTTON
17. AC INPUT SOCKET
18. TUNING KNOB
19. BAND SWITCH (AM /FM/FM ST.)
20. CD DOOR OPEN BUTTON
21. SNOOZE BUTTON
22. VOLUME CONTROL KNOB
23. FUNCTION SWITCH (CD/RADIO/ALARM)
24. HEADPHONE JACK
25. BATTERY DOOR
26. CD DOOR

Unit power supply (mains 120V/60Hz)
Connect the power cable plug to the (120V) wall outlet.
Warning:
Before using the unit. Check that the local mains supply is compatible with the HI-FI System (120V 60Hz).
Do not plug or unplug the power cable when your hands wet.
When planning not to use this unit for long periods of time (i.e, Vacation etc.) disconnect the
plug from the wall outlet.
When disconnecting the power cord from the wall outlet, grasp the plug; do not pull the cord in order to avoid
shock risks caused by the damaged cable.
BATTERY SAFETY PRECAUTIONS:
● Keep batteries away from children and pets.
● Insert the battery observing the proper polarity (+/-). Failure to properly align the battery
polarity can cause personal injury and/or property damage.
● Remove weak or discharged batteries from the product. Remove the battery when the
product will not be used for extended periods of time to prevent damage due to rusted or
corroded batteries
● Never throw batteries into a fire, Do not expose batteries to fire or other heat sources
● Battery Disposal: weak or discharged batteries must be properly disposed of and
recycled in compliance with all applicable laws. For detailed information, contact your
local country solid waste authority.
● Follow the battery manufacturer’s safety, usage, and disposal instructions.
BATTERY BACKUP:
Two 1.5V “AA” batteries (not included) may be installed as a backup option to maintain the
time if electrical power fails. In the event of a power outage, the time will not appear on the
clock LCD Display, however the clock will continue to operate and the actual time will be
maintained. The Clock LCD Display and other functions will resume once electrical power
is restored if using the backup battery .The backup battery should be replaced as needed;
Remove the battery if the clock is not used or stored for long periods of time.
TO SET THE CLOCK TIME
Connect the AC power cord to a wall outlet. Make sure that it is in “Power off”
mode.(Power off LED indicator inside the power ON/OFF button will illuminate)
1. While pressing and holding the TIME.SET BUTTON, press the HOUR BUTTON to set
desired hour
2. While Pressing and holding the TIME.SET BUTTON, press the MINUTE BUTTON to
set desired minute
TO SET ALARM FUNCTION
1. Power off the unit and enter into “POWER OFF” mode. (Power off LED indicator
inside the power ON/OFF button will illuminate)
2. While pressing and holding the AL.SET BUTTON, press the HOUR BUTTON to
set desired alarm hour.
3. While pressing and holding the AL.SET BUTTON, press the MIN BUTTON to set
desired alarm minute.

4. After setting the alarm time as desired, remember to press AL.ON/OFF button to
turn on the alarm function. (“Alarm” indicates on LCD display)
TO WAKE UP TO ALARM BUZZER:
a. Slide the Function switch (CD/RADIO/ALARM) to ALARM position
b. The alarm buzzer will sound for 3 minutes at the set alarm time.
Note: Press ALARM ON/OFF button to turn off the alarm when it sounds.
TO WAKE UP TO CD:
a. Slide the Function Switch (CD/RADIO/ALARM) to CD position
b. Open the CD Door by pressing the CD DOOR OPEN button and insert a CD (with the
label side facing up) into the CD compartment.
c. Close the CD Door.
d. The CD will sound at the set alarm time playing the first track on the CD.
Note: The unit will automatically be turned off after 1 hour.
To deactivate the alarm (CD playing) manually, Press either the STOP Button or Press
the Power on/off button.
TO WAKE UP TO RADIO:
a. Slide the Band Switch (AM/FM/FM ST.) to AM or FM position
b. Press POWER ON/OFF BUTTON to turn on the unit first.
c. Tune the radio to a broadcasting station and adjust the volume as desired.
d. Then press the POWER ON/OFF BUTTON again to turn off the unit. (Backlight will
not illuminate)
e. The radio will sound at the set alarm time.
Note: The unit will automatically be turned off after 1 hour.
To deactivate the alarm (Radio sound) manually, press either the ALARM ON/OFF or
press the POWER ON/OFF BUTTON.
SNOOZE FUNCTION
When you are awakened by music or buzzer but wish to sleep a few minutes more, simply
touch the “SNOOZE” button and it will shut off the music or buzzer for approximately 5
minutes before the music or buzzer sounds again. This can be repeated several times.
SLEEP FUNCTION
1. Set the Function Switch (CD/RADIO/ALARM) and Band Switch (AM/FM/FM ST.) to
the desired source.
2. Press Power ON/OFF button to turn on the unit.
3. Adjust the desired Radio station or CD playing track and adjust the volume control.
4. Repeatedly press the SLEEP BUTTON for desired sleep time of 60,50,40,30,20 and 10
minutes. In radio mode, “Sleep” will appear on the LCD Display.
Note: 00 indicates no sleep function. In radio mode, The “Sleep” will disappear on the LCD
Display.
Note: In CD mode, “SLEEP” will not appear on the LCD, but the sleep setting and
function is the same as Radio.
5. The unit will automatically switch off when the SLEEP time expires.
6. To cancel the sleep time before it expires, simply press the SLEEP BUTTON repeatedly
to select the desired sleep time of “00” or press POWER ON/OFF BUTTON to restart.

HOW TO TURN OFF THE ALARM
To cancel alarm mode:
In “POWER OFF” mode, press ALARM ON/OFF button to turn off the alarm
function. (“Alarm” will disappear on the LCD Display).
RADIO OPERATION
1. Select the Function Switch (CD/RADIO/ALARM) to RADIO position.
2. Select the Band Switch (AM/FM/FM.ST) to AM, FM or FM ST.
3. Press the POWER ON/OFF BUTTON to switch Power on.
4. Rotate the Tuning Control Knob to the desired radio station
Note: For better AM reception, rotate the radio to better position the built-in directional
antenna.
Note: The STEREO Indicator will appear on LCD Display when a program is received
in FM Stereo. If the FM reception is noisy, switch the band selector to the FM position
and the program will be received in Mono radio.
5. Rotate the Volume Control Knob to a comfortable listening level.
6. To switch off the radio, Press the Power ON/OFF Button once.
BACKLIGHT
When the unit is powered on, the backlight will be illuminated.
When the unit is powered off, to illuminate the backlight, please press the LED
ON/OFF button once, press this button again to turn off the backlight.
Note: LED ON/OFF button is valid (no function) if the unit is powered on.
CONDENSATION
On warm humid days, if cold water is poured into a glass, water droplets form on the outside
of the glass. This is called condensation. Condensation may also occur on internal operating parts
of the laser pickup.
Condensation occurs:
·When the unit is brought from the outdoors into a warm room, or if it is in a cold room which is
heated quickly.
·In the summer, if the unit is moved suddenly from an air-conditioned room into a car to a hot or
humid location.
·Should condensation occur, the product may not operate property .When the product is exposed
to temperature extremes, wait for 1-2 hours (to allow the internal parts to adjust to the
surrounding temperature) before use.
HANDLING A COMPACT DISC
Always protect a disc against scratches, soil, dust and etc. If a disc is treated with reasonable
care, wiping off the disc with a soft cloth should be the only maintenance needed to retain its
excellent sound reproduction. Discs should be retained in their original case during periods of
non-use.
Handle a disc only by its edges, Do not touch the surface or rainbow-colored side of the disc
Handle a disc as shown in the illustrations in this section
Use a soft cloth to wipe a disc clean. Do not use benzene, thinner, or other chemical cleaners
to clean the disc as damage may result. A disc should always be wiped in a straight line from its
center to its edge. Never wipe a disc in a circular motion.

Do not expose a disc to direct sunlight, high humidity, or high temperatures for extended
periods of time. Do not place the Disc on other equipment or near any heat source.
Dust on the pickup lens can lead to erratic operation and interruption of the sound during play.
To clean the pickup lens, open the disc compartment and blow the dust off . Using a camera lens
blower(available at most camera stores)
Note: Do not touch the surface of the lens. Do not allow any liquids on the inside of the
product.
To clean the CD player cabinet, use a soft and damp cloth to wire off the exterior surface.
Never use benzol, benzene, or other strong chemical cleaners, as these could damage the
finish.
PLAYING A COMPACT DISC (CD)
NOTE: Never touch the laser lens inside of the CD compartment. Clean the laser lens with a CD
cleaner disc if it becomes dirty.
1. Slide the Function Switch (CD/RADIO/ALARM) to CD position.
2. Open the CD DOOR by pressing the CD Door OPEN button and insert a CD into the
tray with printed label side facing up.
3. Close the CD DOOR and Press the Power on/off button to turn on the unit, the disc will
rotate for a few seconds and then stop.
4. Use the SKIP >>| & SKIP |<< button to choose a track
5. Press the PLAY/PAUSE BUTTON to start play
6. Press the PLAY/PAUSE BUTTON again to pause play.
Press the PLAY/PAUSE Button one more time to resume play.
7. Press the STOP BUTTON to STOP play.
RANDOM PLAY
In CD stop mode, Press the RANDOM BUTTON once, “RANDOM” will appear on
LCD Display. Press PLAY/PAUSE BUTTON, this will enable random tracks to play.
REVERSE/FORWARD Skip & Search
The CD Reverse(SKIP |<<) and CD Forward Skip/Search(SKIP >>|) Buttons can be used to
jump to a different track number or to scan disc tracks at high speed.
Press the CD Reverse Skip Button (SKIP |<<) once to hear the beginning of the current
track. Press it two (2) or more times to hear previous tracks on the disc.
Press the CD Forward Skip Button (SKIP >>|) to hear the next track on the disc.
Press and hold the CD Reverse Search (SKIP |<<) Button, the current track will be
scanned and move backwards to the previous track(s); When the desired track section is found,
release the button and normal play will resume.
Press and hold the CD Forward Search (SKIP >>|) Button, the current track will be
scanned and move forward to the next track(s); When the desired track section is found, release

the selected button and normal play will resume.
REPEAT FEATURE
The CD REPEAT Button may be used to repeat a single track or repeat all tracks on a
compact disc.
Press the REPEAT BUTTON once during playback, the REPEAT indicator on LCD
Display will flash. The same track will be repeated over and over.
Press the REPEAT BUTTON a second time to repeat all tracks. The REPEAT
INDICATOR will not flash.
To cancel REPEAT PLAY, Press the REPEAT BUTTON repeatedly until the REPEAT
INDICATOR disappears.
PROGRAM FEATURE
The Program feature can be used to program up to twenty (20) tracks to play in a
selected order.
1. While in the stop mode only (CD is not playing ), press the CD PROGRAM Button,
LCD Display will show the wording “ PROGRAM 01” and “PROGRAM 01” starts to
flash.
2. Press the CD Reverse/Forward Skip (SKIP |<< or SKIP >>|) Buttons to locate the
desired track.
3. Press the CD PROGRAM BUTTON to select and store the track into memory.
4. Repeat step 2 to 3 to select up to 20 tracks.
5. To play the selected tracks (in the program mode), press the CD PLAY/PAUSE
BUTTON .The track number will appear on the LCD Display and “PROGRAM” will
appear on LCD Display.
6. To hear the previous or next program track, press the CD Reverse Skip(SKIP |<<) or CD
Forward Skip(SKIP >>|) buttons, as appropriate.
Note: After all of the programmed tracks have played, the CD player will return to the
stop mode.
7. To clear the programmed tracks from memory, press STOP two times or open the CD
door in STOP mode to clear the previous programmed tracks.
FOR PRIVATE LISTENING
Connect headphone with plug 3.5mm Diameter to the phone jack. When the headphones are
connected, speakers are automatically disconnected.
Note: In case of error (such as incorrect display etc.),please unplug the AC power cord
from the outlet and remove the backup batteries. After about 1 minute, you can try again.
