Custom LED Blinker Genie User manual

2011-2013 Ducati Diavel Blinker Genie
Illustrated Installation Instructions
This 100% plug-and-play kit allows for run and turn operation of the OEM pilot light assemblies 
(continued on other side)
1) Remove bolt securing side cover on right side of
motorcycle.
2) Remove two bolts securing intake grill.
3) Push intake grill to the side and remove the
10mm bolt securing radiator stay to side cover.
5) Repeat procedure on left side of motorcycle.
6) Locate the OEM blinker lamp connectors, remove
from retention slot behind shroud, and maneuver
connector down as shown. Depress locking tab and
disconnect. Repeat on both sides of motorcycle.
7) Rout long legs of blinker genie harness from
behind steering neck area down to turn signal
connectors on each side of motorcycle. Route wires
inside of frame. See next image for more details.
4) Remove side cover by sliding forward slightly, and
then lifting straight upward.
Slot behind here

12) Reattach one headlamp connector to mounting tab on
frame. Tuck other connector and B.G. body inside of frame
13) Zip-Tie wires as necessary to prevent interference with
steering movement
14) Reinstall the left and right side covers and mounting
hardware.
15)Enjoy! 
Thank you for choosing Custom LED, and supporting USA manufacturing. Please help spread the word! You can share Video of this
product in action on YouTube, and share your pre and post-install pictures on Instagram. Be sure to tag us @Custom_LED_LLC in the
pictures so they will appear on our website Instagram feed!
White wire on LEFT side, Green wire on RIGHT.
To assist
with routing, snake mechanics wire (or similar) from behind radiator
support bolt up to frame area behind neck, and pull harness down.
Blinker Genie
Harness Leg
8) Connect Blinker Genie legs to mating connectors.
Position connector from lamp into in retention slot.
10) Locate the headlamp 2-wire connector attached
to neck. Slide up and off of mounting tab on neck.
Disconnect connector.
11) Connect Blinker Genie connectors to their
mating connectors on the headlamp wires.
9) Tuck other connector behind radiator shroud and
zip tie cables together. Repeat on opposite side.
2-Wire connector sites
behind this 3-wire conn.
