Cyber Power BPE36V60ART2US User manual

User’s Manual
BATTERY PACK
BPE36V60ART2US
BPE72V60ART2US
CyberPower Systems Inc.
www.cpsww.com
K01-0000517-00

Copyright © 2016 CyberPower Systems, Inc.
OVERVIEW
1
The CyberPower Battery packs (BPE36V60ART2US / BPE72V60ART2US) support 50A polarized plugs, and are designed for variety of CyberPower UPS
systems. When combining with the UPS, the Battery pack provides extended runtime with a 36VDC/72VDC external connection. Additional parallel-connected
Battery packs provide the UPS for a longer extended runtime operation.
1K/1.5KVA or 2K/3KVA Battery pack
User’s manual Register card
Rackmount left rail Rackmount right rail
Left hanging bracket Right hanging bracket
Power cord
Rubber feet (12)
Rackmount ears (Stands) (2)
Tie plate (1)
Flat head screws:M5X7L (8)
Pan head screws:M5X12L (4)
Pan head screws:M5X6L (14)
Guide screws:M5X10L (2)
Plastic washers (8)
Screw hole dust covers (12)
UNPACKING

Copyright © 2016 CyberPower Systems, Inc.
HARDWARE INSTALLATION
2
HARDWARE INSTALLATION
These versatile Battery packs can be mounted in a rackmount or vertical
tower orientation. This versatility is especially important to growing
organizations with changing needs that value having the option to
position a Battery pack on a floor or in a rackmount system. Please follow
the instructions below for the respective mounting methods.
SAFETY PRECAUTIONS
CAUTION! To prevent the risk of fire or electric shock, only use the
supplied hardware to attach the mounting brackets.
RACKMOUNT INSTALLATION
Step 1: Remove the dust covers
Remove the dust covers *7pcs from the screw holes.
Step 2: Rackmount ears & hanging brackets installation
Attach two rackmount ears to the Battery pack using the provided
M5X7L*8pcs screws and tighten two hanging brackets with the
M5X6L*6pcs screws.
Step 3: Rackmount rail Installation
The rails adjust to mount in 48-cm (19-inch) panel racks from 52 to
91.5cm (20.5 to 36 inches) deep. Select the proper holes in the rack for
positioning the Battery pack in the rack. The Battery pack takes up
position 1 through 6.
Tighten the provided M5X10L*2pcs guide screws on the center hole of
the rear side for each rail.
Position the guide screws on the rails into the rear rack square holes to
temporarily support the rails in place. Tighten the front rail screws on the
rack.

Copyright © 2016 CyberPower Systems, Inc.
HARDWARE INSTALLATION
3
Step 4: Adjust rackmount rails to fit your rack
Adjust the rail depth to match your rack depth. Attach the rackmount rail
to your rack with two screws and two plastic washers at the front of the
rack. (Located in position 1 & position 4) Tighten the M5X6L screws on
the front bracket. Secure the rail to the rear of the rack with two M5X6L
screws and two plastic washers.
Step 5: Place and secure the Battery pack on the rails
Slide the hanging brackets on the Battery pack into the rails mounted in
the rack with the front of the unit facing toward you. Secure the Battery
pack to your rack with four M5X12L*4pcs screws at the front of the rack.
(Located in position 2 & position 5)
How to Slide out Battery pack from rail
The Battery pack will be secured by a safety locking mechanism midway
of pulling it out of the rack. Use both hands to hold the Battery pack and
press the safety locking tab to pull the Battery pack out.

Copyright © 2016 CyberPower Systems, Inc.
HARDWARE INSTALLATION
4
VERTICAL/TOWER INSTALLATION
Step 1: Adhere the rubber feet on the bottom side of base stands
Adhere the protective rubber feet on the bottom side of base stands
(rackmount ears) UPS and Battery pack.
Step 2: Attach the base stands and attach the dust covers
Secure the tie bracket with the screws (M5X7*4pcs). Tighten the screws
(M5X12*4pcs) of the base stands (rackmount ears) onto the bottom of
the UPS and Battery pack. Insert dust covers into the screw holes that
are not being used.
Step 3: Rotate the Multifunction LCD Module
Unscrew the upper panel of the UPS. Separate the upper panel from the
UPS. Gently lift the LCD module out. Rotate it to the tower orientation.
Reinstall it for a tower configuration.
SAFETY PRECAUTIONS
CAUTION! Installation environment should be in a temperature and
humidity controlled indoor area free of conductive contaminants. Do not
install this Battery pack where excessive moisture or heat is present
(Please see specifications for acceptable temperature and humidity
range).
CAUTION! Never install a Battery pack, or associated wiring or equipment,
during a lightning storm.
CAUTION! Do not work alone under hazardous conditions.
CAUTION! In case of the risk of electric shock, do not remove the top
cover.
CAUTION! The battery can energize hazardous live parts inside even
when the AC input power is disconnected.

Copyright © 2016 CyberPower Systems, Inc.
5
BASIC OPERATION
BATTERY PACK FRONT/REAR PANEL DESCRIPTION
1. On-board Replaceable Fuse Cover
Replaceable fuse is accessible from the rear panel. It must
be done by qualified personnel.
2. Input Connector
Use this input connector to daisy chain the next Battery
pack. Remove the connector cover for access.
3. Output Cable
Use this output cable to connect the Battery pack to the
UPS or to the next Battery pack.
BPE36V60ART2US / BPE72V60ART2US
CONNECTION #1 : UPS WITH ONE BATTERY PACK
Step 1: Turn off the DC breaker of the Battery pack.
Step 2: Loosen the two screws to remove the battery cable
retention bracket of the UPS.
Step 3: Use the output cable of the Battery pack to connect the
Battery pack to the UPS.
Step 4: Rotate the battery cable retention bracket and tighten
the two screws to fix battery cable.
Step 5: Use a power cord to plug AC input inlet of the battery
pack into a wall receptacle.
Step 6: Turn on the DC breaker of the Battery pack.

Copyright © 2016 CyberPower Systems, Inc.
BASIC OPERATION
6
CONNECTION #2 : UPS WITH MULTIPLE BATTERY PACKS
Step 1: Connect the 1st Battery pack to the UPS using the
instructions above.
Step 2: Turn off the DC breaker of the 2nd Battery module.
Step 3: Loosen the two screws to remove the battery cable
retention bracket of the 1st battery pack.
Step 4: Use the output cable of the 2nd Battery pack to
connect the 2nd Battery pack to the 1st Battery pack.
Step 5: Rotate the battery cable retention bracket and tighten
the two screws to fix battery cable.
Step 6: Use a power cord to plug AC input inlet of the 2nd battery
pack into AC output outlet of the 1st Battery pack.
Step 7: Turn on the DC breaker of the 2nd Battery module.

Copyright © 2016 CyberPower Systems, Inc.
7
BASIC OPERATION
EXTERNAL BATTERY PACKS CONFIGURATION
External Battery Packs can be configured by the user to display correct estimated battery runtimes.
1. Press the “ENTER” button to activate the “MAIN MENU”.
2. Press the “▲”and “▼”buttons to scroll to the “Configure”option.
3. Press the “ENTER” button to select the “Configure”submenu.
4. Press the “▲”and “▼”buttons to scroll to the “EBP Number”option.
5. Press the “ENTER” button to select the “EBP Number”submenu.
The first configuration number will be displayed on the second column of LCD display.
6. Press the “▲”and “▼”buttons to scroll through the number of attached Battery packs.
7. Press the “ENTER” button to select the number of Battery packs installed.
You may be prompted to save the selection, if so press the “ENTER” button to save the setting.
8. Press the “ESC” button to cancel or return to the previous LCD menu.
Configure Submenu
Available Settings
Default Settings
EBP Number
= [0] [1] [2] [3] [4] [5] [6] [7] [8] [9] [10]
0

Copyright © 2016 CyberPower Systems, Inc.
MAINTENANCE
8
Storage
To store your UPS for an extended period, cover it and store with the
battery fully charged. Recharge the battery every three months to ensure
battery life.
Battery Replacement
Please read and follow the Safety Instructions before servicing the
battery. Battery replacement should be performed by trained personnel
who are familiar with the procedures and safety precautions. Make a note
of the replacement Battery pack number.
Safety Precautions
CAUTION! Only use replacement batteries which are certified by
CyberPower Systems. Use of incorrect battery type is an electrical
hazard that could lead to explosion, fire, electric shock, or short circuit.
CAUTION! Batteries contain an electrical charge that can cause
severe burns. Before servicing batteries, please remove any conductive
materials such as jewelry, chains, wrist watches, and rings.
CAUTION! Do not open or mutilate the batteries. Electrolyte fluid is
harmful to the skin/eyes and may be toxic.
CAUTION! To avoid electric shock, turn off and unplug the Battery
pack from the wall receptacle before servicing the battery.
CAUTION! Only use tools with insulated handles. Do not lay tools or
metal parts on top of the UPS or battery terminals.
Replacement Batteries
Please refer to the front side of the Battery pack for the model number of
the correct replacement batteries. For battery procurement, log onto
www.CPSww.com, or contact your local dealer.
Battery Disposal
Batteries are considered hazardous waste and must be disposed of
properly. Contact your local government for more information about
proper disposal and recycling of batteries. Do not dispose of batteries
in fire.
CyberPower Systems encourages environmentally sound methods for
disposal and recycling of its UPS products. Please dispose and/or
recycle your UPS and batteries in accordance to the local regulations of
your state.
Battery Replacement
Step 1: Remove the front panels Step 2: Remove the retaining screws from the cable protection
cover and then remove the cover itself
Step 3: Pull the battery tray out slowly and
then put the new battery tray back into the
compartment
Step 4: Fasten back the connectors on the
battery retaining cover. Then insert the
battery connectors and tighten the screws
of battery retaining cover
Step 5: Install the front panels

Copyright © 2016 CyberPower Systems, Inc.
TECHNICAL SPECIFICATIONS
9
CyberPower Systems Inc.
www.cpsww.com
Entire contents copyright©2016 CyberPower Systems Inc., All rights reserved. Reproduction in whole or in part
without permission is prohibited. PowerPanel®Business Edition and PowerPanel®Personal Edition are trademarks of
CyberPower Systems Inc.
Model
BPE36V60ART2US
BPE72V60ART2US
Configuration
AC Input Voltage
100~125Vac
DC Output Voltage
36Vdc
72Vdc
Amperage
60A
Physical
Dimensions (L x W x H =)
16.9 x 17 x 3.5in. (430 x 433 x 88mm)
23.6 x 17 x 3.5in. (600 x 433 x 88mm)
Net Weight
50.6lbs(23.0Kg)
96.8lbs(44.0Kg)
Battery
Specifications
(6) (12V9AH) (2 x Banks of 3 Batteries)
(12) (12V9AH) (2 x Banks of 6 Batteries)
Recharge Time (Typically)
4 hours (0~90%)
Interface
PP45
Sealed, Maintenance Free
Yes
Hot-Swappable
Yes
Built-in Charger
Yes
Environment
Operating Temperature
32℉to 104℉( 0℃to 40℃)
Operating Relative Humidity
0 to 90% Non-Condensing
Safety
Conformance Approvals
EAC, CE, RCM
RoHS
RoHS Compliant
Warranty
Product Warranty
3-year limited warranty, Free Tech Support
Problem
Possible Cause
Solution
Warning
BAT Disconnected
Missing battery power.
Check battery connector and battery breaker.
Battery Failure
UPS has failed in Battery Test.
1. Check battery connector and battery breaker.
2. Contact technical support to replace the
battery.
Replace Battery
Battery will soon need to be replaced due to
insufficient runtime.
Contact technical support to replace the battery.
Fault
Over Charge
Battery is overcharged.
1. Remove battery connector and check
charger voltage.
2. Contact CyberPower for repair.
Charger Failure
Charger has failed.
TROUBLE SHOOTING
