Rockwell RW9906 User manual

RW9906
18V LITHIUM-ION BATTERY PACK EN

RW9906
1

RW9906
Red lightGreen light
A1 A2 A3

18V LITHIUM-ION BATTERY PACK EN
4
COMPONENT LIST
1Battery Release Button
Not all the accessories illustrated or described are included in standard delivery.
We recommend that you purchase your accessories listed in the above list from the same store that sold you the tool.
Refer to the accessory packaging for further details. Store personnel can assist you and offer advice.

18V LITHIUM-ION BATTERY PACK EN
5
Safety Warnings for battery pack
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or
serious injury.
Save all warnings and instructions for future
reference.
Use battery pack for POSITEC cordless products only.
Refer to the marking label and instruction manual
provided with product.
Safety Warnings for battery pack
a) Do not dismantle, open or shred cells or battery
pack.
b) Do not short-circuit a battery pack. Do not store
battery packs haphazardly in a box or drawer
where they may short-circuit each other or be
short-circuited by conductive materials. When
battery pack is not in use, keep it away from other
metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects, that can make
a connection from one terminal to another. Shorting
the battery terminals together may cause burns or a
re.
c) Donotexposebatterypacktoheatorre.Avoid
storage in direct sunlight.
d) Do not subject battery pack to mechanical shock.
e) In the event of battery leaking, do not allow the
liquid to come into contact with the skin or eyes.
If contact has been made, wash the affected area
with copious amounts of water and seek medical
advice.
f) Seek medical advice immediately if a cell or
battery pack has been swallowed.
g) Keep battery pack clean and dry.
h) Wipe the battery pack terminals with a clean dry
cloth if they become dirty.

18V LITHIUM-ION BATTERY PACK EN
6
i) Battery pack needs to be charged before use.
Always refer to this instruction and use the correct
charging procedure.
j) Do not maintain battery pack on charge when not
in use.
k) After extended periods of storage, it may
be necessary to charge and discharge the
battery pack several times to obtain maximum
performance.
l) Battery pack gives its best performance when it is
operated at normal room temperature (20 °C ± 5
°C).
m) When disposing of battery packs, keep battery
packs of different electrochemical systems
separate from each other.
n) Rechargeonlywiththechargerspeciedby
POSITEC. Do not use any charger other than that
specicallyprovidedforusewiththeequipment.A
charger that is suitable for one type of battery pack
may create a risk of re when used with another
battery pack.
o) Do not use any battery pack which is not designed
for use with the equipment.
p) Keep battery pack out of the reach of children.
q) Retain the original product literature for future
reference.
r) Remove the battery from the equipment when not
in use.
s) Dispose of properly.
SYMBOLS
To reduce the risk of injury, user must read
instruction manual
Li-Ion battery. This product has been marked
with a symbol relating to ‘separate collection’
for all battery packs and battery pack. It will then
be recycled or dismantled in order to reduce the

18V LITHIUM-ION BATTERY PACK EN
7
impact on the environment. Battery packs can
be hazardous for the environment and for human
health since they contain hazardous substances.
Do not burn
Batteries may enter water cycle if disposed
improperly, which can be hazardous for
ecosystem. Do not dispose of waste batteries as
unsorted municipal waste.
RCM marking
ABN: Australian Business Number. By this number,
business information such as entity type, status,
business location etc. can be found at website
http://abr.business.gov.au.
ABN of Positec Australia Pty Ltd is 14 101 682 357
TECHNICAL DATA
Battery voltage: 18V
Battery capacity: 4.0 Ah
Battery Weight: 0.653 kg
Battery type: Lithium-Ion
Our battery only ts for charger RW9897.
WARNING! Remove the battery pack from the
package and examine it carefully. Do not discard
the carton or any packaging material until all parts have
been examined.
WARNING! If any part of the battery pack is missing
or damaged, do not attach the battery pack to the
tool until the part has been repaired or replaced. Failure
to heed this warning could result serious injury.

18V LITHIUM-ION BATTERY PACK EN
8
OPERATION
NOTE: Before using your tool be sure to read the
instruction manual carefully.
Before attempting to use this tool, became familiar with all of
its operating features and safety requirements. For optimum
performance and safety, read the following operating
instructions carefully before using.
WARNING! Do not allow familiarity with the battery
to cause a lack of alertness. A fraction of a second
of carelessness is enough to cause severe injury.
Do not continue to press the On/Off Switch after the
machine has been automatically switched off. The
battery could be over-discharged.
Note：
1. Your battery pack is UNCHARGED. To ensure full
capacity of the battery, completely charge the battery in
the battery charger before using your power tool for the
rst time.
2. A battery pack will slowly lose its charge when kept out
of the charger or left in an unplugged charger for a long
time. It may need to be recharged before use.
3. Charge the Lithium-Ion battery pack only with the
correct charger.
The Li-Ion battery is protected against deep discharging.
When the battery is empty, the machine is switched off by
means of a protective circuit: The tool no longer rotates. In
a warm environment or after heavy use, the battery pack
may become too hot to permit charging. Allow time for the
battery to cool down before recharging. The Li-Ion battery
can be charged at any time without reducing its service
life. Interrupting the charging procedure does not damage
the battery.
Cold weather operation
When the battery pack is very cold, it may “pulse” for the
rst minute of use in order to warm itself. Put the battery
pack on a tool and use the tool in a light application.
After about a minute, the battery pack will have warmed
itself and will operate normally.

18V LITHIUM-ION BATTERY PACK EN
9
How to charge the battery pack (See Fig. A1-A3)
CHARGING PROCEDURE
1) Plug the charger into an appropriate outlet. The light
will be green.
2) Slide the battery pack into the charger, make sure the
battery is in the correct charge position rmly. The
light will turn to red to indicate the charging process
has started.
3) When charging is completed, the light will turn to
green.
4) After fully charged, unplug the charger and remove
the battery pack.
Store the battery only within a temperature range
between -10
o
C and 55
o
C (in one month). As an example,
do not leave the battery in the car in summer.
A signicantly reduced working period after charging
indicates that the battery is used and must be replaced.
Transport
The contained Li-Ion batteries are subject to the
dangerous goods legislation requirements. The user
can transport the batteries by road without additional
requirements.
Dispatch batteries only when the battery housing is
undamaged. Pack up the batteries in such a manner that
cannot move around in the packaging.
Maintenance and service
Occasionally clean the venting slots of the battery using
a soft, clean and dry brush.
When the battery is no longer operative, please refer
to an authorized after-sales service agent for POSITEC
power tools.

18V LITHIUM-ION BATTERY PACK EN
10
Troubleshooting
PROBLEM POSSIBLE CAUSES SOLUTIONS
The battery
pack does not
work
It has discharged Attach the battery
pack to a charger

POSITEC AUSTRALIA PTY LTD
ABN 14 101 682 357
MADE IN PRC
Copyright © 2018, Positec. All Rights Reserved.
