Cyber Power HT600WSU2A User manual

CONGRATULATIONS ON YOUR PURCHASE
Thank you for selecting the CyberPower HT600WSU2A
Premium Surge Protector. This manual explains the
features and operation of the HT600WSU2A. Please take
a few moments to read this manual.
FEATURES
1. Power
Plug product into any standard, grounded AC outlet to
provide power to your surge protector outlets.
*Caution: Operating this surge protector from a
non-grounded outlet invalidates your “connected
equipment warranty” and puts your valuable
equipment at risk.
2. Firestop Design Advanced Metal-Oxide Varistor
(MOV) with Built-In Fuses
Encased component dissipates surge events and
potential flame, sparks, and heat.
3. Rotating Outlet Bar
The 90-degree rotating outlet bars allow for easier
connection of multiple electronic devices when the wall
tap is mounted in a hard to reach location.
4. Six Tamper-Resistant Outlets
4 standard and 2 transformer spaced outlets.
5. Advanced Protection - Surge Protected LED
Illuminated when protection is working properly.
6. Clean Power - Ground LED
Illuminated when properly grounded.
7. USB Charging Ports*
Connect and charge up to 2 USB devices using the
surge protected USB charging ports.
*USB outlets cannot be used as a USB hub. This device
does not transfer data.
SPECIFICATIONS
• Model Number: HT600WSU2A
• Outlets: 4 standard and 2 transformer spaced outlets
• USB Charging Rating : 5 V/4.8 A total
• Surge Protection: 1,680 Joules
• Electrical Rating: 125 V/15 A/1875 W
• UL Clamping Voltage: UL 1449 3rd/500 V (L-N, L-G, L-G)
• Maximum Peak Current: 60,000 A
• 3 AC Lines Protected: H-N: 30,000 A, H-G: 15,000 A,
N-G: 15,000 A (The maximum surge possible on
household wiring is 6,000 volts)
• Response Time: Less than 1 nanosecond
• Attenuation: Up to 43 dB
• EMI/RFI Filtration: 150 kHz to 100 MHz
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK - Use only
in dry locations and only indoors. DO NOT plug into
another relocatable power tap. DO NOT “daisy chain”
surge protectors. DO NOT use with any aquarium
equipment. DO NOT use if properly grounded outlets are
not available. DO NOT install this device if there is less
than 10 meters (30 feet) or more of wire between the
electrical outlet and electrical service panel. DO NOT use
with ground-fault circuit-interrupter receptacles or
receptacles with indicator lights or controls. DO NOT use
for medical or life support equipment. To reduce the risk
of fire or electric shock, do not use this device with a
receptacle in which the slot openings do not align with
the blades. This device features an internal protection
that will disconnect the surge protective component at
the end of its useful life, but it will maintain unprotected
power to the load.
TROUBLESHOOTING
▪ If the grounded indicator does not light when you plug
in the surge protector, move the surge protector to a
dierent grounded three-prong AC outlet. If it still does
not light, return the product to the retailer for
assistance. If the surge protector appears to be working
properly, your outlets may not be a properly grounded
and need to be repaired by a professional electrician. If
the grounded indicator turns o after a period of use,
the surge protection has been depleted. Replace your
surge protector.
▪ If the protected indicator does not light, the surge
protector’s AC lines are no longer protected from surge.
The surge protector may have received a power surge
or spike beyond its specified limits that overloaded the
protection circuitry and rendered it inactive. The surge
protector has protected your connected equipment as
designed, but it will not protect against future surges,
and spikes. It should be replaced.
TECHNICAL SUPPORT
Please contact our Tech Support Department with
installation, troubleshooting, or general product questions.
• Phone: [phone]
• Email: [e-mail]
• Hours of Operation:
Monday – Friday 7:00am – 6:00pm CST
USER MANUAL
6-Outlet Surge Protector
HT600WSU2A
6-Outlet Surge Protector
HT600WSU2A
12
Copyright © 2018 Cyber Power Systems (USA), Inc. All rights reserved.
1
TOP
7
2
3
4
5
6
3
ADVANCED
PROTECTION
CLEAN
POWER

3 4
LIMITED WARRANTY AND CONNECTED
EQUIPMENT GUARANTEE
Read the following terms and conditions carefully before
using the CyberPower HT600WSU2A (the “product”). By
using the product, you consent to be bound by the terms
and conditions of this limited warranty and connected
equipment guarantee (together referred to as this
“warranty”). IF YOU DO NOT AGREE TO THE TERMS AND
CONDITIONS OF THIS WARRANTY, YOU SHOULD RETURN
THE PRODUCT FOR A FULL REFUND PRIOR TO USING IT.
Who is providing this warranty, and what does it cover?
Cyber Power Systems (USA), Inc. (“CyberPower”) provides
this limited warranty. It only covers the original purchaser
and ends if you no longer own the product. This warranty
covers defects in materials and workmanship in the product
under normal use and conditions. It also covers equipment
connected to the product damaged because of the failure of
the product. This warranty covers the product and
connected equipment for as long as you own the product.
How do you open a connected equipment claim?
1. Call us at [phone], or write to us at Cyber Power
Systems (USA), Inc., 4241 12th Ave. E., STE 400, Shakopee,
MN 55379, or send us an email at [e-mail]
within 10 days of the occurrence for instructions.
2. When you contact CyberPower, identify the product, the
purchase date, and the item(s) of connected equipment.
Have information on all applicable insurance or other
resources of recovery/payment that are available to the
initial customer, and request a claim number.
3. You must provide a dated purchase receipt (or other proof
of the original purchase) for the CyberPower unit and
connected equipment. You also need to provide a
description of the damage to your connected equipment.
4. Pack and ship the product to CyberPower and the item(s)
of connected equipment, a repair cost estimate for the
damage to the connected equipment, and all claim forms
that CyberPower provides to you. Show the claim number
on the shipping label, or include it with the product. You
must prepay all shipping costs. You are responsible for
packaging and shipment, and you must pay the cost of
the repair estimate.
What will CyberPower do to correct problems?
CyberPower will inspect and examine the product. If the
product is defective in material or workmanship, CyberPower
will replace it at CyberPower’s expense, or CyberPower will
refund the full purchase price you paid for the product
(purchase receipt showing price paid is required). If the
product failed to protect any equipment plugged into it, we
will also send you forms for making your claim for the
connected equipment. We will replace the equipment that
was damaged because of the failure of the product or pay
you the fair market value (NOT REPLACEMENT COST) of
This device is manufactured using environmentally-safe procedures in
compliance with the Restriction of Hazardous Substances (RoHS) directive.
Please join CyberPower in caring for the environment by recycling
this manual.
PRODUCT REGISTRATION
Prompt product registration assures coverage under the limited
warranty, and also allows the opportunity of notifications for
product enhancements, upgrades, and other announcements.
Registration is quick and easy. Go to the Product Registration
Page at www.cyberpowersystems.com/registration.
CONTACT INFORMATION
Cyber Power Systems (USA), Inc.
4241 12th Avenue East Suite 400
Shakopee, MN 55379
Toll-free: 1-877-297-6937 | CyberPowerSystems.com
CONFORMANCE APPROVALS
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference. (2) This device must accept
any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications to this unit, not expressly
approved by the party responsible for compliance, could void
the user’s authority to operate the equipment. This Class B
digital apparatus complies with Canadian ICES-003 (CAN
ICES-3 (B)/NMB (B)).
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and radiates radio
frequency energy. If not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
the equipment at of the time of the damage. We will use Orion
Blue Book, another third-party valuation guide, eBay, Craigslist,
or other source to establish that amount. Our maximum liability
is limited to $250,000 for the HT600WSU2A.
Who pays for shipping?
We pay shipping when we send items to you; you pay when
you send items to us.
What are some things this Warranty does not cover?
1. THIS WARRANTY DOES NOT COVER: ANY SOFTWARE THAT
WAS DAMAGED, SOFTWARE THAT NEEDS TO BE REPLACED
DUE TO THE FAILURE OF THE PRODUCT, OR ANY DATA THAT
IS LOST AS A RESULT OF THE FAILURE. THIS WARRANTY
DOES NOT COVER THE RESTORATION OF DATA OR
RECORDS, OR THE REINSTALLATION OF SOFTWARE.
2. This warranty does not cover: misuse, modification, operation
or storage outside of the environmental limits of the product
or the equipment connected to it. It does not cover damage
while in transit or in storage; if there has been improper
operation or maintenance, or use with items not designed or
intended for use with the product, such as laser printers,
appliances, aquariums, medical, or life support devices, etc.
What are the other limitations?
The sole and exclusive remedies of the initial customer are
those provided by this warranty.
1. This warranty does not apply unless the product and the
connected equipment were connected to properly wired and
grounded outlets (including compliance with electrical and
safety codes of the most current electrical code), without the
use of any adapters or other connectors.
2. The product must have been plugged directly into the power
source. The equipment connected to the product must be
directly connected in the product, not “daisy chained”
together in serial fashion with any extension cords, another
product, or device similar to the product, surge suppressor,
or power tap. Any such installation voids the warranty.
3. The product and connected equipment must have been used
properly in a suitable environment, in conformance with any
applicable license, instruction manual, or warnings.
4. The product must have been used at all times within the
limitations on the product’s VA capacity.
Where can I get more information?
Contact us at:
Cyber Power Systems (USA), Inc.
4241 12th Avenue East Suite 400
Shakopee, MN 55379;
Call us at [phone];
Send us an email at [e-mail].
WARNING: This product can expose you to chemicals, including
styrene, which is known to the State of California to cause cancer.
For more information, go to www.p65warnings.ca.gov.
CyberPowerSystems.com
© 2018 Cyber Power Systems (USA), Inc. All rights reserved.
All other trademarks are the property of their respective owners.
UL Listed to U.S. and Canadian Safety Standards UL 1449. This product
is listed to applicable U.S. and Canadian safety standards by
Underwriters Laboratories Inc.
Full compliance with RoHS.
K01-0000665-01
