User’s Manual

EXTENDED BATTERY MODULE (EBM)

BP240V30ART3UTAA

BP240V50ART3UTAA

Cyber Power Systems (USA), Inc.

4241 12th Avenue East Suite 400 Shakopee, MN 55379

Phone: 877-297-6937

Fax: 952-403-0009

www.cyberpowersystems.com

K01-0000484-01

OVERVIEW

The CyberPower extended battery modules (BP240V30ART3UTAA / BP240V50ART3UTAA) support 30A/50A polarized plugs,

and are designed for variety of Cyber Power UPS systems. When connected to the UPS, the EBM provides extended runtime with

a 240VDC external connection. Additional parallel-connected EBM provide the UPS for a longer extended runtime operation.

Extended Battery Module (EBM)

User’s manual Registration card

Left and right rackmount rails

Left and right hanging brackets

IEC320 C14 to IEC320 C14 power cord

Rackmount ears (Tower stands) (2)

Tie plate

M5X7L black flat head screws (8)

M5X12L black pan head screws (12)

M5X6L silver pan head screws (6)

Plastic washers (8)

Screw hole dust covers (14)

Rubber pads (12)

UNPACKING

HARDWARE INSTALLATION

These versatile EBM can be mounted in a rackmount or

vertical tower orientation. This versatility is especially

important to growing organizations with changing needs that

value having the option to position a EBM on a floor or in a

rackmount system. Please follow the instructions below for

the respective mounting methods.

SAFETY PRECAUTIONS

CAUTION! To prevent the risk of fire or electric shock, only

use the supplied hardware to attach the mounting brackets.

RACKMOUNT INSTALLATION

Step 1: Remove dust covers

Remove ten dust covers from screw holes as shown below.

Step 2: Install rackmount ears & hanging brackets

Attach two rackmount ears to the EBM using the provided

eight M5X7L screws and tighten two hanging brackets with

six M5X6L screws.

Step 3: Rackmount rail Installation

The rails adjust to mount in 19 inch (48 cm) racks from 20.5

to 36 inches (52 to 91.5 cm) deep. Select the appropriate

square holes in the rack to install the EBM. The EBM takes

up square hole positions 1 through 9.

Position the guide screws on the rails into the rear rack

square holes to temporarily support the rails in place.

HARDWARE INSTALLATION

Step 4: Adjust rackmount rails to fit your rack

Adjust the rackmount rail depth to match your rack depth.

Attach the rackmount rail to your rack with two screws and

two plastic washers at the front of the rack. (Located in

square hole position 4 & 8). Tighten the M5X12L screws on

the front bracket. Secure the rail to the rear of the rack with

two M5X12L screws and two plastic washers.

Step 5: Place and secure the EBM on the rails

Slide the hanging brackets on the EBM onto the rails

mounted in the rack with the front of the unit facing toward

you. Secure the EBM to your rack with four M5X12L screws

at the front of the rack. (Square hole position 5 & 7)

How to slide the EBM out from rackmount rails

The EBM is secured by a safety locking mechanism midway

of pulling it out of the rack. Use both hands to hold the EBM

and press the safety locking tab to pull the EBM out.

HARDWARE INSTALLATION

VERTICAL/TOWER INSTALLATION

1. Adhere four circular rubber pads to the left hand side of

the extended battery module. This will become the

bottom side.

2. Stand the extended battery module on its side with the

rubber pads facing down. Install dust covers on open

screw holes. If installing the extended battery module

together with a UPS or an additional EBM secure the

plate between the two using four black M5X7L flat head

screws. Optionally adhere four circular rubber pads to

each rack mount ear to use as tower stands. Screw the

tower stands on to the EBM and UPS using four black

M5X12L pan head screws for added stability as shown

below.

ELECTRICAL INSTALLATION

After completing the hardware installation of the UPS, you

are now ready to plug in the UPS and connect your

equipment.

SAFETY PRECAUTIONS

CAUTION! Installation environment should be in a

temperature and humidity controlled indoor area free of

conductive contaminants. Do not install this EBM where

excessive moisture or heat is present (Please see

specifications for acceptable temperature and humidity

range).

CAUTION! Never install an EBM, or associated wiring or

equipment, during a lightning storm.

CAUTION! Do not work alone under hazardous conditions.

CAUTION! In case of the risk of electric shock, do not

remove the top cover.

CAUTION! The battery can energize hazardous live parts

inside even when the AC input power is disconnected.

BASIC OPERATION

EXTENDED BATTERY MODULE FRONT/REAR PANEL DESCRIPTION

1. On-board Replaceable Fuse Cover

Replaceable fuse is accessible from the rear panel.

Serviceable only by qualified personnel.

2. AC Circuit Breaker

Provides overload and fault protection.

3. AC Fast Charge outlet (IEC320 C13)

Use this outlet to connect to the Fast Charge AC input of a

downstream EBM.

4. AC Fast Charge Input (IEC320 C14)

Connect to a 208V, 30A, AC power source, or connect to the

AC Fast Charge output from an upstream EBM.

5. EBM DC Input Connector

Use this input connector to daisy chain the next EBM.

Remove the connector cover for access.

6. EBM DC Output Cable

Use this output cable to connect the EBM to a UPS power

module or to the next EBM.

7. DC Breaker

Use the DC breaker to disconnect battery output.

BP240V30ART3UTAA / BP240V50ART3UTAA

Connecting UPS to Extended Battery Module

1. Turn off the DC breaker on the EBM.

2. Loosen the two screws to remove the battery cable

retention bracket of the power module.

3. Use the output cable of the EBM to connect it to the power

module.

4. Rotate the battery cable retention bracket and tighten the

two screws to secure the battery connector.

5. Turn on the DC breaker on the EBM.

OFF

○

BASIC OPERATION

Connecting UPS to Multiple Extended Battery Modules

1. Connect the 1st EBM to the UPS power module following

the “Connecting UPS to Extended Battery Module”

instructions.

2. Turn off the DC breaker of the 2nd EBM.

3. Loosen the two screws to remove the battery cable

retention bracket of the 1st EBM.

4. Use the output cable of the 2nd EBM to connect it to the

1st EBM. Rotate the battery cable retention bracket and

tighten the two screws to secure the battery connector.

5. Turn on the DC breaker on the 2nd EBM.

6. Proceed to the External Battery Module Configuration

instructions to set the EBM Number to the quantity of

additional units installed with the UPS system. This

operation can also be done if there is an RMCARD

installed in the UPS, or via PowerPanel®Business

Edition Agent software. Please see their respective

User’s Manuals for instructions.

OFF

○

BASIC OPERATION

EXTENDED BATTERY MODULES CONFIGURATION

Extended Battery Modules can be configured by the user to display correct estimated battery runtimes.

1. Press the “ENTER” button to activate the “MAIN MENU”.

2. Press the “▲”and “▼”buttons to scroll to the “Configure”menu.

3. Press the “ENTER” button to select the “Configure”menu.

4. Press the “▲”and “▼”buttons to scroll to the “EBM Number”option.

5. Press the “ENTER” button to select the “EBM Number”option.

The first configuration number will be displayed on the second column of LCD display.

6. Press the “▲”and “▼”buttons to scroll through the number of attached EBM.

NOTE: The first EBM in recognized by the UPS system as number zero “0”. Set the EBM number to the quantity of

additional units installed with the UPS system.

7. Press the “ENTER” button to select the number of EBMinstalled.

You will be prompted to save the selection. Press the “ENTER” button to save the setting.

8. Press the “ESC” button to cancel or return to the previous LCD menu.

Configure Submenu

Available Settings

Default Settings

EBM Number

= [0] [1] [2] [3] [4] [5] [6] [7] [8] [9] [10]

Sets the quantity of EBM (extended battery modules)

number to get the correct estimated runtime.

MAINTENANCE

Storage

To store your extended battery modules for a long period of time, turn the

DC breaker off, cover it and store with the batteries fully charged.

Recharge the battery every three months to ensure battery life.

Battery Replacement

Please read and follow the Safety Instructions before servicing the

battery. Battery replacement should be performed by trained personnel

who are familiar with the procedures and safety precautions. Make a note

of the replacement EBM number.

Safety Precautions

CAUTION! Only use replacement batteries which are certified by

Cyber Power Systems. Use of incorrect battery type is an electrical

hazard that could lead to explosion, fire, electric shock, or short circuit.

CAUTION! Batteries contain an electrical charge that can cause

severe burns. Before servicing batteries, please remove any conductive

materials such as jewelry, chains, wrist watches, and rings.

CAUTION! Do not open or mutilate the batteries. Electrolyte fluid is

harmful to the skin/eyes and may be toxic.

CAUTION! To avoid electric shock, turn off and unplug the EBM from

the wall receptacle (if installed) before servicing the battery.

CAUTION! Only use tools with insulated handles. Do not lay tools or

metal parts on top of the UPS or battery terminals.

Replacement Batteries

Please refer to the front side of the EBM for the model number of the

correct replacement batteries. For battery procurement, log onto

www.cyberpowersystems.com, or contact your local dealer.

Battery Disposal

Batteries are considered hazardous waste and must be disposed of

properly. Contact your local government for more information about

proper disposal and recycling of batteries. Do not dispose of batteries

in fire.

Cyber Power Systems encourages environmentally sound methods for

disposal and recycling of its UPS products.

Please dispose and/or recycle your UPS and batteries in accordance with

local regulations.

Battery Replacement

Step 1: Remove the front panels

Step 2: Remove the retaining screws from

the cable protection cover and then remove

the cover itself

Step 3: Pull the battery trays out slowly and

then put the new battery trays back into the

compartment

Step 4: Insert the battery connectors and tighten the screws of the

battery retaining cover

Step 5: Install the front panels, then execute a battery test

via the LCD control panel. Go to the Configuration Menu,

scroll to UPS Diagnostic then select Battery Test and

Activate. After the Battery Test completes, scroll to Reset

ReplaceBAT to reset the battery replacement date. This

operation can also be done via PowerPanel® Business

Edition Agent or RMCARD web interface if it is installed.

Please see their respective User Manuals for detailed

instructions.

TECHNICAL SPECIFICATIONS

If the Battery module requires further service, please refer to the following information:

1. Call us at (877) 297-6937 or write to us at Cyber Power Systems (USA), Inc., 4241 12th Ave. E., STE 400, Shakopee, MN 55379 or send us an e-mail

message at tech@cpsww.com for instructions.

2. When you contact CyberPower, identify the Product, the Purchase Date, and the item(s) of Connected Equipment. Have information on all applicable

insurance or other resources of recovery/payment that are available to the Initial Customer and Request a Claim Number.

3. You must provide a dated Proof-of-Purchase receipt (or other proof of the original purchase) and provide a description of the defect.

4. Pack and ship the product to CyberPower and, if requested, the item(s) of Connected Equipment, a repair cost estimate for the damage to the Connected

Equipment, and all claim forms that CyberPower provides to you. Show the Claim Number on the shipping label or include it with the product.

You must prepay all shipping costs, you are responsible for packaging and shipment, and you must pay the cost of the repair estimate.

Model

BP240V30ART3UTAA

BP240V50ART3UTAA

Configuration

AC Input Voltage

180~280Vac

DC Output Voltage

240Vdc

DC Output Current

30A

50A

Physical

Dimensions

L x W x H = 26 x 17 x 5.2in. (660 x 433 x 132mm)

Net Weight

167.2lbs(76Kg)

171.6lbs(78Kg)

Battery

Specifications

(20) 12V/7AH

(20) 12V/9.0AH

Replacement Battery Cartridge

(2) RB1270X10

(2) RB1290X10

Recharge Time 0-90% (Typical)

4 hours

5 hours

Connector Type

PP45

Sealed, Maintenance Free

Yes

Hot-Swappable

Yes

Built-in Charger

Yes

Environment

Operating Temperature

32°F to 104°F ( 0°C to 40°C)

Operating Relative Humidity

0 to 90% Non-Condensing

Safety

Conformance Approvals

CE, UL

RoHS

RoHS Compliant

Warranty

Product Warranty

3-year limited warranty

Problem

Possible Cause

Solution

Warning

BAT Disconnected

Missing battery power.

Check battery connector and battery breaker.

Battery Failure

UPS has failed a Battery Test.

1. Check battery connector and battery breaker.

2. Contact technical support for battery

replacement instructions.

Replace Battery

Battery will soon need to be replaced due to

insufficient runtime.

Contact technical support for battery

replacement instructions.

Fault

Over Charge

Battery is overcharged.

1. Remove the battery connector and check

charger voltage.

2. Contact CyberPower for repair.

Charger Failure

Charger has failed.

TROUBLE SHOOTING

CUSTOMER SERVICE

PRODUCT REGISTRATION

CyberPower requests that you complete and return the Warranty Registration Card enclosed with the Product or register the Product at its website

(www.cyberpowersystems.com) to establish that you are the Initial Customer of the Product, and therefore entitled coverage under the Limited Warranty and

the Connected Equipment Guarantee. (Registration is not required for coverage, but note: if you do not register your purchase, you will be required to provide

proof of purchase.)

Read the following terms and conditions carefully before using the CyberPower BP240V30ART3UTAA / BP240V50ART3UTAA. By using the Product you

consent to be bound by and become a party to the terms and conditions of this Limited Warranty and Connected Equipment Guarantee (together referred to

as this “Warranty”). If you do not agree to the terms and conditions of this Warranty, you should return the Product for a full refund prior to using it.

Who is Providing this Warranty?

Cyber Power Systems (USA), Inc. (“CyberPower”) provides this Limited Warranty.

What Does This Warranty Cover?

This warranty covers defects in materials and workmanship in the Product under normal use and conditions. It also covers equipment that was connected to

the Product and damaged because of the failure of the Product.

What is the Period of Coverage?

This warranty covers the Product for three years and connected equipment for as long as you own the Product.

Who Is Covered?

This warranty only covers the original purchaser. Coverage ends if you sell or otherwise transfer the Product.

How Do You Get Warranty Service?

1. Before contacting CyberPower, identify Your Product model number, the Purchase Date, and each item of Connected Equipment.

2. Email us at tech@cpsww.com or Call us at (877) 297-6937.

3. You must provide a dated purchase receipt (or other proof of the original purchase) for the Cyber Power unit and connected equipment. You also need to

provide a description of the damage to your connected equipment.

How Do You Open A Connected Equipment Claim?

1. Call us at (877) 297-6937 or write to us at Cyber Power Systems (USA), Inc., 4241 12th Ave. E., STE 400, Shakopee, MN 55379, or send us an e-mail

message at claims@cpsww.com for instructions, within 10 days of the occurrence.

2. When you contact CyberPower, identify the Product, the Purchase Date, and the item(s) of Connected Equipment. Have information on all applicable

insurance or other resources of recovery/payment that are available to the Initial Customer and Request a Claim Number.

3. You must provide a dated purchase receipt (or other proof of the original purchase) and provide a description of the damage to your connected equipment.

4. Pack and ship the product to CyberPower and, if requested, the item(s) of Connected Equipment, a repair cost estimate for the damage to the Connected

Equipment, and all claim forms that CyberPower provides to you. Show the Claim Number on the shipping label or include it with the product. You must

prepay all shipping costs, you are responsible for packaging and shipment, and you must pay the cost of the repair estimate.

How Long Do I Have To Make A Claim?

All claims must be made within ten days of the occurrence.

What Will We Do To Correct Problems?

CyberPower will inspect and examine the Product.

If the Product is defective in material or workmanship, CyberPower will repair or replace it at CyberPower's expense, or, if CyberPower is unable to or decides

not to repair or replace the Product (if defective) within a reasonable time, CyberPower will refund to you the full purchase price you paid for the Product

(purchase receipt showing price paid is required).

If it appears that our Product failed to protect any equipment plugged into it, we will also send you forms for making your claim for the connected equipment.

We will repair or replace the equipment that was damaged because of the failure of our Product or pay you the fair market value (NOT REPLACEMENT

COST) of the equipment at of the time of the damage. We will use Orion Blue Book, or another a third-party valuation guide, or eBay, craigslist, or other

source to establish that amount. Our maximum liability is limited to $300,000 for BP240V30ART3UTAA / BP240V50ART3UTAA.

LIMITED WARRANTY AND CONNECTED EQUIPMENT GUARANTEE

Who Pays For Shipping?

We pay when we send items to you; you pay when you send items to us.

What Are Some Examples Of What This Warranty Does Not Cover?

1. This Warranty does not cover any software that was damaged or needs to be replaced due to the failure of the Product or any data that is lost as a result of

the failure or the restoration of data or records, or the reinstallation of software.

2. This Warranty does not cover or apply to: misuse, modification, operation or storage outside environmental limits of the Product or the equipment

connected to it, nor for damage while in transit or in storage, nor if there has been improper operation or maintenance, or use with items not designed or

intended for use with the Product, such as laser printers, appliances, aquariums, medical or life support devices, etc.

What Other Limitations Apply?

The sole and exclusive remedies of the Initial Customer are those provided by this Warranty.

1. This Warranty does not apply unless the Product and the equipment that was connected to it were connected to properly wired and grounded outlets

(including compliance with electrical and safety codes of the most current electrical code), without the use of any adapters or other connectors.

2. The Product must have been plugged directly into the power source and the equipment connected to the Product must be directly connected to the Product

and not “daisy-chained” together in serial fashion with any extension cords, another Product or device similar to the Product, surge suppressor, or power tap.

Any such installation voids the Limited Warranty.

3. The Product and equipment connected to it must have been used properly in a suitable and proper environment and in conformance with any license,

instruction manual, or warnings provided with the Product and the equipment connected to it.

4. The Product must have been used at all times within the limitations on the Product’s VA capacity.

The Product was designed to eliminate disrupting and damaging effects of momentary (less than 1ms) voltage spikes or impulses from lightning or other

power transients. If it can be shown that a voltage spike lasting longer than 1ms has occurred, the occurrence will be deemed outside the rated capabilities of

the Product and the Limited Warranty is void. CyberPower Does Not Cover or Undertake Any Liability in Any Event for Any of the Following:

1. Loss of or damage to data, records, or software or the restoration of data or records, or the reinstallation of software.

2. Damage from causes other than AC Power Line Transients, spikes, or surges on properly installed, grounded and code-compliant 120 volt power lines in

the United States and Canada; transients, surges or spikes on standard telephone land lines, PBX telephone equipment lines or Base 10T Ethernet lines,

when properly installed and connected. (This exclusion applies, for example, to fluctuations in data transmission or reception, by CATV or RF transmission or

fluctuations, or by transients in such transmission.)

3. Damage from any circumstance described as excluded above with respect to the Product.

4. Damages from fire, flood, wind, rain, rising water, leakage or breakage of plumbing, abuse, misuse or alteration of either the product or the Connected

Equipment.

5. CyberPower excludes any liability for personal injury under the Limited Warranty and Connected Equipment Guarantee. CyberPower excludes any liability

for direct, indirect, special, incidental or consequential damages, whether for damage to or loss of property [EXCEPT FOR (AND ONLY FOR) the specific

limited agreement of CyberPower to provide certain warranty benefits regarding "Connected Equipment" under this Warranty], loss of profits, business

interruption, or loss of information or data. NOTE: Some States or Provinces do not allow the exclusion or limitation of incidental or consequential damages,

so the above limitation may not apply to you.

6. The Product is not for use in high-risk activities or with aquariums. The Product is not designed or intended for use in hazardous environments requiring

fail-safe performance, or for use in any circumstance in which the failure of the Product could lead directly to death, personal injury, or severe physical or

property damage, or that would affect operation or safety of any medical or life support device (collectively, "High Risk Activities"). CyberPower expressly

disclaims any express or implied warranty of fitness for High Risk Activities or with aquariums. CyberPower does not authorize use of any Product in any High

Risk Activities or with Aquariums. ANY SUCH USE IS IMPROPER AND IS A MISUSE OF THE PRODUCT.

Where Can I Get More Information?

The application of the United Nations Convention of Contracts for the International Sale of Goods is expressly excluded.

CyberPower is the warrantor under this Limited Warranty.

For further information please feel free to contact CyberPower at Cyber Power Systems (USA), Inc. 4241 12th Ave E., STE 400, Shakopee, MN 55379; call us

at (877) 297-6937; or send us an e-mail message at claims@cpsww.com.

CONFORMANCE APPROVALS

FCC Notice

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause

harmful interference, and (2) this device must accept any interference that may cause undesired operation.

WARNING!! This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user

will be required to correct the interference at his own expense. Shielded signal cables must be used with this product to ensure compliance with the Class A

FCC limits.

This document is believed to be accurate, but CyberPower reserves the right to change or correct the contents and does not assume any responsibility for

omissions or errors.

Need Additional Help?
