CyberResearch CyRAQ Series E User manual

CyberResearch, Inc.
25 Business Park Drive
Branford, CT USA
Phone: [phone]
Fax: [phone]
www.cyberresearch.com
Page 1
Rev 1.3
2 / 13 / 2008
CyberResearch®Industrial Panel PCs
STEP 1
LCD Mounting Plate
Attach LCD mounting plate ()
to monitor using 4 M4 x 8 mm screws ().
Place tabs (shown in detail below) toward
the top of the monitor.
CyRAQ
®
Series E Panel PC
with Flush-Mount Display
Quick Start Panel-Mounting Guide
Shown above: CYRAQ Series E Panel PC with 17" LCD Monitor







Tab
Tab
Mounting Hardware
1. (4) 6-32 x 1/4" trusshead screws (Phillips)
2. (4) M4 x 8 mm panhead screws (Phillips)
3. (4) 6-32 x 5/16" buttonhead screws (hex)
4. (1) 6" long 5/64" hex long-arm L-key
5. Monitor Mounting Clamps (number depends upon LCD size)
6. (1) LCD Mounting Plate
7. (1) PC Mounting Plate

CyberResearch, Inc.
25 Business Park Drive
Branford, CT USA
Phone: [phone]
Fax: [phone]
www.cyberresearch.com
Page 2
Rev 1.3
2 / 13 / 2008
CyberResearch®Industrial Panel PCs
STEP 2
Monitor Installation
Insert monitor and plate into panel cut-out.
Panel cut-out will vary depending upon
monitor size:
Monitor Size Panel Cut-Out (W = width; H = height)
†
12" X = 312 mm (W); Y= 244 mm (H)
15" X = 386 mm (W); Y= 302 mm (H)
17" X = 384 mm (W); Y= 346 mm (H)
19" / 20" / 21" X = 441 mm (W); Y= 356 mm (H)
24" X = 596 mm (W); Y= 421 mm (H)
†Panel-mount cut-out dimensions shown above are for flush-mount
models only; panel cut-outs for universal-mount models may differ.
Please refer to the documentation provided with your 19", 20", 21",
or 24" universal-mount monitor for the appropriate cut-out sizes.
STEP 3
Mounting Clamps*
Install monitor mounting clamps ()
to secure monitor to panel.
X mm*
Y mm*
*dependent on monitor size;
see chart at left
*NOTE: CyRAQ 24s use a compression
mounting plate system. Please refer to the
documentation provided with the CyRAQ 24
monitor for installation instructions.

CyberResearch, Inc.
25 Business Park Drive
Branford, CT USA
Phone: [phone]
Fax: [phone]
www.cyberresearch.com
CyberResearch®Industrial Panel PCs
STEP 4
LCD Cable Connection
Attach all cables to monitor
(i.e. VGA or DVI video, power,
and optional touchscreen).
STEP 5
PC Mounting Plate
Attach PC mounting plate ()
to monitor using 4 6-32 x 1/4"
screws (). The PC mounting plate
has two sets of 100mm VESA holes
that allow you to mount the PC
higher or lower on the monitor
(lower position will allow more
access to the monitor’s connector
panel — see Step 8). Regardless of
which mounting position is chosen,
be sure to place tabs on the plate
toward the top of the PC.
PC Mounting
Plate in
Upper Position
PC Mounting
Plate in
Lower Position
Page 3
Rev 1.3
2 / 13 / 2008
Tab

CyberResearch, Inc.
25 Business Park Drive
Branford, CT USA
Phone: [phone]
Fax: [phone]
www.cyberresearch.com
CyberResearch®Industrial Panel PCs
STEP
PC Installation
Mate PC assembly with
monitor as shown.
STEP 7
Secure PC
Secure PC to monitor using 4
6-32 x 5/16" hex screws ()
and long-arm L-key ().
Page 4
Rev 1.3
2 / 13 / 2008

CyberResearch, Inc.
25 Business Park Drive
Branford, CT USA
Phone: [phone]
Fax: [phone]
www.cyberresearch.com
CyberResearch®Industrial Panel PCs
STEP 8
PC Cable Connection
Attach video cable from monitor,
PC power supply cable, optional
touchscreen cable, and any other
desired user interface cables to the PC.
