DFI KS104-CD User manual

www.dfi.com
1
Chapter 1 Introduction
KS104-CD
10.4” Touch Panel PC
User’s Manual
A34600448

www.dfi.com
2
Chapter 1 Introduction
Copyright
This publication contains information that is protected by copyright. No part of it may be re-
produced in any form or by any means or used to make any transformation/adaptation without
the prior written permission from the copyright holders.
This publication is provided for informational purposes only. The manufacturer makes no
representations or warranties with respect to the contents or use of this manual and specifi-
cally disclaims any express or implied warranties of merchantability or fitness for any particular
purpose. The user will assume the entire risk of the use or the results of the use of this docu-
ment. Further, the manufacturer reserves the right to revise this publication and make changes
to its contents at any time, without obligation to notify any person or entity of such revisions
or changes.
Changes after the publication’s first release will be based on the product’s revision. The website
will always provide the most updated information.
© 2015. All Rights Reserved.
Trademarks
Product names or trademarks appearing in this manual are for identification purpose only and
are the properties of the respective owners.
FCC and DOC Statement on Class B
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reason-
able protection against harmful interference when the equipment is operated in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio TV technician for help.
Notice:
1. The changes or modifications not expressly approved by the party responsible for compli-
ance could void the user’s authority to operate the equipment.
2. Shielded interface cables must be used in order to comply with the emission limits.

www.dfi.com
3
Chapter 1 Introduction
Table of Contents
Copyright.............................................................................................................2
Trademarks........................................................................................................2
FCC and DOC Statement on Class B.....................................................2
About this Manual..........................................................................................4
Warranty..............................................................................................................4
Static Electricity Precautions......................................................................4
Safety Measures..............................................................................................4
Safety Precautions..........................................................................................5
About the Package.........................................................................................5
Chapter 1 - Introduction.............................................................................6
Overview.........................................................................................................6
Key Features..................................................................................................6
Specifications ................................................................................................7
Getting to Know the KS104-CD...............................................................8
Mechanical Dimensions..............................................................................8
Chapter 2 - Getting Started..................................................................... 10
Preparing the System...............................................................................10
Installing Devices....................................................................................... 10
Configuring the BIOS................................................................................ 10
Installing the Operating System............................................................ 10
Installing the Drivers................................................................................10
Chapter 3 - Installing Devices................................................................11
Removing the Chassis Cover..................................................................11
Installing the SODIMM............................................................................. 12
Installing the SATA Drive......................................................................... 13
Chapter 4 - Hardware Installation........................................................15
Board Layout...............................................................................................15
System Memory..........................................................................................16
Jumper Settings .........................................................................................16
Clear CMOS Data .......................................................................................16
USB Power Select.......................................................................................17
Panel Power Select.....................................................................................17
LVDS Panel Select.......................................................................................18
Power-on Select..........................................................................................19
COM 2 RS232/RS422/RS485 Select..............................................................19
Mini PCIe/mSATA Select.............................................................................. 20
Ports and Connectors............................................................................... 21
Bottom Panel I/O Ports............................................................................ 21
COM (Serial) Ports......................................................................................21
Graphics Interface ......................................................................................22
RJ45 LAN Ports...........................................................................................22
USB Ports...................................................................................................23
DC-in.........................................................................................................24
I/O Connectors........................................................................................... 24
Digital I/O Connector.................................................................................. 24
Digital I/O Power Connector........................................................................24
LVDS LCD Panel Connector .........................................................................25
LCD/Inverter Power Connector....................................................................25
Cooling Fan Connectors...............................................................................26
Front Panel Connector ................................................................................26
SATA (Serial ATA) Connector.......................................................................27
Front Audio Connector................................................................................27
Chassis Intrusion Connector........................................................................28
Standby Power LED....................................................................................28
CompactFlash Socket..................................................................................29
Expansion Slot............................................................................................ 29
Battery....................................................................................................... 30
Chapter 5 - Mounting Options................................................................31
Wall Mount...................................................................................................31
Panel Mount ................................................................................................32
Chapter 6 - BIOS Setup............................................................................34
Overview.......................................................................................................34
AMI BIOS Setup Utility.............................................................................35
Updating the BIOS....................................................................................46
Chapter 7 - Supported Software...........................................................47
Appendix A - Smart Fan Setting Guide..............................................56
Appendix B - Watchdog Sample Code................................................62
Appendix C - System Error Message...................................................63
Appendix D - Troubleshooting Checklist............................................64

www.dfi.com
4
Chapter 1 Introduction
About this Manual
An electronic file of this manual is included in the CD. To view the user’s manual in the CD, in-
sert the CD into a CD-ROM drive. The autorun screen (Main Board Utility CD) will appear. Click
“User’s Manual” on the main menu.
Warranty
1. Warranty does not cover damages or failures that arised from misuse of the product,
inability to use the product, unauthorized replacement or alteration of components and
product specifications.
2. The warranty is void if the product has been subjected to physical abuse, improper instal-
lation, modification, accidents or unauthorized repair of the product.
3. Unless otherwise instructed in this user’s manual, the user may not, under any circum-
stances, attempt to perform service, adjustments or repairs on the product, whether in or
out of warranty. It must be returned to the purchase point, factory or authorized service
agency for all such work.
4. We will not be liable for any indirect, special, incidental or consequencial damages to the
product that has been modified or altered.
Static Electricity Precautions
It is quite easy to inadvertently damage your PC, system board, components or devices even
before installing them in your system unit. Static electrical discharge can damage computer
components without causing any signs of physical damage. You must take extra care in han-
dling them to ensure against electrostatic build-up.
1. To prevent electrostatic build-up, leave the system board in its anti-static bag until you are
ready to install it.
2. Wear an antistatic wrist strap.
3. Do all preparation work on a static-free surface.
4. Hold the device only by its edges. Be careful not to touch any of the components, contacts
or connections.
5. Avoid touching the pins or contacts on all modules and connectors. Hold modules or con
nectors by their ends.
Safety Measures
To avoid damage to the system:
• Use the correct AC input voltage range.
To reduce the risk of electric shock:
• Unplug the power cord before removing the system chassis cover for installation or servic-
ing. After installation or servicing, cover the system chassis before plugging the power cord.
Battery:
• Danger of explosion if battery incorrectly replaced.
• Replace only with the same or equivalent type recommend by the manufacturer.
• Dispose of used batteries according to local ordinance.
Important:
Electrostatic discharge (ESD) can damage your processor, disk drive and other com-
ponents. Perform the upgrade instruction procedures described at an ESD worksta-
tion only. If such a station is not available, you can provide some ESD protection by
wearing an antistatic wrist strap and attaching it to a metal part of the system chas-
sis. If a wrist strap is unavailable, establish and maintain contact with the system
chassis throughout any procedures requiring ESD protection.

www.dfi.com
5
Chapter 1 Introduction
About the Package
The package contains the following items. If any of these items are missing or damaged,
please contact your dealer or sales representative for assistance.
• 1 10.4” Touch Panel PC
• 1 Poron foam
• 1 CD disk includes: Manual
• 1 Quick Installation Guide
Optional Items
• Wall Mount kit
• Panel Mount kit
• Power Cord
• Power Adapter
The board and accessories in the package may not come similar to the information listed
above. This may differ in accordance to the sales region or models in which it was sold. For
more information about the standard package in your region, please contact your dealer or
sales representative.
Safety Precautions
• Use the correct DC input voltage range.
• Unplug the power cord before removing the system chassis cover for installation or servic-
ing. After installation or servicing, cover the system chassis before plugging the power cord.
• Danger of explosion if battery incorrectly replaced.
• Replace only with the same or equivalent type recommend by the manufacturer.
• Dispose of used batteries according to local ordinance.
• Keep this system away from humidity.
• Place the system on a stable surface. Dropping it or letting it fall may cause damage.
• The openings on the system are for air ventilation to protect the system from overheating.
DO NOT COVER THE OPENINGS.
• Place the power cord in such a way that it will not be stepped on. Do not place anything on
top of the power cord. Use a power cord that has been approved for use with the system
and that it matches the voltage and current marked on the system’s electrical range label.
• If the system will not be used for a long time, disconnect it from the power source to avoid
damage by transient overvoltage.
• If one of the following occurs, consult a service personnel:
- The power cord or plug is damaged.
- Liquid has penetrated the system.
- The system has been exposed to moisture.
- The system is not working properly.
- The system dropped or is damaged.
- The system has obvious signs of breakage.
• The unit uses a three-wire ground cable which is equipped with a third pin to ground the
unit and prevent electric shock. Do not defeat the purpose of this pin. If your outlet does
not support this kind of plug, contact your electrician to replace the outlet.
• Disconnect the system from the DC outlet before cleaning. Use a damp cloth. Do not use
liquid or spray detergents for cleaning.

www.dfi.com
6
Chapter 1 Introduction
Chapter 1 - Introduction
Chapter 1
Overview
KS104-CD
Bottom View
Side View
Key Features
Model Name KS104-CD
Processor Intel®AtomTM N2800
Chipset Intel®NM10 Express Chipset
LAN 2 LAN ports
COM 3 COM ports
Display 1 VGA
USB 2 USB 2.0 ports
Audio Realtek ALC886 2-channel High Definition Audio

www.dfi.com
7
Chapter 1 Introduction
Expansions • 1 Mini PCIe slot
- Supports PCIe (PCIe and USB signals) or mSATA module
- Supports half size card
Environment • Temperature
- Operating: -20oC ~ 45oC (with SSD/HDD)
- Storage: -30oC ~ 80oC
• Relative Humidity
- 85% RH at 45oC
Vibration • Operating: 1G, 5~500Hz
• Non-operating: 1.5G, 10~500Hz
• IEC 68-2-64 compliant
Shock • Operating: 3G peak acceleration (11 msec. duration)
• Non-operating: 10G peak acceleration (11 msec. duration)
• IEC 68-2-27 compliant
Front Panel
Protection • IP65 (Dust Tight; Water Proof protection)
Construction • Aluminum front bezel
• Rear panel: aluminum
Mounting*
(optional) • Wall mount (VESA 75x75) • Panel mount (Mounting clamp)
Dimensions • 270mm x 220mm x 55mm (W x H x D)
Weight • 2.86 kg
OS Support • Windows 7 (32-bit), WES 7 (32-bit)
• Linux (Project base upon request only, with 3 months lead time)
Specifications
Processor • Intel®AtomTM N2800, 1.86GHz, 2x 512K L2, 6.5W TDP, dual-core
Chipset • Intel®NM10 Express chipset
Memory • One 204-pin DDR3 SODIMM socket
• Supports DDR3 1066MHz
• Supports single channel memory interface
• Supports up to 4GB system memory
LCD and Touch
Screen • 10.4” (1024x768) TFT touch screen LCD • Support projected capacitive touch screen or 5-wire resistive touch screen
• 50,000 MTBF LED backlight
• 350 NITS
Storage • 1 2.5" SATA drive bay
• 1 CompactFlash socket* (optional)
Graphics • Intel®GMA 3650
• Display port: VGA
• VGA: resolution up to 1920x1200 @ 60Hz
LAN • 2 Intel®82574 Gigabit Ethernet Controllers
• Integrated 10/100/1000 transceiver
• Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Audio • Realtek ALC886 2-channel High Definition Audio
I/O Ports • Bottom
- 1 DB-9 RS232/422/485 serial port
- 2 DB-9 RS232 serial ports
- 2 Type A USB 2.0/1.1 ports
- 1 DB-15 VGA port
- 2 RJ45 LAN ports
- 1 Line-out jack
- 1 Mic-in jack
- 1 12V DC-in jack
- 1 Power switch
- 1 Power LED
Chapter 1
Note:
*Optional and is not supported in standard model. Please contact your sales represen-
tative for more information.

www.dfi.com
8
Chapter 1 Introduction
Getting to Know the KS104-CD
Chapter 1
Bottom View
COM Ports
Used to connect a serial device.
USB Ports
Used to connect USB 2.0/1.1 devices.
LAN Ports
Used to connect the system to a local area network.
VGA Port
Used to connect a VGA device.
Line-out
Used to connect to a speaker.
Mic-in jack
Used to connect to a microphone.
DC-in
Used to plug a power adapter.
Power Switch
Press to power-on or power-off the system.
Power LED
Indicates the power status of the system.
Power Switch
Power LED
USB 2.0 DC-in
VGA
COM 3
Mic-in
LAN 2
COM 1
Line-out
COM 2
LAN 1
Mechanical Dimensions
KS104-CD
270.00
220.00 55.00
11.00
167.0042.00
Left View
Bottom View
Right View
Top View
Front View

www.dfi.com
9
Chapter 1 Introduction
Motherboard Dimension
Chapter 1
0.00
3.20
95.20
98.80
87.47
0.00 3.10
8.40 32.43 57.30
73.80
89.41 115.14
134.00 142.90
0.00 3.10
41.37
99.37
134.00 142.90
0.00
3.20
34.12
76.12
95.20
98.80
53.74 59.86
134.32

www.dfi.com
10
Chapter 2 Getting Started
Chapter 2 - Getting Started
Chapter 2
Preparing the System
Before you start using the system, you need the following items:
• SATA hard drive
• AC power adapter
• PS/2 or USB keyboard
• PS/2 or USB mouse
• CD-ROM drive (for installing software/drivers)
• Screwdriver
• Memory module (optional)
Installing Devices
The following are devices that can be installed in the system.
• Memory module
• SATA hard drive
• Mini PCIe card
Configuring the BIOS
To get you started, you may need to change configurations such as the date, time and the
type of hard disk drive.
1. Power-on the system.
2. After the memory test, the message “Press DEL to run setup” will appear on the screen.
Press the Delete key to enter the AMI BIOS setup utility.
Installing the Operating System
Most operating system software are provided in a CD therefore you need to install a CD-ROM
drive in order to use the CD.
Make sure a 2.5” SATA drive is already installed.
1. Refer to the following chapters for information on connecting a CD-ROM drive and install-
ing a SATA drive.
2. Refer to your operating system manual for instructions on installing the operating system.
Installing the Drivers
The system package includes a CD disk. The CD includes drivers that must be installed to pro-
vide the best system performance. Refer to the Supported Software chapter for instructions on
installing the drivers.
