AXIOMTEK GOT321W-521 User manual

GOT321W-521
All-in-One
21.5” FHD TFT Fanless
PCT Multi-Touch Panel PC
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, or any liability arising from such uses.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update any information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted in any
forms or by any means, electronic, mechanical, photocopying, recording, among others,
without prior written permission from Axiomtek Co., Ltd.
WARNING
•Replacing the battery with an incorrect model may cause an
explosion. Only use the same or equivalent type of battery as
recommended by the manufacturer.
•Properly dispose of used batteries according to the instructions.
©Copyright 2021 Axiomtek Co., Ltd.
All Rights Reserved
March 2022, Version A1
Printed in Taiwan

iii
Safety Precautions
Before getting started, please read the following important safety precautions.
1. Be sure to ground yourself to prevent static charge when installing any internal
components. Use a grounding wrist strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
2. Disconnect the power cord from the GOT321W-521 prior to any installation. Be sure both
the system and all external devices are turned off. Sudden surge of power could ruin
sensitive components. Make sure the GOT321W-521 series is properly grounded.
3. Make sure the voltage of the power source is correct before connecting the
GOT321W-521 to any power outlet.
4. Turn off system power before cleaning. Clean the system using a cloth only. Do not spray
any liquid cleaner directly onto the screen.
5. Do not open the system’s back cover. If opening the cover for maintenance is a must,
only a trained technician is allowed to do so. Integrated circuits on computer boards are
sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the
system unit chassis for a few seconds. This will help to discharge any static
electricity on human body.
When handling boards and components, wear a grounding wrist strap available
from most electronic component stores.
Trademark Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel® and Pentium® are registered trademarks of Intel Corporation.
Windows 10 and Windows 10 IoT Enterprise are trademarks of Microsoft Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

iv
Table of Contents
Disclaimers.....................................................................................................ii
Safety Precautions........................................................................................iii
SECTION 1 INTRODUCTION ...................................... 1
1.1 General Descriptions ..........................................................................1
1.2 Specifications......................................................................................2
1.3 Dimensions and Outlines ...................................................................4
1.4 I/O Outlets ............................................................................................6
1.5 Packing List .........................................................................................7
SECTION 2 HARDWARE INSTALLATION .................... 9
2.1 Open Back Cover ................................................................................9
2.2 Jumper and Connector Settings......................................................10
2.2.1 Restore BIOS Optimal Defaults Jumper (JP4).......................................... 10
2.2.2 Auto Power On Jumper (JP6) ....................................................................11
2.2.3 COM Port Connector..................................................................................11
2.3 Ethernet Connector...........................................................................12
2.4 Mounting the Panel PC .....................................................................13
2.4.1 Panel Mount .............................................................................................. 13
2.4.2 Wall Mount................................................................................................. 15
2.4.3 VESA Arm Mount....................................................................................... 17
2.2.4 Desktop Mount .......................................................................................... 19
2.5 Hardware Installation ........................................................................20
2.5.1 Installing an HDD ...................................................................................... 20
2.5.2 Installing DRAM......................................................................................... 21
2.5.3 Installing a CPU......................................................................................... 24
2.5.4 Connecting the Power Input...................................................................... 26
SECTION 3 AMI BIOS SETUP UTILITY..................... 27
3.1 Starting...............................................................................................27
3.2 Navigation Keys ................................................................................27
3.3 Main Menu..........................................................................................28
3.4 Advanced Menu.................................................................................29
3.4.1 IT8625 Super IO Configuration ................................................................. 30
3.4.2 Hardware Monitor...................................................................................... 32
3.4.3 Trusted Computing.................................................................................... 33
3.4.4 ACPI Setting.............................................................................................. 35

v
3.4.5 CPU Configuration .................................................................................... 36
3.4.6 SATA Configuration ................................................................................... 37
3.4.7 PCH-FW Configuration ............................................................................. 38
3.4.8 USB Configuration..................................................................................... 39
3.5 Chipset Menu.....................................................................................39
3.5.1 System Agent (SA) Configuration ............................................................. 39
3.6 Security Menu....................................................................................44
3.7 Boot Menu..........................................................................................45
3.8 Save & Exit Menu ..............................................................................47
SECTION 4 DRIVER and INSTALLATION ................... 49
4.1 Operating System .............................................................................49
4.1.1 Driver CD Content..................................................................................... 49
4.2 Touch Screen.....................................................................................50
APPENDIX A WATCHDOG TIMER ............................... 51
A.1 About Watchdog Timer .....................................................................51
A.2 Sample Program................................................................................51
APPENDIX B iAMT SETTINGS.................................... 53
B.1 Entering MEBx...................................................................................53
B.2 Set and Change Password ...............................................................53
B.3 iAMT Settings ....................................................................................55
B.4 iAMT Web Console............................................................................58

vi
This page is intentionally left blank.

GOT321W-521 User’s Manual
Introduction 1
SECTION 1
INTRODUCTION
This section contains general information and detailed specifications of the GOT321W-521,
including the following subsections:
Figure 1-1 Front panel of the GOT321W-521
⚫General Descriptions
⚫Specifications
⚫Dimensions and Outlines
⚫I/O Outlets
⚫Packing List
1.1 General Descriptions
The GOT321W-521 multi-touch panel PC adopts a 21.5-inch FHDTFT LCD with 250nit
brightness and supports the LGA1151 socket 8/9th gen Intel® Core™ i7/i5/i3 & Pentium®
processor (Tj 100°C) up to 35W, providing excellent computing performance and thermal
resistance. This fanless platform is particularly designed for operation under harsh
environments including steel refineries, oil pipes, ships, machine makers, and many more.
Having the abilities described below surely makes GOT321W-521 the most robust and
cost-effective solution.
Designed for extended operating temperature range and ingress protection
The GOT321W-521’s compact industrial design and fanless cooling system allow the panel
PC to sustain an extended operating temperature range between 0°C and +50°C, making the
system a power-efficient solution. It also features an IP65 front bezel for protection from liquid
and dust.
Reliable and stable design
The GOT321W-521 is specifically designed for vibration-prone environments, best for the
industrial machinery markets. With a patented anti-vibration design, the GOT321W-521 is able
to work in operation mode under 1.0G (10 ~ 500Hz), which has significantly improved system
reliability and sustainability.
NOTE
Heavy-vibration may sometimes cause the LCD screen to flash in white
color; however, it won’t affect the function of the product.

GOT321W-521 User’s Manual
2Introduction
WLAN antenna supported (optional)
The GOT321W-521 includes two Mini Card slots as an add-on option for connecting to a
wireless LAN card under 802.11 a/b/g/n protocols or with other 4G/GPRS applications. These
slots also come with three fixed rotational WLAN/WWAN antennas as optional components for
wireless network connection.
Multi-Touch PCAP touch with 7H surface hardness
The GOT321W-521 comes with a user friendly multi-PCAP touchscreen display which allows
users to operate the panel PC with direct touch. The surface hardness of the touch glass is up
to 7H, providing excellent anti-scratch protection.
Other features
The GOT321W-521 features one 260-pin DDR4-2666/2400 SO-DIMM socket to support
maximum system memory capacity of up to 32GB, along with one 2.5” wide temperature SATA
HDD/SSD for storage needs. It also provides a full set of I/O including RS-232/422/485, USB
2.0, USB 3.0, audio (line-out), HDMI, DP and VGA output, as well as Gigabit Ethernet. This
slim panel PC supports panel mount as the standard installation, plus optional wall mount,
VESA mount, and desktop stand mount to offer more installation flexibility.
1.2 Specifications
Main CPU Board
⚫CPU
➢LGA1151 socket 8/9th gen Intel® Core™ i7/i5 /i3& Pentium® processor (Tj 100°C), up
to 35W
⚫System Memory
➢1 x DDR4 2666/2400MHz SO-DIMM slot
➢Maximum memory up to 32GB
⚫BIOS
➢AMI UEFI BIOS
I/O System
⚫Standard I/O
➢1 x COM (1 x RS-232/422/485)
➢2 x USB 2.0
➢2 x USB 3.0
➢1 x Switch for power on/off
➢1 x Remote switch for power on
➢1 x AT/ATX switch
➢1 x Grounding hole
➢1 x HDMI output
➢1 x DP output
➢1 x VGA output by 9-pin D-sub female
➢1 x Audio line out
⚫Ethernet
➢1 x 10/100/1000 Mbps Ethernet with Intel® i211-AT; supports Wake-on-LAN, PXE Boot
ROM
➢1 x 10/100/1000 Mbps Ethernet with Intel® i219-V (LM); supports Wake-on-LAN, PXE
Boot ROM

GOT321W-521 User’s Manual
Introduction 3
⚫Expansion
➢1 x Full-size PCI-Express Mini Card slot (PCIe + SATA + USB)
➢1 x M.2 Key E 2230 (for Wi-Fi)
⚫Power connector
➢1x Phoenix power connector for DC power input
System Specifications
⚫21.5” FHD (1920x1080) LCD 250 nits with LED backlight
⚫Projected capacitive multi-touch or 5-wire Resistive touch
⚫Fanless design for heat dispensation
⚫IP65 aluminum front bezel
⚫Storage
➢1 x 2.5” wide temperature SATA HDD/SSD(supports 7mm and 9.5mm; removable)
➢1 x mSATA with wide temperature
⚫Weight(Net/Gross)
➢8.8kg (19.4 lb)/11.7 kg (25.8 lb)
⚫Dimensions
➢System: 547.6(W) * 75.6(D) * 339.1(H) (mm)
➢Packing: 730(W) * 215(D) * 555(H) (mm)
⚫Operating temperatures
➢0°C to 50°C (+32°F to +122°F)
⚫Relative humidity
➢20% to 90% @ 40°C, Non-condensing
⚫System power input
➢DC power input: +12V/+19V/+24VDC with small Phoenix power connector
NOTE
•All specifications and images are subject to change without notice.
•The performance of the system might be adversely affected at an
operating temperature above 40°C.

GOT321W-521 User’s Manual
4Introduction
1.3 Dimensions and Outlines
The figures below show the dimensions and outlines of the GOT321W-521 panel PC.
Front dimensions: 547.6(W) * 75.6(D) * 339.1(H) (mm)
Figure 1-2: Outlines of the GOT321W-521

GOT321W-521 User’s Manual
Introduction 5
Figure 1-3: Back outline of the GOT321W-521
Figure 1-4: Cut-out dimensions of the GOT321W-521
Cut-out dimensions: 534.2 x 325.7 mm
NOTE
The wall depth limit for panel mount is 9 mm.

GOT321W-521 User’s Manual
6Introduction
1.4 I/O Outlets
Please refer to figure 1-4 for the I/O locations of the GOT321W-521.
Figure 1-4: Bottom view of the GOT321W-521 For reference
No.
Note.
No.
Note.
1
Power button
8
2x USB3.0
2
Phoenix type power connector
9
2x RJ-45 for Giga Ethernet
3
Grounding hole
10
1x COM for RS232/422/485
4
Remote power switch
11
1x DP out
5
AT/ATX quick switch
12
1x HDMI out
6
Optional flexible I/O
(Default 1x RS-232)
13
1x Line out
7
2x USB2.0
14
1x VGA
NOTE
The GOT321W-521 only supports one output type (DP, HDMI, or VGA) for
the second display.

GOT321W-521 User’s Manual
Introduction 7
1.5 Packing List
A complete bundled package should contain the following items:
⚫GOT321W-521 unit x 1
⚫Phoenix connector (DC power version only)
Please contact an Axiomtek distributor immediately if any of the above-mentioned items is
missing.

GOT321W-521 User’s Manual
8Introduction
This page is intentionally left blank.

GOT321W-521 User’s Manual
Hardware and Installation 9
SECTION 2
HARDWARE INSTALLATION
The GOT321W-521 provides rich I/O ports and flexible expansion features for users to perform
various tasks. This section provides detailed information on the hardware components of the
panel PC as well as installation instructions, including the following subsections:
⚫Open Back Cover
⚫Jumper and Connector Settings
⚫Mounting Methods
⚫Hardware Installation
⚫Power Input
2.1 Open Back Cover
Please follow the steps below to open the GOT321W-521 unit.
Step 1 Remove the four screws (see red circles in Figure 2-1) on the back cover.
Figure 2-1: Back cover
Step 2 Remove the back cover.
Figure 2-2: Board layout

GOT321W-521 User’s Manual
10 Hardware and Installation
2.2 Jumper and Connector Settings
A jumper is a small component consisting of a jumper clip and jumper pins. Proper
configuration of jumper settings enables the GOT321W-521 to meet various application
purposes.
The illustration below shows how to set up jumpers: Place the jumper clip on two jumper pins
to close the jumper pins; remove the jumper clip from two jumper pins to open the jumper pins.
Figure 2-3: Definitions of pin settings
Before applying power to GOT321W-521, please make sure all of the jumpers and connectors
are in default positions, as listed in Table 2-1.
NOTE
Make sure the system is powered off prior to changing any default jumper
settings.
Table 2-1: Factory mode of jumper settings
Jumper
Descriptions
Setting
JP4
Restore BIOS optional defaults (Clear CMOS)
Default: normal operation
1-2 closed
JP6
AT/ATX power mode select
Default: ATX mode
1-2 closed
2.2.1 Restore BIOS Optimal Defaults Jumper (JP4)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the
CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM
data. The onboard button cell battery powers the RAM data in CMOS, which includes system
setup information such as system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Remove the onboard battery.
3. Move the jumper clip from pins 1-2 (default) to pins 2-3. Keep the clip on pins 2-3 for about
5~10 seconds, then move the clip back to pins 1-2.
4. Re-install the battery.
5. Plug the power cord and turn ON the computer.
6. Hold down the <Del> key during the boot process and enter BIOS setup to re-enter data.

GOT321W-521 User’s Manual
Hardware and Installation 11
2.2.2 Auto Power On Jumper (JP6)
If JP6 is enabled for power input, the system will be automatically power on without the need to
press the soft power button. If JP7 is disabled for power input, it is necessary to manually
press the soft power button to power on the system
NOTE
Either one setting (AT/ATX switch or JP7) set to AT mode will be operated by AT
power.
2.2.3 COM Port Connector
This connector is a standard D-Sub connector for the COM1 serial port interface, which can be
set to use RS-232/422/485 mode via the BIOS setting (see section 4.4). The pin assignments
of RS-232/422/485 are listed in the table below.
Table 2-4 Pin assignment for RS-232/ 422/ 485
Function
Setting
Normal operation (default)
1-2 closed
Restore BIOS optimal defaults
2-3 closed
Function
Setting
Enable auto power on ‘’ATX mode”(default)
1-2 closed
Disable auto power on “AT mode”
2-3 closed
Pin
RS-232
RS-422
RS-485
1
DCD
TX-
Data-
2
RXD
TX+
Data+
3
TXD
RX+
N/C
4
DTR
RX-
N/C
5
GND
GND
GND
6
DSR
N/C
N/C
7
RTS
N/C
N/C
8
CTS
N/C
N/C
9
RI
N/C
N/C

GOT321W-521 User’s Manual
12 Hardware and Installation
2.3 Ethernet Connector
The GOT321W-521 has two RJ-45 connectors: LAN1 and LAN2. Ethernet connection can be
established by plugging one end of the Ethernet cable into this RJ-45 connector and the other
end (phone jack) into a 1000/100/10-Base-T hub.
Please refer to Table 2-5 for detailed pin assignment for LAN1 and LAN2.
Table 2-5 Pin assignment for LAN1/ LAN2
LAN1 LAN2
LAN1 with Intel®i211AT
LAN2 with Intel®i219V
Pin
1000
Base-T
100/10
Base-T
Description
L1
BI_DA+
TX+
Bidirectional or Transmit Data+
L2
BI_DA-
TX-
Bidirectional or Transmit Data-
L3
BI_DB+
RX+
Bidirectional or Receive Data+
L4
BI_DC+
N.C.
Bidirectional or Not Connected
L5
BI_DC-
N.C.
Bidirectional or Not Connected
L6
BI_DB-
RX-
Bidirectional or Receive Data-
L7
BI_DD+
N.C.
Bidirectional or Not Connected
L8
BI_DD-
N.C.
Bidirectional or Not Connected
A
Active Link LED (Yellow)
Off: No link
Blinking: Data activity detected
B
Speed LED
1000: Orange
100/10: Green/OFF

GOT321W-521 User’s Manual
Hardware and Installation 13
2.4 Mounting the Panel PC
WARNING
Only trained and qualified technicians are permitted to mount the
product. To prevent accidental damage to the product or human injury
when mounting the product, at least two people are required to perform
the installation.
The GOT321W-521 panel PC supports four types of mounting methods.
⚫Panel mount
⚫Wall mount
⚫VESA arm mount
⚫Desktop mount
2.4.1 Panel Mount
A set of standard panel mount kits, including screws and particular hook brackets for panel
mounting, are bundled with the monitor package. Use the panel mount kits to mount the
GOT321W-521 into a panel.
Step 1 Prepare a panel frame to accommodate the panel PC. Ensure that the cutout
of the frame perfectly fits the monitor’s dimensions.
Step 2 Put the panel PC into the cutout on the front side of the frame, with the panel
PC’s front bezel facing the outside, as shown in Figure 2-4.
Figure 2-4: Fitting the panel PC into a frame.

GOT321W-521 User’s Manual
14 Hardware and Installation
Step 3 Locate the screwing holes and the positions of the hook brackets on the back
side of the panel PC, as shown in the Figure 2-5.
Figure 2-5: Panel mount dimensions (back chassis)
