Cybex 750C/750R Cycle
Owner’s Manual
Cardiovascular Systems
Part Number LT-21613-4 H
www.cybexintl.com

Cybex®and the Cybex logo are registered trademarks of Cybex International, Inc. Safety Sentry™ is a registered trademark of Cybex
International, Inc. Polar®is a registered trademark of Polar Electro Inc. iPOD®is a registered trademark of Apple Inc.
DISCLAIMER: Cybex International, Inc. makes no representations or warranties regarding the contents of this manual. We reserve the right to
revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such
revisions or changes.
© 2011, Cybex International, Inc. All rights reserved. Printed in United States of America.
10 Trotter Drive Medway, MA 02053 • 888-462-9239 • 508-533-4300 • FAX [phone]
www.cybexintl.com • [email protected] • LT-21613-4 H
Cybex 750C/750R Cycle
Owner’s Manual
Cardiovascular Systems
Part Number LT-21613-4 H

Cybex 750C/750R Cycle Owner’s Manual
5
Table of Contents
FCC Compliance Information .......... 7
Safety
Grounding and Voltage Information ..... 9
Important Safety Instructions ......... 10
Warning and Caution Decals ......... 12
Warning and Caution Decals - 750C ... 12
Warning and Caution Decals - 750R ... 15
CSAFE Ports ..................... 18
Assembly and Setup
Warnings and Cautions.............. 19
Choosing and Preparing a Site........ 19
Electrical Power Requirements........ 20
Unit Assemby ..................... 20
750C Assembly.................... 21
750R Assembly.................... 27
Testing the Operation ............... 33
Setup ........................... 34
Operation
Intended Use ..................... 37
Terms Used....................... 37
Mount and Dismount................ 38
Emergency Dismount ............... 38
Console Keys ..................... 39
Audio Visual (AV) Key Pad – Optional .. 41
Program Selection ................. 42
Programs P1 – P9 Setup ............ 42
Manual and Quick Start Programs
Setup .......................... 43
Advanced Programs A1 –A3 Setup .... 43
Custom Programs.................. 46
Data Readouts .................... 47
Heart Rate Indicator ................ 47
Fan Control ....................... 48
Alarm Set ........................ 48
Battery Sentry..................... 48
Preventive Maintenance
Warnings......................... 49
Cleaning Unit ..................... 49
Statistics ......................... 50
Error Codes ...................... 50
Rechargeable Battery............... 51
Environment ...................... 51
Customer Service
Contacting Service ................. 53
Serial Number .................... 53
Servicing of Double-Insulated Products . 54
Return Material Authorization (RMA) ... 54
Damaged Parts.................... 55
Ordering Parts .................... 55
Appendix A -
Technical Specications
Specications ..................... 57

Cybex 750C/750R Cycle Owner’s Manual
6

Cybex 750C/750R Cycle Owner’s Manual
7
FCC Compliance Information
WARNING: Serious injury or death can occur. To avoid injury or death the following
procedure must be followed. Changes or modications to this unit not
expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Modications not expressly approved by the manufacturer could void the user’s authority to operate
the equipment under FCC rules.

Cybex 750C/750R Cycle Owner’s Manual
8

Cybex 750C/750R Cycle Owner’s Manual
PB 9
Safety
IMPORTANT: Read all instructions and warnings before using.
Grounding and Voltage Information
DANGER: Death or serious injury can occur. To avoid death or injury the following
procedure must be followed. Improper connection of equipment grounding
conductor can result in a risk of electric shock. Check with a qualied
electrician or service provider if in doubt as to whether the unit is properly
grounded.
For Optional Power Supply
• Unit must be grounded. This unit is equipped with an optional equipment-grounding conductor cord
and a grounding plug.
• Do not use a ground plug adapter to adapt the power cord to a non-grounded outlet.
• Plug must be plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
• If unit malfunctions, grounding provides path of least resistance for electric current to reduce risk of
electric shock.
Cybex is not responsible for injuries or damages as a result of cord or plug modication.
• Verify voltage requirements of unit match local voltage requirements.
• Verify unit outlet is the same conguration as the plug.
Power Adapter
24 VDC Power Cord
Use Cybex supplied power adapter and power cords only.
Connector
Varies by
Country

Cybex 750C/750R Cycle Owner’s Manual
10
Important Safety Instructions
(Save These Instructions)
DANGER: Death or serious injury can occur. To avoid death or injury the following
procedure must be followed. To reduce the risk of electrical shock, always
unplug unit from electrical outlet immediately after use and before cleaning.
WARNING: Serious injury or death can occur. To avoid injury or death the following
procedure must be followed. Follow precautions to reduce the risk of burns,
res, electric shock or injury.
User Safety Precautions
• Obtain medical exam before beginning any exercise program.
WARNING: Serious injury or death can occur. To avoid injury or death the following
procedure must be followed.Heart rate monitoring systems may be
inaccurate. Over exercise may result in serious injury or death. If you feel
faint stop exercising immediately.
• Stop exercising if you feel faint, dizzy or experience pain and consult your physician.
• Obtain instruction before using. Lisez les instructions avant l’utilisation.
• Read and understand the Owner’s Manual and all warnings posted on the unit before using.
• Keep children away. Teenagers and disabled must be supervised. Tenez les enfants éloignés. Les
adolescents et les handicapés doevent être surveilles.
• Use caution when mounting and dismounting.
• Keep clear of moving parts. DO NOT wear loose or dangling clothing while using.
• DO NOT use the unit if you exceed 400 lbs (180 kg). This is the rated maximum user weight.
• Report any malfunctions, damage or repairs to the facility.
• Replace any warning labels if damaged, worn or illegible.
Facility Safety Precautions
It is the sole responsibility of the user/owner or facility operator to ensure that regular maintenance is
performed.
• Enforce all user and safety precautions.
• Read and understand the Owner’s Manual completely before assembling, servicing or using unit.
• Verify all users are properly trained on using the equipment.
• Do not use unit outdoors.
• Verify that each unit is setup, leveled and operated on a solid, level surface. Do not install
equipment on an uneven surface.

Cybex 750C/750R Cycle Owner’s Manual
10 11
• Verify there is enough room for safe access and operation of unit.
• Use Cybex AC power adapters only.
• Do not use the optional power adapter in damp or wet locations.
• Do not use the unit if: (1) the unit is plugged into an optional power adapter that has a
damaged cord; (2) the unit is not working properly or (3) if the unit has been dropped or
damaged. Seek service from a qualied technician.
• EQUIPMENT is not suitable for use in the presence of aerosol (spray), FLAMMABLE
ANAESTHETIC MIXTURE WITH AIR or WITH OXYGEN or NITROUS OXIDE.
• Perform regular maintenance checks on unit. Performance level can be maintained only
if examined regularly. Pay close attention to all areas most susceptible to wear, including
(but not limited to) cables, pulleys, belts and grips.
• Replace any warning labels if damaged, worn or illegible.
• Immediately replace worn or damaged components. If unable to immediately replace
worn or damaged components, then remove unit from service until repair is made.
• Do not attempt repairs; electrical or mechanical. Seek qualied repair technician when
servicing. Failure to do so could result in serious injury. See Customer Service for contact
information.
• Use only Cybex supplied components to maintain/repair unit.
• Keep a repair log of all maintenance activities.
• Disconnect the optional power adapter before servicing unit.
• Do not use attachments unless recommended for the unit by Cybex.
• The unit may generate electromagnetic or other forms of interference, or it may
be affected by interference from other equipment nearby. If this is suspected, take
precautions by separating the equipment or otherwise shielding it to avoid such
interference.
Unit with A/V Options
• Devices connected to Cybex equipment must comply with appropriate safety standards.
This includes but not limited to: UL 1647 and EN 60335-1.
• There must be adequate mechanical mounting of the device in all combinations
(congurations).
• The device must be stable on the unit in all congurations.

Cybex 750C/750R Cycle Owner’s Manual
12
Warning and Caution Decals
Warning decals indicate a potentially hazardous situation which, if not avoided, could result in death
or serious injury.
Carefully read and understand the following caution and warning labels before using the unit.
Warning and Caution Decals - 750C
DE-21577-4
BA
BGarber
5 OF 9
REV.
SHEET
SIZE
APPROVALS
DRAWN BY
MATERIAL
FINISH
ADOBE GENERATED DRAWING
DO NOT MANUALLY UPDATE
CHECKED
RESP ENG
MFG ENG
QUAL ENG
DATE
DWG. NO.
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
FRACTIONS DECIMALS ANGLES
± .XX ± .02 ± 1
.XXX ± .005
FINISH: 125 RMS
SCALE: 1=1 THIS FILE IS IN ADOBE ILLUSTRATOR
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CYBEX.
ANY REPRODUCTION IN PART OR WHOLE WITHOUT
THE WRITTEN PERMISSION OF CYBEX IS PROHIBITED.
WARNING LABEL, 750C
ENGLISH
SEE NOTES, Page 1
SEE NOTES, Page 1
REVISIONS
DESCRIPTION
SEE SHEET 1
ECOREV DATE APPROVALBY
5/19/08
10 TROTTER DRIVE
MEDWAY, MA
Warning Decal
Part Number
DE-21577-4

Cybex 750C/750R Cycle Owner’s Manual
12 13
WARNING
DE-18363-4
Hot Flywheel! Wait until it
cools before servicing
DE-18363-6
WARNUNG
DE-18363-1
VARNING
DE-18363-7
DE-18363-2
AVERTISSEMENT
ADVERTENCIA
DE-18363-3
Warning Decal Part Number
DE-18363-4
These decals are located inside the cycle, applied to the brake/generator.
Internal View
125
1:1
OWATONNA
MFG. APPR.
TECH. PUBS. APPR. DATE
DATE
REV.
DWG. NO.
SCALE
SIZE
CHECKED BY
DWG. BY
TITLE:
FINISH:
MATERIAL:
B
SHEET
OF
EXCEPTAS NOTED
GENERAL
TOLERANCES:
2 DECIMALS ± .03
3 DECIMALS ± .015
ANGLES ± 1°
FEATURES SHOWN
PERPENDICULAR OR
PARALLEL SHALL BE
SO WITHIN ± 1°
REMOVE ALL BURRS
BREAK SHARP EDGES
.005/.010 R
SURFACE FINISH
INDICATED PER
ANSI B46.1-1985
GENERAL
MACHINING
DIMENSIONS
IN INCHES
DATE
DATE
REMOVE CARBURIZATION
AND SCALE FROM LASER
AND PLASMA CUT EDGES
ALL MATERIAL MUST COMPLY TO
EUROPEAN UNION DIRECTIVE
2002/95/EC RoHS (RESTRICTION
OF HAZARDOUS SUBSTANCES)
DECAL, CAUTION MOVING PARTS
DE-17219-4 B
1 1
JT 7-22-03
1.80
1.25
R .12
4 PLACES
SAFETY YELLOW PMS 108
BACKGROUND BLACK TRIANGLE
W/ YELLOW EXCLAMATION POINT,
BLACK LETTERS 18.9 PTARIAL BLACK FONT
WHITE BACKGROUND WITH
BLACK 12 PTARIAL TEXT
PART NUMBER
6.5 PTARIAL TEXT
DE-17219-4 B
CAUTION
Moving parts.
Keep hands away
when in use.
DE-17219-4 B
CAUTION
Moving parts.
Keep hands away
when in use.
(SPECS)
MASTER
ARTWORK
DE-17219-4 A
CAUTION
Moving parts.
Keep hands away
when in use.
Warning Decal Part Number
DE-18362-4

Cybex 750C/750R Cycle Owner’s Manual
14
DE-21749-4
B A
T.SMITH
5 OF 9
10 TROTTER DRIVE
MEDWAY, MA
REV.
SHEET
SIZE
APPROVALS
DRAWN BY
MATERIAL
FINISH
ADOBE GENERATED DRAWING
DO NOT MANUALLY UPDATE
CHECKED
RESP ENG
MFG ENG
QUAL ENG
DATE
DWG. NO.
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
FRACTIONS DECIMALS ANGLES
± .XX ± .02 ± 1
.XXX ± .005
FINISH: 125 RMS
SCALE: 1=1 THIS FILE IS IN ADOBE ILLUSTRATOR
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CYBEX.
ANY REPRODUCTION IN PART OR WHOLE WITHOUT
THE WRITTEN PERMISSION OF CYBEX IS PROHIBITED.
DECAL,
DISCONNECT POWER
ENGLISH
SEE NOTES, Page 1
SEE NOTES, Page 1
REVISIONS
DESCRIPTION
SEE SHEET 1
ECOREV DATE APPROVALBY
9/03/08
NOTE: SEE SHEET 1 FORADDITIONAL DECAL INFORMATION
Warning Decal
Part Number
DE-21749-4 (When Applicable)
Warning Decal
Part Number
DE-21735-4
Decal located inside cover.
DE-21735-4
B 1
REL
2 OF 2
10 TROTTER DRIVE
MEDWAY, MA
REV.
SHEET
SIZE
APPROVALS
DRAWN BY
MATERIAL
FINISH
ADOBE GENERATED DRAWING
DO NOT MANUALLY UPDATE
CHECKED
RESP ENG
MFG ENG
QUAL ENG
DATE
DWG. NO.
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
FRACTIONS DECIMALS ANGLES
± .XX ± .02 ± 1
.XXX ± .005
FINISH: 125 RMS
SCALE: 1=1 THIS FILE IS IN ADOBE ILLUSTRATOR
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CYBEX.
ANY REPRODUCTION IN PART OR WHOLE WITHOUT
THE WRITTEN PERMISSION OF CYBEX IS PROHIBITED.
LABEL,
WARNING,
ERROR CODE
SEE NOTES, Page 1
SEE NOTES, Page 1
REVISIONS
DESCRIPTION
SEE SHEET 1
ECOREV DATE APPROVALBY
8/13/08
All maintenance activities shall be performed by qualified
personnel. Failure to do so could result in serious injury.
WARNING
DE-21735-4 A
8 Approaching Over-Temperature A,B,C,E
9 Display watchdog triggered B,F,H
22 Speed irregularity - Low speed and High power D
23 Speed irregularity - High speed and Low power B
27 Low Battery B,E,G,H
28 Over-Temperature A,B,C,E
29 Controller watchdog triggered - EEPROM or G
Memory Error
ERROR DESCRIPTION SOLUTION
Error Codes
LED 1 - Console Transmit
LED 2 - Console Receive
LED 3 - Battery Charge Status
LED 4 - Battery Charge Status
LED 5 - Powered from Generator
LED 6 - Brake Current
LED 7 - +24V External Power
LED 8 - Display Voltage (+12V)
Diagnostic LED
Designation
BATTERY STATUS FROM LEDs 3 AND 4
NO
BATTERY PRE
CHARGE HIGH
CHARGE TRICKLE
CHARGE
4
3334
3
44
J4
J7
J5
J1
J6 J2
5
6
8
1
3
4
27
A. Clean Brake/Enclosure
B. Check Connections
C. Check Fuse
D. Check Battery
E. Replace Brake
F. Replace Display Board
G. Replace LCB
H. Replace Battery
Set up (CLEAR 7,5,0, ENTER)
Diagnostic (CLEAR 8,8,8, ENTER)
Statistics (CLEAR 9,9,9, ENTER)
Entering Hidden Menus

Cybex 750C/750R Cycle Owner’s Manual
14 15
Warning and Caution Decals - 750R
DE-21590-4
B A
REL
5 OF 9
10 TROTTER DRIVE
MEDWAY, MA
REV.
SHEET
SIZE
APPROVALS
DRAWN BY
MATERIAL
FINISH
ADOBE GENERATED DRAWING
DO NOT MANUALLY UPDATE
CHECKED
RESP ENG
MFG ENG
QUAL ENG
DATE
DWG. NO.
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
FRACTIONS DECIMALS ANGLES
± .XX ± .02 ± 1
.XXX ± .005
FINISH: 125 RMS
SCALE: 1=1 THIS FILE IS IN ADOBE ILLUSTRATOR
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CYBEX.
ANY REPRODUCTION IN PART OR WHOLE WITHOUT
THE WRITTEN PERMISSION OF CYBEX IS PROHIBITED.
LABEL,
WARNING, 750R
ENGLISH
SEE NOTES, Page 1
SEE NOTES, Page 1
REVISIONS
DESCRIPTION
SEE SHEET 1
ECOREV DATE APPROVALBY
6/30/08
Warning Decal
Part Number
DE-21590-4

Cybex 750C/750R Cycle Owner’s Manual
16
WARNING
DE-18363-4
Hot Flywheel! Wait until it
cools before servicing
DE-18363-6
WARNUNG
DE-18363-1
VARNING
DE-18363-7
DE-18363-2
AVERTISSEMENT
ADVERTENCIA
DE-18363-3
This decal is located inside the cycle, applied to the brake/generator.
Internal
View
Warning Decal
Part Number DE-18362-4 Warning Decal
Part Number DE-18363-4
125
1:1
OWATONNA
MFG. APPR.
TECH. PUBS. APPR. DATE
DATE
REV.
DWG. NO.
SCALE
SIZE
CHECKED BY
DWG. BY
TITLE:
FINISH:
MATERIAL:
B
SHEET
OF
EXCEPTAS NOTED
GENERAL
TOLERANCES:
2 DECIMALS ± .03
3 DECIMALS ± .015
ANGLES ± 1°
FEATURES SHOWN
PERPENDICULAR OR
PARALLEL SHALL BE
SO WITHIN ± 1°
REMOVE ALL BURRS
BREAK SHARP EDGES
.005/.010 R
SURFACE FINISH
INDICATED PER
ANSI B46.1-1985
GENERAL
MACHINING
DIMENSIONS
IN INCHES
DATE
DATE
REMOVE CARBURIZATION
AND SCALE FROM LASER
AND PLASMA CUT EDGES
ALL MATERIAL MUST COMPLY TO
EUROPEAN UNION DIRECTIVE
2002/95/EC RoHS (RESTRICTION
OF HAZARDOUS SUBSTANCES)
DECAL, CAUTION MOVING PARTS
DE-17219-4 B
1 1
JT 7-22-03
1.80
1.25
R .12
4 PLACES
SAFETY YELLOW PMS 108
BACKGROUND BLACK TRIANGLE
W/ YELLOW EXCLAMATION POINT,
BLACK LETTERS 18.9 PTARIAL BLACK FONT
WHITE BACKGROUND WITH
BLACK 12 PTARIAL TEXT
PART NUMBER
6.5 PTARIAL TEXT
DE-17219-4 B
CAUTION
Moving parts.
Keep hands away
when in use.
DE-17219-4 B
CAUTION
Moving parts.
Keep hands away
when in use.
(SPECS)
MASTER
ARTWORK
DE-17219-4 A
CAUTION
Moving parts.
Keep hands away
when in use.

Cybex 750C/750R Cycle Owner’s Manual
16 17
DE-21749-4
B A
T.SMITH
5 OF 9
10 TROTTER DRIVE
MEDWAY, MA
REV.
SHEET
SIZE
APPROVALS
DRAWN BY
MATERIAL
FINISH
ADOBE GENERATED DRAWING
DO NOT MANUALLY UPDATE
CHECKED
RESP ENG
MFG ENG
QUAL ENG
DATE
DWG. NO.
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
FRACTIONS DECIMALS ANGLES
± .XX ± .02 ± 1
.XXX ± .005
FINISH: 125 RMS
SCALE: 1=1 THIS FILE IS IN ADOBE ILLUSTRATOR
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CYBEX.
ANY REPRODUCTION IN PART OR WHOLE WITHOUT
THE WRITTEN PERMISSION OF CYBEX IS PROHIBITED.
DECAL,
DISCONNECT POWER
ENGLISH
SEE NOTES, Page 1
SEE NOTES, Page 1
REVISIONS
DESCRIPTION
SEE SHEET 1
ECOREV DATE APPROVALBY
9/03/08
NOTE: SEE SHEET 1 FORADDITIONAL DECAL INFORMATION
Decal located inside cover.
DE-21735-4
B 1
REL
2 OF 2
10 TROTTER DRIVE
MEDWAY, MA
REV.
SHEET
SIZE
APPROVALS
DRAWN BY
MATERIAL
FINISH
ADOBE GENERATED DRAWING
DO NOT MANUALLY UPDATE
CHECKED
RESP ENG
MFG ENG
QUAL ENG
DATE
DWG. NO.
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
FRACTIONS DECIMALS ANGLES
± .XX ± .02 ± 1
.XXX ± .005
FINISH: 125 RMS
SCALE: 1=1 THIS FILE IS IN ADOBE ILLUSTRATOR
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CYBEX.
ANY REPRODUCTION IN PART OR WHOLE WITHOUT
THE WRITTEN PERMISSION OF CYBEX IS PROHIBITED.
LABEL,
WARNING,
ERROR CODE
SEE NOTES, Page 1
SEE NOTES, Page 1
REVISIONS
DESCRIPTION
SEE SHEET 1
ECOREV DATE APPROVALBY
8/13/08
All maintenance activities shall be performed by qualified
personnel. Failure to do so could result in serious injury.
WARNING
DE-21735-4 A
8 Approaching Over-Temperature A,B,C,E
9 Display watchdog triggered B,F,H
22 Speed irregularity - Low speed and High power D
23 Speed irregularity - High speed and Low power B
27 Low Battery B,E,G,H
28 Over-Temperature A,B,C,E
29 Controller watchdog triggered - EEPROM or G
Memory Error
ERROR DESCRIPTION SOLUTION
Error Codes
LED 1 - Console Transmit
LED 2 - Console Receive
LED 3 - Battery Charge Status
LED 4 - Battery Charge Status
LED 5 - Powered from Generator
LED 6 - Brake Current
LED 7 - +24V External Power
LED 8 - Display Voltage (+12V)
Diagnostic LED
Designation
BATTERY STATUS FROM LEDs 3 AND 4
NO
BATTERY PRE
CHARGE HIGH
CHARGE TRICKLE
CHARGE
4
3334
3
44
J4
J7
J5
J1
J6 J2
5
6
8
1
3
4
27
A. Clean Brake/Enclosure
B. Check Connections
C. Check Fuse
D. Check Battery
E. Replace Brake
F. Replace Display Board
G. Replace LCB
H. Replace Battery
Set up (CLEAR 7,5,0, ENTER)
Diagnostic (CLEAR 8,8,8, ENTER)
Statistics (CLEAR 9,9,9, ENTER)
Entering Hidden Menus
Warning Decal
Part Number
DE-21749-4 (When Applicable)
Warning Decal
Part Number
DE-21735-4

Cybex 750C/750R Cycle Owner’s Manual
18
CSAFE Ports
The CSAFE standard denes a communication protocol and low-voltage DC power source specic
to the Fitness Equipment Industry. These RJ-45 phone jacks are provided for use ONLY within the
CSAFE protocol. For more information on CSAFE standard, visit www.tlinxx.com/csafe.
The CSAFE port inside the console, accessible through the back cover, is the only port that carries
BOTH the CSAFE communication lines and the 8.0v DC CSAFE power supply. If attaching a CSAFE
compliant device that requires power, this connection must be used. Power is present only when the
unit is in use or when a power supply is attached.
J7
J5
J9
J10
J8
J7
J5
J9
J10
J8
CSAFE Port (J9)
Communication
8V DC/100 MA
Power Supply
Back of
Console

Cybex 750C/750R Cycle Owner’s Manual
19
Assembly and Setup
Warnings and Cautions
Read and understand all warnings and cautions listed in the Safety chapter before assembling unit.
Use extreme caution when assembling the unit. Failure to do so could result in injury or death.
CAUTION: Serious injury or damage to machine can occur. To avoid injury or damage
the following procedure must be followed. Always use proper lifting methods
when moving heavy items.
Be sure all electrical requirements are met as indicated in the specications in the Safety chapter and
as listed in this chapter.
Choosing and Preparing a Site
Before assembling the unit, verify the chosen site meets the following criteria:
• Area is well lit and well ventilated.
• Surface is structurally sound and properly leveled. Place a 3/4” (1.9 cm) thick wood base under unit
to protect carpeting.)
• Area allows for ample access and passage clearance around unit or for emergency dismount.
Minimum clearance is 19.7 inches (.5 meters) on at least one side of unit and also in front of or
behind unit.
The access and passage clearance dimensions stated are the recommended minimum dimensions
as set forth by the manufacturer. The actual area for access and passage is the responsibility of the
facility and should take into account any required local codes or regulations.
• Area is not in the vicinity of high humidity, such as in the vicinity of a steam room, sauna, indoor
pool or outdoors. This unit is designed to function normally in an environment with a relative
humidity range of 30% to 75%.
Exposure to extensive water vapor, chlorine and/or bromine could adversely affect the electronics as
well as other parts of the unit.
• Area maintains an ambient temperature range of 50o F (10o C) to 104o F (40o C) degrees.

Cybex 750C/750R Cycle Owner’s Manual
20
Electrical Power Requirements
The AC power kit is optional.
Verify the unit is connected to an outlet having the same conguration as the plug.
Verify connection is a grounded circuit. Do not use a ground-plug adapter to adapt the 3-prong power
cord to a non-grounded electrical outlet.
Use Cybex supplied AC power kit only. Consult an electrician with any questions.
Verify power supply is compliant with local building codes.
Unit Assemby
CAUTION: Serious injury or damage to machine can occur. To avoid injury or damage
the following procedure must be followed. Use extreme caution when
assembling the unit. Failure to do so could result in injury.
CAUTION: Serious injury or damage to machine can occur. To avoid injury or damage
the following procedure must be followed. Always use proper lifting methods
when moving heavy items.
Tools Required
• 3/16” Allen wrench (supplied with 750R only)
• Phillips screwdriver
• 1/2” Socket wrench
• 9/16” Open end wrench
The words “left” and “right” denote the user’s orientation.
Read and understand all instructions thoroughly before assembling the unit.
Verify correct package.
1. Read box label to verify the model number and voltage match what was ordered.
2. Lift and remove cardboard sleeve surrounding unit.
3. Verify paint color matches what was ordered.
4. Verify correct voltage by reading voltage sticker near power outlet. AC power kit is optional.
