CYBEX 770C User manual

Cybex 770C/770R Cycle
Cybex GO Monitor, Owner's Manual
Cardiovascular Systems
Part Number LT-24919-4 D
www.cybexintl.com

Table of Contents
Safety
Safety Guidelines and Practices.........................4
Power Cord Information......................................4
Important Safety Instructions..............................5
Warnings and Cautions......................................6
Assembly
Specifications - 770C, 770R, Cybex GO
Monitor.........................................................11
Choosing and Preparing a Site.........................12
Environment.....................................................13
Electrical Power Requirements........................13
Tools Required..................................................14
Assembly Procedure........................................14
Cybex GO Setup..............................................27
Equipment Setup..............................................33
Testing operation..............................................34
Operation
Intended Use....................................................36
Terms Used......................................................36
User Control Symbols Used.............................37
CardioTouch Symbols Used.............................37
CardioTouch Screen and User Controls...........40
Cybex GO Console and User Controls.............41
Cybex GO Console Log In or Sign Up..............42
Mount and Dismount........................................43
Quick Operation Guide.....................................43
Detailed Operation Guide.................................44
Workout Choices..............................................46
Data Readouts..................................................47
Heart Rate Indicator.........................................48
Fan Control.......................................................49
iPod/iPhone Functions......................................49
Battery Sentry...................................................49
Maintenance
Warnings...........................................................50
Clean Unit.........................................................50
Rechargeable Battery.......................................51
Cybex GO Monitor............................................52
Customer Service
Product Registration.........................................53
Contacting Service...........................................53
Ordering Parts..................................................53
Return Material Authorization (RMA)................54
Damaged Parts.................................................54
Appendix - Workout Overviews
Weight Loss - Rollers 1....................................55
Weight Loss - Rollers 2....................................57
Weight Loss - Hills............................................59
Weight Loss - Peaks.........................................61
Cardio - Ramps................................................63
Cardio - Interval................................................65
Cardio - Bursts..................................................67
Cardio - Wave...................................................69
Cardio - Heartrate Control................................71
Power - Constant Power...................................73
Power - Isokinetic.............................................74
Tests - YMCA....................................................75
Cybex®and the Cybex logo are registered trademarks of Cybex International, Inc. Polar®is a registered trademark of Polar Electro Inc. iPod and
iPhone are trademarks of Apple Inc., registered in the U.S. and other countries.
DISCLAIMER: Cybex International, Inc. makes no representations or warranties regarding the contents of this manual. We reserve the right to
revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such
revisions or changes.
©Copyright 2016, Cybex International, Inc.
10 Trotter Drive, Medway, MA 02053 • 888-462-9239 • 508-533-4300 • FAX [phone]
www.cybexintl.com • LT-24919-4 D • February 2016
Page 2 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

FCC Compliance Information
Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Page 3 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

Safety
Safety Guidelines and Practices
Read the Owner’s Manual carefully before assembling, servicing, or using the equipment. Owner
must comply with all safety guidelines in this manual. It is also the owner’s responsibility to instruct
users on the safe and proper operation of the equipment and to properly display any and all
warning labels and instructional placards. All users should read these labels and placards before
using equipment.
Serious injury or death could occur if the following safety precautions and
instructions are not followed.
Power Cord Information
AC Power Adapter is optional.
Shock and electrocution hazard.
• Connect unit to a grounded outlet.
• Do not use voltage adapter or extension cord.
Cybex is not responsible for injuries or damages as a result of cord or plug
modification.
• Verify voltage requirements of unit match local voltage requirements.
• Verify unit outlet is the same configuration as the plug.
Power cord configurations
ChineseAustraliaDanishJapaneseUK 230 VACEuro Plug115 VAC
GB 2099-1
and GB
1002-1
AS/NZS 3112107-2-D1JIS 8303BS 1363CEE 7/7NEMA 5-15
Page 4 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

Important Safety Instructions
(Save These Instructions)
Shock and electrocution hazard.
• Unplug unit and let sit 10 minutes before cleaning or performing
maintenance.
• Electrical charge can remain in unit after unplugging.
• Keep water and liquids away from electrical parts.
User Safety Precautions
Prior to use:
• Obtain a medical exam before beginning any exercise program.
• Obtain instruction before using.
•Read and understand warning labels.
• Maximum user weight is 400 lbs. (180 kg).
• Inspect unit. If damaged, notify floor staff. DO NOT USE.
• Do not remove this label. Replace if damaged or illegible.
During use
• Do not use for stretching and do not attach straps or other devices.
• Do not allow children 12 or younger to be on or near machine.
• Stop exercise if feeling faint, dizzy, or have pain.
• Use the handrails for support and to maintain balance.
• Keep all body parts, clothing, and accessories, clear of moving parts.
Facility Safety Precautions
It is the sole responsibility of the user/owner or facility operator to ensure that regular maintenance is
performed.
• Enforce all user and safety precautions.
• Read and understand the Owner’s Manual completely before assembling, servicing or using unit.
• Verify all users are properly trained on using the equipment.
• Do not use unit outdoors.
• Verify that each unit is setup, leveled and operated on a solid, level surface. Do not install equipment
on an uneven surface.
• Verify there is enough room for safe access and operation of unit.
• Use Cybex AC power adapters only.
• Do not use the optional power adapter in damp or wet locations.
• Do not use the unit if: (1) the unit is plugged into an optional power adapter that has a damaged cord;
(2) the unit is not working properly or (3) if the unit has been dropped or damaged. Seek service from
a qualified technician.
• EQUIPMENT is not suitable for use in the presence of aerosol (spray), FLAMMABLE ANAESTHETIC
MIXTURE WITH AIR or WITH OXYGEN or NITROUS OXIDE.
Page 5 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

• Perform regular maintenance checks on unit. Performance level can be maintained only if examined
regularly. Pay close attention to all areas most susceptible to wear, including (but not limited to)
cables, pulleys, belts and grips.
• Replace any warning labels if damaged, worn or illegible.
•Immediately replace worn or damaged components. If unable to immediately replace worn or damaged
components, then remove unit from service until repair is made.
• Do not attempt repairs; electrical or mechanical. Seek qualified repair technician when servicing.
Failure to do so could result in serious injury. See Customer Service for contact information.
• Use only Cybex supplied components to maintain/repair unit.
• Keep a repair log of all maintenance activities.
• Disconnect the optional power adapter before servicing unit.
• Do not use attachments unless recommended for the unit by Cybex.
• The unit may generate electromagnetic or other forms of interference, or it may be affected by
interference from other equipment nearby. If this is suspected, take precautions by separating the
equipment or otherwise shielding it to avoid such interference.
Warnings and Cautions
Warning labels indicate a potentially hazardous situation that could result in serious injury or death if
the precautions are not observed.
Caution labels indicate a potentially hazardous situation that could result in serious injury or damage to
machine if the precautions are not observed.
Contact Cybex Customer Service to replace any worn or damaged labels.
Warning and Caution Decals - 770C
Page 6 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

Page 7 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

Label Placement - 770C
Label, Warning, Access tray,DE-23739-X1
Label, Warning, Disconnect PowerDE-21749-X2
Label, Warning, Hot flywheelDE-18363-X3
Decal, Caution moving partsDE-18362-X4
Label, Warning, CanadaDE-24016-25
Page 8 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

Warning and Caution Decals - 770R
Page 9 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

Label Placement - 770R
Label, Warning, Access tray,DE-23740-X1
Label, Warning, Disconnect PowerDE-21749-X2
Label, Warning, Hot flywheelDE-18363-X3
Decal, Caution moving partsDE-18362-X4
Label, Warning, CanadaDE-24016-25
Page 10 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

Assembly
Specifications - 770C, 770R, Cybex GO Monitor
770R Cycle770C Cycle
65” (165 cm)48” (122 cm)Assembled Length
25” (64 cm)22.5” (57 cm)Assembled Width
52” (132 cm)64” (163 cm)Assembled Height
183 lbs. (83 kg)142 lbs. (64 kg)Weight of Product
231 lbs. (105 kg)176 lbs. (80 kg)Shipping Weight
21 (User selected in Manual or Bike Mode)Resistance Levels
Quick Start, four Weight Loss, five Cardio, two Power, and one Fitness Test.
Quick Start is facility selectable as “Bike” mode or Constant Power.
Weight Loss and Cardio workouts are constant power.
Quick Start and Workouts have 21 levels.
Workouts
Upper console: Cybex GO Monitor.
Displays: RPM, Calories, Cal/Hr, Distance, MET, Pace, Time, and Watt.
Lower display shows road speed and resistance level.
Console Features
Built-in 5 KHz wireless heart rate receiver (transmitter not included) and contact
heart rate monitoring.
Heart Rate
Features
Minimum - 20 Watts; Maximum - 900 Watts.Resistance Range
400 lbs. (180 kg).
Maximum User
Weight
Self-powered or optional AC adapter for full time display.Power
100-240 V, 50/60 Hz, 1.0 A, AC (9V DC, 1.7A). NEMA 5-15 plug (TR-18231) or
IEC-320 inlet (TR-18230).
Power Supply
Water bottle holder and utility tray.Other
Page 11 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

Top View 770CR
Dimensions
770R Cycle770C Cycle
25” (64 cm)1
22.5” (57 cm)1
65” (165 cm)248” (122 cm)2
Choosing and Preparing a Site
Before assembling the unit, verify the chosen site meets the following criteria:
• Area is well lit and well ventilated.
• Surface is structurally sound and properly leveled.
•Free area for access to unit and emergency dismount. Minimum clearance is 23.6 inches (0.6 meters).
• Adjacent units may share the free area.
Free area
770R770C
Page 12 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

23.6”, 0.6m1
23.6”, 0.6m1
It is the responsibility of the facility owner/owner of the equipment to ensure that there is appropriate
clearance around each machine to allow for safe use and passage.
In compliance with the ADA (American Disabilities Act) there must be clear floor space of at least 30 by
48 inches and be served by an accessible route for at least one of each type of exercise equipment. If
the clear space is enclosed on three sides (e.g., by walls or the equipment itself), the clear space must
be 36 by 48 inches.
All other machines must have a clear floor space of 23" for all access point on the machine.
The dimensions stated in the assembly instructions of this manual include the maximum foot print (in
use) dimensions.
Minimum clearance of 12” (30 cm) between units for proper wireless heart rate signal operation.
Environment
Humidity and Static Electricity
The unit is designed to function normally in an environment with a relative humidity range of 30% to
75%. The unit can be shipped and stored in a relative humidity range of 10% to 90%.
Climatic dry air may cause static electricity. During workout, user may experience a shock due to build
up of static electricity on the body and the discharge path of the unit. If static electricity is experienced,
increase humidity to a comfortable level through the use of a humidifier.
Do not install, use or store the unit in an area of high humidity, such as in the vicinity of a steam room,
sauna, indoor pool or outdoors. Exposure to extensive water vapor, chlorine and/or bromine could
adversely affect the electronics as well as other parts of the unit.
Temperature
The unit is designed to function normally in an environment with an ambient temperature range of 50°
F (10° C) to 104° F (40° C). The unit can be shipped and stored in an environment with an ambient
temperature range of 32° F (0° C) to 140° F (60° C).
Electrical Power Requirements
The AC power kit is optional.
Verify the unit is connected to an outlet having the same configuration as the plug.
Verify connection is a grounded circuit. Do not use a ground-plug adapter to adapt the 3-prong power
cord to a non-grounded electrical outlet.
Use Cybex supplied AC power kit only. Consult an electrician with any questions.
Verify power supply is compliant with local building codes.
Page 13 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

Tools Required
• 3/16” Allen wrench (supplied with recumbent only)
• Phillips screwdriver
• 1/2” Socket wrench
• 9/16” Open end wrench
Assembly Procedure
Two people will be required for this procedure.
Read and understand all instructions thoroughly before assembling this unit. Check all items
carefully. If there is damage, see the Customer Service section of this manual for proper procedure
to return, replace, or reorder parts.
The words "left" and "right" denote the user's orientation.
Verify you have received the correct package
1. Read box label to verify the model number and voltage (optional) match what was ordered.
2. Verify paint color matches what was ordered.
770C Assembly
Verify parts list shown below
DescriptionPart NumberQuantityItem
Base with covers attachedVaries11
Console assemblyVaries12
Back CapPL-2158413
Front Left CoverPL-2158114
Front Right CoverPL-2158215
Top CapPL-2158316
Hardware packAX-2169817
Owner’s ManualLT-23688-X18
Assembly posterLT-2369019
Warranty sheet, ConsumerLT-23693110
Warranty sheet, CommercialLT-23692110
Power cord (E3 View Monitor option)Varies111
Cable, 6’, Coax (E3 View Monitor option)AW-23836112
Page 14 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

Hardware
DescriptionPart NumberQuantityItem
Screw, 5/16-18 × .75”,HXHD,WHIZ-LOCK,GR5HS-19108413
Screw, 8-16 × .50”, PNHDHS-15706614
Page 15 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

Lift and move the unit
1. Grasp the rear foot.
2. Lift the rear foot so the front transport wheels are able to roll on floor.
Use proper lifting methods.
3. Move unit to intended location.
4. Lower the rear foot.
Page 16 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

Install console assembly
1. Hand thread two screws into the base assembly.
Qty.Description
1Console Assembly1
2Screws2
1Base Assembly3
1Optional A/V Cable4
1Display Cable5
The console assembly will need to be supported during steps 2 through 5.
2. Insert the display cable and optional A/V cable through the frame to the left side.
Do not pinch or damage the cables during assembly.
3. Place the console assembly in the correct position on the base assembly by sliding into position
onto the two mounting screws.
4. Hand thread the other two screws.
Qty.Description
1Console Assembly1
2Screws2
1Base Assembly3
5. Securely fasten the four screws with a 1/2” socket wrench.
Page 17 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

6. Route cables through gray clip on controller.
Qty.Description
1Display cable1
1Display cable connector2
1Gray clip3
1Power supply output4
1Console cable DIN connector5
1A/V cables, optional6
1Power cord7
7. Plug the display cable into the display cable connector on the lower control board.
Ensure the cable connector is securely fastened.
8. Connect the console cable’s DIN connector to the power supply output.
Make sure the two connectors snap firmly together and can not be pulled apart without pulling the
sleeve back to release it.
Install front covers
1. Install front left cover with one screw using a Phillips screwdriver.
Qty.Description
4Plastic Connectors1
2Screw2
1Front Left Cover3
1Optional A/V Cables4
1Front Right Cover5
2. Route optional A/V cables through front covers to front of unit.
Do not pinch or damage the cables during assembly.
In addition to the mounting screws, there are four plastic connectors that secure the front covers
together. Ensure that all four plastic connectors are inserted properly in each front cover.
3. Install front right cover with one screw using a Phillips screwdriver.
Page 18 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

Install top cap
Install top cap with two screws using a Phillips screwdriver.
Qty.Description
1Top Cap1
2Screws2
Install back cap
1. Place the back cap into the top cap.
Ensure the back cap is fully inserted into the top cap.
Qty.Description
1Top Cap1
2Screws2
1Back Cap3
2. Install the back cap with two screws using a Phillips screwdriver.
Page 19 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D

Level unit
Confirm that the unit is on a level surface. If not, use a 9/16” open-end wrench to adjust the leveling feet
up or down.
Qty.Description
2Leveling Feet1
Visually inspect unit
1. Remove any packing material from unit.
2. Examine the unit to ensure that the assembly is correct and complete.
770R Assembly
Verify parts list shown below
DescriptionPart NumberQuantityItem
Base with covers attachedVaries11
Console assemblyVaries12
Front Left CoverPL-2151713
Front Right CoverPL-2151814
Seat Back AssemblyAX-2167015
Accessory TrayAX-2173816
Hardware packAX-2169917
Owner’s ManualLT-23688-X18
Assembly posterLT-2369119
Warranty sheet, ConsumerLT-23693110
Warranty sheet, CommercialLT-23692110
Power cord (E3 View Monitor option)Varies111
Page 20 of 76
Cybex 770C/770R Cycle Part Number LT-24919-4 D
