Cyklos CFM 600 User manual

FOLDING MACHINE CFM 600
OPERATING MANUAL
04/2013
CONTENTS :
1) Warning
2) Parameters
3) Machine description
4) Operation mode – automatic paper feeding
5) Methods for folding and control of stops
6) Removal of faults
7) Dismantling of covers
8) Machine disposal
1) WARNING
a) The folder is designed only for folding paper specified in parameters.
b) It is forbidden to fold foils, sheets and similar materials.
c) The machine may be utilized only in a closed room (office, shop).
d) It is forbidden to utilize the machine outdoors.
e) It is forbidden to utilize the machine with damaged feeding cord.
f) It is forbidden to utilize the machine, if unusual sounds are heard.
g) It is forbidden to operate the machine under a voltage different from the
voltage specified on the type label.
h) Prior to the machine utilization, definitely read all instructions.
i) To reduce the risk of injury, an inspection shall be essential, if the product
utilized in the vicinity of children.
j) It is forbidden to insert fingers or hands to the product after the feeding cord
connecting.
k) If the machine blocked, it shall be first necessary to disconnect the machine
from the mains supply, and then remove the cause of blocking.
l) It is forbidden to replace faulty fuse by another type, or by a fuse with different
power

2) Parameters
a) folding speed - 70 - 120 sheets/min. ± 15 % (A4)
b) types of folding - standard letter
concertina
single
double parallel
brochure
half concertina
c) sheet size - A3 , (B4), A4 , (B5), A5
d) input capacity - 200 sheets (80 g/m²)
e) built-up area - working area: l = 770 mm
w = 445 mm
h = 500 mm
transport
position: l = 345 mm
w = 445 mm
h = 350 mm
f) paper grammage - 80 - 160 g / m²
g) weight - 23 kg
h) voltage / frequency - 230 V / 50 Hz
i) electric input - 50W
j) electric current - 520 m A ± 15 %
3) Machine description
The folding machine is designed to fold paper whose properties meet the parameters
given herein. For the markings of the machine’s main parts, see the picture.
15
11
4
3
13
10
8
7
12
2
1
6

4) Operation mode - automatic paper feeding
Insert the feeding board arrestment lever 5into its lower position. Feed the
paper on the tilting 3 board – being tilted away at the moment, placing it
between side guides 11 which are set approximately to the required paper
width. Then push the side guides towards the paper. Release the arrestment
lever, which allows the feeding board to lift up the stack of paper underneath
the feeding wheel 14. Turn on the machine with using the power switch 16. If
the machine is ready to work the red LED 6shines continuously. If the red
LED 6shines discontinuously, stops X 8and Y 9 aren´t in right position or
there isn´t any paper on the feeding table 4. In such case is necessary to load
some paper on the feeding table 4or put stops Y 8and X 9to the right
position.
After pressing the “start/stop” button 1, the paper will be fed automatically from
the pile of paper and folded into the waste box. The folding speed is regulated
by the button of control speed.When the last sheet leaves the machine, the
machine turns off automatically.
5) Methods of folding and control of stops
Pictures of individual types of folding
Each type of paper folding requires the precise setting of the sheet stop rider 13 at
the X and Y stops, following the information in the table of folding options 15.
1
–
start/stop button
2 – speed control button
3 – feeding board
4 – tilting board
5 – feeding board arrestment lever
6 – light bulb control
7 – delivery drawer
8 – X stop
9 – Y stop
10 – ruler
11 – side guides
12 – front cover
13 – arretation button
14 – feeding wheel
15 – table of folds
16 – socket with the main switch
9
14
5
16
13
10

‘Single’ folding requires that the Y stop is inserted in the machine in the opposite way.
After of the stops the machine turns off automatically.
6) Removal of faults
Paper crumpling in the machine: Both stops must be removed from the
machine and the sheet must be removed so
that the rollers can turn over spontaneously.
7) Dismantling of covers
Covers can be dismantled only by a qualified person, and only after the
machine has been disconnected from the mains supply.
8) Machine disposal
When the machine’s service life is fulfilled, the machine is dismantled
and its parts sorted as follows: metal, non-metal parts, plastic, rubber and
electric parts. These parts are then returned to their respective collecting
points for recycling. Some parts of the equipment may contain dangerous
substances to environment or human health.
The picture of a machine
within a turning of Y stop
