CYP CH-1109TXC User manual

CH-1109TXC & RXC
HDMI to CAT5e/6 with LAN/PoE/IR Extender
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VS1 25/11/11 First release
VR2 02/03/12 POE Supports only family's
device
VS3 23/03/12 Amended PoE function
Updated the connection
diagram and the
specications table
VR4 16/04/12 IR Distance

CONTENTS
1. Introduction..............................................1
2. Applications.............................................1
3. Package Contents ..................................1
4. System Requirements..............................1
5. Features....................................................2
6. Operation Controls and Functions.........3
6.1 Transmitter Front and Rear Panels....3
6.2 Receiver Front and Rear Panels.......4
6.3 IR Cable Pin Assignment....................5
6.4 D-Sub 9 Pin Denitions .......................5
7. Connection Diagram .............................6
8. Specications ..........................................7
9. Acronyms.................................................8

1
1. INTRODUCTION
The device that can make your home or ofce more efcient, the
CH-1109TXC & RXC is capable of sending HDMI (uncompressed
audio/video), 3 Ethernet connections and control ports (through the
built-in RS-232 and IR ports) over a single CAT5e/CAT6 up to a distance
of 100m (300 ft.). Even more, it is adaptor free at the receiver end.
Further, with the HDMI bypass is designed to allow instant display at
the control point. So, if you wish to make your home or ofce more
efcient, get the HDMI over Single CAT5e/CAT6 with LAN/PoE & IR
Extender and prepare to be amazed.
2. APPLICATIONS
• Household entertainment media sharing and control
• Lecture room display and control
• Showroom display and control
• Meeting room presentation and control
• Classroom display and control
• Any Smart AV Installation system
3. PACKAGE CONTENTS
• HDMI to CAT5e/6 with LAN/PoE/IR Transmitter
• CAT5e/6 to HDMI with LAN/PoE/IR Receiver
• 1×IR Blaster
• 1×IR Receiver
• 24V DC Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
• Input HDMI source equipment such as DVD/Blu-ray player and
output display with HDMI input.
• RS232 controlled device
• Ethernet equipped device

2
5. FEATURES
• HDMI 1.4 compliant with 3D formats and 4k×2k resolution support
• Supports CEC bypass function
• Simultaneous transmission of uncompressed video and audio
(1080p@60Hz/-Deep Color) over a single CAT5e/6 type cable for
up to 100m (300ft.).
• Audio support up to 7.1CH Dolby TrueHD and DTS-HD
• Connect and share up to 6 Ethernet connections at speeds up to
100Mbps
• Various controls over HDMI: CEC, RS232 and IR
• 5Play™ convergence: HD video, audio & Control ports (IR and
RS232)/LAN/PoE
• Installation friendly
• Single power supply powers both units, receiver unit is powered
through the transmitter.
Note:
1. This system was tested with CAT6/23AWG cables, results may vary
with cables of a different specication.
2. The PoE function is designed for powering compatible receiver
units only—non-PoE receivers will need their own power supply.
Receivers of another brand may not be compatible.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Transmitter Front and Rear Panels
HDMI
Bypass HDMI In
LAN 1 LAN 2 LAN 3
PowerDC 24V
Extender
Blaster RS232 In CAT5e/6 Out
Link
IR 2
IR 1
1 2 3 4 5 6 7 8 9
Front Rear
10
1
Power LED: The red LED will illuminate when the 24 V DC Adaptor is
connected to the AC outlet.
2
DC 24V: Plug the 24V DC power supply into the unit and connect
the adaptor to an AC outlet.
3
IR 1 Blaster: Connect with the IR blaster cables (included in the
package) for IR signal transmission. The related IR receiver port is
IR1 Extender.
4
IR 2 Extender : Connect with the IR receiver cables (included in the
package) for IR signal reception.The related IR transmitter port is
IR2 Blaster.
5
RS-232 In: Connect to a PC/laptop (with a D-Sub 9-pin male cable)
for the transmission of RS-232 commands.
6
Link LED: This yellow LED will illuminate when the both CAT5e/6
input and output signal is connected.
7
CAT5e/6 Out: Connect the transmitter and receiver via a single
CAT5e/6 type cable for all data transmission.
8
HDMI Bypass: Connect to a HDMI TV/monitor for instant display of
the HDMI input source signal.
Note: When the HDMI bypass is connected, no signals will be
transmitted to the receiver side. Therefore, unplug this connection
after conrming that the correct image is displayed
9
HDMI In: Connect to the HDMI equipped source equipment such
as DVD or Blu-ray player.
10
LAN 1/2/3: The LAN connections can be used to connect and
share up to 6 ethernet connections (3 at the reciver end, 3 at the
transmitter end), including computers, routers and media servers.

4
6.2 Receiver Front and Rear Panels
LAN 1 LAN 2 LAN 3
HDMI Out
1 2 3 4 5 6 7
Front Rear
Power
Extender Blaster
IR 2
IR 1 RS232 Out CAT5e/6 In
Link
8
1
Power LED: The red LED will illuminate when the 24 V DC Adaptor is
connected to the AC outlet.
2
IR 1 Extender: Connect with the IR receiver cables (included in the
package) for IR signal reception. The related IR transmitter port is
IR1 Blaster.
3
IR 2 Blaster: Connect t with he IR blaster cables (included in the
package) for IR signal transmission. The related IR receiver port is
IR2 Extender.
4
RS-232 Out: Connect to a RS-232 enabled device (with a D-Sub
9-pin female cable) for the transmission of RS-232 commands.
5
Link LED: This yellow LED will illuminate when the both CAT5e/6
input and output signal is connected.
6
CAT5e/6 In: Connect the transmitter and receiver via a single
CAT5e/6 type cable for all data transmission.
7
HDMI Out: Connect to a HDMI equipped TV or monitor to display
the HDMI input source signal.
8
LAN 1/2/3: The LAN connections can be used to connect and
share up to 6 ethernet connections (3 at the reciver end, 3 at the
transmitter end), including computers, routers and media servers.

5
6.3 IR Cable Pin Assignment
3
1
3
1
2
2
Power 5V
IR Blaster Signal
NC
IR Signal
Power 5V
Grounding
IR Receiver
IR Blaster
6.4 D-Sub 9 Pin Denitions
Pin Dene TX/RX
1N/C
2TxD / RxD
3RxD / TxD
4N/C
5GND
6N/C
7N/C
8N/C
9N/C

6
7. CONNECTION DIAGRAM
PowerDC 24V
Extender
Blaster RS232 In CAT5e/6 Out
Link
IR 2
IR 1
HDMI
Bypass HDMI In
LAN 1 LAN 2 LAN 3
Power
Extender Blaster
IR 2
IR 1 RS232 Out CAT5e/6 In
Link
LAN 1 LAN 2 LAN 3
HDMI Out
7m
3m 3m
60°
m
IR BLASTER
1.5m
60°
IR RECEIVER
7m
3m 3m
60°
PC
Media Server
Notebook
Media Player
TV/Display
RS232 Controlled
Device
Blu-ray/DVD Player
Modem/Router
TX
PC with RS232
Control
RX
Single CAT5e/6
IR Blaster
Power
Supply
IR Extender

7
8. SPECIFICATIONS
Video Bandwidth 300 MHz/9 Gbps
Ethernet Speed 100 Mbps
Transmitter
Input 1×HDMI , 3×Ethernet
1×RS-232, 1×IR Extender
Output 1×CAT5e/6, 1×HDMI Bypass, 1×IR Blaster
Receiver
Input 1×CAT5e/6, 1×IR Extender
Output 1×HDMI, 1×RS-232
3 ×Ethernet, 1×IR Blaster
HDMI In/Out Cable
Distance Up to 10 Meters
CAT6 In/Out Cable
Distance Up to 100 Meters
HDMI In/Out Supports
Resolution 480i~1080p@50/60, 1080p@24, VGA~WUXGA
IR Frequency 30~50 kHz
ESD Protection Human body model:
±8kV (air-gap discharge)
±4kV (contact discharge)
Power Supply 24V/1.25A DC (US/EU Standards, CE/FCC/
UL certied)
Dimensions 125 mm(W) x 127 mm (D) x 30 mm (H)/Each
Weight 360g (TXC)
382g (RXC)
Chassis Material Aluminum
Silkscreen Color Black
Power Consumption 6W (TXC)
8W (RXC)
Operating Temperature 0˚C~40˚C/32˚F~104˚F
Storage Temperature −20 ˚C~60 ˚C/−4˚F~140 ˚F
Relative Humidity 20~90% RH (non-condensing)

8
9. ACRONYMS
ACRONYM COMPLETE TERM
CAT6 Category 6 Cable
HDMI High Denition Multimedia Interface

Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD
