CH-514TXL/RXL
HDBaseTTM Lite HDMI over Single CAT5e/6/7 Extender
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2012 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VR0 21/12/12 Preliminary Release
VR1 04/03/13
VS2 01/07/13 Updated Text/Diagrams

CONTENTS
1. Introduction................................................. 1
2. Applications................................................ 1
3. Package Contents ..................................... 1
4. System Requirements................................. 1
5. Features....................................................... 2
6. Operation Controls and Functions............ 3
6.1 Transmitter Front and Rear Panels....... 3
6.2 Receiver Front and Rear Panels .......... 4
6.3 Transmitter and Receiver Top Panels.. 5
6.4 IR Cable Pin Assignment....................... 5
7. Connection Diagram ................................. 6
8. Specications ............................................. 8
9. Acronyms .................................................... 9

1
1. INTRODUCTION
The HDBaseT™ Lite HDMI over Single CAT5e/6/7 Extender incorporating
2-way IR signal transfer allows for a more efcient system setup and is
easy to install. Uncompressed video and audio can be transmitted to
distances of up to 60 meters (1080p) or up to 35 meters (4K×2K) and
supports High Denition Audio and 3D signals.
Designed with HDBaseT Lite technology for greater exibility in custom
installations with full HDMI and 2-way IR control signal transfer over a
single CAT5e/6/7 cable.
2. APPLICATIONS
• Residential entertainment sharing and control
• University lecture hall display and control
• Retail sales display and control
• Meeting room presentation and control
• Commercial advertising display and control
3. PACKAGE CONTENTS
• 1×HDMI over Single CAT5e/6/7 Transmitter
• 1×HDMI over Single CAT5e/6/7 Receiver
• 1×IR Blaster
• 1×IR Extender
• 2×5 V/2.6 A DC Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
HDMI source equipment such as DVD/Blu-ray player/PC and TV/
monitor/projector with HDMI input. HDMI and CAT5e/6/7 cables.

2
5. FEATURES
• HDMI including 3D and 4K×2K (Ultra HD) support, HDCP and DVI
compliant
• Supports HDCP repeater and CEC bypass
• Supports HDBaseT Lite Technology including 2-Way IR and RS-232
• Supports transmission distance of up to 60 meters through CAT5e/6/7
cable (1080p or 3D) or 35 meters (4K×2K)
• Supports HDMI input up to 15 meters at 8-bit resolution or 10 meters
at 12-bit resolution and output up to 15 meters at 8-bit or 12-bit
resolution
• Audio support up to LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus
and DTS-HD Master Audio
• Compact size with stylish design
Note: When displaying a 3D signal with a higher bandwidth than
225 MHz or a 4K×2K resolution source, a High Speed HDMI cable is
required.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Transmitter Front and Rear Panels
CAT5e/6 OUT
HDMI INIR1 OUT IR2 IN
DC 5V
HDMI to CAT5e/6
with IR
TRANSMITTER
CAT5e/6 OUT
HDMI IN IR2 INIR1 OUT
DC 5V
HDMI to CAT5e/6
with IR
TRANSMITTER
4 51 2 3
1
IR1 OUT: Connect to the supplied IR blaster for IR signal transmission to
the source equipment. Place the IR blaster in direct line-of-sight of
the equipment to be controlled.
2
HDMI IN: Connect to an HDMI source device such as a DVD player or
Set-top Box with HDMI cable or DVI to HDMI cable.
3
IR2 IN: Connect to the supplied IR extender cable for IR signal
reception and transmission to IR2 OUT on the receiver unit. Ensure
that remote being used is within the direct line-of-sight of the IR
extender.
4
DC 5V: Connect the 5V DC power supply to the unit and plug the
adaptor into an AC outlet.
5
CAT5e/6 OUT: Connect to the receiver unit with a single CAT5e/6/7
cable for transmission of all data signals. The yellow LED will
illuminate when both transmitter and receiver are connected
together and are powered. The green LED will illuminate when the
device is connected to the power supply.

4
6.2 Receiver Front and Rear Panels
CAT5e/6 INDC 5V
CAT5e/6 to HDMI
with IR
HDMI OUT IR2 OUTIR1 IN
RECEIVER
CAT5e/6 INDC 5V
CAT5e/6 to HDMI
with IR
HDMI OUT IR2 OUTIR1 IN
RECEIVER
4 51 2 3
1
IR1 IN: Connect the supplied IR extender cable for IR signal
reception and transmission to IR1 OUT on the transmitter unit.
Ensure that the remote control being used is within the direct line-
of-sight of the IR extender.
2
HDMI OUT: Connect to a HDMI equipped TV/monitor for display of
the HDMI input source signal.
3
IR2 OUT: Connect to the supplied IR blaster for IR signal transmission to
the display equipment. Place the IR blaster in direct line-of-sight of
the equipment to be controlled.
4
DC 5V: Connect the 5V DC power supply to the unit and plug the
adaptor into an AC outlet.
5
CAT5e/6 IN:Connect to the transmitter unit with a single CAT5e/6/7
cable for transmission of all data signals. The yellow LED will illuminate
when both the transmitter and receiver are connected and are
powered. The green LED will illuminate when the device is connected
to the power supply.

5
6.3 Transmitter and Receiver Top Panels
CAT5e/6 OUT
HDMI IN IR2 INIR1 OUT
DC 5V
HDMI to CAT5e/6
with IR
TRANSMITTER
CAT5e/6 INDC 5V
CAT5e/6 to HDMI
with IR
HDMI OUTIR2 OUTIR1 IN
RECEIVER
1
1
1
LINK LED
This LED will illuminate in blue when the devices are connected
with a CAT5e/6 cable. If the data transmission has an error the LED
will blink.
6.4 IR Cable Pin Assignment
3
1
3
1
2
2
Power 5 V
IR Blaster Signal
NC
IR Signal
Power 5 V
Ground
IR Extender
IR Blaster

6
7. CONNECTION DIAGRAM
Example 1: Direct Connection
1.5m
60°
1.5m
60°
7m
3m
3m
60°
m
m
3m
7m3m
3m
60°
m
m
m
RX
TX
HD Monitor
CAT5e/6/7
(60m)
Power
Supply
Power
Supply
Blu-ray Player
IR Blaster
IR BlasterIR Extender
IR Extender
HDMI
Output
HDMI
Input

7
Example 2: Using a Repeater to Extend the Operating Distance
1.5m
60°
1.5m
60°
CAT5e/6 OUT
HDBaseT Repeater
CHDBX-1C
MODE LINK
DC 24V
CAT5e/6 IN
POWER
MODE LINK
7m3m 3m
60°
m
m
m
7m
3m
3m
60°
m
m
3m
HD Monitor
Optional
HDBaseT Lite
Repeater
CAT5e/6/7
(Up to 60m
@ 1080p)
CAT5e/6/7
(Up to 60m
@ 1080p)
Power
Supply
Power
Supply
Power
Supply
Blu-ray Player
IR Blaster
IR BlasterIR Extender
IR Extender
HDMI
Output
HDMI
Input
RX
TX
Front
Rear

8
8. SPECIFICATIONS
Video Bandwidth 300 MHz/10.2 Gbps
Transmitter
Input 1×HDMI, 1×IR Extender
Output 1×CAT5e/6/7, 1×IR Blaster
Receiver
Input 1×CAT5e/6/7, 1×IR Extender
Output 1×HDMI, 1×IR Blaster
ESD Protection Human Body Model:
±8 kV (air-gap discharge)
±4 kV (contact discharge)
Power Supply 5 V/2.6 A DC (US/EU standards, CE/FCC/UL
certied)
Dimensions 55 mm (W)×82 mm(D)×22.5 mm (H)/Each
Weight 56 g/TX, 64 g/RX
Chassis Material Plastic
Silkscreen Color White
Operating Temperature 0 ˚C~40 ˚C/ 32 ˚F~104 ˚F
Storage Temperature −20 ˚C~60 ˚C/−4 ˚F~140 ˚F
Relative Humidity 20~90 % RH (non-condensing)
Power Consumption 3 W/TX, 5.5 W/RX

9
CAT5e/6/7 Cable Specication:
LENGTH BANDWIDTH DATA RATE SUPPORTED VIDEO
Up to
60 m
Up to
225 MHz
Up to
5.3 Gbps
HD Video
Up to 1080p@60 Hz/36-bit, 3D
(data rate lower than 5.3 Gbps
or bandwidth below 225 MHz).
Up to
35 m
Greater
than
225 MHz
Greater
than
5.3 Gbps
Ultra HD Video
Up to 4K×2K@30 Hz.
9. ACRONYMS
ACRONYM COMPLETE TERM
CAT5e Category 5 Cable
CAT6 Category 6 Cable
CAT7 Category 7 Cable
CEC Consumer Electronics Control
DVI Digital Visual Interface
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition multimedia Interface
IR Infrared
