Operation Manual
Operation Manual
Multiviewer with Streaming Solution
for Video Conferencing
MED-VPR-3420

®
registered trademarks of HDMI licensing Administrator, Inc.

DISCLAIMERS
The information in this manual has been carefully checked and is believed
to be accurate. Cypress Technology assumes no responsibility for any
infringements of patents or other rights of third parties which may result from
its use.
Cypress Technology assumes no responsibility for any inaccuracies that
may be contained in this document. Cypress also makes no commitment to
update or to keep current the information contained in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express written
permission and consent from Cypress Technology.
© Copyright 2018 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document are trademarks of
the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply. Please keep the
following in mind as you unpack and install this equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain, moisture
or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any openings
or empty slots in the unit, as you may damage parts inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if it
is damaged.
• Do not allow anything to rest on the power cabling or allow any weight to
be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or openings
in the unit housing that provide ventilation and allow for su󰀩cient space
for air to circulate around the unit.
• Please completely disconnect the power when the unit is not in use to
avoid wasting electricity.
VERSION HISTORY
REV. DATE SUMMARY OF CHANGE
RDV1 2020/06/23 Preliminary release

CONTENTS
1. Introduction.......................................................................1
2. Applications......................................................................2
3. Package Contents ............................................................2
4. System Requirements......................................................2
5. Features.............................................................................3
5.1 Multiviewer Component Features.................................3
5.2 Video Capture Component Features............................4
6. Operation Controls and Functions.................................5
6.1 Front Panel...................................................................5
6.2 Rear Panel....................................................................7
6.3 RS-232 Pinout and Defaults (Multiviewer)....................8
6.4 OSD Menu (Multiviewer) ..............................................9
6.5 WebGUI Control (Multiviewer)....................................26
6.5.1 Upper Tab Windows..........................................28
6.5.2 Window Layout Tab...........................................29
6.5.3 Picture Tab ........................................................31
6.5.4 Audio Tab...........................................................32
6.5.5 Input EDID Tab..................................................33
6.5.6 HDCP Mode & Status Tab.................................34
6.5.7 OSD Settings Tab..............................................35
6.5.8 Logo Settings Tab..............................................36
6.5.9 Ethernet Tab......................................................37
6.5.10 Setup Tab........................................................38
6.5.11 Information Tab................................................39
6.6 Video Capture Control & Conguration ......................40
6.6.1 USB Video Capture Conguration.....................40
6.6.2 Video Capture ...................................................42
6.7 Telnet Control (Multiviewer)........................................43
6.8 Serial and Telnet Commands (Multiviewer)................43

7. Connection Diagram .....................................61
8. Specications ................................................62
8.1 Technical Specications ............................62
8.2 Video Specications ..................................63
8.3 Audio Specications ..................................65
8.3.1 Digital Audio .....................................65
8.3.2 Analog Audio ....................................66
8.4 Cable Specications..................................66
9. Acronyms.......................................................67

1
1. INTRODUCTION
Video conferencing is an important and convenient way to communicate
with people around the globe. If you want to express your thoughts clearly
by sharing a variety of rich images, an integrated machine with multi-
windowing and video capture functions is a splendid idea. This Multiviewer
with Streaming Solution for Video Conferencing is just the thing to meet
your requirements. Besides being a high performance HDMI matrix switch
with integrated scaling and multi-windowing technology, a video capture
component is also included!
Any of 4 di󰀨erent HDMI sources may be displayed individually, full screen,
with seamless switching in Matrix mode, or they can be displayed using
a variety of multi-window modes including standard views like PiP and
PoP as well as fully customizable quad-window modes. By using an HDMI
cable to connect between the multiviewer component’s output and the
video capture component’s input above it, the unit is transformed into a
exible video streaming, distribution, and recording powerhouse. In this
conguration, all HDMI ports support resolutions up to 18Gbps 4K UHD+
(via the bypass path) while simultaneously streaming the audio and video
signal at 1080p to a USB connected PC for capture or re-broadcast. USB
capture is accomplished using the UAC (USB Audio Class) and UVC (USB
Video Class) standards, allowing the video capture component to support
most common video capture, chat, or streaming software, including the Free
OBS (Open Broadcaster Software) streaming software which is available for
Windows PC, macOS and Linux.
The video capture component of the unit is powered directly by the USB 3.0
port while the multiviewer component is powered via a DC 24V power source
and both components can be operated independently if desired. Control of
the multiviewer component is via front panel controls, WebGUI, RS-232, and
Telnet while control of the video capture component is handled by software
on the computer connected via USB 3.0.

2
2. APPLICATIONS
• Medical procedure multiview recording and distribution
• Live video streaming and recording
• Distance learning
• Security camera recording
• Gameplay video webcasting and archival
• Entertainment room & home theater matrixing
• Lecture hall presentations
• Public commercial displays
3. PACKAGE CONTENTS
• 1× Multiviewer with Streaming Solution for Video Conferencing
• 1× 24V/2.7A DC Power Adapter
• 1× USB 3.0 Type-A to Type-B Cable
• 1× Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI source equipment such as media players, video game consoles or
set-top boxes.
• HDMI receiving equipment such as HDTVs, monitors or audio ampliers.
• Personal computer (Windows 10 or macOS) with a USB 3.0 port and
plenty of available hard drive space.

3
5. FEATURES
5.1 Multiviewer Component Features
• HDMI 2.0 and DVI 1.0 compliant (with the use of an HDMI-DVI adapter)
• HDCP 1.x and 2.2 compliant
• 4 HDMI inputs and 2 HDMI outputs
• Supports up to 4K UHD+ (18Gbps, 4K@50/60Hz 4:4:4, 8-bit) video input
and output
Note: HDR bypass is not supported.
• Seamless switching (no loss of sync to display) when switching sources in
Matrix mode
• Supports up to four simultaneous, freely scalable, windows in multi-
windowing modes
• Supports the ability to store a multi-window arrangement as a preset that
can be recalled later
• Independent audio source selection and routing in all modes
• Inputs 1 & 2 support pass-through of many audio formats including 8
channel LPCM, Bitstream, and HD Bitstream (Inputs 3 & 4 are limited to 2
channel LPCM only)
• Each window can have a border with a selectable color
• Uploadable and freely positionable graphic logo support
• Intuitive and easy adjustment of window size, position and settings in
multi-window modes via the WebGUI
• Per-input EDID management with internal or external EDID options
• Controllable via front panel buttons, WebGUI, Telnet, and RS-232

4
5.2 Video Capture Component Features
• HDMI input and output with HDR, 3D & 4K@60Hz support, DVI 1.0
compatible
• HDCP 2.2 and HDCP 1.x compliant
• Supports up to 4K UHD+ (18Gbps, 4K@50/60Hz 4:4:4, 8-bit) video input
and bypass output
• Supports Deep Color input and bypass output up to 12-bit
• Supports 10-bit and 12-bit HDR (High Dynamic Range) input/bypass
output
• Automatically scales 4K sources to 1080p for USB capture
• The video capture component of the unit is powered directly via USB 3.0
Note: When connected via USB 2.0, a Y-cable is required to provide
additional power
• Supports video timing stabilization to help ensure a reliable and stable
USB capture stream
• Capturing over USB 3.0 allows uncompressed video and audio data
capture (up to 1080p, LPCM 2.0)
• Capturing over USB 2.0 requires the application of minimal MJPEG
compression to the video and audio data (up to 1080p, LPCM 2.0)
• Supports capturing 2 channel digital audio from either HDMI (LPCM 2.0)
or the 3.5mm analog audio input (selectable via conguration software)
• Compliance with the UAC (USB Audio Class) and UVC (USB Video Class)
standards, allows the video capture component of the unit to support most
common capture and video streaming software
Note: Availability and access to the controllable features of the video
capture component of the unit depend on the capture software used
• Support for the Free OBS (Open Broadcaster Software) streaming
software which is available for Windows PC, macOS and Linux.

5
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
SERVICE POWER
AB 1080P XGA
IN 1 IN 1 IN 2 IN 3 IN 4
MENU -+ENTER
IN 2 IN 3 IN 4 OUT
VIDEO
MODE
A
B
OUT
1 2 3 4 5 6 7 8 9
1SERVICE Port: This port is reserved for rmware update and user EDID/
logo upload use only.
2POWER LED & Button: Press this button to power the multiviewer
component of the unit on (green LED) or place it into stand-by mode (red
LED).
Note: Ethernet and RS-232 remain active when the unit is in stand-by
mode. Does not aect the video capture component of this unit.
3VIDEO MODE Button: Press this button to sequentially switch the
multiviewer component’s operational mode between Matrix, PiP, PoP,
and Quad.
4OUT A~B/IN 1~4 LED Array: In Matrix mode, these LED’s indicate the
currently selected sources (IN 1~4) routed to each of the two outputs
(OUTA~B). When the multiviewer component is in a multi-windowing
mode (PiP/PoP/Quad/ Preset) all LEDs will be illuminated simultaneously.
Note: When source selection is active the associated output’s LED(s) will
blink.
5OUT A/B Buttons: In Matrix mode, either of these buttons to activate/
deactivate discrete source selection for the associated output. In multi-
windowing modes (PiP/PoP/Quad/Preset) either button will activate/
deactivate sequential source selection for the 4 windows.
Note: These buttons only activate/deactivate the ability to change
sources. Actual source selection is accomplished using the IN 1~4
buttons.

6
6IN 1/MENU Button: When not in source selection mode, press to enter
the OSD menu, or to back out from menu items. When source selection
is active, pressing this button will either select input 1 (Matrix mode) or
sequentially switch through all 4 inputs for window 1 (PiP/PoP/Quad/
Preset modes).
Note: Pressing “MENU” and “+” together will reset the output resolution
to XGA (1024×768@60Hz). Pressing “MENU” and “-” together will reset
the output resolution to 1080p@60Hz.
7IN 2/- (MINUS) Button: When not in source selection mode, press
to move down or adjust selections within OSD menus. When source
selection is active, pressing this button will either select input 2 (Matrix
mode) or sequentially switch through all 4 inputs for window 2 (PiP/PoP/
Quad/Preset modes).
8IN 3/+ (PLUS) Button: When not in source selection mode, press to
move up or adjust selections within OSD menus. When source selection
is active, pressing this button will either select input 3 (Matrix mode) or
sequentially switch through all 4 inputs for window 3 (PiP/PoP/Quad/
Preset modes).
9IN 4/ENTER Button: When not in source selection mode, press to
conrm a selection within the OSD or to go deeper into a menu item.
When source selection is active, pressing this button will either select
input 4 (Matrix mode) or sequentially switch through all 4 inputs for
window 4 (PiP/PoP/Quad/Preset modes).

7
6.2 Rear Panel
USB 3.0 CAPTURE OUT CAPTURE IN
AUDIO IN
HDMI IN
1234HDMI OUT A HDMI OUT B CONTROL RS-232 DC 24V
5
1 2 3 4
6 987 10
1USB 3.0 Port: Connect directly to a PC’s USB 3.0 port to control and
power the video capture component of the unit.
Note: If connected via USB 2.0, use of a Y-cable connected to 2 USB 2.0
ports is required in order to properly power the video capture component
of the unit.
2CAPTURE OUT Port: The video bypass output from the video capture
component of the unit. Connect to an HDMI TV, monitor or amplier for
digital video and audio output.
3CAPTURE IN Port: The video input for the video capture component of
the unit. To capture video from the multiviewer component of the unit,
connect this port to the HDMI OUT B port located directly below it.
Note: Capturing video sources containing HDCP protection is not
supported. Only the bypass CAPTURE OUT port will be active with
HDCP sources.
4AUDIO IN Port: Connect to the stereo analog output of a device such as
an audio player or PC for capture via USB 3.0.
5HDMI IN 1~4 Ports: Video inputs for the multiviewer component of
the unit. Connect to HDMI source equipment such as players, game
consoles, or set-top boxes.
Note: Audio support on inputs 3~4 is limited to 2 channel LPCM.
6HDMI OUT A Port: Primary HDMI output of the multiviewer component
of the unit. Connect to HDMI TVs, monitors, or ampliers for digital video
and audio output.

8
7HDMI OUT B Port: Secondary HDMI output of the multiviewer
component of the unit. To capture video from the multiviewer component
of the unit, connect this port to the CAPTURE IN port located directly
above it.
8CONTROL Port: Connect directly, or through a network switch, to your
PC/laptop to control the multiviewer component of the unit via Telnet/
WebGUI.
9RS-232 Port: Connect directly to a PC, laptop, or other serial control
device with a 3.5mm adapter cable to send RS-232 commands to control
the multiviewer component of the unit.
10 DC 24V Port: Plug the 24V DC power adapter into this port and connect
it to an AC wall outlet to power the multiviewer component of the unit.
Note: The video capture component of the unit receives power only from
the USB 3.0 connection. Both must be connected to fully power the unit.
6.3 RS-232 Pinout and Defaults (Multiviewer)
Serial Port Default Settings
Baud Rate 19200
Data Bits 8
Parity Bits None
Stop Bits 1
Flow Control None
3.5mm to DE-9
Adapter Cable
RxD
TxD
GND
1
2
3

9
6.4 OSD Menu (Multiviewer)
All functions of this unit can be controlled by using the OSD (On Screen
Display) which is activated by pressing the MENU button on the front of the
unit. Use the + (PLUS), − (MINUS), and ENTER buttons to navigate the OSD
menu. Press the MENU button to back out from any menu item and then
press it again to close the menu.
MAIN MENU
Video Mode
Window Layout
Audio
Input EDID
HDCP Mode
Output Resolution
OSD Settings
Logo Settings
Ethernet
Preset
Setup
Information
The individual functions of the OSD will be introduced in the following
section. Items marked in BOLD are the factory default settings.

10
VIDEO MODE
2ND LEVEL 3RD LEVEL
Video Mode Matrix
PiP
PoP
QUAD
Preset 1
Preset 2
Preset 3
Preset 4
PiP/PoP/Quad/Preset Mode
WIN 1 Source In 1~4 (In 1)
WIN 2 Source In 1~4 (In 2)
WIN 3 Source In 1~4 (In 3)
WIN 4 Source In 1~4 (In 4)
Matrix Mode
OUT A Source In 1~4 (In 1)
OUT B Source In 1~4 (In 2)
1) Video Mode: Select the preferred operation mode of the unit.
Note: Selecting some modes will limit available features.
2) WIN 1/2/3/4 Source: Select the source for the specied window in multi-
windowing modes (PiP, PoP, Quad).
3) OUT A/B Source: Select the source for the specied HDMI output when
in Matrix mode.

11
WINDOW LAYOUT (Matrix Mode)
2ND LEVEL 3RD LEVEL
Input Select In 1~4 (In 1)
Aspect Ratio FULL
16:9
16:10
4:3
Best Fit
Mirror NO
Yes
Border On/O󰀨 On
OFF
Border Color Black
Red
GREEN
Blue
Yellow
Magenta
Cyan
White
Dark Red
Dark Green
Dark Blue
Dark Yellow
Dark Magenta
Dark Cyan
Gray
Window Reset NO
Yes

12
1) Input Select: Select the input to modify.
Note: All settings are individually saved, per-input.
2) Aspect Ratio: Select a xed aspect ratio for the currently selected
window. Selecting the “Full” aspect ratio will stretch the source to ll the
output, regardless of original aspect. Selecting “Best Fit” will automatically
set the ratio based on the window’s current source resolution.
3) Mirror: Selecting “On” will ip the currently selected input horizontally.
4) Border On/O󰀨: Enables or disable the color border around the currently
selected input.
5) Border Color: Select the color to use for the border of the currently
selected input.
6) Window Reset: Reset the current input to its default settings.
WINDOW LAYOUT (PiP/PoP/Quad/Preset Modes)
2ND LEVEL 3RD LEVEL
Window Select Win 1~4 (Win 1)
Window On/O󰀨 ON
O󰀨
Position X 0~Max H resolution
Position Y 0~Max V resolution
Size Width 1~Max H resolution
Size Height 1~Max V resolution
Priority 1~4 (4)
Aspect Ratio FULL
16:9
16:10
4:3
Best Fit
User
Mirror NO
Yes
Border On/O󰀨 On
OFF

13
WINDOW LAYOUT (PiP/PoP/Quad/Preset Modes)
2ND LEVEL 3RD LEVEL
Border Color Black
Red
GREEN
Blue
Yellow
Magenta
Cyan
White
Dark Red
Dark Green
Dark Blue
Dark Yellow
Dark Magenta
Dark Cyan
Gray
Window Reset NO
Yes
1) Window Select: Select the window to modify.
Note: All settings are individually saved, per-window/per-mode.
2) Window On/O󰀨: Enable or disable the currently selected window.
3) Position X/Y: Set the X and Y coordinate position of the upper left corner
of the currently selected window.
4) Size Width/Height: Set the horizontal and vertical size of the currently
selected window.
5) Priority:
Select the layer priority of the currently selected window. Priority
1 is at the front and priority 4 is at the back.
6) Aspect Ratio: Select a xed aspect ratio for the currently selected
window. The aspect ratio will be based on the window’s current height.
Selecting the “Full” aspect ratio will return the window to the current

14
mode’s default size and shape for that window. Selecting “Best Fit”
will automatically set the ratio based on the window’s current source
resolution.
7) Mirror: Selecting “On” will ip the currently selected window horizontally.
8) Border On/O󰀨: Enables or disable the color border around the currently
selected window.
9) Border Color: Select the color to use for the border of the currently
selected window.
10) Window Reset: Reset the current window to its default settings based
on the currently selected mode.
2ND LEVEL 3RD LEVEL
Input Select IN 1
In 2
In 3
In 4
Contrast 0~100 (75)
Brightness 0~100 (50)
Saturation 0~100 (50)
Hue 0~100 (50)
Sharpness H 0~10 (10)
Sharpness V 0~10 (10)
Reset NO
Yes
1) Input Select: Select the input to modify.
2) Contrast:
Set the overall contrast of the currently selected input.
3) Brightness: Set the overall brightness of the currently selected input.
4) Saturation:
Set the overall saturation of the currently selected input.
5) Hue:
Set the hue shift of the currently selected input.
6) Sharpness H/V: Set the amount of sharpness processing to apply to the
currently selected input.
7) Reset: Reset the current input to its default settings.
