Cypress VEX-E2502T User manual

Operation Manual
Operation Manual
UHD+USB-C over HDBaseT Transmitter
with USB KVM
VEX-E2502T

DISCLAIMERS
The information in this manual has been carefully checked and is believed
to be accurate. Cypress Technology assumes no responsibility for any
infringements of patents or other rights of third parties which may result from
its use.
Cypress Technology assumes no responsibility for any inaccuracies that
may be contained in this document. Cypress also makes no commitment to
update or to keep current the information contained in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express written
permission and consent from Cypress Technology.
© Copyright 2018 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document are trademarks of
the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply. Please keep the
following in mind as you unpack and install this equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain, moisture
or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any openings
or empty slots in the unit, as you may damage parts inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if it
is damaged.
• Do not allow anything to rest on the power cabling or allow any weight to
be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or openings
in the unit housing that provide ventilation and allow for su󰀩cient space
for air to circulate around the unit.
• Please completely disconnect the power when the unit is not in use to
avoid wasting electricity.
VERSION HISTORY
REV. DATE SUMMARY OF CHANGE
RDV1 2022/06/22 Preliminary release

CONTENTS
1. Introduction...................................................... 1
2. Applications ..................................................... 1
3. Package Contents ........................................... 1
4. System Requirements..................................... 1
5. Features............................................................ 2
6. Operation Controls and Functions ................ 3
6.1 Front Panel ................................................. 3
6.2 Rear Panel................................................... 4
6.3 IR Cable Pinouts.......................................... 5
6.4 Serial Pinout ................................................ 5
6.5 Audio Pinouts............................................... 5
7. Connection Diagram ....................................... 6
8. Specications .................................................. 7
8.1 Technical Specications .............................. 7
8.2 Video Specications .................................... 8
8.3 Audio Specications .................................. 10
8.3.1 Digital Audio ..................................... 10
8.3.2 Analog Audio .................................... 10
8.4 Cable Specications.................................. 11
8.5 HDBaseT Features.................................... 12
9. Acronyms ....................................................... 13

1
1. INTRODUCTION
This 4K UHD+USB-C over HDBaseT transmitter uses HDBaseT 3.0, the
newest generation of HDBaseT technology, and is the perfect solution for
extending full bandwidth (18Gbps, 4K@60Hz 4:4:4) video signals with
HD audio via a single run of Cat.6A/7 cable over distances of up to 40
meters. Multiple control and data signals may also be transmitted along
with the audio and video, including IR, RS-232, and USB 3.0. Additionally,
the inclusion of a USB-C connection as its input allows for the combination
of video, audio, and USB over a single cable from the connected source
device, greatly enhancing installation practicality. This transmitter is ideal
for use in any video extension scenario, especially when latency-free,
uncompressed, high resolution video is critical, such as medical installations,
live conferences, and education.
2. APPLICATIONS
• Household entertainment sharing and control
• Lecture hall/classroom display and control
• Meeting room presentation and control
3. PACKAGE CONTENTS
• 1× UHD+USB-C over HDBaseT Transmitter with USB KVM
• 1× 24V/2.7A DC Power Adapter
• 2× 3-pin Terminal Block
• 1× 8-pin Terminal Block
• 1× Operation Manual
4. SYSTEM REQUIREMENTS
• USB-C source equipment such a media player, laptop, or tablet.
• HDMI receiving equipment such as an HDTV, monitor, or audio amplier.
• A compatible HDBaseT 3.0 receiver with PoH (PD) support is
recommended.
• The use of Premium High Speed HDMI cables, and industry standard
Cat.6A or Cat.7 Ethernet cable is highly recommended.

2
5. FEATURES
• USB-C (USB 3.0) video compatible
• HDMI 2.0 and DVI 1.0 compatible
• HDCP 2.2 and HDCP 1.x compliant
• HDBaseT 3.0 compliant (Backwards compatible with HDBaseT 2.0/1.0)
• 1 USB-C input
• 1 HDBaseT and 1 HDMI output
• Supports up to 4K UHD+ (18Gbps, 4K@60Hz 4:4:4, 8-bit) video output
over both HDMI and HDBaseT
• Supports Deep Color input and output up to 12-bit
• Supports 10-bit and 12-bit HDR (High Dynamic Range) input/output
• Supports CEC bypass
• HDBaseT extends video, audio and data over a single Cat.6A/7 cable and
can reach distances up to 70m/230ft
• HDBaseT feature support: HD Video and Audio, PoH (PSE), Bi-directional
audio (analog), and Control (bi-directional USB/IR/RS-232 pass-through)
• 2 USB 2.0 Type-A device ports and 1 USB-C host port
• Selectable USB-C audio extraction/analog audio bypass functionality when
paired with a compatible receiver
Note: USB-C audio extraction is only available with LPCM 2.0 sources.
• HDMI output functions as a local monitor
• Can supply PoH to a connected compatible receiver
Note: The PoH function is designed for powering compatible receiver units
only. Non-PoH receivers will need their own power supply. Receivers from
other brands may not be compatible.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
AUDIO IR
IN
OUT LR R PWRT
AUDIO BYPASS
EXTRACT LINK
HDMI OUT
31
2 4 8 9
5 6 7 10
1HDMI OUT port: Connect to an HDMI TV, monitor, or amplier for digital
video and audio output.
2AUDIO IN 3-pin Terminal Block: Connect to the analog audio output
of a device such as a media player or game console using a 3-pin
adapter cable. Audio is sent to the analog audio output on the connected
compatible receiver.
3AUDIO OUT 3-pin Terminal Block: Connect to powered speakers or
an amplier for analog audio output using a 3-pin adapter cable. Audio
is sourced from the analog audio input on the connected compatible
receiver in bypass mode, or from the USB-C port in extract mode.
4RS-232 4-pin Terminal Block: Connect to a PC, laptop, or serial
controllable device with a 4-pin adapter cable for the extension of
RS-232 signals between both ends of the HDBaseT connection.
5IR 4-pin Terminal Block (In/Out): Connect to both an IR Blaster and
Extender using a 4-pin Y-adapter cable to transmit and receive IR control
signals and extend them to devices connected to the other end of the
HDBaseT connection.
6USB 2.0 Ports (Type-A): Connect directly to a standard USB device
such as a mouse, keyboard, or ash drive to extend their USB
functionality to the currently active USB host port.
7AUDIO Button: Press this button to toggle the transmitter’s analog audio
out stream source between the receiver’s analog audio input (bypass)
and the USB-C input’s audio (extract).
Note: Audio extraction is only available with LPCM 2.0 sources. Pressing
this will also change the setting on compatible receivers.

4
8BYPASS & EXTRACT LEDs: These LEDs will illuminate to indicate if
the unit is in audio bypass (receiver’s analog audio input) or extract mode
(USB-C input).
9POWER LED: This LED will illuminate to indicate the unit is on and
receiving power.
10 LINK LED: This LED will illuminate solidly when a live connection with a
compatible receiver is active.
6.2 Rear Panel
DC24V 2.7A CAT6A/7 OUT
USB-C
1 2 3
1DC 24V Port: Plug the 24V DC power adapter into this port and connect
it to an AC wall outlet for power.
2CAT6A/7 OUT Port: Connect to a compatible HDBaseT receiver with a
single Cat.6A/7 cable for extension of all data signals. PoH will also be
supplied to a connected compatible PD receiver.
3USB-C Port: Connect directly to a USB-C video and audio source
such as a laptop, or tablet. USB functionality will also be extended to
all currently connected USB devices on both ends of the HDBaseT
connection.

5
6.3 IR Cable Pinouts
IR Blaster + IR Extender
1
2
3
4
RxD
3.3V
TxD
GND
4-pin
Terminal Block
6.4 Serial Pinout
1
2
3
4
GND
NC
TxD
RxD
4-pin
Terminal Block
6.5 Audio Pinouts
Stereo Audio Input Stereo Audio Output
1
2
3
GND
RIGHT
LEFT
3-pin Terminal Block
1
2
3
GND
RIGHT
LEFT
3-pin Terminal Block
