CZone Touch 10 GEN 2 Guide

Touch 10 Generation 2
User & Installation Manual
v1.0

EN / CZone Touch 10 Generation 2 User & Installation Manual
2
Copyright
This document is copyright 2020 under the Creative Commons agreement. Rights are granted to
research and reproduce elements of this document for non-commercial purposes on the condition that
CZone is credited as the source. Electronic re-distribution of the document in any format is restricted,
to maintain quality and version control.
Important
CZone strives to ensure all information is correct at the time of printing. However, the company
reserves the right to change without notice any features and specifications of either its products or
associated documentation.
Translations: In the event that there is a difference between a translation of this manual and the
English version, the English version should be considered the official version.
It is the owner’s sole responsibility to install and operate the device in a manner that will not cause
accidents, personal injury or property damage.

3
EN / CZone Touch 10 Generation 2 User & Installation Manual
Table of Contents
1GENERAL INFORMATION..............................................................................................................4
1.1 Use Of This Manual................................................................................................................. 4
1.2 Liability..................................................................................................................................... 4
1.3 Warranty.................................................................................................................................. 4
1.4 Identification Label................................................................................................................... 4
2OVERVIEW ......................................................................................................................................5
2.1 Description............................................................................................................................... 5
2.2 Features................................................................................................................................... 5
2.3 Overview.................................................................................................................................. 5
2.4 Supplied Parts ......................................................................................................................... 6
2.5 Network Configuration............................................................................................................. 7
2.6 System Example...................................................................................................................... 8
3INSTALLATION ...............................................................................................................................9
3.1 Things You Need..................................................................................................................... 9
3.2 Mounting Location ................................................................................................................... 9
3.3 Mounting Instructions ............................................................................................................ 10
3.4 Connections........................................................................................................................... 11
4OPERATION ................................................................................................................................. 12
4.1 First Power Up....................................................................................................................... 12
4.2 Updating Software................................................................................................................. 13
4.2.1 Checking Current Software Version.................................................................................. 13
4.2.2 Updating Software via USB Flash Drive............................................................................ 13
5SPECIFICATIONS ........................................................................................................................ 14
5.1 Technical Specifications........................................................................................................ 14
5.2 Dimensions............................................................................................................................ 15
6ORDERING INFORMATION......................................................................................................... 15
7EC DELCARATION OF CONFORMITY....................................................................................... 16
Table Of Figures
Figure 1. Touch 10 Front..........................................................................................................................5
Figure 2. Touch 10 Rear...........................................................................................................................6
Figure 3. Client Mode Wired Example......................................................................................................7
Figure 4. Mounting Exploded View........................................................................................................ 10
Figure 5. Connections ........................................................................................................................... 11

EN / CZone Touch 10 Generation 2 User & Installation Manual
4
1 General Information
1.1 Use Of This Manual
This manual serves as a guideline for the safe and effective operation of the following Touch 10
Generation 2 model:
Description
Part number
CZONE TOUCH 10 GEN 2
80-911-0216-00
1.2 Liability
CZone can accept no liability for:
•Consequential damage resulting from the use of the Touch 10.
•Possible errors in the included manual and the consequences of these.
•Use that is inconsistent with the purpose of the product.
Disclaimer: Our products are subject to continual development and improvement. Therefore,
additions or modifications to the products may cause changes to the technical data and functional
specifications. No rights can be derived from this document. Please consult our most current Terms &
Conditions of Sale.
1.3 Warranty
The CZone product warranty covers the Touch 10 for the first two years after the purchase date, on
the condition that the product is installed and used according to the instructions in this manual.
Installation or use that do not comply with these instructions may result in under performance, damage
or failure of the product and may void this warranty. The warranty is limited to the cost
of repair and/or replacement of the product. Costs of labor or shipping are not covered by this
warranty.
1.4 Identification Label
Important information required for service or maintenance can be
derived from the identification label. The identification label is
located on the back of the Touch 10.
CAUTION
Never remove the identification label. This will void the warranty.

5
EN / CZone Touch 10 Generation 2 User & Installation Manual
2 Overview
2.1 Description
CZone Touch 10 Generation 2 is the gateway to your CZone Digital Switching. The state of the art
CZone Touch 10 Generation 2 is a sleek attractive touch screen with glass dash styling that will
complement the interior of any high-end vessel or recreational vehicle. Touch 10 Generation 2, has a
powerful dual-core processer and easy to use, intuitive CZone 2.0 User Interface with customizable
favorites pages, simple controls and easy to follow menu structure. The high bright IPS LCD touch
screen panel offers the very latest generation capacitive touchscreen technology to ensure maximum
responsiveness. The CZone Touch 10 Generation 2 outperforms in sunlight, is viewable from any
angle, and features dimming capability for optimal night-time viewing. All of this packaged into a
splash-proof mounting system makes it suitable for any marine application.
2.2 Features
•10.1" display with modern, low profile glass design
•Optically bonded IPS LCD provides excellent viewing angles
•24 bit colour for better colour accuracy and contrast
•High resolution 1280 x 800 pixel for sharp and clear images
•550 nit brightness dimmable for night time viewing
•New dual core processor provides lightning fast performance
•Easy front mount installation and screwless rear access
•Wide 8-32V DC voltage range
•Consistent and familiar CZone 2.0 User Interface, customizable for any OEM
•Wireless Server for iPad control via wired Router connection
2.3 Overview
Figure 1. Touch 10 Front
Touch Screen

EN / CZone Touch 10 Generation 2 User & Installation Manual
6
Figure 2. Touch 10 Rear
2.4 Supplied Parts
1. Touch 10 Display
2. Metal Backing Frame
3. Plastic mounting bracket
4. Power Cable
5. Torx (T7) Screwdriver
6. Mounting Screws Short (x14)
7. Mounting Screws Long (x14)
8. Mounting Template
USB
Ethernet
GPIO
NMEA200
0
DC Power

7
EN / CZone Touch 10 Generation 2 User & Installation Manual
2.5 Network Configuration
The Touch 10 Gen 2 has an internal Wireless Server. When connected to a WiFi Router via the
Touch 10’s ethernet port, the CZone system can be controlled wirelessly from an iPad and favorites
packages can be sent to The Touch 10 wirelessly. The Client Mode configuration is detailed below:
Figure 3. Client Mode Wired Example

EN / CZone Touch 10 Generation 2 User & Installation Manual
8
2.6 System Example

9
EN / CZone Touch 10 Generation 2 User & Installation Manual
3 Installation
3.1 Things You Need
•Touch 10 Display
•Metal Backing Frame (supplied)
•Plastic Mounting Bracket (supplied)
•Power Cable (supplied)
•14 x Mounting Screws (supplied)
•Mounting Template (supplied)
•NMEA2000 drop cable and T-connector
•3A Fuse
•Screw driver and drill bits
•Electrical Tools
3.2 Mounting Location
When selecting a location for the Touch 10 Display it is important to consider the following factors:
•Ensure mounting wall thickness is 25mm or less (maximum supported by mounting bracket)
•Ensure mounting compartment is of suitable size with adequate airflow
•Ensure display is mounted in a location where it will not be subjected to excessive vibration
•Ensure display is mounted in a location where the operator can easily use controls and clearly
see the screen
•Ensure display is mounted in a location that allows proper routing, support and connection of
cables
•Ensure cables have adequate strain relief to prevent stress on connectors
•Select a location that is far enough away from devices that may cause interference, such as
motors, generators and radio transmitters/receivers.
•The display has a high-contrast screen, and is viewable in sunlight, but for best results install
the unit out of direct sunlight.
Warning! Inadequate ventilation may cause the unit to overheat. The unit is designed to
operate in temperatures from 0° C to +50° C.

EN / CZone Touch 10 Generation 2 User & Installation Manual
10
3.3 Mounting Instructions
Follow the below steps for mounting the Touch 10 to the chosen mounting surface
Figure 4. Mounting Exploded View
1. Place supplied cutout template on mounting wall using adhesive tape (note: maximum wall
thickness = 25mm)
2. Use a 10mm drill bit to cut four corner holes
3. Cut along dotted line and remove inner section
4. Remove the VHB tape liner from back of the plastic mounting bracket and take note of the
TOP and BOTTOM labels
5. Insert plastic mounting bracket in to mounting hole but do not stick to mounting wall yet
6. Hold metal backing frame behind mounting wall cutout and secure to bracket using the
supplied screwdriver and 14 screws (note: two screw sets are supplied. Use short screws for
walls 15mm or less and long screws for walls up to 25mm)
7. Once all screws are tightened, press bracket down firmly to ensure bracket bonds to wall with
the VHB tape
8. Insert Touch 10 into mounting bracket by hooking top of panel into bracket and pressing
bottom of display until it clips firmly in to place
9. To remove Touch 10 from bracket, carefully insert flathead screwdriver into slot at bottom of
display and twist until it unclips
Metal Backing
Frame
Mounting surface
Plastic Mounting Bracket
Mounting Screws
Display

11
EN / CZone Touch 10 Generation 2 User & Installation Manual
3.4 Connections
Warning! Before starting the installation, be sure to turn electrical power off. If power is left on
or turned on during the installation, fire, electrical shock, or other serious injury may occur. Be
sure that the voltage of the power supply is compatible with the unit.
Figure 5. Connections
1. Connect Ethernet to Router (Optional)
Run an ethernet cable from the Ethernet port on the Touch 10 to an ethernet port on the router, only if
the Touch 10 will be configured in Ethernet Mode for iPad connectivity.
2. Connect NMEA 2000 Network
Run NMEA2000 Drop cable from NMEA2000 port on Touch 10 to NMEA2000 backbone.
3. Connect DC Power Cable
The unit has a voltage rating 8 to 32V DC, hence it can be installed in either 12V or 24V systems.
1. Connect Red wire on DC Power Cable to Battery Positive (+) ensuring a 3 Amp fuse is
installed inline.
2. Connect Black wire on DC Power Cable to Battery Negative (-).
3. Plug the supplied power cable to the DC Power port on the Touch 10.
+
-
3A Fuse
BATTERY
2
1
3
To Network Router
(Optional)
To NMEA2000
Network

EN / CZone Touch 10 Generation 2 User & Installation Manual
12
4 Operation
4.1 First Power Up
If connecting Touch 10 to an existing CZone network, ensure the display has been added to the
CZone configuration and assigned a dipswitch. Every CZone device on a network requires a unique
dipswitch to operate correctly, and the Touch 10 has a virtual dipswitch. Refer to the CZone
Configuration Tool manual for this process.
1. Turn on the circuit breaker or switch supplying power to the Touch 10.
2. The CZone splash screen will appear for about 1 minute then the display will attempt to claim
a configuration from the network.
3. When configuration has been successfully claimed you will be prompted to enter the display
dipswitch. Select the dipswitch from the list of configured devices or set the dipswitch
manually by checking the correct boxes.
4. After dipswitch has been entered successfully the Control or Modes page (if configured) will
appear.
5. The Touch 10 is now ready for use.

13
EN / CZone Touch 10 Generation 2 User & Installation Manual
Note: Refer to CZone 2.0 User Interface Manual for detailed operation instructions.
4.2 Updating Software
To keep the Touch 10 up to date with the latest software refer to https://downloads.czone.net/. It is
recommended to update the entire CZone system when updating the Touch 10 to ensure the system
operates correctly. The Touch 10 can be updated via the USB port, see process below:
4.2.1 Checking Current Software Version
To check the current software version on the Touch 10, go to Settings > About.
The current software version is listed at the top of the page. To install a newer version, follow the
below steps
4.2.2 Updating Software via USB Flash Drive
1. Copy the Touch 10 Gen 2 firmware file (extension .swu, previously downloaded from the
CZone portal) on the root directory of a USB Flash Drive.
2. Insert the USB Flash Drive in the USB Port of the Touch 10.
3. Press the ‘Update Software’ button on the Settings > About page and press ‘Yes’ when
prompted.
4. The display will start installing the new software, this process may take a few minutes.
5. When complete the display will boot up to the main screen. Go to Settings > About to confirm
the new Software Version.

EN / CZone Touch 10 Generation 2 User & Installation Manual
14
5 Specifications
5.1 Technical Specifications
Model
CZone Touch 10 Generation 2
Article number
80-911-0216-00
Type
LCD IPS TFT (Optically Bonded)
Touch Screen
Projected Capacitive Multi-Touch
Glass
1.1mm
Brightness
550cd/m2
Resolution
1280 x 800 pixels, WXGA
Aspect Ratio
Widescreen (16:10)
Backlight
LED
Colour
24-bit RGB
CPU
iMX6, Dual Core
Memory
SDRAM 1GB, 8GB e.MMC
Peripherals
Battery-backed real time clock
Power Supply
8-32VDC
Power Consumption
1A @ 12V, 500mA @ 24V
Ingress Protection
IP66
Operating Temperature
0 to 50 degC
Storage Temperature
-30 to 80 degC
Interfaces
NMEA 2000, USB 2.0, 10/100Mbps Ethernet, GPIO
Weight
1.9kg (4lb 3oz)
Dimensions (H x W x D)
279mm x 200mm x 41mm (10⅞” x 7¾” x 1⅝”)
Certification
CE, NMEA

15
EN / CZone Touch 10 Generation 2 User & Installation Manual
5.2 Dimensions
6 Ordering Information
Touch 10 Generation 2 Part Numbers and Accessories
Part Number
Description
80-911-0216-00
CZONE TOUCH 10 GENERATION 2 KIT
80-911-0032-00
CZONE TOUCH 10 POWER CABLE 2m (6.5ft) (SPARE)
80-911-0114-00
CZONE TOUCH 10 MOUNTING BRACKET KIT (SPARE)
4mm [3/16"]
41mm [1 5/8"]
279mm [11"]
279mm [11"]
200mm [7 7/8"]
27mm [1 1/16"]

EN / CZone Touch 10 Generation 2 User & Installation Manual
16
7 EC DELCARATION OF CONFORMITY
