DèLonghi DSR 900-DF Operating instructions

1
DE’LONGHI
COOKING
USER & INSTALLATION INSTRUCTIONS
DSR 900-DF
DUAL FUEL COOKER
GB

2
CONTENTS
Page Number
Introduction............................................... 3
Important Safety & Recommendations ......................... 4-6
Cooking Hob ............................................. 7
Control Panel ............................................. 8
Use of the Hob Burners .................................... 9 - 10
Fan Oven ................................................11 - 12
Oven Temperature Guide ...................................13
120 Minutes Timer.........................................14
Cleaning & Maintenance ....................................15 - 20
Advice For The Installer ....................................21
Installation ...............................................22 - 26
Gas Installation ...........................................27 - 32
Electrical Installation .......................................33 - 34
Guarantee & After Sales Service .............................35

3
DECLARATION OF CE CONFORMITY
This cooker has been designed, constructed, and marketed in compliance with:
• Safety requirements of EU Directive “Gas” 2009/142/EC;
• Safety requirements of EU Directive “Low Voltage” 2006/95/EC;
• Protection requirements of EU Directive “EMC” 2004/108/EC;
• Requirements of EU Directive 93/68/EEC;
• Requirements of EU Directive 2011/65/EU. GB
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT
IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as
urban waste. It must be taken to a special local authority differentiated
waste collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving from
inappropriate disposal and enables the constituent materials to be
recoveredtoobtainsignicantsavingsinenergyandresources.Asa
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.
Dear Customer,
Thank you for purchasing the DeLonghi DSR 900-DF
dual fuel cooker.
The safety precautions and recommendations listed
below are for your own safety and that of others. They
will also provide a means by which to make full use of the
features offered by your appliance.
Please retain this booklet for future reference.
This appliance must be used only for the task it
has explicitly been designed for, that is for cooking
foodstuffs. Any other form of usage is to be considered
as inappropriate and therefore potentially dangerous.
The manufacturer declines all responsibility in the
event of damage caused by improper, incorrect or
illogical use of the appliance.

4
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS
IMPORTANT: This appliance is designed and manufactured
solely for the cooking of domestic (household) food and is
not suitable for any non domestic application and therefore
should not be used in a commercial environment.
The appliance guarantee will be void if the appliance is used
within a non domestic environment i.e. a semi commercial,
commercial or communal environment.
Read the instructions carefully before installing and using
the appliance.
• After having unpacked the appliance, check to ensure that it is not
damaged and that the oven door closes correctly.
In case of doubt, do not use it and consult your supplier or a
professionallyqualiedtechnician.
• Packing elements (i.e. plastic bags, polystyrene foam, nails, packing
straps, etc.) should not be left around within easy reach of children,
as these may cause serious injuries.
• Some appliances are supplied with a protective lm on steel and
aluminium parts. This lm must be removed before using the
appliance.
• IMPORTANT: The use of suitable protective clothing/gloves is
recommended when handling or cleaning of this appliance.
• Do not attempt to modify the technical characteristics of the appliance
as this may become dangerous to use. The manufacturer declines all
responsability for any inconvenience resulting from the inobservance
of this condition.
• CAUTION: this appIiance must only be installed in a permanently
ventilated room in compliance with the applicable regulations.
• Do not carry out cleaning or maintenance operations on the appliance
without having previously disconnected it from the electric power
supply.
• WARNING: Ensure that the appliance is switched off before replacing
the oven lamp to avoid the possibility of electric shock.
• Do not use a steam cleaner because the moisture can get into the
appliance thus make it unsafe.

5
• Do not touch the appliance with wet or damp hands (or feet).
• Do not use the appliance whilst in bare feet.
• If you should decide not to use this appliance any longer (or decide to
substitute another model), before disposing of it, it is recommended
that it be made inoperative in an appropriate manner in accordance to
health and environmental protection regulations, ensuring in particular
that all potentially hazardous parts be made harmless, especially in
relation to children who could play with unused appliances.
• The various components of the appliance are recyclable. Dispose of
them in accordance with the regulations in force in your country. If the
appliance is to be scrapped, remove the power cord.
• After use, ensure that the knobs are in the off position.
• Children less than 8 years of age shall be kept away unless
continuously supervised.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• The manufacturer declines all liability for injury to persons or damage
to property caused by incorrect or improper use of the appliance.
• WARNING: During use the appliance and its accessible parts become
hot; they remain hot for some time after use.
– Care should be taken to avoid touching heating elements (on the
hob and inside the oven).
– The door is hot, use the handle.
– To avoid burns and scalds, young children should be kept away.
• Make sure that electrical cables connecting other appliances in the
proximity of the cooker cannot come into contact with the hob or
become entrapped in the oven door.
• WARNING: Unattended cooking on a hob with fat or oil can be
dangerousandmayresultinre.NEVERtrytoextinguisharewith
water,butswitchoftheapplianceandthencoveramee.g.withalid
orareblanket.

6
• WARNING:Dangerofre:donotstoreitemsonthecookingsurfaces.
• WARNING: When correctly installed, your product meets all safety
requirements laid down for this type of product category. However
special care should be taken around the rear or the underneath of the
appliance as these areas are not designed or intended to be touched
and may contain sharp or rough edges, that may cause injury.
• FIRST USE OF THE OVEN - it is advised to follow these instructions:
– Furnish the interior of the oven as described at chapter “CLEANING
AND MAINTENANCE”.
– Switch on the empty oven on max to eliminate grease from the
heating elements.
– Disconnect the appliance from the electrical power supply, let the
oven cool down and clean the interior of the oven with a cloth
soaked in water and neutral detergent; then dry carefully.
• CAUTION: Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can scratch the
surface, which may result in shattering of the glass.
• Do not line the oven walls with aluminium foil. Do not place baking
trays or the drip tray on the base of the oven chamber.
• FIRERISK!Donotstoreammablematerialintheovenorinthe
storage compartment.
• Always use oven gloves when removing the shelves and food trays
from the oven whilst hot.
• Do not hang towels, dishcloths or other items on the appliance or its
handle–asthiscouldbearehazard.
• Clean the oven regularly and do not allow fat or oils to build up in the
oven base or tray. Remove spillages as soon as they occur.
• Do not stand on the cooker or on the open oven door.
• Always stand back from the appliance when opening the oven door
to allow steam and hot air to escape before removing the food.
• SAFE FOOD HANDLING: Leave food in the oven for as short a time
as possible before and after cooking. This is to avoid contamination
by organisms which may cause food poisoning. Take particular care
during warmer weather.
• WARNING: Taking care NOT to lift the cooker by the door handle.

7
GAS BURNERS
1. Auxiliary burner (A) 1,00 kW
2. Semi-rapid burner (SR) 1,75 kW
3. Rapid burner (R) 3,00 kW
4. Triple-ring burner (TR) 3,50 kW
1 - COOKING HOB
Notes:
• The electric ignition is incorporated in the knobs.
• Theappliancehasasafetyvalvesystemtted,theowofgaswillbestoppedifand
whentheameshouldaccidentallygoout.
Fig. 1.1
1
4
3
2 2

8
Fig. 2.1
CONTROL PANEL - Controls description
1. Front right burner control knob
2. Rear right burner control knob
3. Central burner control knob
4. Rear left burner control knob
5. Front left burner control knob
6. Fan oven thermostat knob
7. Fan oven switch knob
8. 120 minutes timer control knob
9. Fan oven temperature indicator light
2 - CONTROL PANEL
12345
678
9
Please note: This appliance incorporates a safety cooling fan which you will hear operating
whenever the oven or grill is being used.
The cooling fan may even run on after the appliance has been switched off.
The duration of this time is dependent on several factors, including previous cooking
temperature, duration and ambient temperature. Times in excess of 30 minutes are not on
common.

9
3 - USE OF THE HOB BURNERS
Caution!
The cooking hob becomes very hot
during operation.
Keep children well out of reach.
N.B. When the cooker is not being
used, set the gas knobs to their closed
positions.
GAS BURNERS
Gas ow to the burners is adjusted by
turning the knobs (illustrated in g. 3.1)
which control the safety valves.
Turning the knob, so that the indicator line
points to the symbols printed on the panel,
achieves the following functions:
- symbol 0closed valve
- symbol maximum
apertureorow
- symbol minimum
apertureorow
√The maximum aperture position
permits rapid boiling of liquids, whereas
the minimum aperture position allows
slower warming of food or maintaining
boiling conditions of liquids.
√ To reduce the gas ow to minimum
rotate the knob further anti-clockwise
to point the indicator towards the small
amesymbol.
√Other intermediate operating
adjustments can be achieved by
positioning the indicator between the
maximum and minimum aperture
positions, and never between the
maximum aperture and closed
positions.
0
Fig. 3.2
Fig. 3.1

10
DEEP FAT FRYING
For safety purposes when deep fat frying,
donotllthepanmorethanonethirdfull
of oil.
DO NOT cover the pan with a lid and DO
NOT leave the pan unattended.
In the unfortunate event of a re, leave
the pan where it is and turn off the control
knobs.
Place a damp cloth or lid over the pan to
smothertheames.Leavethepantocool
for at least 30minutes before moving the
pan.
DO NOT USE WATER ON THE FIRE.
CHOICE OF THE BURNER
On the control panel, near every knob
there is a diagram that indicates which
burner is controlled by that knob.
The suitable burner must be chosen
according to the diameter and the capacity
used.
As an indication, the burners and the pots
must be used in the following way:
DIAMETERS OF PANS WHICH MAY BE
USED ON THE BURNERS
BURNERS MINIMUM MAXIMUM
Auxiliary 12 cm 14 cm
Semi-rapid 16 cm 24 cm
Rapid 24 cm 26 cm
Triple-ring 26 cm 28 cm
do not use pans with concave or convex
bases
Fig. 3.3
It is important that the diameter of the pot
be suitable to the potentiality of the burner
so as not to compromise the high output
of the burners and therefore energy waste.
A small pot on a large burner does not give
you a boiling point in a shorter amount of
time since the capacity of heat absorption
of a liquid mass depends on the volume
and the surface of the pot.
LIGHTING THE BURNERS
To ignite the burner, the following
instructions are to be followed:
1. Press in the corresponding knob and
turncounter-clockwise(g.3.2)tothe
fullamepositionmarkedbythe
symbol(g.3.1);hold the knob in until
theamehas been lit.
In the case of a mains failure light the
burner with a match or lighted taper.
2. Wait for a few seconds after the gas
burner has been lit before letting
go of
the knob (valve activation delay).
3. Adjust the gas valve to the desired
position.
Iftheburnerameshouldgooutforsome
reason, the safety valve will automatically
stopthegasow.
To re-light the burner, return the knob to
the closed 0position, wait for at least
1 minute and then repeat the lighting
procedure.
If your local gas supply makes it difcult
to light the burner with the knob set to
maximum, set the knob to minimum and
repeat the operation.

11
OPERATING PRINCIPLES
Heating and cooking in the FAN oven are
obtained in the following ways:
a. by forced convection
A fan draws in the air contained in
the oven, which circulates it through
the circular heating element and then
forced back into the oven by the fan.
Before the hot air is drawn back
again by the fan to repeat the cycle,
it envelops the food in the oven,
provoking a complete and rapid
cooking. It is possible to cook several
dishes simultaneously.
b. by radiation
The heat is radiated by the infra red
grill element.
c. by ventilation
The food is defrosted by using the fan
only function without heat.
GENERAL FEATURES
With your new Fan oven it is possible to
cook a variety of food using the 2 different
cooking functions.
The 2 positions, thermostatically controlled,
are obtained by 2 heating elements.
• Grill element 2200 W
• Circular element 2500 W
NOTE:
Upon first use, it is advisable to operate
the oven at the maximum temperature
(thermostat knob on position 250) for 60
minutes in the position
and for another
15 minutes in the mode in order to
eliminate any traces of grease from the
electrical resistances.
WARNING:
The door is hot, use the handle.
ATTENTION - MOST IMPORTANT
Pay special attention not to touch the hot
heating element inside the oven cavity.
Attention: the oven door becomes
very hot during operation.
Keep children away.
4 - FAN OVEN
Smells and fumes produced during this
burn off process are not a cause of alarm.
Adequate ventilation should however be
provided in the room where the appliance
is installed, e.g. by opening a window.
Before introducing the food, preheat the
oven to the desired temperature.
For a correct preheating operation, it is
advisable to remove the tray from the oven
and introduce it together with the food,
when the oven has reached the desired
temperature.
Check the cooking time and turn off the
oven 5 minutes before the theoretical time
to recuperate the stored heat.
Fig. 4.1 Fig. 4.2

12
OVEN LIGHT
By setting the knob to this position, only the oven light comes on.
The light remains on whilst any of the cooking modes are selected.
DEFROSTING FROZEN FOODS
Only the oven fan is on. To be used with the thermostat knob on “0” because the other
positions have no effect. The defrosting is done by simple ventilation without heat.
Recommended for:
To defrost frozen foods.
The defrosting times vary according to the quantity and type of foods to be defrosted.
HOT AIR COOKING
The circular element and the fan are on. The heat is diffused by forced convection and the
temperature must be regulated between 50°C and 250 °C with the thermostat knob.
It is not necessary to preheat the oven.
Cooking temperature may be reduced for fan assisted ovens, see “OVEN TEMPERATURE
GUIDE”.
Recommended for:
For foods that must be well done on the outside and tender or rare on the inside, i. e.
lasagna,lamb,roastbeef,wholesh,etc.
GRILLING
The infra-red heating element is switched on. The heat is diffused by radiation.
Use with the oven door closed and the thermostat knob to between 50°C and 225°C .
Preheat the oven for about 5 minutes.
Introduce the food to be cooked, positioning the rack as close to the grill as possible.
The dripping pan should be placed under the rack to catch the cooking juices and fats.
Use with the oven door closed.
Note: It is recommended that you do not grill for longer than 30 minutes at any one time.
Attention: The oven door becomes very hot during operation. Keep children away.
Recommended for:
Intense grilling action for browning, crisping, “au gratin”, toasting, etc.
FUNCTION SELECTOR KNOB (g.4.1)
Rotate the knob clockwise to set the oven for one of the following functions:
TEMPERATURE KNOB (g.4.2)
Toturnontheheatingelementsoftheoven,setrstthefunctionselectortotherequired
setting and then the thermostat knob to the desired temperature.
To set the temperature, line up the temperature knob indicator with the required
temperature.
The elements will turn ON or OFF automatically according to the energy need which is
determined by the thermostat.
The operation of the heating elements is signalled by a light placed on the control panel.

13
NOTE: Reduce the oven temperature by 10 – 20°C for fan assisted ovens.
For dishes that take over an hour to cook, reduce the cooking time by 10 minutes per
hour.
5 - OVEN TEMPERATURE GUIDE
Cooking process Oven heat Gas mark
Electric oven temperature
°C °F
Keeping food hot,
milk puddings very cool ½120 250
Egg custards cool 1 140 275
Rich fruit cakes,
braising cool 2 150 300
Low temperature
roasting, shortbread moderate 3 160 325
Victoria sandwich,
plain fruit cake,
bakedsh
moderate 4 180 350
Small cakes, choux
pastry fairly hot 5 190 375
Short pastry, Swiss
rolls,soufés fairly hot 6 200 400
High temperature
roasting,aky
pastry, scones
hot 7 220 425
Puff pastry, bread very hot 8 230 450
Small puff pastries,
browning cooked
foods
very hot 9 240 475
These temperatures relate to the centre oven temperature.
Remember to use ovenproof dishes and to adjust the oven temperature during cooking if
necessary.

14
120 MINUTE TIMER (Fig. 6.1)
The timer can be set to a maximum of 120
minutes and a buzzer will sound at the end
of the countdown.
The knob must be rotated clockwise as
far as the 120 minute position rst and
then set to the required time by rotating it
anticlockwise.
IMPORTANT WARNING: This is only a
mechanical timer.
Remember to turn off the oven/grill
manually.
6 - 120 MINUTE TIMER
Fig. 6.1

15
7 - CLEANING AND MAINTENANCE
GENERAL ADVICE
• Before you begin cleaning, you
must ensure that the appliance is
switched off at the cooker switch.
• The periodical lubrication of the gas
taps must be done only by specialized
personnel.
• If a tap becomes stiff, do not force;
contact your local After Sales Service
Centre.
• It is advisable to clean when the
appliance is cold and especially when
cleaning the enamelled parts.
• Avoid leaving alkaline or acidic
substances (lemon juice, vinegar, etc.)
on the surfaces.
• Avoid using cleaning products with
a chlorine or acidic base.
• Important: The use of suitable
protective clothing/gloves is
recommended when handling or
cleaning this appliance.
• Under no circumstances should
any external covers be removed for
servicing or maintenance except by
suitablequaliedpersonnel.
WARNING:
When correctly installed, your product
meets all safety requirements laid down
for this type of product category.
However special care should be taken
around the rear or the underneath of
the appliance as these areas are not
designed or intended to be touched and
may contain sharp or rough edges, that
may cause injury.
CLEANING
• Stainless steel hob: Spillage on
the hob can usually be removed by
a damp soapy cloth. More obstinate
stains can be removed by using a
proprietary stainless steel cleaning
product that does not contain chlorine
or acidic base.
• Control panel facia: Clean very
carefully with water and neutral soap;
the cloth used must be rinsed well and
must be free of any cleaning chemicals
to avoid damaging any screen print on
the facia.
• Door, glass & painted surfaces:
Clean very carefully with water and
neutral soap; the cloth used must be
rinsed well and must be free of any
cleaning chemicals.
• Pan stands & burner caps: Clean
with a sponge and soapy water or
proprietary cream cleaner. Alway
dry throughly. DO NOT PUT IN THE
DISHWASHER.
• Burner bodies (aluminium alloy):
They should be cleaned with soapy
water and a clean cloth. For stubborn
stains a proprietary cream or stainless
steel cleaner may be used; however
to maintain an uniform nish we
would recommend the whole area is
cleaned. NOTE: Please ensure the
slots/castlellations are kept free of the
any material/cleaner.
Attention!
The appliance gets very hot, mainly around the cooking areas. It is very important
that children are not left alone in the kitchen when you are cooking.
Do not use a steam cleaner because the moisture can get into the appliance thus
make it unsafe.
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door
glass since they can scratch the surface, which may result in shattering of the
glass.

16
• Inside of oven: The oven should
always be cleaned after use when it
has cooled down. The cavity should be
cleaned using a mild detergent solution
and warm water. Suitable proprietary
chemical cleaners may be used only
on enamel after rst consulting the
instructions supplied with the oven
cleaner and testing a small sample
on the oven cavity. Abrasive cleaning
agents or scouring pads/cloths should
not be used on the cavity surface.
NOTE: The manufacturers of this
appliance will accept no responsibility
for damage caused by chemical or
abrasive cleaning.
Let the oven cool down and pay
special attention not to touch the
hot heating elements inside the
oven cavity.
REPLACING THE OVEN LIGHT BULB
Switch the cooker off at the mains.
When the cooker is cool unscrew and
replace the bulb with another one resistant
to high temperatures (300°C), voltage
230V, 50 Hz, type E14 and same power
(check watt power as stamped in the bulb
itself) of the replaced bulb.
Note: Oven bulb replacement is not
covered by your guarantee.
CORRECT REPLACEMENT OF THE
AUXILIARY, SEMI-RAPID AND RAPID
BURNERS
It is very important to check that the burner
amedistributor“F” and the cap “C” have
been correctly positioned (see gs. 7.1,
7.2) - failure to do so can cause serious
problems.
CORRECT REPLACEMENT OF THE
TRIPLE RING BURNER
The triple ring burner must be correctly
positioned (see g. 7.5); the burner rib
must be enter in their logement as shown
bythearrow(seeg.7.3).
Then position the cap “A” and the ring “B”
(gs.7.4,7.5).
The burner correctly positioned must not
rotate(g.7.4).
BURNERS AND PAN SUPPORTS
These parts can be removed and cleaned
as indicated previously.
Aftercleaning,theburnersandtheirame
spreaders must be well dried and correctly
replaced.
It is very important to check that the burner
ame spreader and the cap have been
correctly positioned. Failure to do so can
cause serious problems.
Check that the electrode “S” (gs. 7.1,
7.3) next to each burner is always clean to
ensure trouble-free sparking.
Check that the probe “T”(gs.7.1,7.3)next
to each burner is always clean to ensure
correct operation of the safety valves.
Both the probe and ignition plug must
be very carefully cleaned.
Note: To avoid damage to the electric
ignition do not use it when the burners
are not in place.

17
S
F
C
T
Fig. 7.1 Fig. 7.2
A
B
S
T
Fig. 7.3
Fig. 7.4 Fig. 7.5

18
ASSEMBLY AND DISMANTLING OF
THE SIDE RUNNER FRAMES
• Fit the side runner frames into the
holes on the side walls inside the oven
(Fig. 7.6).
• Slide the rack into the runners (Fig.
7.7).
 The rack must be tted so that the
safety notch, which stops it sliding out,
faces the inside of the oven; the guard
rail shall be at the back.
• To dismantle, operate in reverse order.
OVEN TRAY
The oven tray must be correctly placed on
its wire support then inserted into the side
runners(gs.7.7,7.8).
OVEN FLOOR
Theovenoor“F”(g.7.8)canbeeasily
removed to facilitate cleaning.
Remember to replace the oor correctly
afterwards.
Be careful not to confuse the tray “L” with
theovenoor“F”(g.7.8).
Fig. 7.7
Fig. 7.6
L
F
Fig. 7.8
Guard rail
Stop notch
Stop notch

19
OVEN DOORS
The internal glass panel can be easily
removed for cleaning by unscrewing the
retainingscrews(g.7.9).
Donotstoreammablematerialinthe
oven or in the storage compartment.
Do not use harsh abrasive cleaners or
sharp metal scrapers to clean the oven
door glass since they can scratch the
surface, which may result in shattering
of the glass.
STORAGE COMPARTMENT
The storage compartment is accessible
throughthepivotingpanel(g.7.10).
Fig. 7.10
Fig. 7.9

20
REMOVING THE OVEN DOOR
The oven door can easily be removed as
follows:
• Open the door to the full extent (g.
7.11a).
• Open the lever “A” completely on the
leftandrighthinges(g.7.11b).
• Holdthedoorasshowning.7.11.
• Gentlyclosethedoor(g.7.11c)until
left and right hinge levers “A” are
hooked to part “B” of the door (g.
7.11b).
• Withdraw the hinge hooks from their
location following arrow “C”(g.7.11d).
• Rest the door on a soft surface.
• To replace the door, repeat the above
steps in reverse order.
B
A
C
Fig. 7.11c
Fig. 7.11b
Fig. 7.11a
Fig. 7.11d
Fig. 7.11
