USER MANUAL
REMOTE CONTROL
RHR-CFULL
Serie
HEAT RECOVERY FRESHOME RHR
Edition
03/21
Models
RHR 150
RHR 200

DAITSU RHR-CFULL WIRELESS CONTROL
The Daitsu RHR-CFULL wireless control is a user and insta-
llation interface for monitoring and configuring the connec-
ted heat recovery unit.
• This unit allows the quality of the indoor air to be con-
trolled by varying the fan speed.
• The device uses a wireless connection (RF) to commu-
nicate with the central unit (heat recovery unit).
SPECIFICATIONS
AOK button
BBack button
C+ / Up button
D- / Down button
EMenu button
Binding the ventilation unit (VU)
and the wireless multi-control unit
1. Press the MENU button for 10 seconds until the configuration
menu icon appears .
2. If the unit is not bound, by pressing the MENU button again, the
binding icon will appear . Then press the OK button.
3. The icon starts to flash when searching for the VU.
a. If it is bound correctly, the screen shows BND.
b. If it is not bound correctly, the screen shows NO BND.
4. If necessary, you can exit by tapping the BACK button to return to
the configuration menu, or to go back to the home screen.
IMPORTANT: the VU will be visible for binding for 10 minutes after
it is connected to the power supply. If the binding has not occurred
in 10 minutes, the VU must be restarted by disconnecting it from
the power supply and reconnecting it so that it is available again for
binding for 10 minutes.
Selecting the mode and the ventilation speed
From the home screen, the ventilation speed can be changed immedi-
ately by pressing the + and – buttons.
Speed High At home Low Absence
Icon
AUTO AUTO AUTO AUTO
Once high speed is reached, if you press the + button, the AUTO in-
dication lights up, showing that you are in automatic speed selection
mode (regulated by probes or timing).
If the AUTO indication does not appear, you are in manual speed
selection mode.
By pressing the + button again, you will enter the timer mode. An in-
dication icon will appear on the screen in the form of an hourglass .
Icons on the LCD screen
ATimer mode.
BMaximum mode.
CAbsence mode.
DChange filter / Reset filter.
EFan speed.
It can be seen in one of these 4 icons:
Speed High At home Low Absence
Icon
AUTO AUTO AUTO AUTO
FAUTO mode of the ventilation unit.
When AUTO is not shown, the fan speed is in MANUAL mode.
GDisplay of 4-digit real value.
HDisplay of 2-digit real value.
IFault indicator (it can be combined with other icons).
JConfiguration mode.
KLink mode.
LTime setting menu.
M“On” program enabled / “Off” program disabled.
NProgramming activation periods.
ODays of the week.
PBypass indicator.
If you are not on the default screen, tap the BACK button.
 AUTOMATIC MODE
 ABSENCE MODE
To start ABSENCE mode, tap the UP button or DOWN button over
and over until the icon lights up.
To start AUTO mode, tap the UP button or the DOWN button over
and over until the AUTO icon lights up.
 MANUAL MODE
When in AUTO mode, use the UP button or the DOWN button to
stop AUTO mode. Tap the UP or DOWN button over and over to select
the correct speed of the ventilation unit.
 MAXIMUM MODE
To start MAXIMUM mode, tap the UP button or the DOWN button
over and over until the icon lights up.
 TIMER MODE
To start TIMER mode, tap the UP button or the DOWN button over
and over until the icon lights up.
A B C
K
J
I
HG
F
E
D
L M
N
O
P

Reset dirty filter message
If the icon appears on the screen, it means that the unit’s ventilation
filters are dirty.
1. Tap the MENU button.
2. Tap the MENU button over and over to scroll through the menus
on the screen.
3. Stop when the FILTER RESET icon flashes.
4. Tap the ACCEPT button to reset the filter mode.
5. Tap the BACK button to exit the menu.
Tip
To ensure good filtering efficiency, clean the filters at least every 6 months
and replace them every year.
Date/time configuration menu
1. Tap the menu icon over and over until DATE AND TIME .
2. Tap the ACCEPT button to enter the DATE AND TIME menu.
3. Tap the UP button or the DOWN button to configure the year.
Tap ACCEPT to go to the next screen.
4. Tap the UP button or the DOWN button to configure the
month. Tap ACCEPT to go to the next screen.
5. Tap the UP button or the DOWN button to set the day of the
month. Tap ACCEPT to go to the next screen.
6. Tap the UP button or the DOWN button to configure the time.
7. Tap ACCEPT to store the DATE AND TIME settings. Tap the
BACK button to return to the default screen without changing
the DATE AND TIME.
Time setting menu
NOTE:
Time programming is only possible on the Daitsu RHR-CFULL
control version 8 (v.8) or later.
1. Tap the menu button over and over until the menu icon appears.
2. Touch the accept button to enter the time programming menu.
3. Tap the menu button over and over until the different time pro-
gramming functions appear.
time programming functions
ICON FUNCTION
ON program enabled / OFF program disabled.
Programming configuration
Programming activation periods
4. Tap the accept button to select the required function.
enable and disable the time programming
5. Once in the function icon, press the accept button.
6. The up button or the down button displays the current status.
ON: Time programming activated | OFF: Time programming
deactivated. To select the activated status ON or the deactivated
status OFF.
7. Tap the accept button to confirm the required status. To return to
the default screen, tap the back button.
time programming selection
8. Tap the function icon once. Tap the accept button.
9. Tap the menu button once and the screen will display the
icon. Tap the accept button and the screen will display different
types of time programming.
TIME PROGRAM TYPES
1The same time program for all days of the week from Mon-
day to Sunday.
1 6 A time program from Monday to Friday and another one
for the weekend.
1 2 3 4 5 6 7 A different program for every day of the week.
10. With the up button or the down button, select the type of
program to be used.
Tap the accept button to confirm the required program and the
number of periods to be programmed will flash.
11. Tap the or button to select the number of periods to be
programmed.
2 periods 3 periods 4 periods 5 periods 6 periods
12. Tap the accept button to confirm the required number of periods.
13. Tap the menu button twice until the icon.
14. From the icon function, press the accept button until the
icon.
15. Press the button twice and the screen will display the icon.
16. Press the accept button and the screen will display the
AUTO
speed icon.
17. The first period number will flash and the screen will display the
time to be programmed for that period.
18. Press the accept button and the time to be programmed for
that period will flash.
19. Use the or buttons to enter the time for that period.
20. Press the accept button and the
AUTO
speed icon will flash.
21. Use the or buttons to enter the required speed.
Speed 3 Speed 2 Speed 1 Speed 0
Icon
AUTO AUTO AUTO AUTO
22. By pressing the accept button, the period number to be pro-
grammed will flash again.
23. Use the or buttons to enter the next period and so on for the
periods requested in the required periods step.
24. To finish, press the back button twice to return to the home
screen.
BYPASS display
The bypass installed as standard can blow fresh air in directly from
outside, without it passing through the exchanger, allowing the
pleasant temperature that may exist outside at certain times to be
taken advantage of, such as summer nights, when it is desirable for
fresh air to enter from outside in order to refresh the inside of the home
(free cooling).
AUTO
AUTO
Bypass open in AUTO mode
Bypass open
Bypass closed in AUTO mode
Bypass closed
SI
UNA
Cmi
rc
AUTO
