DAB DAB-PC1 User manual

An instruction manual
Model:DAB-PC1

Product Specification：
1. The unit is with both DAB/DAB+ and FM receiver
2. Stereo output
3. With the latest wireless Bluetooth 5.0 technology, it can easily connect with Bluetooth
devices such as iPhone, iPad, smart phone, and enjoy high-quality music at any time
4. Using high-end DAB chip to receive more and more sensitive digital signals
5. DAB program picture display
6. 2.4-inch LCD display, 320x240 points,highlighting clearer text and picture display effect
7. Screen saver and screen brightness adjustment
8. Multiple time display effect and time setting selection
9. Dual alarm setting function
10. Nine countries Language choice
11. High sensitivity FM and dab radio
12. Built in 1200 Ma polymer rechargeable battery
13. Fashionable and portable, suitable for home, office, outdoor travel, sports, leisure,
entertainment, learning, etc
function definition：
Power/Mode：Press and hold the mode key to turn on, and long press mode to Clock
mode ,long press again to turn off.
v:Short press to enter the station list in Dab play mode .Short press the next frequency
point in FM mode.
OK: enter
^:Short press to enter the station list in Dab play mode .Short press the previous
frequency point in FM mode.
Vol+:Short press Vol+ enter Program view，long press Volume up.
Vol- :Short press Vol- enter setting program,long press Volume down.
Dc-in:power jack and charge jack.
C:3.5mm Stereo Headphone Output
Short press Vol- enter setting view in all mode:

Scan Setting: Enter the signal priority selection interface, press the volume - or wait for
10 seconds to return to the setting interface and playback interface automatically.
Backlight: Enter the screen saver and screen brightness adjustment, short press the
volume - or wait for 10 seconds to return to the setting and playing interface
automatically.
Time/Date:Enter the time and date adjustment and display effect setting, press the
volume - or wait for 10 seconds to return to the setting and playing interface
automatically.
Alarms setting: Alarms1，Alarms2，setting, press the volume - or wait for 10 seconds
to return to the setting and playing interface automatically.
Sleep setting: setting sleep time,After completion press the volume - or wait for 10
seconds to return to the setting and playing interface automatically.
EQ: 8 kinds of audio playback effect selection. After completion press the volume - or
wait for 10 seconds to return to the setting and playing interface automatically.
Language:9 countries language display selection , press the volume - or wait for 10
seconds to return to the setting interface and playback interface automatically.
Factory Reset: Factory reset setting.press the volume - or wait for 10 seconds to return
to the setting interface and playback interface automatically.
System Version: View system version number
DAB operation：
After turning on the power switch of the machine, select DAB icon OK key to enter.
Long press OK key to search stations, and then press volume - enter settings: station list to
enter station search list, preset recall to call up DAB favorite radio stations, preset store to
save DAB favorite stations, scan to search stations, manual tune to manually search DAB
radio stations, short press volume - or wait 10 seconds to return to the playback interface.
FM operation：
After entering FM playing mode, press (^ key) to manually search backward channels,
short press (^ key) to press OK key for semi-automatic backward channel search, short
press (V key) to manually search forward channel, short press (V key) to press OK key
to semi-automatic forward channel search, and short press volume - enter setting:
preset recall to tune out FM favorite radio station Store to save FM favorite stations,
short press volume - or wait 10 seconds to return to the playback interface.

Bluetooth link operation:
Select the Bluetooth icon OK key to enter, open the Bluetooth function of the mobile
phone, search the Bluetooth name, and click the pairing success.
Specification:
Bluetooth version: 5.0
Output power:4Ω 1W
frequency response: 20HZ-2KHZ
distance of Bluetooth: 8m
Power input: Micro usb 5v 1A
Continuous playback time: about 8H with dab Mode
Charge time: about 4h
FM Frequency range 87.5-108MHz
DAB Frequency range: 170-240MHz
DAB Receiver sensitivity: -99dbm
2.4 寸TFT LCD: 320*240 dot
Built in 1200ma 3.7V lithium battery
Temperature: 0 ℃~45℃
Storage temperature: -20℃-70℃
Packing list:
dab receiver :1pcs
USB line: 1 pcs
Unit user guide :1 pcs
Common troubleshooting:
A. No power on: Please connect to external power supply or battery low power. Please
charge.
B. No signal : Adjust antenna direction or move outdoors or signal very poor.
C. No sound : Plug in the headphones or vol adjust too min
Product Maintenance
Don’t expose the unit to the liquid, humid or moist area as the set is not water proof.
Don’t attempt to clean this unit with chemical solvents as this might damage the
finish.
Avoid extremes of temperature either hot or cold, recharge under normal
temperature.

Don’t touch sharp objects, which will cause scratches or damage
Don’t attempt to insert any object into the body to avoid damage the internal parts.
Don’t attempt to disassemble the unit for there is not any serviceable parts inside.
If long time no use, be sure to play the unit in a dry area, avoid in a temperature
changes and dusty place.
Please save after rechargeable fully when unused for a long time (one-two month),
to avoid completely discharge normally which lead to open improperly or not
rechargeable.
