Dacor PGM Series User manual

The life of the kitchen TM
Use & Care
PGM Cooktops
D
SAFETY IS EVERYONE'S RESPONSIBILITY. ALL DACOR APPLIANCES ARE DESIGNED
AND CONSTRUCTED TO GIVE YOU MANY YEARS OF SAFE OPERATION. THE
OPERATION WILL BE FURTHER ENHANCED IF PROPER CARE AND JUDGEMENT ARE
EXERCISED IN THE USE AND MAINTENANCE OF THIS APPLIANCE.
please p,ead
IMPORTANT INFORMATION
•Operating Instructions
•Care and Cleaning Instructions
•Safety Tips
WARNINGS:
Must be followed carefully to avoid personal injury or damage. !_toP
NOTES: "1'OUr COO
Contains helpful hints and tips. e, _Using
and save ore
Place Serial Number Label Here
Pad No. 65484 RevA

Dear DACOR Consumer,
Congratulations! You have purchased the very latest in kitchen appliances. Your new DACOR product offers features,
styling and performance not found in any other appliance.
Please read this manual before operating your new appliance. It is imperative that you read the IMPORTANT
INSTRUCTIONS section and become familiar with the controls and procedures to understand the full potential of this
product.
All DACOR appliances are designed and manufactured to meet the highest quality standards. Each unit is thoroughly
tested. Should you have a problem, however, please first check the PROBLEM SOLVING section in this manual. This
section contains a checklist of possible problems and solutions that may save you the time and expense of an
unnecessary service call.
If you cannot readily find the solution to the problem, please contact your nearest DACOR Authorized Service
Representative. In the unlikely event they are unable to solve your problem to your satisfaction, please contact
DACOR Customer Service.
Web site: www.dacor.com
Phone: [phone]
Fax: [phone]
Business Hours: 7:30 A.M to 4:00 RM. Pacific Time
DACOR Customer Service
1440 Bridge Gate Dr,
Diamond Bar, CA 91765
Thank you for selecting DACOR for your home. We are dedicated to you and ensure that this appliance in your home
will bring years of outstanding performance for your family and friends.
Sincerely,
Chairman/CEO

TABLE OF CONTENTS .................................... 1
Purpose of this Manual ................................ 1
Product Registration .................................... 1
IMPORTANT INSTRUCTIONS ......................... 2
What To Do .................................................. 2
What Not To Do............................................ 2
COOKTOP FEATURES ................................. 3-4
Burner Configuration .................................... 3
Sealed Burners ............................................ 3
Smart-Flame TM ............................................. 3
Burner Igniters and Perma-FIame TM ......... 3-4
Knobs and Spill Protector Rings .................. 4
COOKTOP OPERATION .................................. 5
Selecting the Proper Cookware ................... 5
Before Cooking ............................................ 5
Operating the Control Valves ....................... 5
Setting the Burner Flame Heights ................ 5
Using Simmer Plate ..................................... 5
Energy Saving Tips ...................................... 5
Accessories .................................................. 5
CARE AND CLEANING .................................... 5
Cleaning Tips ............................................... 5
Stainless Steel Surfaces .............................. 5
Porcelain Surfaces ....................................... 5
Knobs and Knob Bezels ............................... 5
Burner Bases ............................................... 5
Burner Rings ................................................ 5
Burner Igniters ............................................. 5
PROBLEM SOLVING ........................................ 5
Troubleshooting ........................................... 5
Product Maintenance ................................... 6
If You Need Service ..................................... 6
PRODUCT WARRANTY ................................... 6
What Is Covered .......................................... 6
What Is Not Covered .................................... 6
ILPurpose of This Manual Jl
This Use & Care Manual is designed to enable
you to properly operate and maintain your new
cooktop. Please keep this manual handy for
easy access and quick reference.
Additional information may be requested by
e-mailing, writing or phoning the DACOR
Customer Service Department. The address
and phone number of this department are listed
on the inside front cover of this manual.
IkProductReg,stra.on 1
What to Do
1. Begin by ensuring proper installation and
grounding of the appliance by a qualified
technician according to the accompanying
Installation Instructions. Have the installer
show you where the fuse or junction box is
located so that you know how and where
to turn off power. Also, have the installer
show you the location of the gas supply.
If you smell gas, do not use the cooktop.
Immediately turn off the gas supply at the
shut off valve, disconnect electrical power
to the unit at the fuse or junction box
and contact the gas supplier or qualified
appliance technician.
2. Ensure that the cooktop is used only by
those individuals who are able to operate it
properly.
3. Use the cooktop only for cooking tasks
expected of a home appliance as outlined
in this manual.
4. Properly clean and maintain as
recommended in this manual, cleaning only
the parts listed.
5. Use only dry potholders to avoid steam
burns when removing hot cookware.
6. In the event that a burner flame goes out
and gas escapes, open a window or door.
Wait at least 5 minutes before attempting to
use the cooktop.
7. Select utensils of the proper size, material
and construction for the particular type of
cooking being done. Select utensils that
are large enough to contain food without
boil-overs or spill-overs. Choose pans with
easily grasped handles that will stay coot
while cooking. Do not use utensils with
loose handles. Avoid using pans that are
too heavy to lift safely. Use cookware only
for its intended purpose. Certain types of
glass, ceramic, and earthenware utensils
are suitable for use only in an oven and not
in cooktop applications.
8. When cooking, set the burner controls so
that the flame heats only the bottom of the
utensil and does not lick at the sides of the
utensil.
9. When deep fat frying, be certain that the
pan is large enough to contain the desired
volume of food without overflow caused by
bubbling of the fat. Never leave a deep fat
fryer unattended. Avoid deep fat frying of
moist or frost-covered foods. Foods with
high water content may cause spattering or
spilling of the hot fat. Heat fat slowly and
stir together any combinations of oils and
fats prior to applying heat. Utilize a deep
fat frying thermometer to avoid heating the
fat to temperatures above the flash point.
10. Always turn pan handles to the side or
back of the cooktop. Do not turn handles
towards the room where they are easily hit.
Handles should not extend over adjacent
burners.
11. Always check the positions of the control
knobs to make sure the cooktop is oft when
you are finished cooking.
12. Before performing any service, turn off the
gas supply by closing the gas shut-off valve
and disconnect the electrical power supply.
13. Always light each burner prior to placing a
utensil on the burner grate. Also, turn the
control knob to the "oft" position before
removing an utensil from the burner grate.
14. Always clean the cooktop cautiously. If
using a damp sponge or cloth, wait until
the cooktop has cooled sufficiently to
prevent steam burns. Also, some cleaners
can produce harmful or unpleasant fumes if
applied to hot surfaces.
15. Keep any ventilation filters from any
adjacent or overhead vent hoods clean to
avoid grease fires.
16. Always set utensils gently onto the grates
and center them so that they are well-
balanced.
17. Always keep the cooktop surface clean and
dry.
I[What.ottooo I
1. Do not use the cooktop for warming or
heating the room.
2. Do not leave children alone or unattended
in the area where the cooktop is in use.
Never allow children to sit or stand on any
part of the cooktop. Do not let children play
with the cooktop.
g. Do not store items of interest to children
above the cooktop. Children could be
burned or injured while climbing on the
appliance.
4. Do not wear loose or hanging apparel while
using the cooktop.
5. Do not repair or replace any part of the
cooktop unless specifically recommended
in literature accompanying this appliance.
All other service should be referred to a
qualified technician.
6. Do not use water on grease fires. A violent
steam explosion may result. Smother any
flames with a lid, cookie sheet or flat tray.
If you received a damaged product,
immediately contact your dealer or builder.
Do not install or use a damaged appliance,
_} Please enter the information requested in the spaces provided below. This information will be required in the unlikely event that a service call
becomes necessary:
Model No. Serial No.
Date Purchased Date Installed
Purchased From
Address
Phone

Flaminggreasecanbeextinguishedwith
bakingsodaoramulti-purposechemicalor
foamextinguisher.
7. DonotallowpothoIderstotouchgas
burners.Donotuseatowelorbulkycloth
asapotholder.
8. Donotblockorobstructtheholesbeneath
thecontrolknobs.Blockingtheseholes
mayaffectburneroperationandmayresult
inahazard.
9. Whenusingthecooktop,donottouchthe
grates,burnercaps,burnerbases,orany
otherpartsinproximitytotheflame.These
componentsmaybehotenoughtocause
burns.
10.Ifthecooktopisnearawindow,donotuse
longcurtainsasawindowtreatment.They
canblowoverthecooktopandcreateafire
hazard.
11.Donotcovertheburnersandgrateswith
anythingexceptproperlyselectedutensils.
Decorativecoversshouldnotbeused.
12.Donotheatunopenedfoodcontainers
suchasbabyfoodjarsandcans.Pressure
build-upmaycausethecontainertoburst
andcauseinjury.
13.Donotuseabrasiveorcausticcleaners
ordetergentsonthisappliance,asthese
maycausepermanentdamage.Donot
useaerosolcleaners,asthesemaybe
flammableorcausecorrosionofmetal
parts.
14.Donotuseorattempttousethisappliance
intheeventofapowerfailure.
Burner Configuration I
On PGM3O4 Cooktops, there are a total of
four burners, including one burner rated at a
maximum output of 15,000 BTU/HR, one burner
rated at a maximum of 12,500 BTU/HR and two
burners rated at a maximum output of 9,500
BTU/HR. The knobs are grouped in twos. The
front two knobs operate the front two burners,
and the rear two knobs control the two rear
burners Single Burner
9,500 BTU
Dual Burner
15,000 BTU
w/simmer
Single Burner
©
©
SingleBurner
9.500BTU
PGM304
Top View
On the PGM365 Cooktop, there are a total of
five burners, including one burner rated at a
maximum of 18,000 BTU/HR with a minimum
of 500 BTU/HR simmer, one burner rated at a
maximum of 12,500 BTU/HR with a minimum
of 650 BTU/HR simmer, one burner rated at a
maximum of 12,500 BTU/HR, and two burners
rated at a maximum of 9,500 BTU/HR. The
knobs are positioned to correspond with the
burner layout.
Single Burner
Dual Burner
18,009 BTU
w/simmer
Single Burner
DualBurner
12,500BTU
w/simmer
PGM365
Top View
Single Burner
9.590 BTU
©©©
00
ISealed Burners i
Single burners and dual burners are attached
to the cooktop by retaining screws. Gaskets
around the underside of the single burner bases
and around the top of the dual burner bases
ensure that the burrers are sealed, thereby
preventing any liquid spi]{s from entering the
cooktop chassis, All spills remain on the surface
of the cooktop.
The brass burner heads spread the flame evenly
around the burner perimeters. The burner
heads must seat properly in the burner cross
rings or burner bases to enable proper cooktop
operation. To ensure proper seating, positioning
tabs have been placed on the bottom of each
burner cross ring or burner head to slide into
corresponding notches in the fixed burner base.
ISmart'FlameTM i
Each burner head features Smart-Flame TM
technology. When oriented properly by the
burner head positioning tabs, Smart-Flame TM
prevents direct flame impingement on the
fingers of the porcelain grate. This reduces
temperatures on the grate and improves flame
and performance characteristics, as well as
increasing longevity of the porcelain enamel
coating on the grate.
IBurner Igniters & Perma-Flame TM
A burner igniter is located on each gas burner
base. When a control knob is rotated more
than 90 °counterclockwise, only the selected
burner will spark. Additionally, due to the Perma-
Flame TM reignition feature, the igniters will spark
automatically if a flame should blow out or be
severely distorted by a draft or by a cooktop
ventilation system. Burner igniters must always
be kept clean and dry to function properly. Dirty
or wet igniters will result in constant sparking,
even if there is a flame present.
Sing_eeBd .....
Sing;e sE'eU.....
Single Burner Assemb/y
Dual Burner _ _- _
Cap Cover
Dual Burner _,- _-_ _
Cap
Dual Burner
Head
Cross Ring
Skirt
Dual Burner
Cross Ring
Dual Burner Assembly
II.nobsan,:,Spi,,Pro,ectorRingsIi
The control knobs provided with this cooktop
are designed for ease of use and longevity. The
"D" shaped design of the knob shaft ensures
proper orientation when re-installing the knob.
The PGM knobs have a triangular shape with a
blue indicator light located on point of the knob
for reference when setting the burner. Beneath
each knob, a spill protector ring is inserted
into the opening in the cooktop. These rings
prevent liquid spills from entering the chassis
beneath the cooktop and they also show heat
control information. The control knobs and spill
protectors are made of a composite plastic
material that is resistant to staining.
On the dual burners, the spill protector ring
shows the simmer setting and frames the blue
simmer indicator light. See "Operating the
Control Valves" for further information.
ISelecting the Proper Cookware Ii
Utensils will affect the overall safety and
performance of cooktop cooking, so it is
important to select them carefully. An improperly
selected utensil will not cook efficiently or evenly.
For best results, follow these guidelines:
1. Use medium to heavy gauge metal
cookware with flat and smooth
bottoms for greatest efficiency
2. Use utensils with tight fitting lids to
retain heat, odors, and steam.
IBefore Cooking i
Ensure that the cooktop has been installed
by a qualified individual who has tested the
operation of the cooktop in accordance with the
Installation Instructions. The brass burner heads,
cross rings, burner caps, grates, knobs, and spill
protectors must be in place for the cooktop to
operate properly. All cooktop components must
be clean. Be certain that the gas and electrical
power supplies to the cooktop are operational.
Read this Use and Care Manual in its entirety
prior to operating the cooktop.

IIOperating the Control Valves i
To light a particular burner, press down on the
corresponding control knob, then immediately
rotate the knob counterclockwise from the "OFF"
(O) position to the "HIGH" position (the thickest
part of the flame indicator line). Only the
selected burner will spark continuously until
the gas ignites on that burner. The igniters
will stop sparking as soon as the burner
ignites.
Once the burner is lit, reduce the flame height
if desired by rotating the control knob further
counterclockwise, then place the utensil on
the grate. The flame indicator lines indicate
progressively lower flame height as the lines get
thinner.
Knob position
Light & high
position
Area o
operation Low
position
PGM Single Burner Control Valve
On the dual burners of the PGM, there are
two indicator lines. The knob light is for higher
heat settings. Both the outer and inner burners
operate when in this setting. Turning the knob
further counterclockwise reduces the flame to
the Simmer setting. Once in the simmer mode,
only the small inner burner is operational and
the simmer indicator light comes on. Again,
moving counterclockwise will reduce the heat
out of the simmer burner.
Knob position
Light & high
Area of
operation
\,,_peration
Low High
position position
PGM Dual Burner Control Valve
Low
[_ WARNING:
Do not touch any burner cap, burner base, or
igniter while the igniters are sparking, as an
electrical shock could result.
_IMPORTANT:
1. If the gas does not ignite within four
seconds, once the gas reaches the
burner ports, turn off the valve. Allow
at least five minutes for any gas to
dissipate, then repeat the lighting
procedure.
2. Burner igniters must always be kept
clean and dry to function properly.
Due to the Perma-Flame TM reignition
feature, dirty or wet igniters will result
in constant sparking, even if there is
aflame present. Additionally, igniters
will spark automatically if the flame is
distorted by a draft or by a cooktop
ventilation system. Eliminate the draft or
reduce the ventilation blower speed in
this case.
3. When the cooktop is cool and/or more
than two burners are in use, the igniters
may continue to spark if the control
knob is set to the "LOW" position. This
is normal until the burner warms up.
The tendency to spark under these
conditions can be reduced by operating
the burner at a higher flame setting
for a short period of time (normally
60 seconds or less), then adjusting
the control knob down to the "LOW"
setting. The burner will also warm up
faster if a utensil is placed on the grate.
4. The flame should be steady and blue in
color. Foreign material in the gas line,
especially in new construction, may
cause an orange flame during initial
operation. This will disappear with
further use.
5. The flame should burn evenly around
the perimeter of the burner, except
underneath each grate support finger
where the flame height is reduced by
the Smart-Flame TM feature. If the flame
is uneven, ensure that the brass burner
head is properly positioned, then check
for any foreign material in the burner
head or on the burner cap. Remove any
foreign material with a straightened
paper clip, wire, or needle. Do not use
a toothpick to remove clogs, as it could
break off. Do not damage the brass or
distort the shape of the burner head
ports. Only handle burners when cold.
6. Never light the burners with a match
or other open flame. If a burner does
not ignite, refer to the Troubleshooting
Guide.
Setting the Burner Flame
Setting the proper burner flame height for the
desired cooking process and selected utensil
will result in superior cooking performance,
while also saving time and energy. Follow these
recommendations for best results:
1. Use low or medium flame heights when
cooking in utensils that are poor conductors
of heat, such as glass, ceramic, and cast
iron cooking vessels. Reduce the flame
height until it covers approximately 1t3 of
the utensil diameter. This will ensure even
heating within the utensil and reduce the
likelihood of burning or scorching of food.
2. Reduce the flame if it is extending beyond
the bottom of the utensil. A flame that licks
along the sides of the utensil is potentially
dangerous, heats the utensil handle and
kitchen instead of the food, and wastes
energy.
3. Reduce the flame height to the minimum
level necessary to perform the desired
cooking process. Remember that food
cooks just as quickly at a gentle boil as it
does at a vigorous, rolling boil. Maintaining
a higher boil than is necessary wastes
energy, cooks away moisture, and causes
a Ioss in food flavor and nutrient level.
ILEnergy Saving Tips i
Always use utensils with flat, smooth
bottoms and tight-fitting lids to retain heat
and moisture.
Minimize the amount of liquid or fat to
reduce cooking times.
Select cookware of the proper size,
material and construction for the cooking
process being performed.
Adjust the flame height to fit the utensil
size.
After liquid reaches a boil, reduce the heat
to maintain a simmer rather than a rolling
boil.
Use a timer rather than repeatedly
removing the lid to check food.
Thaw foods prior to cooking to reduce
cooking time.
ILAccess°ries (Order Separately) i
Wok Ring (AWR) - the wok ring is a safe,
convenient way to stir fry. Just place it on
top of the grate, aligning the wok ring feet
with the grate fingers. It will hold most
standard sized wok.
Griddle (AG13) - The AG13 easy clean
griddles are coated with a non-stick finish.
Wonderful for pancakes, eggs and various
other foods. It is designed to sit on top of
your cooktop burner grates. A maximum
setting of medium is recommended
to avoid damage to the cooktop. See
instructions included in griddle carton for
further information.
Simmer Plate - The Simmer Plate has
been specifically designed for simmering
and holding food at the lowest safe
temperature. Simply align plate with the
five longest fingers on the cooktop grate
then set on top of the grate. When correctly
installed, the Simmer Plate will rest about
1/2 inch above the top surface of the grate
and will be locked in place to prevent
turning.

_ WARNING:
To avoid electrical shock or burns, turn off
all controls and ensure the cooktop is cool
before cleaning.
_IMPORTANT:
Do not use harsh or abrasive cleaning
agents, waxes, polishes, or commercial
cooktop cleaners to clean the cooktop.
Read and follow the CARE AND CLEANING
INSTRUCTIONS to ensure that proper cooktop
operation and appearance will be maintained
throughout the lifetime of the product. Several
materials and finishes are used in the
cooktop. Each material and finish must be
properly cleaned according to the following
recommendations. Failure to follow these
recommendations may result in permanent
damage to the cooktop.
JCleaning Tips
_ WARNINGS:
1. Before cleaning the cooktop, ensure
that all burners are turned off and that
all components are cool enough to
safely touch.
2. After cleaning, reassemble all
components before attempting to
operate the cooktop.
3. Burner ports must be dry for proper
operation
I
Proper cleaning is necessary to maintain
cooktop performance and appearance, while
also ensuring safe operation. The cleaning
effort necessary to maintain the cooktop varies
according to the type and amount of cooking.
For example, more frequent cleaning is required
if the cooktop is used often for frying or other
high temperature operations.
Clean the cooktop thoroughly prior to operating
it the first time. For initial and everyday cleaning,
use a soft cloth or sponge lightly dampened with
a solution of warm water and hand dishwashing
liquid to clean all components.
_IMPORTANT:
1. To keep the cooktop looking its best,
clean it after every use as soon as all
components are cool enough to safely
touch. Also, quickly wipe up spills that
occur while cooking, being careful
not to touch any hot areas. Spills that
remain on hot burner components will
be very difficult to clean, especially if
allowed to burn on. Spills of certain
foods, such as tomatoes, citrus
juices, vinegar, alcohol, and milk, are
very harmful if allowed to stand for
any length of time. Therefore, save
time while also maintaining a new
appearance by cleaning regularly and
shortly after spills occur.
2. Use the mildest cleaner or procedure
available to perform the cleaning
operation.
3. Use only a sponge, soft cloth, fibrous
or plastic brush, and nylon pad for
cleaning. Avoid the use of abrasive
cleaners such as steel wool.
4.
5.
Always dry components completely
before using the cooktop.
The use of brand names is intended
only to indicate a type of cleaning
agent or cleaning implement. All
products listed by name must be used
in accordance with the manufacturer's
recommendations. Use of a brand name
does not constitute an endorsement,
nor does omission of a particular brand
imply that a product is inferior.
Recommendations for cleaning specific cooktop
components are summarized below:
_IMPORTANT:
The grates, burner covers, burner heads,
burner caps, and spill-over areas on the
cooktop, unlike other porcelain enamel
appliances in your home, are exposed to
extremely high temperatures in a matter
of seconds. In addition to this extreme
thermal shock, the grates are subjected to
mechanical shock when utensils are placed
on or slid across them. Finally, spillovers
introduce foods with high acidity to all of the
porcelain components. Due to these severe
ooeratina conditions, all porcelain enamel
components on the cooktoo will underao an
inevitable chanae in appearance with use.
Meticulous care and cleaning will slow but
not eliminate this natural and expected aging
process.
Treating the porcelain components with care will
slow the natural deterioration that takes place
with cooktop use. Please follow these guidelines
to keep the porcelain parts looking their best:
1. Do not use utensils having rough bottoms,
as this can result in permanent damage
to the top surfaces of the porcelainized
grates.
2. Do not drop utensils onto the grates or
drag heavy pots across the tops of the
grates.
3. Set the grates into the locating dimples
gently. Do not drop the grates into place.
4. Use caution when cooking to avoid spills
as much as possible. Porcelain is acid-
resistant but not acid-proof, so some foods
can cause permanent damage if allowed to
remain on porcelain surfaces.
Daily cleaning of the grates, burner covers,
burner heads, and burner caps is best
accomplished with a soft cloth or sponge
dampened in a solution of warm water and
hand dishwashing liquid. Grates, burner covers,
burner heads, and burner caps should not be
cleaned in the dishwasher.
Stubborn stains may be removed by applying
full-strength sprays such as Simple Green, Ajax
All-Purpose Cleaner, Formula 409, or Scotch
Guard. Metal polishing compounds such as
Luneta or Flitz may also be used. (if you are
unable to locate these cleaning compounds,
please phone the DACOR Customer Service
Department for a referral.)
Mildly abrasive cleaners or applicators, such
as S.O.S. Pads, soap-filled steel wool pads,
Soft Scrub, or Bon-Ami may be used with
extreme care on occasion to remove the most
serious stains. Exercise caution - extensive
use of abrasives will eventually damage the
porcelain enamel surface.
JlStainless Steel Surfaces
Clean these surfaces with the provided EIco
Stainless Steel Cleaner. Rinse and dry with a
soft lint-free cloth.
1
_) IMPORTANT:
If commercially available stainless steel
cleaners are used, it is important to read the
labels for chlorine compounds. Chlorine is a
corrosive substance. If these compounds are
present, rinse thoroughly and dry with a soft
lint-free cloth.
Always wipe stainless steel surfaces with the
grain.
j[Porcelain Surfaces j
Clean this surface with a solution of mild
detergent and hot water. Rinse with a soft
cloth. Do not use abrasives or commercial oven
cleaners.
Stubborn stains may be removed by applying
full-strength sprays such as Simple Green, Ajax
All-Purpose Cleaner, Formula 409, or Scotch
Guard.
_IMPORTANT:
1. Never use the cooktop surface as a
cutting board.
2. Do not use abrasive cleaners or
applicators on the cooktop.
3. Do not try to remove heavy spills with
a sharp object such as a knife or metal
spatula. Sharp objects may scratch the
cooktop.
4. A small amount of baby oil may be
applied to stainless steel tops to restore
the lustre.
JJKnobs and Knob Bezels j
The control knobs provided with this cooktop are
designed for ease of use and longevity. The "D"
shaped design of the knob shaft ensures proper
orientation when re-installing the knob.
(_ IMPORTANT:
Never block the holes in the control panel
beneath the knobs, because this will impair
the flow of combustion air and adversely
affect burner operation, possibly creating a
hazardous condition.
The knobs are made of a composite plastic.
These components should be washed regularly
in warm, soapy water. Hand dishwashing
liquid is excellent for this task. Knobs should
be removed by gently pulling them straight out
and off of the valve shafts. The spill protectors
should be cleaned in place. Use caution to avoid

introductionofmoistureintothecontrolpanel
behindthebezels.Toreplaceknobs,alignthe
"D-shaped"openingatthebottomoftheknob
withthe"D-shaped"valveshaft,thencarefully
presstheknobontothevalve.
_ IMPORTANT:
1. Turn the knobs to the "OFF" position
prior to removing them from the valve
stems.
2. The cooktop should never be operated
without the knobs in place.
3. Do not soak the knobs in water or place
them in the dishwasher.
4. Do not expose the knobs to direct
flame, hot utensils, or other sources of
heat.
5. Do not use abrasive or corrosive
cleaners or applicators, as these could
cause permanent damage.
I[Single Burner Bases ]1
The single burner base is permanently attached
to the cooktop. The base should be wiped clean
using a soft cloth or sponge that has been
lightly dampened with warm water and hand
dishwashing liquid.
IIDual Burner Cross Rings i
The dual burner skirts and cross rings are
removable from the cooktop. The skirts should
be wiped clean using a soft cloth or sponge that
has been lightly dampened with warm water and
hand dishwashing liquid. The igniters, located
in the burner base, should be wiped clean
using a soft cloth, or sponge, that has been
lightly dampened with warm water and hand
dishwashing liquid.
ILBurnerHeads 1
The brass burner heads spread the flame evenly
around the burner perimeters. The burner heads
must seat properly in the burner bases or cross
rings to enable proper cooktop operation. To
ensure proper seating, positioning tabs have
been placed on the bottom of each burner ring
to slide into corresponding notches in the fixed
burner base.
To remove the burner head, first remove the
grate. The burner head may then be removed
from the burner base. Soak the burner ring in a
warm solution of hand dishwashing liquid and
water, then rinse well with clean water. Dry the
burner thoroughly before placing it back on the
burner base or cross ring.
Stubborn stains may be removed by applying
a metal polishing compound such as Luneta
or Flitz. (If you are unable to locate this type of
polishing compound, please phone the DACOR
Customer Service Department for a referral.)
Burner Igniters
Under certain cooking or cleaning conditions,
your cooktop igniters may become coated
with or corroded by food deposits, splattered
grease or cleaning agents. This condition can
cause erratic or continuous sparking. Keeping
the igniters clean and dry will help to reduce
this problem. To avoid unnecessary and costly
service calls, the homeowner should perform
periodic cleaning of the igniters. An Igniter
Cleaning Brush is enclosed for your use in
cleaning the cooktop igniters.
i
To clean the igniters:
1. Be sure burners are cool to the touch.
Remove the grate, burner cap and burner
heads.
2. Brush completely around the igniter,
including over and under the edge of
the metal cap and base. Use care while
cleaning here. Parts of the igniter are
porcelain and can be fragile.
3. DO NOT USE WATER when cleaning the
igniters. If a liquid must be used to clean
the igniter effectively, use only a small
amount of rubbing alcohol.
4. After cleaning, reinstall the burner head,
head cover, burner cap cover, burner cap
and grate. Make sure caps on dual burners
are properly seated into the burner base.
5. Test the burners. If erratic clicking is still
present, make sure the igniter is completely
dry. If the unit still exhibits problems after
drying, call your local DACOR Authorized
Servicer.
Burner Covers
For this surface, nonabrasive cleaners should
be used. First, try hot, soapy water and the soft
side of a sponge to clean the burner covers.
Then, proceed to the oven cleaners for tougher
stains.
Recommended cleaners are Easy-Off Fume-
Free or Mr. Muscle. Spray the cleaner onto
a soft cloth and rub onto the part. Leave the
cleaner on for about 30 minutes, wipe clean,
then rinse thoroughly with water and dry with a
soft cloth.

Troubleshooting i
Unnecessary service calls may be expensive, frustrating and time consuming. Before you call for service, please review the potential problems, possible
causes and remedies shown in the table below.
Problem Possible Cause Remedy
1. Nothing works. Cooktop is not connected to electrical power. Have cooktop connected to the electrical
power supply by a qualified electrician
following the specifications outlined in the
installation instructions.
2. Burner lights but continues to click. Burner components are not properly seated. Confirm that the burner components are
properly seated.
3. Sparking, but no ignition. Gas shut-oft valve is on "off" position. Turn shut-oft valve to "on" position.
4. No spark. Inner burner area and burner cap are coated Confirm that inner burner and burner cap are
with cooking residue or wet. clean and dry.
Cooktop not connected to power supply. Check incoming power.
Power supply is not grounded. Have power supply properly grounded.
5. Burner Flame goes out at low setting. Low gas pressure. Have incoming gas pressure tested. Contact
gas company.
6. Igniters spark continuously after flame Power supply polarity is reversed. Have polarity corrected.
ignition. Igniters are wet, dirty or damaged. Clean and dry igniters.
7. Burners ignite, but flame is extremely Burner Ring ports are clogged. Clean burner ring ports with straightened
large, distorted or yellow paper clip, needle or wire.
Burner ports or burner caps are not positioned
properly. Remove and carefully re-install burner rings and caps.
Cooktop is being operated on the wrong type of Ensure the cooktop is correct for the gas
gas. supply - (Natural Gas or LP, the PGM is not a
convertible cooktop).
Regulator is either not installed, is faulty, or is
set for the wrong type of gas. Check installation, replace regulator or set regulator for the proper gas type.
Troubleshooting Guide

II Product Maintenance
No maintenance, other than the CARE AND
CLEANING INSTRUCTIONS identified in this
Use & Care Manual, should be attempted
by the owner/operator. All other maintenance
and service must be performed by a qualified
appliance technician.
II If You Need Service.,. j
First, review the recommended checks listed in
the preceding Troubleshooting Guide. Then,
be certain that the appliance has been installed
properly and is being operated correctly.
Familiarize yourself with the warranty terms and
conditions listed in the PRODUCT WARRANTY
section.
If the above checks have been completed and
the problem has not yet been remedied, call your
local authorized DACOR service representative.
Your dealer can normally provide the name
and telephone number of the nearest service
company.
DACOR works diligently to ensure your
satisfaction when service is necessary. However,
if you are not completely satisfied with the
service provided, contact the company that
performed the service and express why you are
not pleased. Normally, they will be willing and
able to resolve the problem.
If the service agency is not able to respond
effectively, call or write the DACOR Customer
Service Department. The phone number and
address of this department are listed on the
inside front cover of this manual. Please include
your telephone number if you choose to write.
We will then do our utmost to assure your
happiness and satisfaction.
IIWhat Is Covered ]1
CERTIFICATE OF WARRANTIES
DACOR COOKTOPS
WITHIN THE FIFTY STATES OF THE
U.S.A., THE DISTRICT OF COLUMBIAAND
CANADA*:
FULL ONE-YEAR WARRANTY
If your DACOR product fails to function within
one year of the original date of purchase, due
to a defect in material or workmanship, DACOR
will remedy the defect without charge to you
or subsequent users. The owner must provide
proof of purchase, upon request, and have the
appliance accessible for service.
* Warranty is null and void if non-CUL approved
product is transported from the U.S.
jOUTSIDE THE FIFTY STATES OF THE U.S.A.,
THE DISTRICT OF COLUMBIAAND CANADA:
LIMITED FIRST YEAR WARRANTY
If your DACOR product fails to function within
one year of the original date of purchase, due
to a defect in material or workmanship, DACOR
will furnish a new part, F.O.B. factory, to replace
the defective part. All delivery, installation
and labor costs are the responsibility of the
purchaser. The owner must provide proof of
purchase, upon request, and have the appliance
accessible for service.
What Is Not Covered j
Service calls to educate the customer in
the proper use and care of the product.
Failure of the product when used for
commercial, business, rental or any
application other than for residential
consumer use.
Replacement of house fuses or fuse boxes,
or resetting of circuit breakers.
Damage to the product caused by accident,
fire, flood or other acts of God.
Breakage, discoloration or damage to
glass, metal surfaces, plastic components,
trim, paint, or other cosmetic finish, caused
by improper usage or care, abuse, or
neglect.
THE REMEDIES PROVIDED FOR IN THE
ABOVE EXPRESS WARRANTIES ARE
THE SOLE AND EXCLUSIVE REMEDIES.
THEREFORE, NO OTHER EXPRESS
WARRANTIES ARE MADE, AND OUTSIDE
THE FIFTY STATES OF THE UNITED STATES,
THE DISTRICT OF COLUMBIAAND CANADA,
ALL IMPLIED WARRANTIES, INCLUDING BUT
NOT LIMITED TO, ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR USE OR PURPOSE, ARE
LIMITED IN DURATION TO ONE YEAR FROM
THE DATE OF ORIGINAL PURCHASE. IN
NO EVENT SHALL DACOR BE LIABLE FOR
INCIDENTAL EXPENSE OR CONSEQUENTIAL
DAMAGES. NO WARRANTIES, EXPRESS OR
IMPLIED, ARE MADE TO ANY BUYER FOR
RESALE.
Some states do not allow limitations on how
long an implied warranty lasts, or do not allow
the exclusion or limitation of inconsequential
damages, so the above limitations or exclusions
may not apply to you. This warranty gives you
specific legal rights, and you may also have
other rights that vary from state to state.

NOTES:

fold here IIl1
NO POSTAGE
NECESSARY
IF MAILED
IN THE
UNITED STATES
IFB_US_/NESSM,REoPLYDMoA!RLcAI
POSTAGEWILL BE PAIDBYADDRESSEE
ATTN: WARRANTY PROCESSING DEPT
DACOR
1440 BRIDGEGATE DR STE 200
PO BOX 6532
DIAMOND BAR CA 91765-9861
I1,1,,,,,111,,,I,I1,,,I,1,1,1,,I,,I,,11,,,,,111,,I,I

I" | "IIEI" _I'" _*
Pleasevisitwww.dacor.comto activateyourwarrantyonline.
WARRANTYINFORMATION
IMPORTANT:
Yourwarrantyfor this productCANNOTBEACTIVATEDuntilthisform hasbeenreturnedto Dacor,Ifyou have
purchasedmorethanoneDacorproduct,Pleasereturnallforms inoneenvelope,
PleaserestassuredthatundernoconditionswillDacorsellyournameoranyofthe informationonthisformformailinglist purposes.We
are verygratefulthatyouhavechosenDacorproductsforyourhomeanddo notconsiderthesaleofsuchinformationtobea properway
ofexpressingour gratitude!
(Phase Print or Type)
Owner'sName: Last First Middb
Street:
City: State: Zip:
PurchaseDate: Email: Telephone:
Dealer:
City: State: Zip:
Yourwillingnesstotakea fewsecondstofillin thesectionbelowwillbesincerelyappreciated.Thankyou.
1.Howwereyoufirst exposedtoDacorproducts?(Pleasecheckoneonly.)
[] A. T.V.CookingShow [] F Builder
[] B. Magazine [] G. Architect/Designer
[] C. ApplianceDealerShowroom [] H. AnotherDacorOwner
[] D. KitchenDealerShowroom [] I. ModelHome
[] E. HomeShow [] J. Other
2.WheredidyoubuyyourDacorappliances?
[] A. ApplianceDealer [] D. Builder
[] B. KitchenDealer [] E. Other
[] C. BuilderSupplier
3. Forwhatpurposewastheproductpurchased?
[] A. Replacementon/y [] C. NewHome
[] B. Partofa Remodeled [] D. Other
4.Whatis yourhouseholdincome?
[] A. Under$75,000 [] D. $150,000-$200,000
[] B. $75,000-$100,000 [] E. $200,000-$250,000
[] C. $100,000-$150,000 [] F. Over$250,O00
5.Whatotherbrandsofappliancesdoyouhaveinyourkitchen?
A. Cooktop
B.Oven
6.Wouldyoubuyor recommendanotherDacorproduct?
[] Yes
Comments:
C. Dishwasher
D.Refrigerator
[] No
Thankyouverymuchforyourassistance.Theinformationyouhaveprovidedwillbeextremelyvaluablein helpingusplanforthefuture
andgivingyouthesupportyoudeserve.
Web Site: www.dacor.com
For a DeaIer/Service: [phone]
Corporate Phone: [phone] ®PlaceSerialNumberLabelHere
I
I
I
I
I
I
I
I
I
I
I
I
°I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
°I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
