Dacor DRT304S Technical manual

PLANNING
GUIDE
www.Dacor.com Phone: [phone]
Specications subject to change without notice.
Install all appliances according to accompanying installation instructions. 4.14
A
30” and 36” Wide, Distinctive Series
Slide-in Gas Cooktops
DRT304S, DRT366S
ELECTRIC CIRCUIT REQUIREMENTS
Circuit Required Total Connected Load
120 Vac 60Hz, 15 Amp. (3 wire) 1.0 Amp @ 120 Vac, 60 Hz
GAS SUPPLY PRESSURE REQUIREMENTS*
Gas Type Manifold Pressure Minimum Gas Supply
Pressure
Natural Gas 5” Water Column 6” Water Column
Propane (LP) 10” Water Column 11” Water Column
* Maximum gas supply pressure for all models is 1/2 p.s.i.
Installation of a non-combustible material* (up to the hood) or a backsplash
is always recommended, and mandatory if the distance to the back
wall from the cooktop is less than 2 1/2” (Figure 2). When installing
a backguard, use only Dacor model numbers AEB3009, AEB3012
(DRT304S), AEB3609 or AEB3612 (DRT366S).
SIDE VIEW WITHOUT BACKGUARD
SIDE VIEW WITHOUT BACKGUARD
SIDE VIEW
Product Dimensions
Electrical and Gas Supply Requirements
Cabinet and Countertop Layout
COOKTOP WIDTH (A)
DRT304S 29 7/8” (759 mm)
DRT366S 35 7/8” (911 mm)
Product tolerances:
±1/16” (±1.6 mm)
unless otherwise noted
WARNING
Observe all governing codes and ordinances during planning•
and installation. Contact your local building department for
further information.
This appliance must be installed in accordance with the•
accompanying installation instructions.
Document # PG04 - 003 Revised 02/16/10 Page 1/3
4” (102 mm) 5/8” Min.
(16 mm)
7 3/4”
(197 mm)
Trim:
1/2”
(13 mm)
thick
25 7/8” (657 mm)
1 5/8” (41 mm) cooking surface
height (grate level) above
countertop
3/4” gas inlet, connects to regulator from
bottom or rear of unit, end is recessed
2” (51 mm) from chassis bottom
28 1/8” (714 mm)
Power cord
32” long
Combustible
rear wall
Backguard mandatory if
gap from back of cooktop
to combustible wall is less
than 2 1/2”
Combustible
rear wall
2 1/2” (64 mm) Min. to
combustible rear wall

PLANNING
GUIDE
www.Dacor.com Phone: [phone]
Specications subject to change without notice.
Install all appliances according to accompanying installation instructions. 4.15
See note 2
2See Cabinet/Countertop Dimensions - Top View
3Not applicable for cabinets more than a horizontal
distance of 10” (254mm) from the edge of the cooktop.
1Vertical to combustible surface from cooktop grate level;
if installing an overhead vent hood, also check the hood
specifications for minimum required clearances.
C
13” (330 mm)
max.3
Top of
finished
counter
18” (457 mm)
Min.1, 3
30” (762 mm)
Min.1Cutout for
utility access
Hood
Recommended
gas and electrical
service location,
consult local code
B
10” (254 mm) to
combustible side
wall Min. both sides 1/2” (13 mm)
overhang,
both sides
1 1/2” (38 mm)
typical countertop
thickness
7 3/4”
(197 mm)
36” (914 mm)
typical
Cooktop platform
1” (25 mm) Min.
thickness
Model No. B C
DRT304S 30” (762 mm) 30” (762 mm)*
36” (914 mm)**
DRT366S 36” (914 mm) 36” (914mm)*
42” (1067 mm)**
* Minimum ** Recommended
Cabinet tolerances: +1/16”, -0 (+1.6 mm, -0)
unless otherwise noted.
CABINET/COUNTERTOP DIMENSIONS - FRONT VIEW
CABINET/COUNTERTOP DIMENSIONS -
ISO VIEW
Continued. on following page...
Cabinet and Countertop Layout (Continued)
DRT304S, DRT366S
Document # PG04 - 003 Revised 02/16/10 Page 2/3
NOTE: Models DRT304S and DRT366S are not
approved for installation with a raised vent.
30” and 36” Wide, Distinctive Series
Slide-in Gas Cooktops

PLANNING
GUIDE
www.Dacor.com Phone: [phone]
Specications subject to change without notice.
Install all appliances according to accompanying installation instructions. 4.16
CABINET/COUNTERTOP CUTOUT DIMENSIONS - TOP VIEW
Model No. B - Cutout Width D - Hole Offset
DRT304S 30” (762 mm) 13 3/8” (340 mm)
DRT366S 36” (914 mm) 16 5/8” (422 mm)
Cutout tolerances: +1/16”, -0, (+1.6 mm, -0) unless otherwise stated
DRT304S, DRT366S
Document # PG04 - 003 Revised 02/16/10 Page 3/3
Cabinet and Countertop Layout (Continued)
Non-combustible
rear wall, rear of
mounting platform
10” (254 mm) min.
to combustible wall
above countertop,
both sides
Cabinet face
below countertop
overhang
Increase countertop and overhang
additional 2 1/2” (64 mm) Min. for
combustible rear wall above
countertop
3/8” (13 mm)
countertop overhang
Hole 1/2” dia. (13 mm),
2 places, through platform
for hold down bolts
Gas/electrical utility cut-out in right rear corner of
mounting platform 8” W X 6” D (203 mm X 152 mm),
if gas and electrical are routed through bottom
1/2” (13 mm)
countertop
overhang
1” thick mounting platform Min.
Countertop
Countertop
1/2” (13 mm)
countertop
overhang
2” (51 mm)
1” (25 mm)
11 7/16”
(291 mm)
24 5/8”
(625 mm)
C
L
D D
B
C
LC L
C
L
Gas connection and power cord may be
routed through bottom or back of chassis
Gas and electrical connections at
right rear section of chassis
30” and 36” Wide, Distinctive Series
Slide-in Gas Cooktops
