Dacor Epicure ER36D Technical manual

PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 5.15
Epicure®Ranges
ER36D, ER48D
1/2
GAS - ELECTRICAL ACCESS DIMENSIONS
Model A B C D E*
ER36D 5 5/8”
(142.9mm)
18 3/8”
(466.7mm)
10 3/4”
(273.0mm)
13 11/16”
(347.7mm)
7/8”
(22.2mm)
ER48D 3 13/16”
(96.8mm)
18 11/16”
(474.7mm)
9 3/8”
(238.1mm)
13 3/4”
(349.3mm)
1 1/8”
(28.6mm)
* The diameter on models equipped for use in Canada is ¼”
(6.4mm) larger than those stated. Canadian units come from
the factory pre-wired with an appliance cord. When installing an
appliance cord on models that are not pre-wired, the hole size must
be increased to 1 1/8” (1 3/8” for model ER48D) by removing the
conduit bracket inside the range electrical access box.
48” (1219mm)
**
**
**
** Optional
1 1/16” (27mm) to cooking
surface (top of grates) from
top of trim
Finished Side
Panel
Width: ER36D - 35 7/8” (911mm)
ER48D - 47 7/8” (1216mm)
NOTES:
1. When installing a backguard, always install it
before sliding the range into place.
B
A
C
D
Gas Regulator Access,
Cover Removed
Range Electrical Access,
Cover Removed
E Electrical Connection
Hole in Bottom
Inlet
Back of Range
Revised
03/10/09
All tolerances: +/- 1/16” (+/- 1.6mm) unless otherwise stated
GAS SUPPLY PRESSURE REQUIREMENTS*
Gas Type Manifold Pressure Minimum Gas
Supply Pressure
Natural Gas 5” Water Column 6” Water Column
Propane (LP) 10” Water Column 11” Water Column
* Maximum gas supply pressure 1/2 p.s.i. for all models
WARNING
Observe all governing codes and ordinances during◊
planning and installation. Contact your local building
department for further information.
This appliance must be installed in accordance with the◊
accompanying installation instructions.
ELECTRIC CIRCUIT REQUIREMENTS
Range Model Circuit Required Total Connected Load
ER36D
240 Vac, 4-wire* 60 Hz,
30 Amp. (Min.) 40 Amp.
(Recommended)
6.5 kW (28 Amp.)
ER48D 240 Vac, 4-wire* 60 Hz,
50 Amp. 10.0 kW (42 Amp.)
* 4-wire, two 120 Vac hot (L1 and L2), one neutral, one ground

PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 5.16
Epicure®Ranges
ER36D, ER48D
2/2
CUT-OUT DIMENSIONS
Range Model “F” “G” “H”
ER36D 42” (1067mm)*
36” (914mm)**
36 1/16”
(916mm)**
33 1/2”
(848mm)
ER48D 54” (1372mm)*
48” (1219mm)**
48 1/16”
(1221mm)**
43 1/2”
(1102mm)
* Recommended
**Minimum
Gas and Electrical Service
For replacement purposes, the location of the existing utilities◊
may be utilized provided they do not interfere with the sides or
rear of the range. Check local building codes for permissible
locations.
An external manual shut-off valve must be installed between◊
the gas inlet and the range, for the purpose of turning on or
shutting off gas to the appliance.
The installation must allow for the following:
Access to the gas shut-off valve when the unit is installed.◊
Access to the remote circuit breaker panel/fuse box, when the◊
range is in place.
The gas supply piping and shut-off valve, and the electrical◊
junction box/receptacle must be located so they do not
interfere with the range when it is installed.
The junction box and gas shut off valve must be located so◊
that the range can be pulled out for service while the appliance
remains connected.
Revised
03/10/09
3
2, 5
F
G
3
Cabinet/countertop depth is at discretion of customer but
cabinet face MUST NOT protrude further than rear of front
panel, see product dimensions.
4
Consult local code for exact location requirements.
5
Not applicable for cabinets more than a horizontal
distance of 10” (254mm) from the edge of the range.
1
Vertical to combustibles directly above cooking surface;
if installing an overhead vent hood, also check the hood
specifications for minimum required clearances.
2
Measured from range top panel.
Non-combustible
surface along
back wall
recommended
30” (762mm)
Min.
1
36 1/2”
(927mm)
Max.
13” (330mm)
Max.
5
Suggested
location of
utilities
4
G
10" (254 mm) Min.
to combustible side
walls above the range
(both sides)
non-combustible
Minumum Countertop Height:
30 1/4” (768 mm)
Maximum Countertop Height:
36 1/2” (927 mm)
rear wall recommended
Backsplash
3/8" (10 mm)
Min. flat countertop
overhang
H
2 13/16"
(71.4 mm)
3
CUTOUT WITH OPTIONAL ERV RAISED VENT
(TOP VIEW)
APPROVED RAISED VENT MODELS
Raised Vent Model For use with
Range Model
ERV36-ER ER36D
ERV48-ER ER48D
Stiffener Cabinet face**
Countertop*
* IMPORTANT: See “CUTOUT WITH OPTIONAL ERV RAISED VENT”
for countertop cutout dimensions.
** IMPORTANT: Cabinet face must not stick out further than
back of control panel.
Back of
control
panel
ERV36-ER or
ERV48-ER
raised vent
ER36D or ER48D Range
3/8” Min. (10 mm)
space behind
raised vent
chassis to clear
stiffener
3/8” Min. (10 mm)
flat countertop overhang
required behind cutout
Countertop height:
30 1/4" (768 mm) Min.
36 1/2” (927 mm) Max.
RAISED VENT INSTALLATION SIDE VIEW
Tolerances: +1/16”, -0, (+1.6mm, -0) unless otherwise stated
