Dacor HRV46 User manual

Installation Instructions
Downdraft Vent
HRV46, MRV3015*, MRV3615*, MRV48, MRV3015-ER,
MRV36-ER, MRV48-ER
Includes installation instructions for Dacor cabinet blower CABP3, which is an
option for the indicated* models.
Part No. 113910 Rev E
Use these downdraft vents only with approved Dacor®appliances.
See the instructions in this manual to determine suitability with the
companion appliance.

Installation Specifications ................................................ 6
Planning the Installation................................................... 6
Planning the Duct Work ................................................... 8
Installation Instructions.................................................. 12
Installation Preparation .................................................. 12
Installing the Downdraft Vent in the Cutout ................... 13
Verifying Proper Operation............................................. 16
Installation Checklist ...................................................... 16
Wiring Diagram: All Models............................................ 17
CABP3 Cabinet Blower Ratings..................................... 17
Table of Contents
Before You Begin...
Important Safety Instructions .......................................... 1
Safety Symbols and Labels ............................................. 1
General Safety Precautions ............................................. 2
Product Specifications ..................................................... 2
Electrical Specifications ................................................... 2
Dimensions: MRV3015, MRV3615....................................3
Dimensions: HRV46, MRV48............................................4
Dimensions: MRV3015-ER, MRV36-ER, MRV48-ER......5
•Installer: In the interest of safety and to minimize problems, read these installation instructions completely and care-
fully before you begin the installation process. Leave these installation instructions with the customer.
•Customer: Keep these installation instructions for future reference and the local electrical inspector’s use.
Customer Assurance Information
All specifications subject to change without notice. Dacor assumes no liability for such changes.
© 2018Dacor, all rights reserved.
Model Number Description
MRV3015 30” wide downdraft vent; MRV-style top cap
MRV3615 36” wide downdraft vent; MRV-style top cap
MRV36-ER 36” wide downdraft vent; MRV-style top cap
MRV48 48” wide downdraft vent; MRV-style top cap
MRV48-ER 48” wide downdraft vent; MRV-style top cap
If You Need Help...
For installation or warranty questions/issues, contact Dacor Customer Assurance. Have available the vent’s model and
serial numbers, which are on the data label on the front of the unit. This label includes power-supply requirements.
Dacor Customer Assurance: Phone: 833-35-ELITE (833-353-5483) USA, Canada; Mon - Fri 5:00 a.m.to 5:00 p.m.
Pacific Time; Website: www.dacor.com/customer-care/contact-us
Model Identification
Use HRV, and MRV downdraft vents with approved Dacor cooktops and ranges only.
HRV46 46” wide downdraft vent; HRV-style top cap
MRV3015-ER 30” wide downdraft vent; MRV-style top cap

1
Important Information About
Safety Instructions
• The Important Safety Instructions and warnings in this
manual do not cover all possible issues. Use common
sense and caution when installing, maintaining, or operat-
ing the appliance.
•Contact Dacor Customer Assurance about issues
and conditions you cannot resolve. (See Customer
Assurance Information.)
Important Safety Instructions
Safety Symbols and Labels
DANGER
Immediate hazards that WILL result in severe personal
injury or death.
WARNING
Hazards or unsafe practices that COULD result in severe
personal injury or death.
CAUTION
Hazards or unsafe practices that COULD result in minor
personal injury or property damage.
WARNING
The unit has a 3-prong grounding plug to protect against
electric shock. It must plug into a dedicated, 3-prong,
grounded outlet. The owner shall ensure that such an
outlet is available for the appliance. Do not:
•remove the third (ground) prong from the power cord.
•use an adapter plug.
•use an extension cord.
•use a damaged power cord.
•Use a ground fault interrupter (GFI).
DANGER
Do not store/use combustible, flammable substances
(e.g., gasoline, alcohol, benzene) in/on/near the vent.
WARNING
TO REDUCE RISK OF PROPERTY DAMAGE AND
PERSONAL INJURY, OBSERVE THE FOLLOWING:
a) Installation work and electrical wiring must be done by
qualified person(s) per applicable codes, including
fire-rated construction.
b) Sufficient air is needed for proper combustion and
exhaust of gases via the flue of fuel-burning equipment
to prevent backdraft. Follow manufacturer guidelines
such as are published by the National Fire Protection
Association (NFPA); the American Society for Heating,
Refrigeration, and Air Conditioning Engineers
(ASHRAE); and local code authorities.
c) Know the location of wiring and piping before cutting
or drilling into a wall or ceiling.
d) Fans must always vent to the outdoors.
READ AND SAVE THESE INSTRUCTIONS

2
Important Safety Instructions
•Do not install a damaged appliance. If you receive a dam-
aged appliance, contact your dealer or builder.
•Observe all governing ordinances during planning and instal-
lation. Contact the local building department for details.
•The electrical outlet for the downdraft vent should be
installed by a licensed electrician.
•Do not vent hazardous or explosive materials and vapors
through the unit.
•Use this downdraft vent only as outlined in the User Manual.
The vent is not designed for commercial use.
•The owner should install/repair/replace partts only as
specified in the product literature. A qualified technician
should perform all other service. Contact Dacor Customer
Assurance for examination, repair, or adjustment.
•Keep all packaging away from children.
•For proper operation, install the unit with a cabinet, in-line, or
remote blower. Use only a specified model.
WARNING
General Safety Precautions
To reduce risk of fire, electric shock, serious injury, or death when using the vent, follow basic safety precautions, including:
•Ensure the vent is unplugged for installation/service.
•The installer must show the customer the outlet so the owner
can unplug the vent as needed.
•Install the vent as instructed in this manual, the Dacor range/
cooktop installation instructions, and the blower installation
instructions.
•Read the User Manual completely before operating the vent.
•Do not tamper with the vent controls.
•Do not let the filters or vent openings become blocked. Do
not let foreign objects be sucked into vent holes.
•Clean the filters and all grease-laden surfaces often to pre-
vent grease fires and maintain performance. Clean the appli-
ance only as specified in the User Manual.
•Do not leave children/pets unattended near the operating
range/cooktop.
•Do not let children play with the downdraft vent.
WARNING
Electrical Specifications
The downdraft vent comes with a 28” (71.1 cm) power cord
with a 3-prong plug. Plug it directly into a 3-prong outlet
meeting the requirements below.
The correct voltage, frequency and amperage must be sup-
plied as specified below. The circuit must be protected by a
properly sized circuit breaker or time-delay fuse.
Electrical-Supply Requirements
A 3-prong outlet connected to a 120 Vac, 60 Hz, 15 Amp.
grounded, dedicated, single-phase circuit is required.
•The above specifications are for reference only. If they
conflict with spec’s on the product data label, use the
spec’s on the label.
•The customer must supply 3 conductor wiring/conduit
with minimum 8-Amp current-carrying capacity to sup-
ply power to the blower from the downdraft vent. (See
Installation Specifications for details.)
•The owner shall ensure the electrical outlet is installed
by a licensed electrician. The electrical installation must
comply with local ordinances and the latest revision of
the National Electric Code ANSI/NFPA 70 (latest revi-
sion), a copy of which may be obtained from:
National Fire Protection Association
1 Batterymarch Park
Quincy, Massachusetts 02269-9101
•The electrical outlet situated so the vent can be
unplugged for service without removing appliances from
the cabinet.
Product Specifications

3
Product Dimensions: MRV3015, MRV3615
Product Specifications
15"
(38.1 cm)
30"
(76.2 cm)
20”
(50.8 cm)
1 1/8”
(2.9 cm)
28" 3 prong
grounded
power cord
Motor
cover
Front of unit
6”
(15.2 cm)
2 9/16”
(6.5 cm)
9/16”
(1.4 cm)
3”
(7.6 cm)
1 15/16”
(4.9 cm)
B
A
2 1/8”
(5.4 cm)
2 3/16”
(5.6 cm)
3/16”
(5 mm)
5/16” (8 mm)
thick stiffener
across back
Top cap with
vent down
Vent shown
in raised
position
3 3/4”
(9.5 cm)
30 1/4”
(76.8 cm)
to
37 1/4”
(94.6 cm)
Adjustable
anchor legs
Product
data label
Tolerances: ±1/16” (±1.6 mm) unless otherwise stated
See pages 9 and 10
for exhaust locations
and dimensions.
** Maximum height of downdraft vent must not exceed maximum specified counter
height for cooking appliance. See installation instructions for cooking appliance.
* Total chassis depth with optional CABP3 blower installed is 10 3/8” (26.3 cm).
*
**
2 1/8" (5.4 cm)
3/8"
(1.0 cm)
2 1/8" (5.4 cm)
PRV top cap - side view
7/16"
(1.1 cm)
Model A - Top-Cap Width B - Chassis Width
30” (76.2 cm) 27 3/8” (69.5 cm)MRV3015
36” (91.4 cm) 33 3/8” (84.8 cm)MRV3615
MRV top cap (side view)
IMPORTANT
INSTALLER: To ensure the cooking unit performs properly, seal
all seams around the motor cover where it contacts the vent
chassis with aluminum tape. (See the graphic below for motor
cover location.)
Aluminum tape
Motor cover
Vent chassis

4
2 1/8" (5.4 cm)
3/8"
(1.0 cm)
Product Specifications
30 1/4"
(76.8 cm)
to
37 1/4"
(94.6 cm)
10"
(25.4 cm)
30"
(76.2 cm)
18 5/8”
(47.3 cm)
5/16” (8 mm)
thick stiffener
across back
3 3/4"
(9.5 cm)
1"
(2.5 cm)
28" 3-prong
grounded
power cord
Vent shown
in raised
position
Product
data label
Motor
cover
Front of unit
6"
(15.2 cm)
2 9/16"
(6.5 cm)
9/16"
(1.4 cm)
2 1/2"
(6.4 cm)
1 15/16"
(4.9 cm)
B
A
Adjustable
anchor legs
2 1/8"
(5.4 cm)
2 3/16"
(5.6 cm)
3/16"
(5 mm)
Top cap with
vent down
Tolerances: ±1/16” (±1.6 mm) unless otherwise stated
See Pg. 9 for exhaust
locations/dimensions.
*Max height of downdraft
must not exceed cooking
unit’s max. specified counter
height. (See cooking unit’s
installation instructions.)
*
Product Dimensions: HRV46, MRV48
Model No. A - Top-Cap Width B - Chassis Width
HRV46 46” (116.8 cm) 43 3/8” (110.2 cm)
MRV48 48” (121.9 cm) 43 3/8” (110.2 cm)
HRV, MRV top cap (side view)
IMPORTANT
INSTALLER: To ensure the cooking unit performs properly, seal
all seams around the motor cover where it contacts the vent
chassis with aluminum tape. (See the graphic below for motor
cover location.)
Aluminum tape
Motor cover
Vent chassis

Aluminum tape
Motor cover
Vent chassis
5
Product Specifications
Product Dimensions: MRV3015-ER, MRV36-ER, MRV48-ER
30 1/4"
(76.8 cm)
to
37 1/4"
(94.6 cm)
30"
(76.2 cm)
18 5/8”
(47.3 cm)
5/16” (8 mm)
thick stiffener
across back
3 3/4"
(9.5 cm)
1"
(2.5 cm)
28" 3 prong
grounded
power cord
Vent shown
in raised
position
Product
data label
Motor
cover
Front of unit
6"
(15.2 cm)
2 9/16"
(6.5 cm)
2 1/2"
(6.4 cm)
1 15/16"
(4.9 cm)
B
A
Adjustable
anchor legs
2 13/16"
(7.1 cm)
1/4"
(6 mm)
Top cap with
vent down
Tolerances: ±1/16”, (±1.6 mm) unless otherwise stated
*
See Pg. 9 for exhaust
locations/dimensions.
*Max height of downdraft
vent must not exceed
cooking appliance’s max.
specified counter height.
(See cooking appliance’s
installation instructions.)
IMPORTANT
INSTALLER: To ensure the cooking unit performs properly, seal
all seams around the motor cover where it contacts the vent
chassis with aluminum tape. (See the graphic below for motor
cover location.)
To close the gap between the Range and the Downdraft,
install this trim bracket behind the range with the included
hardware.
C
Model Number Top Cap Width (A) Chassis Width (B) Height (C) Trim Part No.*
MRV3015-ER 30” (76.2 cm) 26 3/8” (67.0 cm) 15” (38.1 cm) 115044
MRV36-ER 36” (91.4 cm) 33 3/8” (84.8 cm) 15” (38.1 cm) 115086
MRV48-ER 48” (121.9 cm) 43 3/8” (110.2 cm) 10” (25.4 cm) 115087

6
Installation Specifications
Planning the Installation
General System Layout
The vent system consists of the downdraft vent and a
Dacor-approved cabinet blower (MRV3015 and MRV3615),
remote blower, or in-line blower. (See Pg. 7).
WARNING
•Failure to install an approved blower and proper duct-
ing will cause a backdraft and poor venting.
•To reduce risk of personal injury from reaching over a
hot appliance, avoid cabinet storage directly above the
cooking surface.
•Follow minimum clearances and installation location in
the vent, appliance, and blower instructions. Failure to
do so may cause a fire or safety hazard.
•Plan the installation so minimum dimensions are met or
exceeded. All contact surfaces between the downdraft
vent and cabinets/walls must be solid and at right angles.
•The downdraft vent has adjustable anchor legs to accom-
modate various cabinet heights.
•Install the downdraft vent and range/cooktop so they can
be removed for service.
•Allow access from the cabinet front to the chassis, and
utilities of the downdraft vent and cooktop for inspection
and service. (Drawers/shelves must be removable.)
•There are 7/8” access holes in the bottom and side of the
downdraft vent for connecting blower wiring and strain
relief. Wire the blower to turn on when the downdraft vent
is turned on. When installing a remote or in-line blower,
run the blower wiring/conduit parallel to the duct work,
connecting it to the downdraft vent on one end and the
blower on the other.
•Allow room for the exhaust duct coming out of the unit.
(See Planning the Duct Work, Pg. 8, for details.)
•Consider the maximum-allowable duct run when decid-
ing the layout. (See Planning the Duct Work, Pg. 8, for
details.)
•See the range/cooktop installation instructions for mini-
mum cutout dimensions specific to the downdraft vent
being installed.
Vertical
non-combustible
surface rear wall
Notches for self-rimming
style installations, see range
installation instructions
Notches required for some downdraft vent
installations, see range
installation instructions
Backsplash
Countertop
overhang
See the range installation
instructions for exact countertop
and cabinet dimensions
Vertical
non-combustible
surface rear wall
Notches required for some downdraft vent
installations, see cooktop
installation instructions
Backsplash
Countertop
overhang
See the cooktop installation
instructions for exact countertop
and cabinet dimensions
Flush with back side
of cabinet front
Range Cabinet/Countertop Cutout - Top View
Cooktop Cabinet/Countertop Cutout - Top View

7
Installation Specifications
Example of Layout with Range
and Bottom Exhaust
Example of Layout with Cabinet
Blower Configuration, Exhaust Through Wall
ILHSF series
in-line blower
3 ¼ x 10 to
round transition
Duct work Duct work
Outside wall
Range
Wall cap on
outside wall
Downdraft vent
Downdraft vent
configured for
bottom exhaust
Floor
Wiring/conduit
from downdraft to
in-line blower
Cabinet back
Front of unit
Connection to
cabinet blower
Blower wiring
access hole
Blower wiring
access hole
Connection to
remote/in-line
blower
Electrical Layout
only
Cooktop
Floor
12” min.
(30.5 cm)
3 1/4 x 10
90° elbow
Wall
Downdraft vent
Wall cap
Backsplash
Cabinet blower
option: MRV3015
and MRV3615
Cabinet blower
option: MRV3015
and MRV3615

8
Installation Specifications
Installations with ILHSF-/REMP-series blowers:
•The downdraft vent can be configured to exhaust through
the back/bottom/sides by removing the proper exhaust
knock-out. (See Pg. 9.)
•When installing an ILHSF blower, minimize noise by
installing it as close as possible to the duct-system
exhaust. (Minimum recommended distance from the
downdraft vent is 5 feet.)
•When connecting the duct work to the back of the unit,
the customer must supply a 3¼ x 10 rectangular transi-
tion to make the connection.
•For side/bottom exhaust connections, use the supplied
transition to connect the duct work to the unit. It transi-
tions between the unit’s 15/8x 16 exhaust outlet and a
3¼ x 10 rectangular duct connection. On bottom exhaust
installations, cut a hole in the floor so the transition and/
or duct work can pass through the floor. (See Pg. 13).
•On side exhaust installations, allow 5 in. on the side for
the 2 x 16 to 3 ¼ x 10 transition, plus space for the duct
attached to it (X).
Planning the Duct Work
WARNING
•To reduce risk of fire and to properly exhaust air, duct
air outdoors, not into any interior spaces or garages.
•TO REDUCE FIRE RISK, USE ONLY METAL DUCTING.
•DO NOT install multiple blowers to lengthen the duct
run. Even small differences between blower airflow
rates can greatly reduce the downdraft vent’s air draw.
Building codes may require makeup air systems with ven-
tilation systems that move air greater than the specified
movement rate (CFM). Consult a qualified HVAC specialist
when designing the system for the requirements in your
area and to assure optimal performance.
You must install a Dacor blower for the downdraft vent to
operate properly. See the blower installation instructions for
directions. For model CABP3, see the instructions later in
this manual.
APPROVED DACOR BLOWERS FOR USE WITH
MODEL MRV SERIES DOWNDRAFT VENTS
Dacor Blower Rating Compatible Vent
CABP31600 CFM2MRV30153, MRV36153
ILHSF8 600 CFM4All
ILHSF10 1100 CFM4All
REMP3 600 CFM4All
REMP16 1000 CFM4All
1Due to a lack of clearance, do not use this blower if installing
a range or wall oven in front of the downdraft vent; 2Nominal
rating at zero inches static pressure, see the CABP3 blower rat-
ings on page 17 for actual rating; 3Revision B and later units
only; 4Nominal rating at zero inches static pressure. See blower
installation instructions for actual ratings.
For installations with CABP3 blowers:
•Installation requires Dacor adapter kit # AERVCAB.
•The blower assembly is mounted to the front of the down-
draft vent with the exhaust pointing in the desired direc-
tion. (See Pg. 10.)
•The CABP3 blower output connects directly to 3¼ x 10
rectangular ducting.
1 5/8x 16 duct
transistion
5”
X
3 ¼ x 10 to duct work
2 x 16, connects to
side or bottom exhaust
on downdraft
1"
(2.5 cm)
5"
(12.7 cm)
1 5/8x 16 Duct Transition

9
Duct installation requirements for all blowers:
•All duct work (including screws and duct tape) shall be
purchased by the customer.
•In planning new duct work, always look for the shortest,
most direct route to the outside. (See Pg. 7.)
•You can increase duct size over the duct run if desired.
To prevent backdraft, never decrease duct size.
•Do not rely on duct tape alone to seal joints. Fasten all
connections with sheet-metal screws, then tape all joints
with certified silver tape or duct tape.
•Use sheet-metal screws as needed to support the ducting.
3”


Vertical center line of rear exhaust knock out lines up with vertical
center line of chassis


On 46” and 48” wide models, the vertical center line of bottom knock-
out lines up with vertical center line of chassis


On 30” and 36” wide models, the vertical center line of bottom knock-
out is offset 3”

 Side Exhaust Knock Outs (1
5
/ 8 x 16)


 Bottom Exhaust Knock Out (1
5
/ 8 x 16)

Motor
cover
Front of unit
26" (66.0 cm)
6 1/4"
(15.9 cm)
1 1/8"
(2.9 cm)
C
L
C
L
C
L
Exhaust Knock-out Locations for Use with REMP- and ILHSF-Series Blowers
•To avoid backdraft, the duct outlet may required a damper.
•Ensure duct work does not interfere with joists or studs.
•With concrete slab construction, “box in” the duct work
and blower wiring to prevent crushing or other damage
when concrete is poured.
•Cross-drafts or air currents from adjacent open windows
or doors, heating-/air-conditioning outlets, ceiling fans,
and recessed ceiling lights reduce vent efficiency.
•System exhaust location (Pg. 8) must account for
snow buildup where applicable.
Installation Specifications









10
Installation Specifications
Model A B C
MRV3015 12 1/8” (30.7 cm) 5 5/8” (14.4 cm) 1 3/4” (4.4 cm)
MRV3615 9 3/4” (24.8 cm) 8” (20.3 cm) 4 1/4” (10.8 cm)
29 1/4”
(74.3 cm)
Duct connection
center line
C
Downdraft vent
center line
Countertop
3 1/4x 10
duct connection
Duct connection
center line
B
Downdraft vent
center line Countertop
3 1/4x 10
duct
connection
15 3/8”
(39.1 cm)
Duct connection
center line
A
Downdraft vent
center line
Countertop
3 1/4x 10
duct
connection
26 1/4”
(66.7 cm)
Exhaust Locations and Side Dimensions
for CABP3 Cabinet blower
Front Exhaust Dimensions
CABP3 Blower - Bottom Exhaust
Front Exhaust Dimensions
CABP3 Blower - Right Exhaust
Front Exhaust Dimensions
CABP3 Blower - Left Exhaust
ADAPTER
Bottom exhaust
configuration shown
DUCT
C
L
CABP3
Cooktop
MRV
Exhaust Locations/Dimensions for CABP3 Cabinet Blower Installations
(MRV3015, MRV3615)
8 7/8" (22.5 cm)
from back of
MRV cutout to
centerline of
CAPB3 exhaust in
any orientation

11
Installation Specifications
Calculating Maximum Duct Run Length
•For best performance, consult a qualified HVAC specialist
when designing the duct system.
•Do not use duct work that is smaller than the required
sizes in the tables below.
•For best performance, keep the duct run as short as pos-
sible, and never exceed the maximums in the table in the
Duct Work Design Tips section.
•The max. duct length for the downdraft vent depends on
the blower used, and number of elbows and transitions.
The Equivalent Number of Feet for each elbow and
transition must be subtracted from the maximum straight
length to compensate for wind resistance. To decide the
maximum allowable length of the ducting, subtract all
equivalent lengths of the elbows and transitions listed
below from the Blower Maximum Duct Straight Length.
Example: For a downdraft vent system using a 3¼ x 10
rectangular duct, two (2) 3¼ x 10 90° elbows, a 3¼ x
10” rectangular to 10” round transition, and a REMP16
remote blower:
•From the Blower Maximum Duct Straight Length table,
the max length without transitions and elbows is 60 ft.
•The equivalent length of each 90°elbow is 15 ft.
•The equivalent length of 45°elbow is 2 ft.
•The equivalent length of the transition is 4 ft.
•The total equivalent length of the above parts is: 15 ft +
15 ft + 4 ft + 2 ft = 36 ft.
•The max amount of straight duct that can be used with a
REMP16 and the above parts is: 60 ft – 34 ft = 24 ft.
Equivalent Number of Feet (Nominal) -
Duct Elbows and Transitions
45° elbow/8” 3 ft 3¼ x 10/45° elbow 7 ft
45° elbow/10” 2 ft 3¼ x 10/90° elbow 15 ft
90° elbow/8” 7 ft 3¼ x 10/90° flat elbow 20 ft
90° elbow/10” 5 ft 3¼ x 10 to
8” round transition 4 ft
90° 3 ¼ x 10 to
8” round transition 25 ft 3¼ x 10 to 10” round transition 4 ft
Roof cap *Wall cap** *
*Equivalent lengths of roof and wall caps vary with model and
configuration. For equivalent length, contact the manufacturer or
a qualified HVAC specialist; **Not applicable to REMP blowers.
Duct Work Design Tips
•Reduce transitions and turns to the fewest sharp angles.
Two staggered 45° angles are better than one 90°. Keep
turns as far from the hood exhaust as possible, with the
most possible space between each bend.
•For best performance, use round ducting when possible,
especially when elbows are required.
•If multiple elbows are used, try to keep a minimum of 24”
of straight duct between them. Avoid “S” or “back to back”
configurations of adjacent elbows.
•Do not use flexible metal ducting.
Blower
Blower Maximum Duct Straight Length
8” Duct 10” Duct 3¼ x 10 Duct
CABP3 40 ft (12.2 m) 30 ft (9.2 m) 30 ft (9.2 m)
ILHSF8 50 ft (15.2 m) 40 ft (12.2 m) 40 ft (12.2 m)
ILHSF10 60 ft (18.3 m) 70 ft (21.3 m) 60 ft (18.3 m)
REMP3 50 ft (15.2 m) 40 ft (12.2 m) 40 ft (12.2 m)
REMP16 60 ft (18.3 m) 70 ft (21.3 m) 60 ft (18.3 m)

12
Installation Preparation
Verifying Package Contents
1. Unpack the unit, and verify that all items on the parts list
are present. Notify your dealer immediately if anything is
missing. Do not install a damaged or incomplete appli-
ance. The customer must report cosmetic issues within
30 days of installation.
Parts List
•Product literature
•Anchoring legs (left - PN 36861, right - PN 36862)
•2 wood screws, #14 x 2 1/2 (PN 83047)
•3 wire nuts
• 1 5/8x 16 to 3 ¼ x 10 duct transition (PN 13768)
•2 sheet metal screws, #10 x 1/2 (PN 83022)
•2 keps nuts, 1/4-20 (PN 83049)
•2 flat washers, 1/4-20 (PN 83203)
•Insulation foam (tape)
Installation with CABP3 blower requires Dacor adapter kit
# AERVCAB. Kit includes adapter, wiring diagram label
(PN 106770), 3 wing nuts (PN 83035), 3 flat washers (PN
83008) and 6 lock washers (PN83340).
WARNING
•If the electrical outlet does not meet the Electrical
Specifications on Pg. 2, postpone the installation
until a licensed electrician install the proper outlet.
•Install the vent vertically only.
•Do not enlarge or modify the exhaust knock-outs. Cut
an exhaust hole on the chassis only as shown to pre-
vent an increase in noise and compromised function.
NOTE: The downdraft vent installs in the back of the cut-
out, separate from the range or cooktop. Install the down-
draft vent before installing the range or cooktop.
2. Start by loosely attaching the anchoring legs to the
studs on the left and right sides of the downdraft vent
using the provided Keps nuts and washers.
Installation Preparation: Downdraft Vent
With ILHSF-/REMP-Series Blower
NOTE: For units using the CABP3 cabinet blower, skip to
Installation Preparation for Downdraft Vent with CABP3
Cabinet Blower, on facing page.
1. Remove the appropriate side or bottom exhaust
knockout (depending on the desired exhaust configu-
ration) from the downdraft vent chassis by cutting the
metal cross overs and removing the insert.
2. Cut and remove the foil material inside the knock-out
hole or the vent will not work.
•If the unit will vent through the bottom or side, install
the suppled 15/8x 16 to 3¼ x 10 transition to the
exhaust location. Before installing, peel the protective
backing off the foam tape, and apply it to the transition
flanges. Attach the transition with the provided sheet
metal screws (see below).
•If the unit will vent through the back, attach a 3 ¼
x 10 duct to the vent hole created by removing the
knock-out on the back of the unit.
3. See Installing the Downdraft Vent in the Cutout, Pg.
13.
Installation Instructions
Back of unit
Side
knock-out Side
knock-out
Bottom knock-out
Put nuts/
washers on
studs
Front of unit
Anchor leg
Transition side
installation
Transition bottom
installation
Attach sealing
foam

13
Installing the Downdraft Vent in
the Cutout
1. Cut a hole in the cabinet so the ducting can pass to
the floor/wall for the planned ducting layout. Use the
dimensions on pages 9, 10 to decide the hole center
line locations. If using the 2” x 16” to 3 1/4” x 10” transi-
tion (REMP and ILHSF blower installations), the hole may
need to be enlarged slightly.
2. Gently slide the vent into the rear of the countertop cut-
out with the electrical access panel toward the front.
3. Adjust the anchoring leg height so that the top of the
downdraft vent rests on the counter, then tighten the hex
nuts. Secure the anchoring legs to the cabinet floor with
the provided wood screws.
Adapter Installation: CABP3 Blower
(Optional: MRV3015, MRV3615)
1. Remove the front cover so the AERVCAB cabinet
blower adapter can be installed. Remove and retain the
3 wing nuts and 3 flat washers on the front of the unit.
Discard the 3 lock washers (which will be replaced). Tilt
the cover out and pull up to remove it.
2. Peel the backing off of some of the foam tape included
with the adapter. Attach it to the right and left flanges.
3. Hold the adapter in front of the opening, located on the
front of the unit with the adapter’s studs on top,and all
flanges closest to the downdraft vent chassis.
4. Slide the adapter’s bottom into the bottom retainer bracket
on the downdraft vent at an angle. Attach the adapter
using the 3 wing nuts and flat washers removed in Step 1
and 3 of the lock washers from the adapter kit.
Installation Instructions
Cover
Front of unit
Rear corner of cutout
(back of downdraft vent)
plumbed down
Exhaust: size and location
varies with installation type
Front of unit
Floor
Top of vent resting
on countertop
Electrical access
panel
Anchor leg
Adapter
Front of unit
Studs
Bottom retainer bracket
Insert bottom
flange into
bottom retainer
bracket
Attach foam
to right/left
flanges
For cabinet cutout,
please refer to the
range, rangetop or
cooktop Installation
Instructions for more
details.

14
Installation Instructions
Cabinet Blower Installation
(Optional: MRV3015, MRV3615)
1. Find the wiring diagram label included with the adapter
kit. Remove the protective backing, and place it over the
existing label on the CABP3 blower as shown.
2. Find the foam tape supplied with the downdraft vent.
Place the blower on the floor as it will be mounted on
the front of the downdraft vent. Remove the backing
from the foam tape, and attach it to the right and left
flanges of the blower base plate.
3. With the exhaust oriented as desired, slide the bottom
flange of the CABP3 blower base plate behind the tab
on the bottom of the adapter mounted to the front of the
downdraft vent.
4. Cover the adapter opening by pushing the blower
against it. Ensure the foam tape creates a good seal on
the right and left side of the opening. Center the blower
base plate horizontally over the adapter’s front opening.
5. Install the adapter top retainer bracket over the blower
base plate flange. Secure it with the 3 wing nuts, lock
washers, and flat washers included with the adapter.
CABP3
Top retainer
bracket
Insert bottom flange into
tab at bottom of adapter
Attach foam
to right/left
flanges
Adapter
New label
Existing
label
ILHSF or REMP Series Blower Installation
If using a ILHSF or REMP series blower, install it according
to the blower installation instructions.
Duct Work Installation
WARNING
For best performance and to keep smoke, odors, and
combustion byproducts from entering the home, tape all
duct joints securely.
Install the duct work per the Installation Specifications
section. Use sheet-metal screws and duct tape to connect
and seal all pieces. Support the duct weight as needed to
ensure sealed joints.
Electrical Installation
WARNING: ELECTRIC SHOCK HAZARD
•Plug in the downdraft vent after installation is complete.
•Follow the wiring diagram carefully. Do not change the
factory-wired terminal connections inside the electrical-
access panel for the downdraft vent or blower.
•Route wiring away from hot surfaces.
1. For ILHSF and REMP blower installations, run the wir-
ing/conduit line used to supply power from the downdraft
vent to the blower parallel to the duct work.
2. Remove the cover from the downdraft vent electrical-
access panel.
3. Connect the wiring/conduit to the blower as shown on
pgs. 15 and 17 per local ordinances. Ensure all terminal
connections (including factory-wired connections) are
tight. Replace the electrical-access panel.
Range/Cooktop Installation
Install the range or cooktop as instructed.

15
Installation Instructions
Floor
Example of Electrical Installation
with ILHSF or REMP Series Blower
(Side View)
REMP16
remote blower
Connect wires/conduit
according to remote
blower installation
instructions
Downdraft vent
Range
Wiring/conduit from
downdraft vent to remote
(or in-line) blower
See Downdraft Vent
Electrical Access
Panel, above
Electrical Installation - CABP3 Cabinet Blower Downdraft Vent Electrical Access Panel
Front of unit
Wire Colors : Black = Line (L), White = Neutral (N),
Green = Ground (Gnd)
Electrical connection
from downdraft vent,
match Wire Colors
CABP3 cabinet
blower
Downdraft vent
blower wiring
access hole
Ground Power
Input
Blower Output
Blower power wiring/conduit.
Connect other end of wires
to blower terminal block.
Wires to power plug.
Pre-wired at factory.
Do not modify.
Attach ground wire
as shown
Match wire colors to
terminals as shown.
BLACK
WHITE
GREEN
Electrical access
panel

16
Installation Instructions
Verifying Proper Operation
WARNING
•Read the downdraft vent user manual completely
before operation.
•Install all front filters before operating the downdraft
vent. (See the user manual about filter installation.)
CAUTION
Before plug-in, route the downdraft-vent power cord away
from range or cooktop surfaces.
1. Ensure the power switch atop the downdraft vent is in
the up position.
2. Plug in the downdraft vent.
3. Press the power switch to raise the vent.
4. Once raised, the vent should begin to draw air. Turn the
variable-speed control switch in both directions to verify
that the system operates correctly.
5. Press the top cap up/down switch to lower the vent.
6. Ensure the vent top cap does not catch on the back
edge of the cooktop/range. If it does catch, reposition
the cooktop/range to avoid permanent vent damage.
If the downdraft vent is not functional after installation:
•Ensure power is supplied to the downdraft vent.
•Ensure the downdraft vent supplies power to the blower.
•If the vent will not raise properly or makes a scraping
sound, check for under-counter obstructions.
If the downdraft vent fails to function after performing the
above checks, do not try to repair it yourself. Contact Dacor
Customer Assurance: 833-353-5483. Have available all
vent and blower model/serial numbers from the product
data labels when you call.
Dacor is not financially responsible for correcting prob-
lems due to faulty installation.
Installation Checklist
□Are the anchor legs tightened in place? Is the unit level?
□Is the duct work completely installed and all joints
attached with sheet-metal screws and wrapped with
duct tape?
□Are both ends of the blower power cable connected (to
the downdraft vent and the blower itself)?
□Are the vent filters installed per user manual instructions?
□Is the power cord routed away from the hot range/
cooktop surfaces.
□Is the unit connected to an electrical outlet that meets
the electrical specifications in these instructions?
□Was proper operation verified?
□Was the warranty activated online or the warranty card
filled out and mailed?

17
Technical Data
STUD
CHASSIS
GROUND
GROUNDPOWER
INPUT
BLOWER
OUTPUT
GNDL2 N1L1N2 GND
COM
COM
NO NO
UP
LIMIT SWITCH
DOWN
LIMIT SWITCH
COM NCNO
NC
NC
REMOTE POT
SNORKEL SWITCH
COM
N
NO
RELAY
SPEED CONTROL
RED RED
BLUE
BLUE
RED
BLK
ORNG
ORNG
BLK
YEL
YEL
WHT
L
BLK
WHT WHT
Wiring Diagram: All Models
CABP3 Cabinet Blower Ratings
CABP3 Cabinet blower Airflow*
Nominal 600 CFM
Actual 585.6 CFM
* At zero inches static pressure. Performance varies based
on duct system configuration.
Electrical Rating: 4 Amps. @ 120 Vac, 60 Hz.
For ILHSF or REMP series blower ratings, see the blower
installation instructions.
Airflow CFM (Cubic feet/minute)
Static pressure - inches of water
0
1.0
2.0
3.0
4.0
5.0
100 200 300 400 500 600
CABP3 Blower Performance

Dacor ● 14425 Clark Avenue, City of Industry, CA 91745 ● Phone: [phone] ● Fax: [phone] ● www.dacor.com
